Polygroup H209506 User manual

ASSEMBLY INSTRUCTIONS MADE IN CHINA
MODEL #: H209506
• Before you start to assemble your tree, choose an appropriate location near a wall outlet.
• Assemble the tree stand and place on a level surface. (See Fig. B)
Congratulations on purchasing your new tree from Polygroup®!
Carefully follow the instructions below on how to quickly and easily set up your new tree.
TREE ASSEMBLY INSTRUCTIONS
Fig. B - Tree Stand Assembly
Click
Pull apart the legs of the stand so that they
are snapped into an x-shape, place the tree
stand on a level surface.
To close the stand, press the metal button
and fold the legs together.
B
C
12
Section 1
Section 3
Section 2
Each tree section is numbered
with a tag. Please identify all
sections before assembling.
Insert Section 1 into the tree stand.
SET UP INSTRUCTIONS WITH QUICK FOLDTM
3
A. Locate “Pull Here” tab and corresponding
Cinch Handle
B. Hold Cinch Clip firmly with one hand and
press down on clip
C. With Cinch Clip depressed, pull clip away from
tree until all branches are released.
A
Section 1
Cinch
Handle
Tree stand Tree stand
Cinch Clip
*Electrical Rating For The Tree
(For Indoor Use Only)
1.87A 120VAC 60Hz
Fig. A - Tree and Light Assembly
1
2
3
Do Not Tamper
Internal Parts
Open the
protective
cover
Do Not Tamper
Internal Parts
Open the
protective
cover
Insert
Green Label
Plug Into Wall
Outlet
Foot Pedal
on/off Switch
Quick Set®
Connections
Quick Set®
Connections
Quick FoldTM Cinch
Quick FoldTM Cinch
Quick FoldTM Cinch

ASSEMBLY INSTRUCTIONS MADE IN CHINA
Top view Side view
Fig. C
• Insert green label plug into the wall outlet. (see Fig. A ), your entire tree should now be lit. If some bulbs
do not light or flickers, search for any loose plugs and/or broken, loose or missing bulbs. Connecting the
plugs or replace the bad bulbs promptly in order to maintain the performance and life expectancy of
your pre-lit tree.
• Begin to shape the branches and tips working from the bottom to the top. Start with tips farthest from
the pole and fan out one to the right, one to the left and one at the center of the main stem. (See Fig. C)
• After shaping the entire tree following the previous step, slightly upsweep all branch tips for a uniform
look. Shift branches to fill any gaps.Your Christmas tree is now complete and ready to be decorated.
4 5 6
Remove the protective cap of Section 1
and add Section 2.
Release all branches using the same
procedures described in step 3.
Remove the protective cap of Section
2 and add Section 3.
Section 1 Section 1
Section 3
Section 3
Section 2
Section 1
Section 2
Section 1
Section 1
Section 1
Section 2
Section 3
Section 2
Section 2
4 5 6
1 32
STORAGE INSTRUCTIONS WITH QUICK FOLDTM
• Unplug extension cord from the wall outlet first and then remove all ornaments and decorations.
• When not in use, please store your tree in a cool, dry place away from sunlight. Exposing your tree to
excessive heat or humidity may damage your tree.
Detach tree top and store it
in box.
Fold the lower layer of Section 2
like step 2.
Detach Section 2 and put it into
the box.
Cover the protective cap of tree
bottom Section 1, then follow step 2
to fold tree.
Detach section1 from the tree stand
and place into box. Then fold up tree
stand by unlock the disc and then
store in box.
A. Cover the protective cap of the Section 2.
B. Hold Cinch Handle with one hand.
C. Hold Cinch Clip firmly with other hand and press down on clip.
D. Pull handle toward you while pushing away cinch clip
until the upper branches of tree middles Section 2 are
folded completely.
A
Tree stand Tree stand
Tree stand
Tree stand
Tree stand
Tree stand
B
C D

ASSEMBLY INSTRUCTIONS MADE IN CHINA
TROUBLE SHOOTING TIPS
SPARE PARTS
For Pre-lit Trees, If The Tree Does Not Illuminate
1. Please check to make sure that all plugs are properly connected and power cord is plugged into the wall
outlet. (If the tree comes with a foot pedal, try stepping on the on/off button).
2.Turning the poles gently to make sure pole to pole are connected into place.
3. Check for loose connection between light string plugs and extension cords.
4. Please check for loose, broken or missing light bulbs and replace as needed.
1. Extra hinge pins are included for repairing the hinges. Place the branch into the slot of the bracket.
2. Insert a new hinge pin through the hole and secure using the retainer washer.(See Fig. D)
Each tree includes hinge pins/washers, and for pre-lit
trees spare bulbs and fuses are also included. If extra
parts are needed, please contact our customer service
center.
Loose Hinge Pin
Fig.D
CUSTOMER SERVICE FOR CHRISTMAS TREES
For any questions, assistance, or missing parts, Do Not Return To Place Of Purchase. Please contact
us at 1-888-919-0070 or visit our website at www.polygroup.com. One of our customer service
representatives will be happy to assist you.
TREE ID# IS LOCATED ON END PANEL OF BOX. TREE ID# IS REQUIRED WHEN REQUESTING REPLACEMENT PARTS.
Customer Name:
Address:(No P.O. Boxes)
City & State:
Zip Code:
Day Phone:
Date Purchased:
Tree ID#:
Tree UPC#:
Store Purchased:
Specify Problem:
