PolyJohn MS02-1000 User manual

MS02-1000 Lifting Sling
July 2008
Page 1 of 4
®
P OLY J OHN
®
MS02-1000
Lifting Sling
Assembly Instructions
POLYJOHN
USA
PolyJohn Enterprises Corp
2500 Gaspar Ave.
Whiting, IN 46394
Phone: [phone]
Fax: [phone]
www.polyjohn.com
[email protected]
POLYJOHN
WORLDWIDE
PolyJohn (UK) Ltd.
Equinox 1 Audby Lane
Wetherby, England LS22 7RD
Phone: [phone]
Fax: [phone]
[email protected]
POLYJOHN
CANADA
PolyJohn Canada
P.O. Box 2300
199 Forest Plain Rd.
Orillia, Ontario LV3 6S2
Phone: [phone]
Fax: [phone]
[email protected]
Clearance Height
when attached
to Unit 104 in 264 cm
Legs Can Extend
to length of the
Unit 48 in 122 cm
Width of Lifting
Arm 47.75 in 121 cm
Lifting Capacity 1000 lbs 453.59 kg
Specications
The MS02-1000 Lifting Sling, made
of a no rust galvanized steel. De-
signed to move most portable rest-
rooms around a construction site.
Shipped with the MS01-0200 - Small
Parts Bag which includes the neces-
sary parts for easy assembly.
General Overview
SEE PAGE 4 FOR PRODUCT WARNINGS
MS02-1000 Lifting Sling
July 2008
Page 2 of 4
Attaching the Lifting Sling using the Steel Clips
Step 1. Attach one end of the MS01-0002G - Lifting Arm to the looped-end of
one of the MS01-0001G - Sling Legs. Repeat for the other end of arm and leg.
Step 2. Push the Portable Unit between the sling legs.
Step 3. Lift or tilt one end of the restroom and slide one of the metal clips
(MS02-0001G) over the end of the runner of the oor skid. Line up the hole of
the clip with the groove in the bottom of the runner. (Make sure the tall end of
the clip is on the outside of the skid, with the holes of the clip on the bottom along
the oor.)
Step 4. Insert one foot of a sling leg into the outer hole of the metal clip and
through the inner hole of the clip. Place a PC-000129 washer over the foot of
the sling leg. Follow by inserting a PC-000132 hairpin cotter into the hole of
the foot and push until the foot is in the middle opening of the hairpin cotter
to lock in place.
Step 5. Repeat for the three other ends of the skid.
Follow steps in reverse order to detach lifting sling.

MS02-1000 Lifting Sling
July 2008
Page 3 of 4
MS01-0002G -Lifting Arm
MS01-0001G-Sling Legs
PC-000132 Hairpin Cotter
PC-000129 Washer
MS02-0001GMetal Clip
Step 1. Attach one end of the MS01-0002G - Lifting Arm to the looped-end of
one of the MS01-0001G - Sling Legs. Repeat for the other end of arm and leg.
Step 2. Push the Portable Unit between the sling legs.
Step 3. For all skids whether plastic or wood, drill four 11/16”holes through the
sides of the runners (two holes per runner). The ideal drill locations should be 5”
in from each end of the runner and 1-1/2” from the bottom of the skid. NOTE:
Before drilling check the inside of the runner for any obstructions and adjust
drill locations accordingly.
Step 4. Insert one foot of a sling leg through the hole in the runner. Place a PC-
000129 washer over the foot of the sling leg. Follow by inserting a PC-000132
hairpin cotter into the hole of the foot and push until the foot is in the middle
opening of the hairpin cotter to lock in place.
Step 5. Repeat for the three other ends of the skid.
Follow steps in reverse order to detach lifting sling.
Attaching the Lifting Sling without the Steel Clips
MS02-1000 Lifting Sling
July 2008
Page 4 of 4
MISSION STATEMENT
“PolyJohn is a family owned, state of the art, plastics manufacturing company
dedicated to providing its employees with a work environment committed to
excellence, and its customers with innovative products, services and technology
that meet or exceed their requirements.”
THANK YOU FOR PURCHASING POLYJOHN PRODUCTS!
Look for us on the Web @ www.PolyJohn.com
1. This unit is made to lift portable restrooms only. It has a lifting capacity of
1000 lbs. This unit was designed to lift PolyJohn brand portable restrooms. If
using this product with a dierent portable restroom manufacturer, the unit
must be weighed to insure that the 1000 lb. lifting capacity is not exceeded.
The unit must not be used to lift anything or anyone inside of the portable
restroom.
2. Only one (1) sling set/unit to be lifted by one (1) lifting device at a time.
3. The base of the portable restroom and the lifting sling must be visually in-
spected prior to any lift.
4. All lifting must be done from the center apex of the sling cross bar.
5. Any bent or damaged parts must be reported to supervisor immediately
and taken out of service.
FAILURE TO FOLLOW THESE INSTRUCTIONS
COULD RESULT IN INJURY OR DEATH.
We highly recommend membership in the Portable Sanitation Association International
(PSAI); the worldwide authority on portable sanitation services. The PSAI, “Portable
Sanitation Industry Certication Program” manual contains a wealth of information on
standards and service procedures. For more information contact the PSAI:
PORTABLE SANITATION ASSOCIATION INTERNATIONAL PSAI
7800 METRO PARKWAY, SUITE 104
BLOOMINGTON, MINNESOTA 55425 USA
8008223020 / 6128548300 FAX 6128547560
www.psai.org
Safe Handling Instructions
