Pondline EMP Dirty Water Series User manual

Overload protection
The pump has a built-in thermal overload trip which prevents the pump from
overheating. In the case of the pump overheating, it must be allowed to cool down
before restarting.
If the pump will not start again automatically when cooled down, please follow
the maintenance and cleaning instructions
Maintenance and cleaning (see fig 1& 2)
Follow these safety instructions, making sure that the pump is switched off
and unplugged
1. Undo the four latches of the outer casing which reveals the pump body (see
figure 2)
2. Screw out the universal hose connector (3)
3. Unclip the pump housing (6) from the motor housing (4)
4. Remove the impellor (8) from the motor housing (4)
5. Clean all parts using water and a soft sponge.
Assembling the pump
1. Place the impellor (8) in the motor housing (4) with caution.
2. Make sure the impellor is assembled correctly and will turn freely.
3. Check the position of the sealing ring (7) on the pump housing (6)
4. Put the pump housing (6) in the motor housing (4) and tighten the four screws (9)
5. Put the outer casing (2) back together containing the pump body (figure 2)
Please read these Instructions carefully before using your
Pondline Pond Pump.
CAUTION: Installation should be carried out in accordance with your
local electrical installation code. Please contact a suitable electrician.
For all technical data, please refer to the content, stated on the rating
label of the pump.
68
7
49
Figure 1
Figure 2
EMP Dirty Water series

Pondline Pond Pumps are suitable for filtration systems and
waterfalls in garden ponds and fountains both indoor &
outdoor
Pondline pond pumps are to be used in a submersible application only.
Model
Voltage
Hz
Power
Hmax
Volume
PLDW3500
220-240V
50Hz
25 W
3.0m
3500lph
PLDW4500
220-240V
50Hz
40 W
3.5m
4500lph
PLDW6000
220-240V
50Hz
60 W
4.0m
6000lph
PLDW8000
220-240V
50Hz
80 W
4.5m
8000lph
PLDW10000
220-240V
50Hz
90 W
5.0m
10,000lph
PLDW13000
220-240V
50Hz
110 W
5.5m
13,000lph
PLDW15000
220-240V
50Hz
135 W
6.0m
15,000lph
PLDW18000
220-240V
50Hz
170 W
6.5m
18,000lph
PLDW20000
220-240V
50Hz
200W
7.0m
20,000lph
Safety instructions
Read all of the instructions supplied with this pump
Make sure that your outlet voltage corresponds to that stated on the rating label
of the pump
Make sure the pump is installed correctly before operating
The electrical connection should be located in a water-proof area and should be
at least 2 meters away from the edge of the pond
All electrical connections must be kept dry! Ensure that the electrical cord loops
below the electrical outlet, to form a “Drip Loop”. This will prevent water from
running down the cord into the electrical socket
Always unplug the pump when performing maintenance on the pump or pond
Do not operate if cord or plug are damaged. The supply cord of the appliance
cannot be replaced. If the cord is damaged the appliance should be
discarded.
For safety reasons, any repair work should be done only by the manufacturer or
authorized service provider
Never hang or move the pump by means of pulling the power cord!
Close supervision is necessary when the pump is used by or near children
If you want to disconnect the pump, you can pull out the plug from the power
supply in an accessible position
Never use accessories which are not recommended by the pump manufacturer.
This may result in fire, electric shock and/or personal injury
The pump is to be supplied through a residual current device (RCD) with a rated
residual operating current not exceeding 30mA
IMPORTANT: Do not let the pump run dry –this could cause damage
to the motor.
Submerse the pump completely in the water, a water level of 20cm is required
for submersible use in order to prevent the pump from taking in air
To prevent the pump becoming prematurely clogged, place the pump on a
surface just above that of the sludge on the floor of your pond
The water temperature should not exceed 350C
Do not let the pump freeze over winter
WARRANTY
The warranty is valid for 24 months from the date of purchase. When
following the directions correctly, the Pondline Pond Pump will perform reliably and
efficiently. Wearable parts are excluded from the warranty. Liability is limited to the
purchase value of the unit only. Any damages as a result of improper treatment
are excluded from the warranty. The warranty is limited to the unit only. In case of
malfunction please contact your retailer.
