PondXpert Easyfilter 4500 Operating manual

PondXpert Easyfilter
4500
Set up and maintenance guide

Easyfilter 4500
This is how your Easyfilter main unit will look when you take it out of the box.

Opening the filter
In order to access the filter you will need to remove the metal clamp that holds the
base and lid together.
The lid can then be removed from the base; this will simply pull apart. At first, with
a new unit this may be difficult to remove; do not be alarmed as this is normal.
PLACE THE O-RING
IN THIS GROOVE

Setting Up
The hosetails supplied need to be
fitted securely to the screw fittings
to the front of the filter unit.
(1) The outlet valve allows the
returning clean water to enter the
pond from the filter.
(2) The inlet valve requires the
hose to be connected from the
pond pump.
(3) The dirty water valve allows
the water that is accumulated
during the cleaning process to be
directed away from the filter.
Please note that it is important
to follow the instructions as to
which pipe to fit to each hosetail
as they enable the filter to
perform different jobs.

Filter Foams
Inside the filter you will find a layer of two
filter foams in the order shown here;
black to blue.
Always make sure that they are replaced
in the same order.
There is a plastic tray to the bottom of the
unit which protects the biological media
and allows drainage of the filter foams.

How to change from normal
filtering to cleaning mode
The filter will arrive set in
this position. This is the filter
position; handle down to the
left.
The grey handles need to be
moved to the alternative
position; handle down to the
right to use the cleaning
function.
The grey handles may be a
little stiff at first; do not be
alarmed as this is due to the
unit being new. A little bit f
pressure and rocking should
allow you to rotate this to
change to clean mode.

How to change the
UV Bulb
Firstly turn the lid upside
down, this will allow access to
the plastic quartz housing.
Once you have turned the unit
upside down, there are three
screws to be removed, this will
then allow you access to the
casing that surrounds the bulb.

How to change the
UV Bulb
Once you have taken the
casing off, your able to
remove the quartz sleeve.
There is a screw fitment to
the base which needs to be
turned anti-clockwise.
Now you are able to take out
the UV bulb which is held in
by pins; this will easily
remove to be changed.
