POOLEX Nano User manual

INSTALLATION
AND
USER MANUAL
for your heat pump
Model Poolex Nano

Dear Customer,
Thank you for your purchase and for your condence in our products.
These are the result of many years of research in the eld of design and production
of heat pumps for swimming pools. Our aim is to provide you with an exceptional high
performance quality product.
We have produced this manual with the utmost care so that you get maximum benet
from your Poolex heat pump.
Thank you

PLEASE READ CAREFULLY
These installation instructions are an integral part of the product.
They must be given to the installer and retained by the user.
If the manual is lost, please consult the website:
www.poolex.fr
The instructions and recommendations contained in this manual should be read carefully and understood
since they provide valuable information concerning the heat pump’s safe handling and operation. Keep this
manual in an accessible place for easy future reference.
Installation must be carried out by a qualied professional person in accordance with current regu-
lations and the manufacturer’s instructions. An installation error may cause physical injury to persons or
animals as well as mechanical damage for which the manufacturer can under no circumstances be held
responsible.
After unpacking the heat pump, please check the contents in order to report any damage. Please
also check that the pressure indicated on the gauge is higher than 80 psi. If not, this could mean a
leak of refrigerant.
Prior to connecting the heat pump, ensure that the information provided in this manual is compatible with
the actual installation conditions and does not exceed the maximum limits authorized for this particular
product.
In the event of a defect and/or malfunction of the heat pump, the electricity supply must be discon-
nected and no attempt made to repair the fault.
Repairs must be undertaken only by an authorized technical service organization using original replace-
ment parts. Failure to comply with the above-mentioned clauses may have an adverse effect on the heat
pump’s safe operation.
To guarantee the heat pump’s efciency and satisfactory operation, it is important to ensure its regular
maintenance in accordance with the instructions provided.
If the heat pump is sold or transferred, always make sure that all technical documentation is transmitted
with the equipment to the new owner.
This heat pump is designed solely for heating a swimming pool. Any other use must be considered as being
inappropriate, incorrect or even hazardous.
! !
Any contractual or non-contractual liability of the manufacturer/distributor shall be deemed null and void for
damage caused by installation or operational errors, or due to non-compliance with the instructions provid-
ed in this manual or with current installation norms applicable to the equipment covered by this document.

Contents
1. General ........................................................................................................................................................................................... 6
1.1 General Terms of Delivery .......................................................................................................................................................... 6
1.2 Safety instructions ...................................................................................................................................................................... 6
1.3 Water treatment ......................................................................................................................................................................... 7
2. Description ..................................................................................................................................................................................... 8
2.1 Package contents ...................................................................................................................................................................... 8
2.2 General characteristics .............................................................................................................................................................. 8
2.3 Technical specications ............................................................................................................................................................. 9
2.4 Unit dimensions ....................................................................................................................................................................... 10
2.5 Exploded view ...........................................................................................................................................................................11
3. Installation ................................................................................................................................................................................... 12
3.1 Location ................................................................................................................................................................................... 12
3.2 Installation layout ..................................................................................................................................................................... 13
3.3 Connecting the condensation draining kit ................................................................................................................................ 13
3.4 Hydraulic connection ................................................................................................................................................................ 14
3.5 Electrical connection ................................................................................................................................................................ 15
4. Use ................................................................................................................................................................................................ 16
4.1 control panel ............................................................................................................................................................................ 16
4.2 Heating Mode ........................................................................................................................................................................... 17
4.3 Status values and advanced settings ...................................................................................................................................... 18
5. Operation ...................................................................................................................................................................................... 20
5.1 Operation ................................................................................................................................................................................. 20
5.3 Using the pressure gauge ........................................................................................................................................................ 21
6. Maintenance and servicing ......................................................................................................................................................... 22
6.1 Maintenance, servicing and winter storage .............................................................................................................................. 22
7. Repairs ......................................................................................................................................................................................... 23
7.1 Breakdowns and faults ............................................................................................................................................................. 23
8. Recycling ...................................................................................................................................................................................... 24
8.1 Recycling the heat pump ......................................................................................................................................................... 24
9. Warranty ....................................................................................................................................................................................... 25
9.1 General warranty conditions .................................................................................................................................................... 25
10. Appendices ................................................................................................................................................................................ 26
10.1 Wiring diagrams ....................................................................................................................................................................... 26

6
All equipment, even if shipped ‘free of carriage and packing’, is dispatched at the consignee’s own risk.
The person responsible for receiving the equipment must carry out a visual inspection to identify any dam-
age to the heat pump during transport (refrigerant system, body panels, electrical control box, frame). He/
she must note down on the carrier’s delivery note any remarks concerning damage caused during transport
and conrm them to the carrier by registered letter within 48 hours.
The equipment must always be stored and transported vertically on a pallet and in its original packaging. If
it is stored or transported horizontally, wait at least 24 hours before switching it on.
During installation and servicing
Only a qualied person may undertake installation, start-up, servicing and repairs, in compliance with
current standards.
Before operating or undertaking any work on the equipment (installation, commissioning, usage, servicing),
the person responsible must be aware of all the instructions in the heat pump’s installation manual as well
as the technical specications.
Under no circumstances install the equipment close to a source of heat, combustible materials or a build-
ing’s air intake.
If installation is not in a location with restricted access, a heat pump protective grille must be tted.
To avoid severe burns, do not walk on pipework during installation, repairs or maintenance.
To avoid severe burns, prior to any work on the refrigerant system, turn off the heat pump and wait several
minutes before placing temperature and pressure sensors.
Check the refrigerant level when servicing the heat pump.
Check that the high and low pressure switches are correctly connected to the refrigerant system and that
they turn off the electrical circuit if tripped during the equipment’s annual leakage inspection.
Check that there is no trace of corrosion or oil stains around the refrigerant components.
1.2 Safety instructions
1.1 General Terms of Delivery
WARNING : Please read carefully the safety instructions before using the equipment.
The following instructions are essential for safety so please strictly comply with them.
1. General

7
1.3 Water treatment
Poolex heat pumps for swimming pools can be used with all types of water treatment systems.
Nevertheless, it is essential that the treatment system (chlorine, pH, bromine and/or salt chlorinator meter-
ing pumps) is installed after the heat pump in the hydraulic circuit.
To avoid any deterioration to the heat pump, the water’s pH must be maintained between 6.9 and
8.0.
1. General
During use
To avoid serious injuries, never touch the fan when it is operating.
Keep the heat pump out of the reach of children to avoid serious injuries caused by the heat exchanger’s
blades.
Never start the equipment if there is no water in the pool or if the circulating pump is stopped.
Check the water ow rate every month and clean the lter if necessary.
During cleaning
Switch off the equipment’s electricity supply.
Close the water inlet and outlet valves.
Do not insert anything into the air or water intakes or outlets.
Do not rinse the equipment with water.
During repairs
Carry out work on the refrigerant system in accordance with current safety regulations.
Brazing should be performed by a qualied welder.
When replacing a defective refrigerant component, use only parts certied by our technical department.
When replacing pipework, only copper pipes conforming to Standard NF EN12735-1 may be used for
repairs.
When pressure-testing to detect leaks:
To avoid the risks of re or explosion, never use oxygen or dry air.
Use dehydrated nitrogen or a mixture of nitrogen and refrigerant.
The low and high side test pressure must not exceed 42 bar.

8
2.1 Package contents
2.2 General characteristics
✔Heat pump Poolex Nano
✔2 hydraulic inlet/outlet connectors 32/38mm diameter
✔This installation and user manual
✔Condensation draining kit
✔4 anti-vibration pads
A Poolex heat pump has the following features:
CE certication and complies with the RoHS European directive.
High performance with up to 80% energy savings compared to a conventional heating system.
Clean, efcient and environmentally friendly R410A refrigerant.
Reliable high output leading brand compressor.
Wide hydrophilic aluminum evaporator for use at low temperatures.
User-friendly intuitive control panel.
Heavy duty shell, anti-UV treated and easy to maintain.
Designed to be silent.
2. Description

9
2.3 Technical specications
2. Description
Nano
Air (1) 26°C
Water (2) 26°C
Heating power (W) 2800
Consumption (W) 530
COP (Coeff. of performance) 5,3
Air (1) 15°C
Water (2) 26°C
Heating power (W) 2200
Consumption (W) 510
COP (Coeff. of performance) 4,3
Electricity supply 220-240V single-phase ~ 50Hz
Maximum power (W) 810
Maximum current (A) 3.62
Heating temperature range 15°C~40°C
Operating range 7°C~43°C
Unit dimensions L × W × H (mm) 385 x 400 x 280
Unit weight (kg) 15
Packaging dimensions L × W × H (mm) 415 x 460 x 380
Packaging weight (kg) 17
Sound pressure level at 10 m (dBA) (3) <28
Hydraulic connection (mm) PVC 32 / 38mm
Heat exchanger PVC tank and titanium heating coil
Min. water ow rate (m³/h) 1,3
Compressor Toshiba
Compressor type Rotary
Refrigerant R410A
Refrigerant content (kg) 0,3
GWP 2088
Equivalent CO2 0,63
Waterproof IP IPX4
Load loss (mCE) 0,8
Max. pool volume (m3) (4) ≤20
Control panel Backlight LCD screen
Mode Heating
The technical specications of our heat pumps are provided for information purposes only. We reserve the right to make changes without prior notice.
1 Ambient air temperature
2 Initial water temperature
3Noise at 10 m in accordance with Directives EN ISO 3741 and EN ISO 354
4Calculated for an in-ground private swimming pool covered with a bubble cover.

10
2.4 Unit dimensions
2. Description
比例 1.000
B
A
DE
C
Dimensions in mm
Nano
A385
B400
C280
D55
E140

11
2.5 Exploded view
1. Base plate
2. Compressor
3. Evaporator
4. Top panel
5. Throttling parts
6. Electrical control box
7. Flow switch
8. Pressure gauge
9. Left side panel
10. Heat exchanger
11. Fan and motor
12. Fan support
13. Control panel cover
14. Control panel
15. Front panel
16. Fan protective grill
2. Description
1
2
3
4
5
8
11
13
16
10
12
6
9
7
14
15

12
>2.5m
The heat pump should be located at least 2.5 meter away from the swimming pool.
Pool
3.1 Location
Please comply with the following rules concerning the choice of heat pump location.
1. The unit’s future location must be easily accessible for convenient operation and maintenance.
2. It must be installed on the ground, laid ideally on a level concrete oor. Ensure that the oor is sufciently
stable and can support the weight of the unit.
3. A water drainage device must be provided close to the unit in order to protect the area where it is installed.
4. Check that the unit is properly ventilated, that the air outlet is not facing the windows of neighboring
buildings and that the exhaust air cannot return. In addition, provide sufcient space around the unit for
servicing and maintenance operations.
5. The unit must not be installed in an area exposed to oil, ammable gases, corrosive products, sulfurous
compounds or close to high frequency equipment.
6. To prevent mud splashes, do not install the unit near a road or track.
7. To avoid causing nuisance to neighbors, make sure the unit is installed so that it is positioned towards the
area that is least sensitive to noise.
8. Keep the unit as much as possible out of the reach of children.
3. Installation
The heat pump is very easy to install, only water and power need to be connected during
installation.
Place nothing less than 1,50 m in front of the heat pump.
Leave 30 cm cm of empty space around the sides and rear of the heat pump.
Do not leave any obstacle above or in front of the unit!
≥1500
≥300
≥300
Dimensions in mm

13
3.3 Connecting the condensation draining kit
While operating, the heat pump is subject to condensation. This will result in a more or less large run-off
of water, depending on the degree of humidity. To channel this ow, we recommend that you install the
condensation drainage kit.
3. Installation
3.2 Installation layout
The lter located upstream of the heat pump must be regularly cleared so that the water in
the system is clean, thus avoiding the operational problems associated with dirt or clog-
ging in the lter.
TOWARDS THE POOL
Filtration + Pump
Automated treatment
system
FROM THE POOL
POOL

14
3. Installation
Step 1 : Screw the connectors to the heat pump
Step 2 : Connect the water outlet pipe and the water intake pipe
3.4 Hydraulic connection
TOWARDS THE POOL
FROM THE POOL

15
3. Installation
The heat pump electrical plug integrates a 10mA differential circuit breaker.
Before connecting your heat pump, please ensure that the plug is connected to the ground.
The lter pump should function at the same time as the heat pump. Therefore, you need to connect them to
the same electrical circuit.
3.5 Electrical connection

16
1. ON/OFF 2. Heating 3. Malfunction 4. Defrost 5. Fan
6. Water pump 7. Compressor 8. Setting 9. + 10. -
4. Use
4.1 Control panel

17
Useful information about how the heating mode operates
When the incoming water temperature is less than or equal to the required temperature (setpoint tempera-
ture) -X°C, the heat pump will switch to heating mode. The compressor will stop when the temperature of
the incoming water is greater than or equal to the required temperature (setpoint temperature).
Indicators for adjustment range X and Y
X : adjustable parameter from 1° to 15°C, default setting is 3°C. (Parameter N°6)
Step 1 : Press to switch on your pump.
Step 2 : Using buttons and select the required temperature.
EXAMPLE:
If the current temperature is 15°C, default setting temperature is 27° required temperature is 30°C.
4. Use
4.2 Heating Mode
Current water
temperature
Required
temperature
WARNING: Before starting, ensure that the ltration pump is operating correctly.

18
The system’s settings can be checked and adjusted via the remote control by following these steps
Step 1 : Keep pressing until you enter the settings verication mode.
Step 2 : Press and for see the parameters.
Step 3 : Press to select the setting to be modied.
Note, some settings cannot be modied. Consult the settings table for further information.
Step 4 : Press and to adjust the setting value.
Step 5 : Press to set the new value.
Step 6 : Press to return to the main screen.
WARNING: This operation is used to assist servicing and future repairs.
The default settings should only be modied by an experienced professional person.
4. Use
4.3 Status values and advanced settings
Value 30 Parameter N°5

19
4. Use
Parameters table
4. Use
N° Description Adjustment range Factory
setting Remarks
0Reserved - Do not adjust 8~37°C 12°C Reserved
1Default temperature 15~40°C 27°C Adjustable
2Defrost auto-activation time 10~90 min 40 min Adjustable
3Defrost activation temperature -30~0°C 0°C Adjustable
4Defrost deactivation temperature 1~30°C 2°C Adjustable
5Maximum defrost duration 10~40 min 30 min Adjustable
6Adjustment of temperature difference for restart 2~10°C 3°C Adjustable
7Automatic restart 0 = OFF
1 = ON 1 Adjustable
8Reserved - Do not adjust 0 / 1 / 2 0 Reserved
9Reserved - Do not adjust 0 / 1 0 Reserved
AReserved - Do not adjust 8~60°C 30°C Reserved
BAntifreeze protection - low air temperature 0~15°C 8°C Ajustable
CAntifreeze protection - low water temperature 2~14°C 4°C Ajustable
DReserved - Do not adjust - - Reserved
EReserved - Do not adjust 0 / 1 0 Reserved
FReserved - Do not adjust 3~20°C 5°C Reserved
HReserved - Do not adjust 5~20°C 13°C Reserved
JReserved - Do not adjust 65~90°C 70°C Reserved
oWater intake temperature -9~99°C Actual data
PWater outlet temperature -9~99°C Actual data
tCoil temperature -9~99°C Actual data
UAmbient air temperature -9~99°C Actual data

20
5. Operation
5.1 Operation
Conditions of use
For the heat pump to operate normally, the ambient air temperature must be between 7°C and 43°C.
Recommendations prior to start-up
Before activating the heat pump, please:
✔Check that the unit is stable.
✔Check that the gauge indicates a pressure greater than 80 psi.
✔Control the proper functioning of your electrical installation.
✔Check that the hydraulic connections are tight and that there is no leakage of water.
✔Remove any unnecessary object or tool from around the unit.
Operation
1. Connect the unit power plug.
2. Activate the circulating pump.
3. Activate the unit’s power supply protection (differential switch and circuit-breaker).
4. Activate the heat pump by pressing once on .
5. Select the required temperature.
6. The heat pump’s compressor will start up after a few moments.
All you have to do now is wait until the required temperature is reached.
WARNING: Under normal conditions, a suitable heat pump can heat the water in a swimming
pool by 1°C to 2°C per day. It is therefore quite normal to not feel any temperature difference in
the system when the heat pump is working.
A heated pool must be covered to avoid any loss of heat.
5. Operation
