Popodusche Eco 2.0 User manual

Popodusche Eco 2.0
OPERATION MANUAL

2
LIABILITY DISCLOSURE
The supplier is not liable for damages caused by negligence in the following areas:
1. This is an electronic device and must be grounded!
2. Persons with disabilities or small children should not be allowed to use this product without supervision.
3. This product is an electrical device, please pay attention to a proper installation.
SAFETY INSTRUCTIONS
1. Do not insert or remove any electrical plug with wet hands. Electrical shock may occur.
2. Do not damage the power cord and the plug.
Otherwise there is a risk of electric shock, short circuit and re.
3. Do not use a damaged electrical plug, cord or a loose plug-in. Any negligence could result
in electrical shock, re, short circuit or damage to your product may occur.
4. An electrical installation should be installed professionally. Any negligence could result
in electric shock, short circuit, re or damage to your device.
5. Do not disassemble any device without expert knowledge. Any negligence could result
in electric shock, short circuit, re or damage to your device.
6. Do not allow any uids of any kind to come in contact with the electrical components.
Any negligence could result in electric shock, short circuit, re or damage to your device.
7. Caution! Please pay attention to the water ow direction. Negligence can cause
irreparable damage to your device.
8. Don not bend, twist or bend the steel water hose, this could cause a leak.

3
Rear Wash
Lady Wash
Water temperature settings
Stream settings
Stream direction settings
Self-cleaning jet
Manuell cleaning
Nightlight settings
Ambient light
Intelligent energy saver
Soft-Close seat
Control head
Rimless toilet
Water connection
Electrical connection
Watts
Length of cable
Waterpressure
Water temperature
Operating temperature range
Safety class
Water
Water temperatur
Wash cycle
Heating module
Maximum Heat
Safety Fuse
Back check
Net weight
Dimensions
Wash
Hygiene
Water Settings
5 Settings (Standard 3)
5 Settings (Standard 3)
5 Settings (Standard 5)
G 3/8“
240 V, 50/60 Hz
950 W
1,80 m
0,07 - 0,75 MPa (0,7-7,5 bar)
4°C - 35°C
4°C - 40°C
IPX4
350 ~ 650 Milliliter per minute
31°C - 39°C
3 minutes
Warm water boiler
1200 W
Thermo-cut-off-fuse, Fill cut-off fuse,
Air gap
32 kg
B 384 x T 593 x H 380 mm
TECHNICAL SPECIFICATIONS

4
TECHNICAL DRAWINGS

5
OVERVIEW
Seat sensor
Cover
Nicht Light
Rear Wash
Lady Wash
Control-Knob
Seat
Ceramic
Ambient Light

6
REAR WASH / LADYWASH
You can operate the Rear or Lady -Wash by pressing the „ “ or „ “ button on the control-knob.
The washing will stop after 3 minutes or you can stop the funktion by pressing the „ “ button on the control-knob.
Lady Wash Rear Wash
FUNKTIONS
ADJUST WATER FLOW
less more
STOP-button
ADJUST THE NOZZLE POSITION
ADJUST WATER TEMPERATURE
Press the „
Temperature.
“ or „ “ button for adjusting the
less
more
pull
moves forwardmoves back
You can adjust the nozzle position by pulling out the contol-knob
and then turn it clockwise (the nozzle moves forward) or
turn it anti clockwise (the nozzle moves backwards) .
In the process of Rear Wash or Ladywash you can operate by
rotating the knob. The rate will increase in the clockwise
direction and decrease in the anticlockwise direction.

7
AMBIENT LIGHT
for adjusting the night light, pull out the contol-knob and turn it anti clockwise
the night light model will change like:
Night light out --> Night light always on --> Night light smart mode.
The smart mode refers that the night light will light up in a dark environment and
light off in a bright environment.
NIGHT LIGHT
SETTINGS
pull
turn
Open the cover and be unseated, pull the knob and rotate it in the clockwise direction .
The ambient light will be lighted off. It will be lighted up when rotating it in the
clockwise direction again
pull
turn
POWER OF SETTING
Keep pressing the middle button of the knob for more than 6seconds, it will go into power standby mode.
Press again the button for more than 6 seconds to restart it.

8
1. The nozzle will be cleaned before washing and after washing.
2. Manual cleanig
Open the cover and seat then rotate the knob in the clockwise
direction.Then the nozzle will extend with cleaning water.
It will return after 5 minutes or press the " stop " button .
NOZZLE CLEANIG
AB
E
D
C
Not used for more than 72 hours, when the user operates the washing ,it will open the
self-cleaning for about 30 seconds. All the buttons are invalid during the self- cleaning and
it will return to normal after the self-cleaning
SELF-CLEANIG TANK

AB
D
C
RELEASE AND INSTALL COVER AND SEAT
9

10
TROUBLESHOOTING
noitcadetsegguSesuaclaitnetoPmelborP
The power supply may not be opened rewopehtnonrutesaelP.1
The water supply may not be opened2. please open the inlet water valve,or check if there is without water
supply
3.Maybe not in the seating state Please sit on the seat and adjust sitting position
1.The washing cycle is 3 mins. It will stop
washing after 3 mins then the nozzle will go This is normal and please return the knob to start washing again
2.There may be some problems of water supply Please check if there is without water supply
3.Maybe the user stand up and leave the seated
sensor area. Please sit down and adjust sitting position
1.The water flow rate may be set at low grades Please increase the flow rate as per "adjusting water flow rate" of
operating instructions.
2.The water supply pressure may be too low Please check and ensure the water supply pressure is 0.07Mpa
Low water temperature The water temperature may be set at low grades Please set the water temperature at high grade as per "adjusting
temperature"of operating instructions.
The nozzle comes out slow
When start washing function, the nozzle will do
self-cleaning before coming out, and this will take
a few seconds
This is normal.
1.Maybe in the bright environment. When the night light is set at smart mode,the night light will not work
when in the bright environment.
2.The night light function may be closed. Please open the night light function and adjust the night light mode as
per "Light Setting" of operating instructions.
1.Maybe in the dark environment. When the night light is set at smart mode,the night light will be always
on when in the dark environment.
2.Something may be covered around the knob. Clean the obstructions around the knob.
3.The night light may be set at always on mode Please adjust the night light mode as per "Light Setting" of operating
instructions.
1.The nozzle goes back after washing 5 minutes. This is normal.
.bonkehtsserpfideppotseblliwgninaelclaunamehTbonksserpebyaM.2
3.Maybe the seated sensor detected that it is in
the seating state Please do not put down the seat during the manual cleaning
The light flash twice with
constantly "beep" The water temperature may be too high. Please shut off the power and water supply,stop using the product,and then contact local distributor
The light around the knob keep
flashing There may be something wrong with the product.
Please check if the power and water supply are normal,cut off the
power for 1 minute then restart the product. If the product still cannot
work,please contact local distributor.
The nozzle goes back
automaticly when manual
cleaning
The electronic bidet cannot
work
The nozzle goes back
suddenly
Low water flow rate
Night light cannot work
Night light is always on
Do not dispose of electrical appliances as unsorted municipal waste, use separate
collection facilities.
Contact you local government for information regarding the collection systems available.
If electrical appliances are disposed of in landfills or dumps, hazardous substances can leak
into the groundwater and get into the food chain, damaging your health and well-being.
When replacing old appliances with new ones, the retailer is legally obligated to take back
your old appliance for disposals at least free of charge.
