RAM 1500 2023 User manual

SECOND EDITION
23_DT_OM_EN_USC
©2022 FCA US LLC. All Rights Reserved. Tous droits réservés. Ram is a registered trademark of FCA US LLC.
Ram est une marque déposée de FCA US LLC. App Store is a registered trademark of Apple Inc. Google Play Store is a registered trademark of Google.
DOWNLOAD THE MOST UP-TO-DATE OWNER’S MANUAL,
RADIO AND WARRANTY BOOKS
OWNERS.MOPAR.CA
CANADA
MOPAR.COM/OM
USA
2023 RAM 1500
OWNER’S MANUAL
2023 RAM 1500
Whether it is providing information about specific product features, taking a tour through your vehicle’s heritage, knowing
what steps to take following an accident or scheduling your next appointment, we know you will find the app an important
extension of your Ram vehicle. Simply download the app, select your make and model and enjoy the ride. To get this app, go
directly to the App Store®or Google Play®Store and enter the search keyword “ram toolbox” (U.S. residents only).

WARNING: Operating, servicing and maintaining a passenger vehicle or off-highway motor
vehicle can expose you to chemicals including engine exhaust, carbon monoxide, phthalates, and
lead, which are known to the State of California to cause cancer and birth defects or other reproductive
harm. To minimize exposure, avoid breathing exhaust, do not idle the engine except as necessary,
service your vehicle in a well-ventilated area and wear gloves or wash your hands frequently when
servicing your vehicle. For more information go to www.P65Warnings.ca.gov/passenger-vehicle.
The driver’s primary responsibility is the safe operation of the vehicle. Driving while distracted can result in loss of vehicle control, resulting in an accident and personal injury.
FCA US LLC strongly recommends that the driver use extreme caution when using any device or feature that may take their attention off the road. Use of any electrical devices,
such as cellular telephones, computers, portable radios, vehicle navigation or other devices, by the driver while the vehicle is moving is dangerous and could lead to a serious
accident. Texting while driving is also dangerous and should never be done while the vehicle is moving. If you find yourself unable to devote your full attention to vehicle
operation, pull off the road to a safe location and stop your vehicle. Some states or provinces prohibit the use of cellular telephones or texting while driving. It is always the
driver’s responsibility to comply with all local laws.
This Owner’s Manual has been prepared to help you get acquainted with your new Ram brand vehicle and to provide a convenient reference for common questions.
Not all features shown in this manual may apply to your vehicle. For additional information on accessories to help personalize your vehicle, visit mopar.com/om (USA),
owners.mopar.ca (Canada) or your local Ram brand dealer.
This Owner’s Manual is intended to familiarize you with the important features of your vehicle. Your most up-to-date Owner’s Manual, Radio Instruction Manual and
Warranty Booklet can be found by visiting the website on the back cover.
U.S. Residents: If you are the first registered retail owner of your vehicle, you may obtain a complimentary printed copy of the Warranty Booklet by calling 1-866-726-4636
or by contacting your dealer. Replacement kits can be purchased by visiting www.techauthority.com.
Canadian Residents: If you are the first registered retail owner of your vehicle, you may obtain a complimentary printed copy of the Warranty Booklet or purchase a
replacement kit by calling 1-800-387-1143 or by contacting your dealer.
DRIVING AND ALCOHOL
Drunk driving is one of the most frequent causes of accidents. Your driving ability can be seriously impaired with blood alcohol levels far below the legal minimum. If you
are drinking, don’t drive. Ride with a designated non-drinking driver, call a cab, a friend or use public transportation.
WARNING
Driving after drinking can lead to an accident. Your perceptions are less sharp, your reflexes are slower and your judgment is impaired when you have been drinking.
Never drink and then drive.
This Owner’s Manual illustrates and describes the operation of features and equipment that are either standard or optional on this vehicle. This manual may also include
a description of features and equipment that are no longer available or were not ordered on this vehicle. Please disregard any features and equipment described in this
manual that are not on this vehicle. FCA US LLC reserves the right to make changes in design and specifications, and/or make additions to or improvements to its products
without imposing any obligation upon itself to install them on products previously manufactured.
With respect to any vehicles sold in Canada, the name FCA US LLC shall be deemed to be deleted and the name FCA Canada Inc. used in substitution therefore.
FCA US LLC reserves the right to modify the terms or discontinue the Roadside Assistance Program at any time. The Roadside Assistance Program is subject to restrictions and conditions of use,
that are determined solely by FCA US LLC.
ROADSIDE ASSISTANCE
24 HOURS, 7 DAYS A WEEK AT YOUR SERVICE.
CALL 1-800-521-2779 OR VISIT CHRYSLER.RSAHELP.COM (USA)
CALL 1-800-363-4869 OR VISIT FCA.ROADSIDEAID.COM (CANADA)
SERVICES: Flat Tire Service, Out Of Gas/Fuel Delivery, Battery Jump Assistance, Lockout Service and Towing Service
Please see the Customer Assistance chapter in this Owner’s Manual for further information.

TABLE OF CONTENTS
1
2
3
4
5
6
7
8
9
10
11
1 INTRODUCTION .............................................................................................................................. 8
2 GETTING TO KNOW YOUR VEHICLE ................................................................................. 16
3 GETTING TO KNOW YOUR INSTRUMENT PANEL ....................................................... 93
4 STARTING AND OPERATING ................................................................................................ 118
5 MULTIMEDIA ................................................................................................................................ 191
6 SAFETY ........................................................................................................................................262
7 IN CASE OF EMERGENCY .....................................................................................................314
8 SERVICING AND MAINTENANCE ...................................................................................... 333
9 TECHNICAL SPECIFICATIONS ............................................................................................ 392
10 CUSTOMER ASSISTANCE .....................................................................................................398
11 INDEX ............................................................................................................................................ 403
23_DT_OM_EN_USC_t.book Page 1

2
INTRODUCTION
SYMBOLS KEY .......................................................................9
VAN CONVERSIONS/CAMPERS ......................................... 9
CONSUMER INFORMATION — TRUCK-CAMPER
LOADING ................................................................................9
VEHICLE MODIFICATIONS/ALTERATIONS ......................11
SYMBOL GLOSSARY...........................................................11
GETTING TO KNOW YOUR VEHICLE
KEYS ....................................................................................16
Key Fob........................................................................ 16
SENTRY KEY ........................................................................19
IGNITION SWITCH ..............................................................20
Keyless Enter ‘n Go™ Ignition .................................... 20
REMOTE START — IF EQUIPPED ......................................21
How To Use Remote Start .......................................... 21
To Exit Remote Start Mode ........................................ 22
Remote Start Front Defrost Activation —
If Equipped .................................................................. 22
Remote Start Comfort Systems — If Equipped.......... 22
Remote Start Windshield Wiper De-Icer
Activation — If Equipped ............................................. 23
Remote Start Abort Message..................................... 23
VEHICLE SECURITY SYSTEM — IF EQUIPPED .................23
To Arm The System ..................................................... 23
To Disarm The System................................................ 23
Rearming Of The System............................................ 24
Security System Manual Override.............................. 24
DOORS ................................................................................24
Manual Door Locks......................................................24
Power Door Locks — If Equipped ...............................25
Power Side Steps — If Equipped ................................25
Keyless Enter ‘n Go™ — Passive Entry ......................25
Automatic Unlock Doors On Exit — If Equipped .........27
Automatic Door Locks — If Equipped ........................27
Child-Protection Door Lock System — Rear Doors.....27
STEERING WHEEL ..............................................................28
Tilt/Telescoping Steering Column .............................28
Heated Steering Wheel — If Equipped .......................28
DRIVER MEMORY SETTINGS — IF EQUIPPED ................29
Programming The Memory Feature............................29
Linking And Unlinking The Key Fob To Memory.........29
Memory Position Recall...............................................30
SEATS ..................................................................................30
Manual Adjustment
(Front Seats) — If Equipped.........................................30
Manual Adjustment (Rear Seats) ...............................31
Power Adjustment (Front Seats) — If Equipped .........32
Heated Seats — If Equipped .......................................33
Ventilated Seats — If Equipped...................................34
Plastic Grocery Bag Retainers — If Equipped ............34
Head Restraints ..........................................................34
UCONNECT VOICE RECOGNITION —
IF EQUIPPED .......................................................................36
Introducing Voice Recognition ....................................36
Basic Voice Commands...............................................36
Get Started...................................................................37
Additional Information.................................................37
DRIVER ADJUSTABLE PEDALS —
IF EQUIPPED ...................................................................... 38
MIRRORS ............................................................................ 38
Inside Rearview Mirror................................................ 38
Illuminated Vanity Mirror ............................................ 39
Outside Mirrors ........................................................... 40
Outside Automatic Dimming Mirrors —
If Equipped................................................................... 40
Outside Mirrors With Turn Signal And
Approach Lighting — If Equipped................................ 40
Power Mirrors .............................................................. 41
Power Folding Outside Mirrors For Standard
And Trailer Tow — If Equipped .................................... 41
Trailer Towing Mirrors — If Equipped ......................... 42
Heated Mirrors — If Equipped .................................... 42
UNIVERSAL GARAGE DOOR OPENER
(HOMELINK®) — IF EQUIPPED ......................................... 42
Before You Begin Programming HomeLink® ............ 43
Erasing All The HomeLink® Channels ....................... 43
Identifying Whether You Have A Rolling Code Or
Non-Rolling Code Device............................................. 43
Programming HomeLink® To A Garage Door
Opener ......................................................................... 44
Programming HomeLink® To A Miscellaneous
Device .......................................................................... 44
Reprogramming A Single HomeLink® Button........... 45
Canadian/Gate Operator Programming .................... 45
Security ........................................................................ 45
Troubleshooting Tips................................................... 46
23_DT_OM_EN_USC_t.book Page 2

3
EXTERIOR LIGHTS ..............................................................46
Headlight Switch ........................................................ 46
Multifunction Lever .................................................... 47
Daytime Running Lights (DRLs) ................................ 47
High/Low Beam Switch ............................................. 47
Automatic High Beam Headlamp Control —
If Equipped ................................................................. 47
Flash-To-Pass ............................................................. 48
Automatic Headlights — If Equipped ......................... 48
Parking Lights And Panel Lights................................. 48
Automatic Headlights With Wipers ............................ 48
Headlight Delay........................................................... 48
Lights-On Reminder .................................................... 48
Fog Lights — If Equipped ........................................... 48
Turn Signals ................................................................ 49
Lane Change Assist — If Equipped............................. 49
Cargo Lights/Trailer Spotter Lights/Trailer
Hitch Light With Bed Lights — If Equipped ................ 49
Battery Saver............................................................... 50
INTERIOR LIGHTS ...............................................................50
Courtesy Lights............................................................ 50
Illuminated Entry ........................................................ 52
WINDSHIELD WIPERS AND WASHERS ..........................52
Windshield Wiper Operation....................................... 52
Rain Sensing Wipers — If Equipped .......................... 53
CLIMATE CONTROLS .........................................................54
Automatic Climate Control Descriptions
And Functions ............................................................. 54
Manual Climate Control Descriptions
And Functions ............................................................. 56
Automatic Temperature Control (ATC) —
If Equipped ................................................................. 59
Climate Voice Recognition — If Equipped.................. 59
Operating Tips ............................................................ 59
INTERIOR STORAGE AND EQUIPMENT ............................60
Storage .........................................................................60
USB/AUX Control ........................................................65
Electrical Power Outlets .............................................66
Power Inverter — If Equipped .....................................67
Wireless Charging Pad — If Equipped ........................68
UV-C Light — If Equipped .............................................69
WINDOWS ..........................................................................70
Power Windows............................................................70
Automatic Window Features .......................................70
Reset Auto-Up .............................................................71
Window Lockout Switch ..............................................71
Power Sliding Rear Window — If Equipped ...............71
Manual Sliding Rear Window — If Equipped ..............71
Wind Buffeting ............................................................72
POWER SUNROOF — IF EQUIPPED ................................. 72
Dual Pane Power Sunroof ..........................................72
HOOD ...................................................................................74
To Open The Hood .......................................................74
To Close The Hood.......................................................74
TAILGATE .............................................................................74
Opening ........................................................................74
Closing..........................................................................75
Locking Tailgate...........................................................75
Multifunction Tailgate — If Equipped .........................75
Tailgate Removal ........................................................76
Bed Step — If Equipped...............................................78
PICKUP BOX .......................................................................79
Bed Rail Tie-Down System — If Equipped .................80
RAMBOX — IF EQUIPPED ..................................................81
Locking And Unlocking RamBox .................................82
RamBox Cargo Storage Bins.......................................82
RamBox Safety Warning..............................................83
Bed Extender — If Equipped .......................................84
TRI-FOLD TONNEAU COVER — IF EQUIPPED .................. 86
Tonneau Cover Components ...................................... 86
Tri-Fold Tonneau Cover Folding For Driving
Or Removal .................................................................. 87
Tri-Fold Tonneau Cover Installation ........................... 90
Tri-Fold Tonneau Cover Cleaning ............................... 92
GETTING TO KNOW YOUR
INSTRUMENT PANEL
MIDLINE INSTRUMENT CLUSTER — GASOLINE.............. 93
Midline Instrument Cluster Descriptions —
Gasoline ....................................................................... 94
HIGHLINE INSTRUMENT CLUSTER — GASOLINE............ 95
Highline Instrument Cluster Descriptions —
Gasoline ....................................................................... 96
PREMIUM INSTRUMENT CLUSTER — GASOLINE............ 97
Premium Instrument Cluster Descriptions —
Gasoline ....................................................................... 98
INSTRUMENT CLUSTER DISPLAY..................................... 98
Instrument Cluster Display Location
and Controls ................................................................ 98
Oil Life Reset..............................................................101
Display Menu Items ..................................................101
Head Up Display (HUD) —
If Equipped ................................................................105
Battery Saver On/Battery Saver Mode
Message — Electrical Load Reduction Actions —
If Equipped ................................................................106
23_DT_OM_EN_USC_t.book Page 3

4
WARNING LIGHTS AND MESSAGES.............................. 107
Red Warning Lights................................................... 108
Yellow Warning Lights...............................................110
Yellow Indicator Lights..............................................113
Green Indicator Lights ..............................................114
White Indicator Lights...............................................115
Blue Indicator Lights................................................. 116
ONBOARD DIAGNOSTIC SYSTEM — OBD II ................. 116
Onboard Diagnostic System
(OBD II) Cybersecurity ...............................................116
EMISSIONS INSPECTION AND MAINTENANCE
PROGRAMS ..................................................................... 117
STARTING AND OPERATING
STARTING THE ENGINE .................................................. 118
Automatic Transmission ........................................... 118
Tip Start Feature ...................................................... 118
Keyless Enter ‘n Go™ — Ignition .............................. 118
Normal Starting Using ENGINE START/STOP
Button .......................................................................118
AutoPark .................................................................... 119
Extended Park Starting............................................. 120
If Engine Fails To Start ............................................. 121
After Starting ............................................................. 121
ENGINE BLOCK HEATER — IF EQUIPPED...................... 121
ENGINE BREAK-IN RECOMMENDATIONS .................... 122
PARKING BRAKE ............................................................ 122
Electric Park Brake (EPB) ........................................ 122
AUTOMATIC TRANSMISSION ......................................... 124
Ignition Park Interlock...............................................125
Brake/Transmission Shift Interlock (BTSI)
System ...................................................................... 125
8-Speed Automatic Transmission ........................... 125
FOUR-WHEEL DRIVE OPERATION —
IF EQUIPPED .................................................................... 130
Four-Position Electronically Shifted Transfer
Case — If Equipped .................................................. 130
Five-Position Electronically Shifted Transfer
Case — If Equipped .................................................. 132
ACTIVE-LEVEL FOUR CORNER AIR SUSPENSION
SYSTEM — IF EQUIPPED ................................................ 134
Description................................................................ 134
Air Suspension Modes.............................................. 135
Instrument Cluster Display Messages .................... 136
Operation................................................................... 136
ACTIVE-LEVEL FOUR CORNER AIR SUSPENSION
SYSTEM (OFF-ROAD GROUP) — IF EQUIPPED ............ 137
Description................................................................ 137
Air Suspension Modes.............................................. 138
Instrument Cluster Display Messages .................... 139
Operation................................................................... 139
AXLE LOCK SYSTEM — IF EQUIPPED ............................ 140
LIMITED-SLIP DIFFERENTIAL — IF EQUIPPED ............. 140
POWER STEERING .......................................................... 141
Electric Power Steering ........................................... 141
FUEL SAVER TECHNOLOGY 5.7L ENGINES ONLY —
IF EQUIPPED..................................................................... 141
STOP/START SYSTEM — IF EQUIPPED ......................... 141
Autostop Mode.......................................................... 141
Possible Reasons The Engine Does
Not Autostop ............................................................. 142
To Start The Engine While In Autostop Mode ......... 142
To Manually Turn Off The Stop/Start System ......... 143
To Manually Turn On The Stop/Start System ......... 143
System Malfunction.................................................. 143
CRUISE CONTROL SYSTEMS — IF EQUIPPED ............. 143
Cruise Control ........................................................... 143
Adaptive Cruise Control (ACC) ................................. 145
PARKSENSE FRONT/REAR PARK ASSIST
SYSTEM — IF EQUIPPED .................................................152
ParkSense Sensors...................................................153
ParkSense Warning Display......................................153
ParkSense Display ....................................................153
Enabling And Disabling Front And/Or Rear
ParkSense..................................................................156
Service The ParkSense Park Assist System ............156
Cleaning The ParkSense System .............................156
ParkSense System Usage Precautions....................156
PARKSENSE ACTIVE PARK ASSIST
SYSTEM — IF EQUIPPED ..................................................157
Enabling And Disabling The ParkSense
Active Park Assist System.........................................158
Parallel/Perpendicular Parking Space
Assistance Operation ................................................159
LANESENSE — IF EQUIPPED ..........................................161
LaneSense Operation ...............................................161
Turning LaneSense On Or Off...................................161
LaneSense Warning Message..................................161
Changing LaneSense Status ....................................163
Turn Signal Activated Blind Spot Assist —
If Equipped.................................................................163
PARKVIEW REAR BACK UP CAMERA ...........................163
SURROUND VIEW CAMERA SYSTEM —
IF EQUIPPED ....................................................................165
Forward Facing Camera With Tire Lines —
If Equipped.................................................................167
TRAILER CAMERAS — IF EQUIPPED .............................168
Trailer Surround View Camera System —
If Equipped.................................................................168
AUX Camera — If Equipped.......................................170
REFUELING THE VEHICLE ...............................................171
23_DT_OM_EN_USC_t.book Page 4

5
VEHICLE LOADING .......................................................... 172
Gross Vehicle Weight Rating (GVWR) ..................... 172
Payload ...................................................................... 172
Gross Axle Weight Rating (GAWR)............................ 172
Tire Size ..................................................................... 172
Rim Size..................................................................... 172
Inflation Pressure...................................................... 172
Curb Weight...............................................................172
Loading ...................................................................... 172
TRAILER TOWING ............................................................ 173
Common Towing Definitions .................................... 173
Trailer Hitch Type and Maximum Trailer Weight..... 176
Trailer Towing Weights
(Maximum Trailer Weight Ratings) .......................... 176
Trailer And Tongue Weight ......................................176
Trailer Reverse Steering
Control — If Equipped................................................177
Towing Requirements ..............................................179
Towing Tips ...............................................................184
SNOWPLOW ..................................................................... 184
Before Plowing .......................................................... 185
Snowplow Prep Package Model Availability ............ 185
Over The Road Operation With Snowplow
Attached .................................................................... 185
Operating Tips ........................................................... 185
General Maintenance............................................... 185
RECREATIONAL TOWING (BEHIND MOTORHOME) .... 186
Towing This Vehicle Behind Another Vehicle .......... 186
Recreational Towing — Two-Wheel Drive Models ... 186
Recreational Towing — Four-Wheel Drive Models... 187
DRIVING TIPS ................................................................... 189
Driving On Slippery Surfaces .................................. 189
Driving Through Water ............................................. 189
Off-Road Driving Tips ............................................... 190
MULTIMEDIA
UCONNECT SYSTEMS ..................................................... 191
CYBERSECURITY ............................................................. 191
UCONNECT SETTINGS .................................................... 191
Customer Programmable Features ........................ 192
UCONNECT INTRODUCTION............................................ 215
System Overview....................................................... 215
Safety And General Information ............................. 217
UCONNECT MODES ......................................................... 218
Steering Wheel Audio Controls ............................... 218
Radio Mode .............................................................. 218
Media Mode ............................................................. 226
Phone Mode ............................................................. 228
CONNECTED VEHICLE SERVICES —
IF EQUIPPED .................................................................... 236
Is My Vehicle Connected? ........................................ 236
Introduction To Connected Vehicle Services ......... 237
Getting Started With Connected Vehicle
Services .................................................................... 238
Using SiriusXM Guardian™ ..................................... 239
Manage My SiriusXM Guardian™ Account ............. 248
CONNECTED SERVICES FAQS ....................................... 248
Connected Services SOS FAQs — If Equipped ....... 248
Connected Services Remote Door
Lock/Unlock FAQs ................................................... 249
Connected Services Roadside Assistance FAQs ....249
Connected Services Send & Go FAQs —
If Equipped ................................................................249
Connected Services Vehicle Finder FAQs ...............249
Connected Services Stolen Vehicle
Assistance FAQs — If Equipped ...............................250
Connected Services Remote Vehicle
Start FAQs .................................................................250
Connected Services Remote Horn & Lights
FAQs ...........................................................................250
Connected Services Account FAQs —
If Equipped.................................................................251
Data Collection & Privacy..........................................252
RADIO OPERATION AND MOBILE PHONES .................252
Regulatory And Safety Information ..........................253
PERFORMANCE PAGES — IF EQUIPPED .......................253
Timers ........................................................................253
Gauges.......................................................................254
G-Force.......................................................................254
Dynamometer (Dyno)/Engine...................................255
Vehicle Dynamics ......................................................255
OFF-ROAD PAGES — IF EQUIPPED ................................256
Off-Road Pages Status Bar ......................................257
Vehicle Dynamics .....................................................258
Accessory Gauge .......................................................259
Pitch & Roll ................................................................260
Suspension — If Equipped ........................................261
Forward Facing Camera — If Equipped....................261
23_DT_OM_EN_USC_t.book Page 5

6
SAFETY
SAFETY FEATURES........................................................... 262
Anti-Lock Brake System (ABS) ................................. 262
Rear Seat Reminder Alert (RSRA)............................ 263
Electronic Brake Control (EBC) System .................. 263
AUXILIARY DRIVING SYSTEMS ...................................... 269
Blind Spot Monitoring (BSM) —
If Equipped ...............................................................269
Forward Collision Warning (FCW) With
Mitigation — If Equipped........................................... 274
Tire Pressure Monitoring System (TPMS) ............... 277
OCCUPANT RESTRAINT SYSTEMS ................................ 282
Occupant Restraint Systems Features ................... 282
Important Safety Precautions .................................. 282
Seat Belt Systems .................................................... 282
Supplemental Restraint Systems (SRS) .................. 288
Child Restraints ........................................................ 298
SAFETY TIPS .................................................................... 311
Transporting Passengers.......................................... 311
Transporting Pets ..................................................... 311
Connected Vehicles .................................................. 311
Safety Checks You Should Make Inside
The Vehicle ...............................................................311
Periodic Safety Checks You Should Make
Outside The Vehicle .................................................. 312
Exhaust Gas ............................................................. 313
Carbon Monoxide Warnings .................................... 313
IN CASE OF EMERGENCY
HAZARD WARNING FLASHERS .................................... 314
ASSIST AND SOS SYSTEM — IF EQUIPPED ................. 314
JACKING AND TIRE CHANGING .................................... 317
Preparations For Jacking.......................................... 317
Jack Location ............................................................ 318
Removal Of Jack And Tools...................................... 318
Removing The Spare Tire......................................... 319
Jacking Instructions.................................................. 321
To Stow The Flat Or Spare ....................................... 323
Reinstalling The Jack And Tools .............................. 324
JUMP STARTING ............................................................. 325
Preparations For Jump Start.................................... 325
Jump Starting Procedure.......................................... 325
REFUELING IN EMERGENCY........................................... 326
IF YOUR ENGINE OVERHEATS ....................................... 327
MANUAL PARK RELEASE ............................................... 328
FREEING A STUCK VEHICLE .......................................... 329
TOWING A DISABLED VEHICLE ..................................... 330
Two-Wheel Drive Models.......................................... 331
Four-Wheel Drive Models......................................... 331
Emergency Tow Hooks — If Equipped ..................... 332
ENHANCED ACCIDENT RESPONSE SYSTEM
(EARS) .............................................................................. 332
EVENT DATA RECORDER (EDR)..................................... 332
SERVICING AND MAINTENANCE
SCHEDULED SERVICING .................................................333
Maintenance Plan .....................................................334
ENGINE COMPARTMENT ................................................337
3.6L Engine With Stop/Start ...................................337
5.7L Engine Without Stop/Start...............................338
5.7L Engine With Stop/Start ....................................339
Checking Oil Level .....................................................340
Adding Washer Fluid ................................................340
Maintenance-Free Battery .......................................340
Pressure Washing .....................................................341
VEHICLE MAINTENANCE .................................................341
Engine Oil ..................................................................341
Engine Oil Filter ........................................................342
Engine Air Cleaner Filter ..........................................342
Air Conditioner Maintenance ...................................344
Accessory Drive Belt Inspection ...............................346
Body Lubrication .......................................................347
Windshield Wiper Blades .........................................347
Exhaust System ........................................................348
Cooling System .........................................................349
Brake System ...........................................................352
Automatic Transmission ..........................................353
Rear Axle And 4x4 Front Driving Axle
Fluid Level .................................................................353
Transfer Case ...........................................................354
Fuses..........................................................................354
Bulb Replacement ....................................................365
23_DT_OM_EN_USC_t.book Page 6

7
TIRES ................................................................................. 370
Tire Safety Information ............................................ 370
Tires — General Information .................................... 377
Tire Types................................................................... 380
Spare Tires — If Equipped ........................................ 381
Wheel And Wheel Trim Care .................................... 383
Snow Traction Devices ............................................ 384
Tire Rotation Recommendations ............................ 386
DEPARTMENT OF TRANSPORTATION UNIFORM
TIRE QUALITY GRADES .................................................. 386
Treadwear.................................................................. 386
Traction Grades.........................................................387
Temperature Grades................................................. 387
STORING THE VEHICLE ................................................... 387
BODYWORK ...................................................................... 388
Protection From Atmospheric Agents ..................... 388
Body And Underbody Maintenance ......................... 388
Preserving The Bodywork ......................................... 388
INTERIORS ....................................................................... 390
Seats And Fabric Parts ............................................. 390
Plastic And Coated Parts .......................................... 390
Leather Surfaces.......................................................391
Glass Surfaces ......................................................... 391
TECHNICAL SPECIFICATIONS
VEHICLE IDENTIFICATION NUMBER (VIN)..................... 392
BRAKE SYSTEM .............................................................. 392
WHEEL AND TIRE TORQUE SPECIFICATIONS ............. 392
Torque Specifications .............................................. 392
FUEL REQUIREMENTS .................................................... 393
3.6L Engine .............................................................. 393
5.7L Engine............................................................... 393
Reformulated Gasoline ........................................... 393
Materials Added To Fuel ......................................... 393
Gasoline/Oxygenate Blends ................................... 394
Do Not Use E-85 In Non-Flex Fuel Vehicles ............ 394
CNG And LP Fuel System Modifications.................. 394
Methylcyclopentadienyl Manganese
Tricarbonyl (MMT) In Gasoline................................. 394
Fuel System Cautions............................................... 394
FLUID CAPACITIES .......................................................... 395
ENGINE FLUIDS AND LUBRICANTS .............................. 396
CHASSIS FLUIDS AND LUBRICANTS ............................ 397
CUSTOMER ASSISTANCE
SUGGESTIONS FOR OBTAINING SERVICE FOR YOUR
VEHICLE ............................................................................398
Prepare For The Appointment ..................................398
Prepare A List ............................................................398
Be Reasonable With Requests.................................398
IF YOU NEED ASSISTANCE .............................................398
Roadside Assistance.................................................398
FCA US LLC Customer Center...................................399
FCA Canada Inc. Customer Center...........................399
Mexico........................................................................399
Puerto Rico And US Virgin Islands............................399
Customer Assistance For The Hearing Or
Speech Impaired (TDD/TTY).....................................400
Service Contract .......................................................400
WARRANTY INFORMATION.............................................400
MOPAR® PARTS ..............................................................400
REPORTING SAFETY DEFECTS ......................................401
In The 50 United States And Washington, D.C........401
In Canada...................................................................401
PUBLICATION ORDER FORMS .......................................401
CHANGE OF OWNERSHIP OR ADDRESS.......................402
GENERAL INFORMATION.................................................402
23_DT_OM_EN_USC_t.book Page 7

8
INTRODUCTION
Dear Customer,
Congratulations on the purchase of your new Ram vehicle. Be assured that it represents precision workmanship, distinctive styling, and high quality.
This is a specialized utility vehicle. It can go places and perform tasks that are not intended for conventional passenger vehicles. It handles and maneuvers differently from many
passenger vehicles both on-road and off-road, so take time to become familiar with your vehicle. If equipped, the two-wheel drive version of this vehicle was designed for on-road use
only. It is not intended for off-road driving or use in other severe conditions suited for a four-wheel drive vehicle. Before you start to drive this vehicle, read the Owner’s Manual. Be sure
you are familiar with all vehicle controls, particularly those used for braking, steering, transmission, and transfer case shifting. Learn how your vehicle handles on different road surfaces.
Your driving skills will improve with experience. When driving off-road, or working the vehicle, don’t overload the vehicle or expect the vehicle to overcome the natural laws of physics.
Always observe federal, state, provincial and local laws wherever you drive. As with other vehicles of this type, failure to operate this vehicle correctly may result in loss of control or a
collision Úpage 189.
This Owner's Manual has been prepared with the assistance of service and engineering specialists to acquaint you with the operation and maintenance of your vehicle. It is
supplemented by customer-oriented documents. Within this information, you will find a description of the services that FCA US LLC offers to its customers as well as the details of the
terms and conditions for maintaining its validity. Please take the time to read all of these publications carefully before driving your vehicle for the first time. Following the instructions,
recommendations, tips, and important warnings in this manual will help ensure safe and enjoyable operation of your vehicle.
This Owner's Manual describes all versions of this vehicle. Options and equipment dedicated to specific markets or versions are not expressly indicated in the text. Therefore, you should
only consider the information that is related to the trim level, engine, and version that you have purchased. Any content introduced throughout the Owner's Information, which may or
may not be applicable to your vehicle, will be identified with the wording “If Equipped”. All data contained in this publication are intended to help you use your vehicle in the best possible
way. FCA US LLC aims at a constant improvement of the vehicles produced. For this reason, it reserves the right to make changes to the model described for technical and/or commercial
reasons. For further information, contact an authorized dealer.
When it comes to service, remember that authorized dealers know your Ram vehicle best, have factory-trained technicians, genuine Mopar® parts, and care about your satisfaction.
23_DT_OM_EN_USC_t.book Page 8

9
SYMBOLS KEY
If you do not read the entire Owner’s Manual, you may miss important information.
Observe all Cautions and Warnings.
VAN CONVERSIONS/CAMPERS
The New Vehicle Limited Warranty does not apply to body modifications or special
equipment installed by van conversion/camper manufacturers/body builders.
US residents refer to the Warranty Information, Section 2.1.C. Canadian residents refer to
the “What Is Not Covered” section of the Warranty Information. Such equipment includes
video monitors, DVD/Blu-Ray™, heaters, stoves, refrigerators, etc. For warranty coverage
and service on these items, contact the applicable manufacturer.
CONSUMER INFORMATION — TRUCK-CAMPER LOADING
This information is provided in fulfillment of the requirement by the United States
Government, Department of Transportation, National Highway Traffic Safety
Administration, that “every manufacturer of trucks that are capable of accommodating
slide-in campers, manufactured on or after April 1, 1973 shall provide... at the time of
original purchase to the first person who purchases the truck”... information on Truck
Camper Loading.
A slide-in camper document is provided in your vehicle’s glove compartment that contains
your Vehicle Identification Number, truck model, cargo weight rating, and the forward/
rearward limit of a camper. To obtain additional dimensional and technical specifications
for your vehicle, please visit https://www.ramtrucks.com.
WARNING! These statements apply to operating procedures that
could result in a collision, bodily injury and/or death.
CAUTION! These statements apply to procedures that could result in
damage to your vehicle.
NOTE: A suggestion which will improve installation, operation,
and reliability. If not followed, may result in damage.
TIP: General ideas/solutions/suggestions on easier use of the
product or functionality.
PAGE REFERENCE ARROW
Follow this reference for additional information on a
particular feature.
FOOTNOTE
Supplementary and relevant information pertaining to
the topic.
1
23_DT_OM_EN_USC_t.book Page 9

10
Figure 1 illustrates the dimensions describing the forward and rearward limits of the zone in which the Center of Gravity (CG) of a slide-in camper must be located, to provide satisfactory
vehicle handling and to prevent overload of the front and rear axles.
Figure 2 illustrates a proper match between truck and camper.
NOTE:
The camper Center of Gravity falls within the specified zone.
A — Forward Limit of Camper CG
B — Rearward Limit of Camper CG
23_DT_OM_EN_USC_t.book Page 10

11
When the truck is used to carry a slide-in camper, the total cargo load of the truck consists
of the manufacturer’s camper weight figure, the weight of installed additional camper
equipment not included in the manufacturer’s camper weight figure, the weight of camper
cargo, and the weight of passengers in the camper. The total cargo load should not exceed
the truck’s cargo weight rating and the camper’s CG should fall within the truck’s
recommended CG zone when installed.
Secure loose items to prevent weight shifts that could affect the balance of your vehicle.
When the truck camper is loaded, drive to a scale and weigh the front and rear wheels
separately, to determine axle loads. Individual axle loads should not exceed either of the
Gross Axle Weight Ratings (GAWR). The total of the axle loads should not exceed the Gross
Vehicle Weight Rating (GVWR). If weight ratings are exceeded, move or remove items to
get the total weight below the ratings.
NOTE:
These ratings are also provided on the Vehicle Certification Label located on the driver’s
side B-pillar. See Úpage 172 for more information.
For any additional instructions, please contact your conversion/camper manufacturer or
an authorized dealer.
VEHICLE MODIFICATIONS/ALTERATIONS
SYMBOL GLOSSARY
Some car components have colored labels with symbols indicating precautions to be
observed when using this component. It is important to follow all warnings when operating
your vehicle. See below for the definition of each symbol Úpage 107.
NOTE:
Warning and Indicator lights are different based upon equipment options and current
vehicle status. Some telltales are optional and may not appear.
WARNING!
Any modifications or alterations to this vehicle could seriously affect its roadworthiness
and safety and may lead to a collision resulting in serious injury or death.
Red Warning Lights
Air Bag Warning Light
Úpage 108
Battery Charge Warning Light
Úpage 108
Brake Warning Light
Úpage 108
Door Open Warning Light
Úpage 108
Electronic Throttle Control (ETC) Warning Light
Úpage 109
Electric Power Steering (EPS) Fault Warning Light
Úpage 109
Engine Coolant Temperature Warning Light
Úpage 109
1
23_DT_OM_EN_USC_t.book Page 11

12
Hood Open Warning Light
Úpage 109
Oil Pressure Warning Light
Úpage 109
Oil Temperature Warning Light
Úpage 110
Seat Belt Reminder Warning Light
Úpage 110
Tailgate Open Warning Light
Úpage 110
Trailer Brake Disconnected Warning Light
Úpage 110
Transmission Temperature Warning Light
Úpage 110
Vehicle Security Warning Light
Úpage 110
Red Warning Lights Yellow Warning Lights
Adaptive Cruise Control (ACC) Fault Warning Light
Úpage 110
Air Suspension Fault Warning Light
Úpage 110
Anti-Lock Brake System (ABS) Warning Light
Úpage 110
Cruise Control Fault Warning Light
Úpage 112
Electric Park Brake Warning Light
Úpage 111
Electronic Stability Control (ESC) Active Warning Light
Úpage 111
Electronic Stability Control (ESC) OFF Warning Light
Úpage 111
Engine Check/Malfunction Indicator Warning Light (MIL)
Úpage 111
23_DT_OM_EN_USC_t.book Page 12

13
Low Washer Fluid Warning Light
Úpage 111
Low Fuel Warning Light
Úpage 111
Rear Axle Locker Fault Warning Light
Úpage 112
Service Forward Collision Warning (FCW) Light
Úpage 112
Service Stop/Start System Warning Light
Úpage 112
Service 4WD Warning Light
Úpage 112
Service LaneSense Warning Light
Úpage 111
Tire Pressure Monitoring System (TPMS) Warning Light
Úpage 112
Yellow Warning Lights Yellow Indicator Lights
Air Suspension Payload Protection Indicator Light
Úpage 113
Air Suspension Off-Road 1 Indicator Light
Úpage 113
Air Suspension Off-Road 2 Indicator Light
Úpage 113
Air Suspension Normal Height Indicator Light
Úpage 113
Air Suspension Aerodynamic Height Indicator Light
Úpage 113
Air Suspension Ride Height Raising Indicator Light
Úpage 113
Air Suspension Ride Height Lowering Indicator Light
Úpage 113
Cargo Light Active Indicator Light
Úpage 113
1
23_DT_OM_EN_USC_t.book Page 13

14
Entry/Exit Indicator Light
Úpage 114
Forward Collision Warning (FCW) Off Indicator Light
Úpage 114
NEUTRAL Indicator Light
Úpage 114
Trailer Merge Assist Indicator Light
Úpage 114
TOW/HAUL Indicator Light
Úpage 114
Rear Axle Lock Indicator Light
Úpage 114
4WD Indicator Light
Úpage 114
Yellow Indicator Lights
4WD Low Indicator Light
Úpage 114
4WD High Indicator Light
Úpage 114
Green Indicator Lights
Adaptive Cruise Control (ACC) Set With Target Indicator Light
Úpage 114
Adaptive Cruise Control (ACC) Set With No Target Detected Indicator Light
Úpage 114
Cruise Control SET Indicator Light
Úpage 115
ECO Mode Indicator Light
Úpage 114
Yellow Indicator Lights
23_DT_OM_EN_USC_t.book Page 14

15
Front Fog Indicator Light
Úpage 114
LaneSense Indicator Light
Úpage 115
Parking/Headlights On Indicator Light
Úpage 115
Stop/Start Active Indicator Light
Úpage 115
Turn Signal Indicator Lights
Úpage 115
4WD AUTO Indicator Light
Úpage 115
Green Indicator Lights White Indicator Lights
Adaptive Cruise Control (ACC) Ready Indicator Light
Úpage 115
Cruise Control Ready Indicator Light
Úpage 115
Cruise Control SET Indicator Light
Úpage 116
Selec-Speed Control (SSC) Indicator Light
Úpage 115
LaneSense Indicator Light
Úpage 116
Blue Indicator Lights
High Beam Indicator Light
Úpage 116
1
23_DT_OM_EN_USC_t.book Page 15

16
GETTING TO KNOW YOUR VEHICLE
KEYS
KEY FOB
Your vehicle is equipped with a key fob which supports
Passive Entry, Remote Keyless Entry (RKE), Keyless
Enter ‘n Go™ (if equipped), remote air suspension
lowering (if equipped), and Remote Start (if equipped).
The key fob allows you to lock or unlock all doors, tailgate,
and the RamBox (if equipped) as well as activate the Panic
Alarm from distances up to approximately 66 ft (20 m).
The key fob does not need to be pointed at the vehicle to
activate the system. The key fob also contains an
emergency key, which is stored in the rear of the key fob.
NOTE:
The key fob’s wireless signal may be blocked if the key
fob is located next to a mobile phone, laptop, or other
electronic device. This may result in poor performance.
If your vehicle is equipped with a Wireless Charging
Pad, the key fob may not be detected if it is placed
within 6 inches (15 cm) of the pad Úpage 68.
With the ignition in the ON position and the vehicle
moving at 2 mph (4 km/h), all RKE commands are
disabled.
Key Fob
In case the ignition switch does not change with the push
of a button, the key fob may have a low or fully depleted
battery. A low key fob battery can be verified by referring to
the instrument cluster display, which will display a
procedure to follow.
NOTE:
A low key fob battery condition may be indicated by a
message in the instrument cluster display, or by the LED
light on the key fob. If the LED key fob light no longer
illuminates from key fob button pushes, then the key fob
battery requires replacement Úpage 402.
To Lock/Unlock The Doors And Tailgate
All doors, liftgate, and RamBox (if equipped) can be
programmed to either unlock on the first push of the
unlock button, or for the first push to unlock only the
driver’s door, then twice within five seconds to unlock all
doors, liftgate, and RamBox (if equipped). To lock all the
doors, liftgate, and RamBox (if equipped), push the lock
button once.
When the doors are unlocked, the turn signals will flash
and the illuminated entry system will be activated. When
the doors are locked, the turn signals will flash and the
horn will chirp.
The horn chirp when the lock button is pushed can be
programmed on/off within Uconnect Settings
Úpage 191.
1 — LED Indicator Light
2 — Unlock
3 — Tailgate Lowering (If Equipped)
4 — Air Suspension Remote Lowering (If Equipped)
5 — Lock
6 — Remote Start (If Equipped)
7 — Panic
8 — Emergency Key
23_DT_OM_EN_USC_t.book Page 16

GETTING TO KNOW YOUR VEHICLE 17
Using The Panic Feature
To turn the Panic feature on or off, push the Panic button
on the key fob. When the Panic feature is activated, the
turn signals will flash, the horn may pulse on and off
(if equipped with horn alarm), and the interior lights will
turn on.
The Panic feature will stay on for three minutes unless you
turn it off by either pushing the Panic button a second time
or driving the vehicle at a speed of 15 mph (24 km/h) or
greater.
NOTE:
The interior lights will turn off if you place the ignition in
the ON/RUN position while the Panic feature is
activated. However, the exterior lights and horn
(if equipped with horn alarm) will remain on.
You may need to be less than 35 ft (11 m) from the
vehicle when using the key fob to turn off the Panic
feature due to the radio frequency noises emitted by
the system.
Key Left Vehicle Feature
If a valid key fob is no longer detected inside the vehicle
while the vehicle’s ignition system is in the ON/RUN or
START position, the message “Key Fob Has Left The
Vehicle” will be shown in the instrument cluster display
along with an interior chime. An exterior audible and visual
alert will also be activated to warn the driver.
The vehicle’s horn will rapidly chirp three times along with
a single flash of the vehicle’s exterior lights.
NOTE:
The doors have to be open and then closed in order for
the vehicle to detect a key fob; the Key Left Vehicle
feature will not activate until all of the doors are closed.
These alerts will not be activated in situations where
the vehicle’s engine is left running with the key fob
inside.
Air Suspension (Remote Lowering Of The
Vehicle) — If Equipped
For easy entry and loading, your vehicle can be
lowered by pushing the key fob air suspension
lowering button two times. When air
suspension lowering is requested using the key
fob, the vehicle will send a series of chirps and flashes to
alert the customer that the operation has begun and will
continue these alerts until it successfully lowers.
The following conditions must be met for the vehicle to
lower remotely:
The vehicle must not already be in Entry/Exit ride
height.
The vehicle battery must be fully charged.
All doors must be closed.
The key fob must be out of the vehicle.
Gear selector must be in PARK.
NOTE:
Ensure the vehicle is clear of all objects, pets, and people
prior to remote lowering.
Canceling Remote Lowering
Vehicle lowering can be canceled at anytime. When
vehicle lowering is canceled, the vehicle will raise to the
next defined level and lock out the remote lowering
feature for five seconds until a new request is made.
To cancel vehicle lowering, push the key fob air
suspension lowering button one time during the lowering
process. When vehicle lowering is canceled, the horn will
chirp two times and the turn signal lamps will flash four
times. Once raising is completed, the horn will chirp
one time.
NOTE:
More information on air suspension is provided later in
this manual, see Úpage 134.
Replacing The Battery In The Key Fob
The replacement battery model is one CR2450 battery.
NOTE:
Customers are recommended to use a battery
obtained from Mopar®. Aftermarket coin battery
dimensions may not meet the original OEM coin battery
dimensions.
Perchlorate Material — special handling may apply. See
www.dtsc.ca.gov/hazardouswaste/perchlorate for
further information.
2
23_DT_OM_EN_USC_t.book Page 17

18 GETTING TO KNOW YOUR VEHICLE
Do not touch the battery terminals that are on the back
housing or the printed circuit board.
Do not replace the coin battery if the LED on the key fob
above the top row buttons blinks when a button is
pressed. The coin battery should last a minimum of
three years with normal vehicle usage.
1. Remove the emergency key (1) by pushing the
emergency key release button (2) on the side of the
key fob, and pulling the emergency key out with your
other hand.
Emergency Key Removal
2. Hold the key fob with the button side facing down,
and locate the small rectangular gap on the left side
between the housing and the back cover of the key
fob. Use a small screwdriver (or similar tool) to pry
open the left side of the fob cover while applying
pressure until the cover snaps open.
3. Next, locate the gap on the right side of the key fob,
which is positioned farther to the edge than the left
side gap. Pry open the right side, and remove the
back cover.
4. Remove the battery by using your thumb to slide the
battery downward and back toward the key ring.
Key Fob Battery Location
NOTE:
When replacing the battery, ensure the (+) sign on the
battery is facing upward. Avoid touching the new battery
with your fingers. Skin oils may cause battery deterio-
ration. If you touch a battery, clean it with rubbing alcohol.
5. Replace the battery by using your thumb to push
down and slide the battery under the small lip on the
top edge of the opening.
Key Fob Battery Replacement
6. To assemble the key fob case, line up the top edge of
the back cover with the top of the fob, and press the
edges into the interlocking hinges until all edges snap
together with no large visual gaps.
7. Reinsert the emergency key until it locks into place.
NOTE:
The key fob battery should only be replaced by qualified
technicians. If the battery requires replacement, see an
authorized dealer.
1 — Emergency Key
2 — Emergency Key Release Button
23_DT_OM_EN_USC_t.book Page 18
