Portable USA BT-APLUS User manual

Aplus BT Head Set
Operation Manual

1
Congratulations on your purchasing BT-APLUS, a bluetooth headset
with the following features：
-Wireless connection to cell phone with BlueTooth™ 1.2
technology
-Supports handsfree and headset profile
-Full duplex
-Easy operation with one button：On/Off, pairing,
pick-up/hang-up
-Two color LED status indicator
-Volume control
Specification:
Standard Bluetooth 1.2 specification
Range (free space) 10 meters
Frequency Band 2.45 GHz
Dimension 46x28x12mm
Weight 12 grs
Speaker 120 ± 3 dB
Talk time Up to 4 hr
Standby time Up to 120 hr
Output Power 0 dBm (class II)
Power Consumption 30mA(working); <1mA
(standby)
Battery Rechargeable Li-ion polymer
Battery Capacity 120mAh
Charger 5V DC, 100~240VAC adaptor
Charging time 2 hr ~ 3 hr
Operating Temperature -10°C~55°C
Storage Temperature -20°C~60°C
Humidity 10%~90%

2
Control Button
Volume
Up
Volume
Down
Microphone
USB Charge Jack
Blue LED
Configuration

3
Adjust
1. Adjust the ear hook left or right.
2. Adjust the angle of the ear hook.
3. Slide the hanger slowly on the ear.
4. Adjust the headset to 30~45 degree to get better microphone receiving.
Adjust Hook Angle

4
1. Power On:
Button LED/Tone/Mode
zPress the Control Button
for 3Seconds from power
off.
zBlue Indicators flick.
Mode: standby

5
2. Power Off:
Button LED/Tone/Mode
zPress the Control Button for
3Seconds from power on.
zThe Blue Indicators
flick 3 times then goes
off.
Mode: Off

6
3. Pairing:
Phones LED/Tone/Mode
Follow the
operation manual
of your mobile
phones.
zThe “BT-APLUS” will be
shown on the mobile phone.
Select “Yes” or “Enter”
zPasskey or Pin , enter
“0000”.
zPress the control button
for 3 seconds.
zBlue LED Indicators
flash.
zPairing successful, The
Blue indicator flash
every 3 seconds.

7
4. Answer/End a Call:
Answer a Incoming call End a call
zPress the Control Button
once to Answer a call.
zPress the Control Button
once to End a call.

8
5. Voice Dialing:
Phone Voice Tag Voice Dialing
zFollow the operation
manual of your mobile
phones to enable the voice
dialing.
zRecord the voice tags
zPress the Control Button
once.
zSay the name of the
person you want to
call.

9
6. Re-Connecting:
Re-connecting
zPress the Control Button
once to enter the standby
mode

10
7. Battery Low/Charging
Battery Low Charging
zBlue indicator flashes.
zCharging the battery
immediately.
1. Plug the charge adaptor into the
charge jack.
2.
Blue Indicator steady On
3. Charging time : 3 hours
4. Full Charge: Blue indicator off

11
STATUS Indication
Status BLUE / RED Indicators
Off mode Indicator is off
Turn On BLUE indicator flicks 3 times then
flashes once every 3s
Turn Off BLUE indicator flicks 3 times and
then off
Standby mode BLUE indicator flashes once every
3s
Pairing mode BLUE indicator flashes
Connecting mode BLUE indicator flashes twice per
second
Talking mode BLUE indicator flashes once per
second
Battery runs low BLUE indicator flashes
Charging mode BLUE indicator steadily on
Fully charge BLUE indicator is off

12
PAIRING PROCEDURES：
The first time you use BT-APLUS, you will need to pair BT-APLUS to your
phone.
●NOKIA 6310 & 8910
A. Press the control button for 3 seconds, Blue LED Indicators
flash, and a pairing tone will be heard.
B. Carry out the following sequence on your phone.
1. Access to the Menu and scroll to “Bluetooth”, enter ‘Select’.
2. Find “On” to activate Bluetooth.
3. Scroll to “Search for audio accessories”, enter ‘Select’.
4. Display reads “Searching for devices”. Please wait until the
display reads “BT-APLUS”, enter ‘Select’ to make the

13
connection.
5. Display reads “Connecting” then “Enter passcode”, type
‘0000’ then ‘OK’.
6. Display reads “Connecting” then “Connected to BT-APLUS”.
The pairing procedure is completed. The BLUE indicator
will flash every 3s interval. Now, you can press CONTROL
button to answer/end a call or make a voice dialing.
C. Settings
1. Automatically Answer On
1.1. Access to the Menu and scroll to “Settings”, enter
‘Select’.
1.2. Scroll to “Accessory settings”, enter ‘Select’.
1.3. Scroll to “Headset”, enter ‘Select’.
1.4. Scroll to “Automatic answer”, enter ‘On’.
1.5. The BT-APLUS will answer the incoming calls
automatically after 2 rings.

14
2. Re-connecting Authorization
2.1. Access to the Menu and scroll to “Bluetooth”, enter
‘Select’.
2.2. Scroll to “View paired devices”, enter ‘Select’.
2.3. Display reads “BT-APLUS” then click ‘Options’.
2.4. Scroll to “Request conn. Authorisation”, enter ‘Select’
then click “No”.
C. Adjusting the volume：During a call, press the VOLUME
UP or VOLUME DOWN or the volume keys of your phone.
D. Re-connecting.
The next time, re-connecting BT-APLUS to your phone, just press
CONTROL button in standby mode.

15
●NOKIA 3650
APress the control button for 3 seconds, Blue LED Indicators
flash, and a pairing tone will be heard.
B. Carry out the following sequence on your 3650.
1. Access to the Menu and scroll to “Connectivity”, then the
“Bluetooth” for Nokia 3650.
2. Find “On” to activate Bluetooth.
3. Select the “Paired Devices” by pressing the right arrow, press
‘Options’.
4. Select “New Paired Device” (searching). Please wait until the
display reads “BT-APLUS”, enter ‘Select’ to make the
connection.
5. Display reads “Enter passcode”, enter ‘0000’ then ‘OK’.
6. Select ‘Options’, then “Connecting”, enter ‘Select’, then
“Connected to BT-APLUS”.

16
The pairing procedures are completed. The BLUE indicator
will flash every 3s interval. Now, you can press CONTROL
button to answer/end a call or make a voice dialing.
zSettings
1. Automatically Answer On
1.1. Access to the Menu and scroll to “Tools”, enter ‘Select’.
1.1. Scroll to “Settings”, enter ‘Select’.
1.2. Scroll to “Accessories”, enter ‘Select’.
1.3. Scroll to “Handsfree”, enter ‘Select’.
1.4. Scroll to “Automatic answer”, enter ‘On’.
1.5. The BT-APLUS will answer the incoming calls
automatically after 2 rings.
2. Re-connecting Authorization
2.1. Access to the Menu and scroll to “Connectivity”, then
the “Bluetooth”, enter ‘Options’.
2.2. Find “On”, pressing the right arrow,

17
2.3. Display reads “BT-APLUS” then click ‘Options’.
2.4. Scroll to “No request conn. Authorisation”, enter ‘select’
then click “Yes”.
3. Adjusting the volume：During a call, press the VOLUME UP or
VOLUME DOWN or the right/left arrow keys of your 3650.
zRe-connecting.
The next time, re-connecting BT-APLUS to your phone, just press
CONTROL button in standby mode.

18
●Ericsson T68/T39
A. Press the control button for 3 seconds, Blue LED Indicators
flash, and a pairing tone will be heard.
B. Carry out the following sequence on your T68.
1. Enter Menu and scroll to “Connect”, enter ‘Yes’.
2. Scroll until “Bluetooth”, enter ‘Yes’.
3. Scroll to “Operation mode”, enter ‘Yes’.
4. Scroll to “On”, enter ‘Yes’.
5. Scroll to “Discover”, enter ‘Yes’.
6. Display reads “Searching…” then “BT-APLUS”, enter
‘Yes’.
7. “Add to paired” is displayed, enter ‘Yes’.
8. “Passkey” is displayed, enter ‘0000’, then ‘Yes’.
9. “Pairing succeeded” is displayed.
The pairing procedures are completed. The BLUE indicator
will flash every 3s interval. Now, you can press CONTROL

19
button to answer/end a call or make a voice dialing.
C. Carry out the following sequence on your T39.
1. Enter Menu and scroll to “Extras”, enter ‘Yes’.
2. Scroll until “Bluetooth”, enter ‘Yes’.
3. Scroll to “Operation mode”, enter ‘Yes’.
4. Scroll to “On”, enter ‘Yes’.
5. Scroll to “Discover”, enter ‘Yes’.
6. Reads “Searching…” then “BT-APLUS”, enter ‘Yes’.
7. “Add to paired” displayed, enter ‘Yes’.
8. “Passkey” displayed, enter ‘0000’, then ‘Yes’.
9. “Pairing succeeded” is displayed.
The pairing procedure is completed. The BLUE indicator
will flash every 3s interval. Now, you can press CONTROL
button to answer/end a call or make a voice dialing.
D. Settings
Adjusting the volume：During a call, press the VOLUME UP or
