Portwell PEB-2773VG2ATM User manual

PEB-2773VG2ATM
Copyright © Portwell 2017 PEB-2773VG2ATM User's Guide
1
3.5" Embedded Motherboard Board
Version 1.0
PEB-2773VG2ATM

PEB-2773VG2ATM
Copyright © Portwell 2017 PEB-2773VG2ATM User's Guide
2
Revision History
R1.0
Preliminary

PEB-2773VG2ATM
Copyright © Portwell 2017 PEB-2773VG2ATM User's Guide
3
Contents
1 Introduction .............................................................................................................................................................................................................................. 7
2 Specifications........................................................................................................................................................................................................................... 8
2.1 Supported Operating Systems ............................................................................................................................................................................9
2.2 Mechanical Dimensions ...................................................................................................................................................................................11
2.3 Power Consumption.........................................................................................................................................................................................12
2.4 Environmental Specifications............................................................................................................................................................................13
3 Block Diagram........................................................................................................................................................................................................................ 14
4 Hardware Configuration ......................................................................................................................................................................................................... 15
4.1 Jumpers and Connectors .................................................................................................................................................................................15
4.2 Jumper Settings ..............................................................................................................................................................................................16
5 Signal Descriptions ................................................................................................................................................................................................................ 30
5.1 Watch Dog Signal............................................................................................................................................................................................30
5.2 Signal GPIO Signal..........................................................................................................................................................................................31
6 System Resources................................................................................................................................................................................................................. 33
6.1 Intel® Apollo Lake-S PCH ................................................................................................................................................................................33
6.2 Main Memory ..................................................................................................................................................................................................33
6.3 Installing the Single Board Computer.................................................................................................................................................................33
6.3.1 Chipset Component Driver ................................................................................................................................................................................... 34
6.3.2 Intel® HD Graphics 50X ....................................................................................................................................................................................... 34
6.3.3 Intel LAN I210IT/I219LM Gigabit Ethernet Controller ........................................................................................................................................... 35
7 BIOS Setup Items .................................................................................................................................................................................................................. 36

PEB-2773VG2ATM
Copyright © Portwell 2017 PEB-2773VG2ATM User's Guide
4
7.1 Introduction.....................................................................................................................................................................................................36
7.2 BIOS Setup.....................................................................................................................................................................................................36
7.2.1 Main ..................................................................................................................................................................................................................... 38
7.2.2 Configuration........................................................................................................................................................................................................ 40
7.2.3 Security ................................................................................................................................................................................................................ 88
7.2.4 Boot...................................................................................................................................................................................................................... 90
7.2.5 Save & Exit........................................................................................................................................................................................................... 93
8 Troubleshooting ..................................................................................................................................................................................................................... 95
8.1 Hardware Quick Installation..............................................................................................................................................................................95
8.2 BIOS Setting............................................................................................................................................................................................................................. 98
8.3 FAQ…….........................................................................................................................................................................................................99
9 Portwell Software Service .................................................................................................................................................................................................... 101
10 Industry Specifications ......................................................................................................................................................................................................... 102

PEB-2773VG2ATM
Copyright © Portwell 2017 PEB-2773VG2ATM User's Guide
5
Preface
This user’s guide provides information about the components, features, connectors and BIOS Setup menus available on the PEB-2773VG2ATM. This document
should be referred to when designing 3.5" Embedded board application. The other reference documents that should be used include the following:
Intel Apollo Lake Design Guide
Intel Apollo Lake l Specification
Please contact Portwell Sales Representative for above documents.
Disclaimer
The information contained within this user’s guide, including but not limited to any product specification, is subject to change without notice.
Portwell provides no warranty with regard to this user’s guide or any other information contained herein and hereby expressly disclaims any implied warranties
of merchantability or fitness for any particular purpose with regard to any of the foregoing. Portwell assumes no liability for any damages incurred directly or
indirectly from any technical or typographical errors or omissions contained herein or for discrepancies between the product and the user’s guide. In no event
shall Portwell be liable for any incidental, consequential, special, or exemplary damages, whether based on tort, contract or otherwise, arising out of or in
connection with this user’s guide or any other information contained herein or the use thereof.
Trademarks
Product names, logos, brands, and other trademarks featured or referred to within this User’s guide or the Portwell website, are the property of their respective
trademark holders. These trademark holders are not affiliated with Portwell, our products, or our website.

PEB-2773VG2ATM
Copyright © Portwell 2017 PEB-2773VG2ATM User's Guide
6
Warranty
Portwell makes no representation, warranty or guaranty, express or implied regarding the products except its standard form of limited warranty (“Limited
Warranty”). Portwell may in its sole discretion modify its Limited Warranty at any time and from time to time.
Beginning on the date of shipment to its direct customer and continuing for the published warranty period, Portwell represents that the products are new and
warrants that each product failing to function properly under normal use, due to a defect in materials or workmanship or due to non conformance to the agreed
upon specifications, will be repaired or exchanged, at Portwell’s option and expense.
Certification
Portwell is certified to DIN EN ISO 9001:2000 standard.
Technical Support
Portwell technicians and engineers are committed to providing the best possible technical support for our customers so that our products can be easily used and
implemented.
We request that you first visit our website at http://www.portwell.com.tw/support/ for the latest documentation, utilities and drivers, which have been made
available to assist you. If you still require assistance after visiting our website then contact our technical support department by email at
[email protected]for further assistance. Thank you!

PEB-2773VG2ATM
Copyright © Portwell 2017 PEB-2773VG2ATM User's Guide
7
1Introduction
Portwell Inc., a world-leading innovator in the Industrial PC (IPC) market and a member of the Intel®Embedded and Communications Alliance (Intel ECA),
announced today the Portwell PEB-2773VG2ATM utilizing the Intel®ECX form factor based on the Intel®Atom™ processor E3900 series and N4200 / N3350
sku, includes integrated, enhanced graphics and memory controllers on 14nm process technology, delivering significant power reduction, performance
improvements and smaller platform footprint over the previous Intel®Atom™ processor E3900 series and N4200 / N3350 sku. The PEB-2773VG2ATM can
provide the low power consumption for low profile fanless applications such as POS, Print Imaging, ATM, Kiosk, Medical, Panel PC, Digital Security and Digital
Signage.

PEB-2773VG2ATM
Copyright © Portwell 2017 PEB-2773VG2ATM User's Guide
8
2Specifications
Main Processor
◆Intel®Atom™ Dual/Quad Core E3900 series, Pentium N4200 , Celeron N3350 Processor
System BIOS
◆AMI UEFI BIOS
Main Memory
◆Up to 8 GB in 1 slots DDR3L SO-DIMM sockets.
Graphics
◆Controller: Intel®HD Graphics 505
◆LVDS: Supports Dual Channel 24bit up to resolution 1920 x 1200
◆DP: Supports DP up to resolution 4096 x 2304
◆HDMI: Supports HDMI up to resolution 3840 x 2160
Expansion Interface
◆Two mini-PCIe socket (Full size support mSATA / Half size support WiFi/BT)
SATA Interface
◆One SATA ports(SATA 6Gb/s)
Input/Output
◆Serial Ports: 5x RS-232 & 1x RS-232/422/485
◆USB Port: 2x USB 3.0 on REAR I/O, 4x USB 3.0 on board header
◆Audio Interface: Audio jack on rear I/O with Line-out ,Line-in, Line-out, and Mic-in on board pin header
Ethernet
◆Supports one 10/100/1000 Mbps Ethernet port (s) via PCI Express x1 bus which provides 500 MB/s
data transmission rate
High Drive GPIO
◆One pin-header for GPIO(8bit in / out)

PEB-2773VG2ATM
Copyright © Portwell 2017 PEB-2773VG2ATM User's Guide
9
Mechanical
and
environmental specifications
◆Operating temperature: -40 ~ 85° C
◆Storage temperature:-20 ~ 80° C
◆Humidity: 5 ~ 90% non-condensing
◆Power supply voltage: 12~24V DC in
◆Board size: 146(L) x 102(W) mm; 5.74"(L) x 4.02"(W)
2.1 Supported Operating Systems
The PEB-2773VG2ATM supports the following operating systems.
Windows 10* (64 bit), IoT Core(32/64bit)
Wind River* 8.0 Linux Distribution(64 bit)
Yocto* Tool-based Embedded Linux Distribution (64 bit)
Android* 6.0(64bit)
VxWorks*7.0 (RTOS) (64 bit)

PEB-2773VG2ATM
Copyright © Portwell 2017 PEB-2773VG2ATM User's Guide
10

PEB-2773VG2ATM
Copyright © Portwell 2017 PEB-2773VG2ATM User's Guide
11
2.2 Mechanical Dimensions

PEB-2773VG2ATM
Copyright © Portwell 2017 PEB-2773VG2ATM User's Guide
12
2.3 Power Consumption
Test Configuration
CPU Type
Intel®Atom™Processor E3940 @ 1.6GHz
SBC BIOS
Portwell,Inc. PEBE-2773 TEST BIOS (61111T00)
Memory
Transcend DDR3L SO-DIMM 1866/4GB (wide temperature)
VGA Card
Onboard Intel®HD Graphics
VGA Driver
Intel®HD Graphics ,Version:21.20.16.4526
LAN Card
Onboard Intel®I210 Gigabit Network Connector
LAN Driver
Intel®I210 Gigabit Network Connector ,Version:12.15.184.0
LAN Card
Onboard Intel®I210 Gigabit Network Connector #2
LAN Driver
Intel®I210 Gigabit Network Connector #2 ,Version:12.15.184.0
Audio Card
Onboard Realtek High Definition Audio
Audio Driver
Realtek High Definition Audio ,Version:6.0.1.7541
Chip Driver
Intel®Chipset Device software ,Version:10.1.1
USB3.0 Driver
Intel®USB3.0 eXtensible Host Controller –1.0(Microsoft), Ver:10.0.10586.0
EC Version
61107T01(11/07/2016)
Power Supply
FSP GROUP INC. FSP120-AHAN1
Power Supply
GADIWA-B9120(005)
Power consumption(24V)

PEB-2773VG2ATM
Copyright © Portwell 2017 PEB-2773VG2ATM User's Guide
13
ATX:
Item
Power ON
Full Loading 10Min
Full Loading 30Min
CPU +24V
1.5 A
0.8 A
0.8 A
Device+12V
1.5 A
0.1 A
0.1 A
Device +5V
0.3 A
0.4 A
0.4 A
CPU+ Device +24V+12V
3.1 A
1.0 A
1.0 A
USB3.0 Loading Test
4.93V/ 990 mA
2.4 Environmental Specifications
Storage Temperature : -40~85°C
Operation Temperature : 0~60°C
Storage Humidity : 5~90%
Operation Humidity: 10~90%

PEB-2773VG2ATM
Copyright © Portwell 2017 PEB-2773VG2ATM User's Guide
14
3 Block Diagram

PEB-2773VG2ATM
Copyright © Portwell 2017 PEB-2773VG2ATM User's Guide
15
4 Hardware Configuration
4.1 Jumpers and Connectors

PEB-2773VG2ATM
Copyright © Portwell 2017 PEB-2773VG2ATM User's Guide
16
This chapter indicates jumpers, headers, and connector’s locations. Users may find useful information related to hardware settings in this chapter.
4.2 Jumper Settings
For users to customize PEB-2773VGATM’s features. In the following sections, Short means covering a jumper cap over jumper pins; Open or N/C (Not
Connected) means removing a jumper cap from jumper pins. Users can refer to Figure 1 for the Jumper allocations.
Jumper Table
The jumper settings are schematically depicted in this manual as follows:
Jumper Function List:
Jumper
Function
Remark
J1
SMBus
J2
Backlight Connector
J3
SATA GEN3 Connector
J4
LVDS Connector
J5
Front Panel Pin HDR
5x2 pin header
J6
80 Port Connector
10x2 connector
J7
SATA Power Connector
J8/J12
External USB3 Connector

PEB-2773VG2ATM
Copyright © Portwell 2017 PEB-2773VG2ATM User's Guide
17
J9
DDR3L SO-DIMM Socket
J10
miniPCIE/USB(half size)
J11
mSATA/miniPCIE(full size)
J13
Battery Socket
J14
GPIO Pin HDR
2x5 pin header
J15
External Audio (Mic + Line_in + Line_out )Pin
HDR
4x2 pin header
J16/J17/18/20/21
RS232 Pin HDR
J19
ATX 4 Pin Connector
+12V Input
J22
HDMI Connector
J23
DP Connector
J24
USB3.0 Connector
J25/J26
RJ45 Connector
J27
Audio Jack
J28
DC Jack
+12~24V Input
J29
RS232/422/485 D-SUB Connector

PEB-2773VG2ATM
Copyright © Portwell 2017 PEB-2773VG2ATM User's Guide
18
Jumper
Function
Remark
JP1
BKLTCTRL Signal Level Selection
3x2 pin header
JP2
mSATA/miniPCIE Selection
1x2 pin header
JP3
BACKLIGHT Enable Voltage Level Selection
3x2 pin header
JP4
BKLTCTRL Signal Source Selection
1x3 pin header
JP5
BKLTCTRL Level Signal Selection
1x3 pin header
JP6
Power On Mode Selection
1x3 pin header
JP7
GPIO Voltage Output Level Selection
1x3 pin header
JP8
CMOS Clear
1x3 pin header
JP10
COM3 RI Voltage Output Level Selection
3x2 pin header
JP11
COM4 RI Voltage Output Level Selection
3x2 pin header
JP12
COM1 RI Voltage Output Level Selection
3x2 pin header
JP13
COM2 RI Voltage Output Level Selection
3x2 pin header

PEB-2773VG2ATM
Copyright © Portwell 2017 PEB-2773VG2ATM User's Guide
19
JP1 : BKL PANEL Voltage Selection
JP2 : mSATA/miniPCIE Selection
JP3 : BACKLIGHT Enable Voltage Level Selection
PIN No.
Signal Description
1-3 Short
VCC3 ★
3-5 Short
VCC5
3-4 Short
+12V
PIN No.
Signal Description
vacancy
mSATA
1-2 Short
miniPCIE ★
PIN No.
Signal Description
1-3, 2-4
5V, Active High ★
1-3, 4-6
12V, Active High
3-5,2-4
5V, Active Low
3-5,4-6
12V, Active Low

PEB-2773VG2ATM
Copyright © Portwell 2017 PEB-2773VG2ATM User's Guide
20
JP4：BKLTCTRL Signal Source Selection
JP5：BKLTCTRL Level Signal Selection
JP6: Power On Mode Selection
PIN No.
Signal Description
1-2 Short
EC
2-3 Short
SOC ★
PIN No.
Signal Description
1-2 Short
+3.3V ★
2-3 Short
+5V
PIN No.
Signal Description
1-2 Short
AT ★
2-3 Short
ATX
