Portwell WADE-8213-Q670E User manual

WADE-8213-Q670E

Copyright © Portwell 2022 WADE-8213-Q670E User's Guide 1
Industrial mini-ITX Board
Version 1.0
WADE-8213-Q670E

WADE-8213-Q670E

Copyright © Portwell 2022 WADE-8213-Q670E User's Guide 2
Revision History
R1.0 Preliminary

WADE-8213-Q670E

Copyright © Portwell 2022 WADE-8213-Q670E User's Guide 3
Contents
1Introduction..............................................................................................................................................................................................................................7
2Specifications...........................................................................................................................................................................................................................8
2.1Supported Operating Systems .................................................................................................................................................................. 9
2.2Mechanical Dimensions ......................................................................................................................................................................... 10
2.3Power Consumption .............................................................................................................................................................................. 11
2.4Environmental Specifications ................................................................................................................................................................. 12
3Block Diagram........................................................................................................................................................................................................................13
4Hardware Configuration.........................................................................................................................................................................................................14
4.1Jumpers and Connectors ....................................................................................................................................................................... 14
4.2Jumpers Settings .................................................................................................................................................................................. 15
5Signal Descriptions................................................................................................................................................................................................................42
5.1Watch Dog Signal ................................................................................................................................................................................. 42
5.2GPIO Signal ......................................................................................................................................................................................... 45
6System Resources.................................................................................................................................................................................................................48
6.1Intel®Alder Lake -S PCH ...................................................................................................................................................................... 48
6.2Main Memory ........................................................................................................................................................................................ 48
6.3Installing the Single Board Computer ...................................................................................................................................................... 48
6.3.1Chipset Component Driver ..................................................................................................................................................................... 49
6.3.2Intel®UHD 770 Graphics ........................................................................................................................................................................ 49
6.3.3Intel LAN I225LM / I210ATGigabit Ethernet Controller .............................................................................................................................. 49

WADE-8213-Q670E

Copyright © Portwell 2022 WADE-8213-Q670E User's Guide 4
7BIOS Setup Items..................................................................................................................................................................................................................50
7.1Introduction .......................................................................................................................................................................................... 50
7.2BIOS Setup .......................................................................................................................................................................................... 50
7.2.1 Main ........................................................................................................................................................................................................ 52
7.2.2 Advanced ................................................................................................................................................................................................. 53
7.2.3 H/W Monitor ............................................................................................................................................................................................. 88
7.2.4 Security ................................................................................................................................................................................................... 91
7.2.5 Boot ........................................................................................................................................................................................................ 94
7.2.6 Exit .......................................................................................................................................................................................................... 95
7.2.7 MEBx ...................................................................................................................................................................................................... 96
8Troubleshooting.....................................................................................................................................................................................................................97
8.1Hardware Quick Installation ................................................................................................................................................................... 97
8.2BIOS Setting ......................................................................................................................................................................................... 98
8.3FAQ ..................................................................................................................................................................................................... 99
9Portwell Software Service....................................................................................................................................................................................................105
10Industry Specifications.........................................................................................................................................................................................................106
10.1Industry Specifications ......................................................................................................................................................................... 106

WADE-8213-Q670E

Copyright © Portwell 2022 WADE-8213-Q670E User's Guide 5
Preface
This user’s guide provides information about the components, features, connectors and BIOS Setup menus available on the WADE-8213-Q670E. This
document should be referred to when designing mini-ITX application. The other reference documents that should be used include the following:
 Intel Alder Lake Design Guide
 Intel Alder Lake Specification
Please contact Portwell Sales Representative for above documents.
Disclaimer
The information contained within this user’s guide, including but not limited to any product specification, is subject to change without notice.
Portwell provides no warranty with regard to this user’s guide or any other information contained herein and hereby expressly disclaims any implied warranties
of merchantability or fitness for any particular purpose with regard to any of the foregoing. Portwell assumes no liability for any damages incurred directly or
indirectly from any technical or typographical errors or omissions contained herein or for discrepancies between the product and the user’s guide. In no event
shall Portwell be liable for any incidental, consequential, special, or exemplary damages, whether based on tort, contract or otherwise, arising out of or in
connection with this user’s guide or any other information contained herein or the use thereof.
Trademarks
Product names, logos, brands, and other trademarks featured or referred to within this User’s guide or the Portwell website, are the property of their respective
trademark holders. These trademark holders are not affiliated with Portwell, our products, or our website.

WADE-8213-Q670E

Copyright © Portwell 2022 WADE-8213-Q670E User's Guide 6
Warranty
Portwell makes no representation, warranty or guaranty, express or implied regarding the products except its standard form of limited warranty (“Limited
Warranty”). Portwell may in its sole discretion modify its Limited Warranty at any time and from time to time.
Beginning on the date of shipment to its direct customer and continuing for the published warranty period, Portwell represents that the products are new and
warrants that each product failing to function properly under normal use, due to a defect in materials or workmanship or due to non conformance to the agreed
upon specifications, will be repaired or exchanged, at Portwell’s option and expense.
Certification
Portwell is certified to DIN EN ISO 9001:2000 standard.
Technical Support
Portwell technicians and engineers are committed to providing the best possible technical support for our customers so that our products can be easily used and
implemented.
We request that you first visit our website at http://www.portwell.com.tw/support/ for the latest documentation, utilities and drivers, which have been made
available to assist you. If you still require assistance after visiting our website then contact our technical support department by email at
[email protected]for further assistance. Thank you!

WADE-8213-Q670E

Copyright © Portwell 2022 WADE-8213-Q670E User's Guide 7
1 Introduction
WADE-8213-Q670E is based on the Intel®Core™ S Processor which offers 10nm process with Hybridtechnology. WADE-8213-Q670E supports dual channels
DDR5SO-DIMM up to64GB.
Desktop solution is still popular in the market of DVR and FactoryAutomation which can fulfill most of these applications; therefore, with high performance and
high-end specifications, WADE-8213-Q670E is our first generationAlder Lake -S chip architecture on mini-ITX line.

WADE-8213-Q670E

Copyright © Portwell 2022 WADE-8213-Q670E User's Guide 8
2 Specifications
Main Processor ◆Intel®Alder Lake -S Core™ i9 / i7 / i5 / i3,Pentium®and Celeron®Processors
System Chipset ◆ Intel®Q670E Express chipset
System BIOS ◆AMI UEFI BIOS
Main Memory ◆Up to 64GB in 2 slots DDR5SO-DIMM sockets. Supports dual channel DDR54800 MHz
Graphics
◆Controller: Intel® UHD 770 Graphics, support DirectX12,OpenGL 4.6
◆LVDS: Supports one LVDS up to resolution 1920 x 1200 (Support either eDP or LVDS; switch by BIOS)
◆DP: Supports three DP up to 8K
◆HDMI: Supports one HDMI port
Expansion Interface ◆One M.2 (Key E_2230) for Wifi/BT device(PCIe x1/CNVi)
◆One M.2 (Key M_2242/2260/2280) for SSD(PCIe x4 / SATA)
◆One PCIe Gen5 x16 slot(1 x16 mode / 2 x8 mode)
SATA Interface ◆FourSATA ports(SATA Gen3.06Gb/s), support RAID 0,1,5,10
Input/Output
◆COM Ports:Five Ports: 1x RS-232/422/485 on rear I/O &1x RS-232/422/485 on board header & 3x
RS-232 on board header
◆USB Port:3x USB 3.2 Gen2 on rear I/O(2x typeA, 1x Type C),1x USB 3.2 Gen1 on rear I/O(TypeA), 1x
Header support additional 2x USB3.2 Gen1 ports, 1x USB3.2 Gen1 vertical typeAconnector,4x
USB2.0(TypeA)&1x Header support additional 2x USB2.0 on board header
◆Audio Interface: Line-In / Line-Out
Ethernet ◆Supports one 10/100/1000 Mbps Ethernet port (s) via PCI Express x1 bus
◆Supports one 10/100/1000/2500 Mbps Ethernet port (s) via PCI Express x1 bus
High Drive GPIO ◆One pin-header for GPIO(8bit GPIO )

WADE-8213-Q670E

Copyright © Portwell 2022 WADE-8213-Q670E User's Guide 9
Mechanical and
environmental specifications
◆Operating temperature: 0 ~ 60° C
◆Storage temperature:-20 ~ 80° C
◆Humidity: 5 ~ 95% non-condensing
◆Power supply voltage: ATX
◆Board size: 170mm x 170 mm
Safety ◆CE, FCC
2.1 Supported Operating Systems
The WADE-8213-Q670E supports the following operating systems.
 Windows* 10 IOT Enterprise (64-bit)
 Ubuntu, Fedora Workstation, OpenSUSE

WADE-8213-Q670E

Copyright © Portwell 2022 WADE-8213-Q670E User's Guide 10
2.2 Mechanical Dimensions

WADE-8213-Q670E

Copyright © Portwell 2022 WADE-8213-Q670E User's Guide 11
2.3 Power Consumption Test Configuration
CPU Type Intel® Core™ i9-12900 CPU @ 1.8GHz
BIOS 1.13.00.92
Memory Hynix/DDR5 4800 SO-DIMM 32G
VGACard Onboard Intel® UHD Graphics 770 driven by XeArchitecture
VGADriver Intel® GraphicsAccelerator Driver V30.0.101.1002
LAN Card Onboard Intel® LAN I225
LAN Driver Intel® Ethernet Connection I225 Version: 1.0.2.14
LAN Card #2 Onboard Intel® I210ATGigabit Network Connection
LAN Driver #2 Intel® Ethernet Connection I210 Version: 12.18.11.1
Audio Card Onboard RealtekALC897High DefinitionAudio
Audio Driver RealtekALC897High DefinitionAudio Version: 6.0.9285.1
Chipset Driver Intel®Alder lake-S Chipset Device Software Version:10.1.18838.8284
USB 3.0 Driver Intel® USB 3.0 eXtensible Host Controller-1.20(Microsoft)
SATAHDD SK Hynix 512G
Power Supply AXT PSU: 600WATX PSU
12V DC IN:ASUS EMA-DCB-A(DC source)

WADE-8213-Q670E

Copyright © Portwell 2022 WADE-8213-Q670E User's Guide 12
Power consumption
ATX:
Source Voltage
Minimum Load Max Voltage MB Capacitive Load Mean Mean / Max. Mean MB Current
(A) Tolerance (uf) w/o peripherals(A)
ATX PSU
+12V 0.216 ±5% 1300 6.13 / 7.154
+5V 0.292 ±5% 500 1.834 / 2.067
+3V 0.169 ±5% 100 0.265 / 0.403
+5VSB_ATX N/A ±5% 100 0.019 / 0.126
12V DC in +12V N/A ±5% 1300 7.484 / 8.43
2.4 Environmental Specifications
Storage Temperature: -20~80°C
Operation Temperature: 0~60°C
Storage Humidity: 5~95%
Operation Humidity: 10~90%

WADE-8213-Q670E

Copyright © Portwell 2022 WADE-8213-Q670E User's Guide 13
3 Block Diagram

WADE-8213-Q670E
Copyright © Portwell 2022 WADE-8213-Q670E User's Guide 14
4 Hardware Configuration
4.1 Jumpers and Connectors
This chapter indicates jumpers’, headers’and connectors’locations. Users may find useful information related to hardware settings in this chapter.


WADE-8213-Q670E
Copyright © Portwell 2022 WADE-8213-Q670E User's Guide 15
4.2 Jumpers Settings
For users to customize WADE-8213-Q670E’s features. In the following sections, Short means covering a jumper cap over jumper pins; Open or N/C (Not
Connected) means removing a jumper cap from jumper pins. Users can refer to Figure 1 for the Jumper allocations.
Jumper Table
The jumper settings are schematically depicted in this manual as follows:
Jumper Function List
1 CPU and Chassis Fan headers (4-pin CPU_FAN, 4-pin CHA_FAN)
2 Display panel VCC power selection (6-pin VCC_PWR_SEL)
3 LVDS/eDP Backlight panel connector (5-pin LCD_BLKT_PANEL)
4 ATX Power connectors (24-pin EATXPWR, 8-pin EATX12V)
5 Intel LGA1700 CPU socket
6 Digital Audio header (4-1 pin SPDIF_OUT)
7 Chassis Intrude header (4-1 pin CHASSIS)
8 AT/ATX mode selection (3-pin AT_ATX_SEL)
9 Serial Port headers (10-1 pin COM2, COM3, COM4, COM5)
10 General purpose input/output connector (10-pin GPIO_CON)
11 Speaker header (4-pin SPEAKER)
12 System Panel header (10-1 pin F_PANEL)
13 COM1/2 Ring/+5V/+12V selection jumpers (6-pin COM1_SEL, COM2_SEL)

WADE-8213-Q670E
Copyright © Portwell 2022 WADE-8213-Q670E User's Guide 16
14 DDR5 SO-DIMM slots
15 USB 3.2 Gen 1 connectors (20-1 pin U32G1_78)/ (U32G1_6)
16 USB 2.0 header (10-1 pin USB_213)
17 SATA 6.0Gb/s ports (7-pin SATA6G_1-4)
18 Clear CMOS header (2-pin CLRTC)
19 PCI Express 5.0 x16 slot
20 Disable ME jumper (3-pin DIS_ME)
21 Front Panel Audio header (10-1 pin AAFP)
22 RTC Battery header (2-pin BATTERY)
23 M.2 Wi-Fi
24 M.2 socket 3
25 SPI TPM header (14-1 pin SPI_TPM)
26 LCD Panel Monitor Switch header (2-pin PANEL_SW)
27 LVDS/eDP Signal connector (LVDS_eDP)
28 LVDS/eDP Panel Enable Signal Selection header (3-pin BKLTEN_SEL)

WADE-8213-Q670E
Copyright © Portwell 2022 WADE-8213-Q670E User's Guide 17
1: CPU and Chassis Fan headers (4-pin CPU_FAN, 4-pin CHA_FAN)
*Connector Type: 2.54mm pitch

WADE-8213-Q670E
Copyright © Portwell 2022 WADE-8213-Q670E User's Guide 18
2: Display panel VCC power selection (6-pin VCC_PWR_SEL)
PINNo. Description
1-2(Short) 3V(Default)
2-3(Short) 5V
5-6(Short) 12V
*Connector Type: 2.54mm pitch

WADE-8213-Q670E
Copyright © Portwell 2022 WADE-8213-Q670E User's Guide 19
3: LVDS/eDP Backlight panel connector (5-pin LCD_BLKT_PANEL)
*Connector Type: 2.0mm pitch

WADE-8213-Q670E
Copyright © Portwell 2022 WADE-8213-Q670E User's Guide 20
4: ATX Power connectors (24-pin EATXPWR, 8-pin EATX12V)
DC Mode EATXPWR
PINNo. Description PINNo. Description PINNo. Description PINNo. Description
1 +3.3V out 7 GND 13 +3.3V out 19 GND
2 +3.3V out 8 NC 14 NC 20 +12V out
3 GND 9 NC 15 GND 21 +5V out
4 +5V out 10 +12V in 16 PSON# 22 +5V out
5 GND 11 +12V in 17 GND 23 +5V out
6 +5V out 12 +3.3V out 18 GND 24 GND
