Portwell WADE-8211 User manual

WADE-8211
Copyright © Portwell 2018 WADE-8211
User's Guide
1
Industrial Mini-ITX Board
Version 1.1
WADE-8211

WADE-8211
Copyright © Portwell 2018 WADE-8211
User's Guide
2
Revision History
R1.0 Preliminary
R1.1 Update USB power setting jumper information

WADE-8211
Copyright © Portwell 2018 WADE-8211
User's Guide
3
Contents
1Introduction .............................................................................................................................................................................................................................. 7
2Specifications ...........................................................................................................................................................................................................................
2.1 Supported Operating Systems..................................................................................................................................................................9
2.2 Mechanical Dimensions.........................................................................................................................................................................10
2.3 Power Consumption..............................................................................................................................................................................11
2.4 Environmental Specifications .................................................................................................................................................................12
3Block Diagram ........................................................................................................................................................................................................................ 13
4Hardware Configuration ......................................................................................................................................................................................................... 14
4.1 Jumpers and Connectors.......................................................................................................................................................................14
4.2 Jumpers Settings ..................................................................................................................................................................................15
5Signal Descriptions ................................................................................................................................................................................................................ 31
5.1 Watch Dog Signal .................................................................................................................................................................................31
5.2 GPIO Signal .........................................................................................................................................................................................34
6System Resources ................................................................................................................................................................................................................. 3
6.1 Intel® Coffee Lake -S PCH ....................................................................................................................................................................38
6.2 Main Memory........................................................................................................................................................................................38
6.3 Installing the Single Board Computer ......................................................................................................................................................39
6.3.1 Chipset Component Driver .....................................................................................................................................................................39
6.3.2 Intel® UHD Graphics 630.......................................................................................................................................................................40
6.3.3 Intel LAN I210AT/I219LM Gigabit Ethernet Controller................................................................................................................................40

WADE-8211
Copyright © Portwell 2018 WADE-8211
User's Guide
4
7BIOS Setup Items .................................................................................................................................................................................................................. 41
7.1 Introduction ..........................................................................................................................................................................................41
7.2 BIOS Setup ..........................................................................................................................................................................................41
7.2.1 Main.....................................................................................................................................................................................................43
7.2.2 Advanced .............................................................................................................................................................................................44
7.2.3 H/W Monitor..........................................................................................................................................................................................73
7.2.4 Security ................................................................................................................................................................................................75
7.2.5 Boot .....................................................................................................................................................................................................81
7.2.6 Exit ......................................................................................................................................................................................................85
Troubleshooting ..................................................................................................................................................................................................................... 7
.1 Hardware Quick Installation ...................................................................................................................................................................87
.2 BIOS Setting.........................................................................................................................................................................................88
.3 FAQ.....................................................................................................................................................................................................89
9Portwell Software Service ...................................................................................................................................................................................................... 94
10 Industry Specifications ........................................................................................................................................................................................................... 95
10.1 Industry Specifications...........................................................................................................................................................................95

WADE-8211
Copyright © Portwell 2018 WADE-8211
User's Guide
5
Preface
This user’s guide provides information about the components, features, connectors and BIOS Setup menus available on the WADE- 211. This document should
be referred to when designing Mini-ITX application. The other reference documents that should be used include the following:
Intel Coffee Lake Design Guide
Intel Coffee Lake Specification
Please contact Portwell Sales Representative for above documents.
Disclaimer
The information contained within this user’s guide, including but not limited to any product specification, is subject to change without notice.
Portwell provides no warranty with regard to this user’s guide or any other information contained herein and hereby expressly disclaims any implied warranties
of merchantability or fitness for any particular purpose with regard to any of the foregoing. Portwell assumes no liability for any damages incurred directly or
indirectly from any technical or typographical errors or omissions contained herein or for discrepancies between the product and the user’s guide. In no event
shall Portwell be liable for any incidental, consequential, special, or exemplary damages, whether based on tort, contract or otherwise, arising out of or in
connection with this user’s guide or any other information contained herein or the use thereof.
Trademarks
Product names, logos, brands, and other trademarks featured or referred to within this User’s guide or the Portwell website, are the property of their respective
trademark holders. These trademark holders are not affiliated with Portwell, our products, or our website.

WADE-8211
Copyright © Portwell 2018 WADE-8211
User's Guide
6
Warranty
Portwell makes no representation, warranty or guaranty, express or implied regarding the products except its standard form of limited warranty (“Limited
Warranty”). Portwell may in its sole discretion modify its Limited Warranty at any time and from time to time.
Beginning on the date of shipment to its direct customer and continuing for the published warranty period, Portwell represents that the products are new and
warrants that each product failing to function properly under normal use, due to a defect in materials or workmanship or due to non conformance to the agreed
upon specifications, will be repaired or exchanged, at Portwell’s option and expense.
Certification
Portwell is certified to DIN EN ISO 9001:2000 standard.
Technical Support
Portwell technicians and engineers are committed to providing the best possible technical support for our customers so that our products can be easily used and
implemented.
We request that you first visit our website at http://www.portwell.com.tw/support/ for the latest documentation, utilities and drivers, which have been made
available to assist you. If you still require assistance after visiting our website then contact our technical support department by email at
[email protected]for further assistance. Thank you!

WADE-8211
Copyright © Portwell 2018 WADE-8211
User's Guide
7
1Introduction
WADE- 211-Q370 based on the Intel® Core™ Processor which offers 14nm Hi-K process technology with energy efficient architecture. WADE- 211 support
dual channels DDR4 So - DIMM up to 32GB.
Desktop solution is still popular in the market of DVR and Factory Automation which can fulfill most of these applications; therefore, with high performance and
high-end specifications, WADE- 211 is our first generation Coffee -S chip architecture on Mini-ITX line.

WADE-8211
Copyright © Portwell 2018 WADE-8211
User's Guide
8
2Specifications
Main Processor
◆ Intel® Coffee -S Core™ i Processors
System Chipset
◆ Intel®Q370 Express chipset
System BIOS
◆ AMI UEFI BIOS
Main Memory
◆ Up to 32 GB in 2 slots DDR4 So-DIMM sockets. Supports dual channel DDR4 2400/2666 MHz
SDRAM
Graphics
◆ Controller: Intel® Gfx Gen 9, UHD 630 graphics
◆ VGA: Supports VGA up to resolution 1920 x 1200
◆ DP: Supports DP up to resolution 4096 x 2304
◆ LVDS: Supports LVDS up to resolution 1920 x 1200
Expansion Interface
◆ One mini-PCIe socket
◆ One M.2 (Key E, 2230) with PCIe x1, CNVI and USB2.0 for Wireless
◆ One M.2 (Key M, 2242/2260/22 0) with PCIe x4 and SATA3 for SSD
SATA Interface
◆ Four SATA ports(SATA 6Gb/s)
Input Output
◆ Five Ports: 2x RS-232/422/4 5 on REAR I/O & 3x RS-232 on board header
◆ USB Port: 4x USB 3.0 on REAR I/O, 4x USB 2.0 on board header
◆ GPIO connector: 4GPI + 4GPO
◆ Audio Interface: Mic-In / Line-Out
Ethernet
◆ Supports dual 10/100/1000 Mbps Ethernet port (s) via PCI Express x1 bus which provides 500 MB/s
data transmission rate
High Drive GPIO
◆ One pin-header for GPIO(4bit in & 4bit out)

WADE-8211
Copyright © Portwell 2018 WADE-8211
User's Guide
9
Mechanical and
environmental specifications
◆
Operating temperature: 0 ~ 60° C
◆
Storage temperature:-20 ~ 0° C
◆
Humidity: 5 ~ 90% non-condensing
◆
Power supply voltage: ATX
◆
Board size: 170mm x 170 mm
2.1 Supported Operating Systems
The WADE- 211 supports the following operating systems.
Windows 10 Enterprise & IOT Enterprise (64b) RS3
Ubuntu, SuSe, Redhat Enterprise 1,2 (Kernel 4.14)
Yocto 2.4 Tool-based Embedded Linux Distribution
Wind River VxWorks 7

WADE-8211
Copyright © Portwell 2018 WADE-8211
User's Guide
10
2.2 Mechanical Dimensions

WADE-8211
Copyright © Portwell 2018 WADE-8211
User's Guide
11
2. Power Consumption
Test Configuration
CP
U Type
Intel®
Core™ i7
-
700TE
CPU @ 3.2GHz
SBC BIOS Portwell, Inc. WADE- 211 TEST BIOS (51104T00)
Memory WARIS UB-DIMM DDR4 2133 16GB
VGA Card Onboard Intel® UHD Graphics 630
VGA Driver Intel® UHD Graphics 630 Version: 24.20.100.62 6
LAN Card Onboard Intel® Ethernet Connection(2) I219-LM
LAN Driver Intel® Ethernet Connection(2) I219-LM Version: 12.13.17.7
LAN Card #2 Onboard Intel® I210AT Gigabit Network Connection
LAN Driver #2 Intel® I210AT Gigabit Network Connection Version: 12.14.7.0
Audio Card Onboard Realtek ALC 7 High Definition Audio
Audio Driver Realtek ALC 7 High Definition Audio Version: 6.0.1. 1 6
Chipset Driver Intel® Coffee lake-S Chipset Device Software Version: 10.1.17541
USB 3.0 Driver Intel® USB 3.0 eXtensible Host Controller Adaptation Driver Version: 6.3.9600.17393
SATA HDD Intel SSD 256G
Power Supply FSP460-60PFB 460W / GADIWA 5V/12V DC POWER

WADE-8211
Copyright © Portwell 2018 WADE-8211
User's Guide
12
Power consumption
ATX:
Item Power ON Full Loading 10Min Full Loading 30Min
CPU +12V 0.9 A 2.05A 1.9 A
System +12V 0. 3A 1.4 A 1.26A
System +3.3V 0.55A 0.65A 0.69A
System +5V 1.11A 1.37A 1.34A
System+ Device +12V 0.97A 1. 1A 1.56A
System+ Device +5V 1. 7A
USB2.0 Loading Test 4.9 V/ 570 mA
2.4 Environmental Specifications
Storage Temperature : -20~ 0°C
Operation Temperature : 0~60°C
Storage Humidity : 5~90%
Operation Humidity: 10~90%

WADE-8211
Copyright © Portwell 2018 WADE-8211
User's Guide
13
3Block Diagram

WADE-8211
Copyright © Portwell 2018 WADE-8211
User's Guide
14
4Hardware Configuration
4.1 Jumpers and Connectors
This chapter indicates jumpers’, headers’ and connectors’ locations. Users may find useful information related to hardware settings in this chapter.

WADE-8211
Copyright © Portwell 2018 WADE-8211
User's Guide
15
4.2 Jumpers Settings
For users to customize WADE- 211’s features. In the following sections, Short means covering a jumper cap over jumper pins; Open or N/C (Not Connected)
means removing a jumper cap from jumper pins. Users can refer to Figure 1 for the Jumper allocations.
Jumper Table
The jumper settings are schematically depicted in this manual as follows:
Jumper Function List
1 EDP_LVDS_J1, EDP_LVDS_ J2
2 Backlight Power Select
3 BL1
4 Inverter Power Control afer
5 LVDS Panel Connector
6 BL2
7 Buzzer
8 Panel Power Select(LCD_VCC)
9 Backlight Volume Control(BLT_Vol1)
10 COM Port Headers(COM 1,2,5)
11 Digital Input / Output Default Value Setting(JGPIO_SET1)
12 4-Pin Chassis FAN Connector(+12V)
13 24-Pin ATX Power Input Connector

WADE-8211
Copyright © Portwell 2018 WADE-8211
User's Guide
16
14 SIO_AT1
15 System Panel Header
16 LPC Header
17 Digital Input / Output Power Select(JGPIO_P R)(JGPIO_P R1)
18 Digital Input / Output Pin Header(JGPIO1)
19 COM Port P R Setting Jumpers(P R_COM5 is Optional)
20 Chassis Intrusion Headers(CI1,CI2)
21 4-Pin ATX Power Input/Output
22 P R_BAT1
23 USB2.0 Headers
24 Clear CMOS Headers
25 3 Audio AMP Output afer
26 Front Panel Audio Header
27 Audio Output
28 Top:RJ45 LAN port(LAN2)
Bottom:USB 3.0 Ports(USB3_3_4)
29 Top:RJ45 LAN port(LAN1)
Bottom:USB 3.0 Ports(USB3_1_2)
30 SATA3 Connectors(SATA3_1~4)
31 D-Sub Port(VGA1)
32 USB Power Setting Jumper
33 4-Pin CPU FAN connector(+12V)

WADE-8211
Copyright © Portwell 2018 WADE-8211
User's Guide
17
34 Top: Display Port(DP1)
Bottom: Display Port(DP2)
35 Top: COM Port 3(RS232/422/485)*
Bottom: COM Port 4(RS232/422/485)*
1: EDP_LVDS_J1, EDP_LVDS_ J2
1-2：LVDS
2-3：eDP(WADE-8211-Q370 not support eDP)
2: Backlight Power Select
(LCD_BLT_VCC)(BKT_PWR1)
1-2：LCD_BLT-VCC：+5V
2-3：LCD_BLT-VCC：+12V

WADE-8211
Copyright © Portwell 2018 WADE-8211
User's Guide
18
3: BL1
Open：Protect LCD_BLT_VCC
Short：No Protect LCD_BLT_VCC
4: Inverter Power Control Wafer(BLT_PWR1)

WADE-8211
Copyright © Portwell 2018 WADE-8211
User's Guide
19
5: LVDS Panel Connector
6: BL2
Open：Protect LCD_VCC
Short：No Protect LCD_VCC

WADE-8211
Copyright © Portwell 2018 WADE-8211
User's Guide
20
7: Buzzer
8: Panel Power Select(LCD_VCC)
(PNL_PWR1)
1-2：LCD_VCC：+3V
2-3：LCD_VCC：+5V
4-5：LCD_VCC：+12V
9: Backlight Volume Control(BLT_Vol1)
