Portwell NANO-6051 User manual

NANO-6051
Copyright © Portwell 2020 NANO-6051 User's Guide
1
NANO-ITX Embedded Motherboard
Version 1.1
NANO-6051

NANO-6051
Copyright © Portwell 2020 NANO-6051 User's Guide
2
Revision History
R1.0
Preliminary

NANO-6051
Copyright © Portwell 2020 NANO-6051 User's Guide
3
Contents
1 Introduction...............................................................................................................................................................................................................7
2 Specifications ...........................................................................................................................................................................................................8
2.1 Supported Operating Systems ............................................................................................................................................................................9
2.2 Mechanical Dimensions ...................................................................................................................................................................................10
2.3 Power Consumption.........................................................................................................................................................................................11
2.4 Environmental Specifications............................................................................................................................................................................12
3 Block Diagram ........................................................................................................................................................................................................13
4 Hardware Configuration ...........................................................................................................................................................................................14
4.1 Jumpers and Connectors .................................................................................................................................................................................14
4.2 Jumper Settings ..............................................................................................................................................................................................15
4.3 Connector Settings ..........................................................................................................................................................................................17
5 Signal Descriptions..................................................................................................................................................................................................36
5.1 Watch Dog Signal............................................................................................................................................................................................36
5.2 Signal GPIO Signal..........................................................................................................................................................................................38
6 System Resources ..................................................................................................................................................................................................40
6.1 Intel® Whiskey Lake - U SoC............................................................................................................................................................................40
6.2 Main Memory ..................................................................................................................................................................................................40
6.3 Installing the Single Board Computer.................................................................................................................................................................41
6.3.1 Chipset Component Driver .......................................................................................................................................................................41
6.3.2 Intel® HD Graphics 620 ...........................................................................................................................................................................42
6.3.3 Intel LAN I210IT/I219LM Gigabit Ethernet Controller...................................................................................................................................42

NANO-6051
Copyright © Portwell 2020 NANO-6051 User's Guide
4
7BIOS Setup Items .................................................................................................................................................................................................43
7.1 Introduction ..........................................................................................................................................................................................43
7.2 BIOS Setup ..........................................................................................................................................................................................43
7.2.1 Main................................................................................................................................................................................................45
7.2.2 Configuration ...................................................................................................................................................................................47
7.2.3 Security ..................................................................................................................................................................................................72
7.2.4 Boot .......................................................................................................................................................................................................73
7.2.5 Save & Exit.............................................................................................................................................................................................75
8Troubleshooting ....................................................................................................................................................................................................76
8.1 Hardware Quick Installation ...................................................................................................................................................................76
8.2 BIOS Setting.........................................................................................................................................................................................77
8.3 FAQ.....................................................................................................................................................................................................78
9Portwell Software Service ......................................................................................................................................................................................80
10 Industry Specifications...........................................................................................................................................................................................81
10.1 Industry Specifications...........................................................................................................................................................................81

NANO-6051
Copyright © Portwell 2020 NANO-6051 User's Guide
5
Preface
This user’s guide provides information about the components, features, connectors and BIOS Setup menus available on the NANO-6051. This document should
be referred to when designing NANO-ITX application. The other reference documents that should be used include the following:
Intel Whiskey Lake-U Design Guide
Intel Whiskey Lake-U Specification
Please contact Portwell Sales Representative for above documents.
Disclaimer
The information contained within this user’s guide, including but not limited to any product specification, is subject to change without notice.
Portwell provides no warranty with regard to this user’s guide or any other information contained herein and hereby expressly disclaims any implied warranties
of merchantability or fitness for any particular purpose with regard to any of the foregoing. Portwell assumes no liability for any damages incurred directly or
indirectly from any technical or typographical errors or omissions contained herein or for discrepancies between the product and the user’s guide. In no event
shall Portwell be liable for any incidental, consequential, special, or exemplary damages, whether based on tort, contract or otherwise, arising out of or in
connection with this user’s guide or any other information contained herein or the use thereof.
Trademarks
Product names, logos, brands, and other trademarks featured or referred to within this User’s guide or the Portwell website, are the property of their respective
trademark holders. These trademark holders are not affiliated with Portwell, our products, or our website.

NANO-6051
Copyright © Portwell 2020 NANO-6051 User's Guide
6
Warranty
Portwell makes no representation, warranty or guaranty, express or implied regarding the products except its standard form of limited warranty (“Limited
Warranty”). Portwell may in its sole discretion modify its Limited Warranty at any time and from time to time.
Beginning on the date of shipment to its direct customer and continuing for the published warranty period, Portwell represents that the products are new and
warrants that each product failing to function properly under normal use, due to a defect in materials or workmanship or due to non conformance to the agreed
upon specifications, will be repaired or exchanged, at Portwell’s option and expense.
Certification
Portwell is certified to DIN EN ISO 9001:2000 standard.
Technical Support
Portwell technicians and engineers are committed to providing the best possible technical support for our customers so that our products can be easily used and
implemented.
We request that you first visit our website at http://www.portwell.com.tw/support/ for the latest documentation, utilities and drivers, which have been made
available to assist you. If you still require assistance after visiting our website then contact our technical support department by email at
[email protected]for further assistance. Thank you!

NANO-6051
Copyright © Portwell 2020 NANO-6051 User's Guide
7
1 Introduction
Portwell Inc., a world-leading innovator in the Industrial PC (IPC) market and a member of the Intel®Embedded and Communications Alliance (Intel ECA),
announced today the Portwell NANO-6051 utilizing the NANO-ITX form factor based on the Intel®Whiskey Lake-U processor . The NANO-6051 supports one
DDR4SODIMM socket up to 32GB system memory and comes with one M.2 E key socket, one M.2 M key socket, Dual mini DP ports, two GbE Ethernet, one
COM port support RS-232/422/485, four USB3.1(Gen1) on board and two USB3.1(Gen2) on REAR IO. The NANO-6051 can provide the low power
consumption for low profile fanless applications such as POS, Print Imaging, ATM, Kiosk, Medical, Panel PC, Digital Security and Digital Signage.

NANO-6051
Copyright © Portwell 2020 NANO-6051 User's Guide
8
2 Specifications
Main Processor
◆Intel®Whiskey lake -U series Processor
System BIOS
◆AMI UEFI BIOS
Main Memory
◆Up to 32 GB in 1 slots DDR4SO-DIMM sockets.
◆Supports DDR4 2400 MHz.
Graphics
◆Controller: Intel®HD Graphics 620
◆DP: Supports mini DP up to resolution 4096x2304
Expansion Interface
◆One M.2(NGFF) E key socket for wireless application
SATA Interface
◆One M.2 M key socket for SSD application
Input/Output
◆Serial Port: 1x RS-232/422/485, switched by BIOS
◆USB Port: 2x USB 3.1(Gen2) on REAR I/O, 4x USB 3.1(Gen1) on board header
◆Audio Interface: Audio jack on rear I/O with Line-out and on board pin header with Line-in, Line- out, and
Mic-in.
Ethernet
◆Supports dual 10/100/1000 Mbps Ethernet port (s) via PCI Express x1 bus.
◆Controller: Intel I210AT / I219LM
High Drive GPIO
◆One pin-header for GPIO(8bit in / out)

NANO-6051
Copyright © Portwell 2020 NANO-6051 User's Guide
9
Mechanical
and
environmental specifications
◆Operating temperature: 0 ~ 60° C
◆Storage temperature:-40 ~ 80° C
◆Humidity: 5 ~ 95% non-condensing
◆Power supply voltage: 12V DC in
◆Board size: 120mm x 120 mm (4.72" x 4.72")
2.1 Supported Operating Systems
The NANO-6051 supports the following operating systems.
Windows* 10 IoT Enterprise RS5 (64b)
Ubuntu*, SUSE, Red Hat* Enterprise (64b)
Yocto Project* BSP tool-based embedded Linux distribution (64b)
Wind River VxWorks* 7 (64b)

NANO-6051
Copyright © Portwell 2020 NANO-6051 User's Guide
10
2.2 Mechanical Dimensions

NANO-6051
Copyright © Portwell 2020 NANO-6051 User's Guide
11
2.3 Power Consumption
Test Configuration
CPU Type
Intel® Core™ i5-8365UE CPU @ 1.60GHz
SBC BIOS
Portwell, Inc. NANO-6051 BIOS Rev.:0.0.3 (11052019)
Memory
Samsung DDR4 SO-DIMM 2666/32GB *1
VGA Card
Onboard Intel® UHD Graphics 620
VGA Driver
Intel® HD Graphics 620 , Version: 26.20.100.7158
LAN Card #1
Onboard Intel® Ethernet Connection I219-LM
LAN Driver #1
Intel® Ethernet Connection I219-LM , Version:12.18.9.10
LAN Card #2
Onboard Intel® I210 Gigabit Network
LAN Driver #2
Intel® I210 Gigabit Network , Version:12.18.9.1
LAN I210 FW
3.25
Audio Card
Onboard Realtek High Definition Audio
Audio Driver
Realtek High Definition Audio , Version: 6.0.8720.1
Chip Driver
Intel® Chipset Software , Version: 10.1.27.2
USB 3.0 Driver
Intel® USB3.1 eXtensible Host Conntroller-1.10(Microsoft),Ver:10.0.18362.1
EC Version
R00.E05 (10/14/2019)
CPU ID
000806EC

NANO-6051
Copyright © Portwell 2020 NANO-6051 User's Guide
12
Power consumption(12V)
ATX:
Item
Power ON
Full Loading 10Min
Full Loading 30Min
CPU +12V
0.9 A
2.2 A
1.7 A
USB 3.0 Loading Test
4.93V/ 970 mA
2.4 Environmental Specifications
Storage Temperature : -40~85°C
Operation Temperature : 0~60°C
Storage Humidity : 5~95%
Operation Humidity: 10~90%

NANO-6051
Copyright © Portwell 2020 NANO-6051
User's Guide
13
3 Block Diagram
V

NANO-6051
Copyright © Portwell 2020 NANO-6051 User's Guide
14
4 Hardware Configuration
4.1 Jumpers and Connectors
Note. Top side with J16/J17 Note. Top side with J18/J19

NANO-6051
Copyright © Portwell 2020 NANO-6051 User's Guide
15
4.2 Jumper Settings
For users to customize NANO-6051’s features. In the following sections, Short means covering a jumper cap over jumper pins; Open or N/C (Not Connected)
means removing a jumper cap from jumper pins. Users can refer to Figure 1 for the Jumper allocations.
Jumper Table
The jumper settings are schematically depicted in this manual as follows:
Jump Function List:
Jumper
Function
Remark
JP1
Combo Jack Microphone setting
PH2Px1/2mm
JP3
EC' GPO voltage level selection
Header5Px2/2mm
JP5
AT/ATX Mode selection
PH3Px1/2mm
JP6
Clear CMOS
PH3Px1/2mm
JP1: Combo Jack Microphone setting
PIN No.
Description
1-2, Short
No stereo Microphone
1-2, Open
Normal

NANO-6051
Copyright © Portwell 2020 NANO-6051 User's Guide
16
JP3: EC' GPO voltage level selection
JP5: ATX/AT Mode selection
JP6: Clear CMOS
PIN No.
Description
1-2, Short
Select 5V
2-3, Short
Select 3.3V
PIN No.
Description
1-2 Short
AT mode
2-3 Short
ATX mode
PIN No.
Description
1-2, Short
Normal
2-3, Short
Clear CMOS

NANO-6051
Copyright © Portwell 2020 NANO-6051 User's Guide
17
4.3 Connector Settings
Connector Allocation
I/O peripheral devices are connected to the interface connectors
Connector Function List
Connector
Function
Remark
J1
DC-in Jack
J2
Combo Audio Jack
J3
MiniDP (DDI1)
J4
MiniDP (DDI2)
J5
RJ45 (i219)
J6
RJ45 (i210)
J7
USB2.0/3.0(Gen2) Connector (Type-A)
Port1
J8
USB2.0/3.0(Gen2) Connector (Type-A)
Port2
J9
ATX 4P connector (+12v)
J10
M2 2280 Connector (M-Key)
NVMe/SATA
J11
RTC Battery Connector
3WAFER2x1P
J12
GPIO pin header
Header5Px2/2mm

NANO-6051
Copyright © Portwell 2020 NANO-6051 User's Guide
18
J13
DDR4 Memory Socket (Channel B)
J14
COM port Connector
BH5Px2/2mm
J15
M2 2230 Connector (E-Key)
J16/J17
USB2.0/3.1(Gen1) Connector
BH10Px2/2.0mm
J18/J19
USB2.0/3.1(Gen1) Connector
BH10Px2/2.0mm
J20
EC’s SMBUS debug Pin header
PH5Px1-Pin2/2.54mm
J21
Front Panel Pin header
Header4Px2/2mm
JP2
Audio pin header
Header4Px2/2mm
JP4
Port80 Pin header
Header5Px2-Pin9/2.5
4mm
J1: DC-in Jack
PIN No.
Description
1
PWR_LED (+)
3
PWR_LED (-)
5
I219_LAN (+)

NANO-6051
Copyright © Portwell 2020 NANO-6051 User's Guide
19
J2: Combo Audio Jack
PIN No.
Description
1
GNDAU
2
FRNT_OUT_B_L
3
FRNT_OUT_T_R
4
N/C
5
N/C
6
MIC_IN_B_L
7
CGND
8
CGND

NANO-6051
Copyright © Portwell 2020 NANO-6051 User's Guide
20
J3：MiniDP connector (DDI1)
PIN No.
Description
PIN No.
Description
1
GND
2
DP_HPD1#
3
DDI1_R_TXP0
4
OC_AUX_EN1#
5
DDI1_R_TXN0
6
CFG2
7
GND
8
GND
9
DDI1_R_TXP1
10
DDI1_R_TXP3
11
DDI1_R_TXN1
12
DDI1_R_TXN3
13
GND
14
GND
15
DDI1_R_TXP2
16
DPD_OC_AUX_P
17
DDI1_R_TXN2
18
DPD_OC_AUX_N
19
GND
20
DP_PWR
CG1
CGND
CG2
CGND
CG3
CGND
CG4
CGND
