Portwell WADE-8173-J6412 User manual

WADE-8173-J6412
Copyright © Portwell 2022 WADE-8173-J6412 User's Guide 1

Version 1.0
IndustrialMini‐ITXBoard
WADE‐8173‐J6412

WADE-8173-J6412
Copyright © Portwell 2022 WADE-8173-J6412 User's Guide 2
Revision History
R1.0 Preliminary

WADE-8173-J6412
Copyright © Portwell 2022 WADE-8173-J6412 User's Guide 3
Contents
1Introduction ............................................................................................................................................................................................................ 7
2Specifications ......................................................................................................................................................................................................... 8
2.1Supported Operating Systems ............................................................................................................................................................................. 9
2.2Mechanical Dimensions ................................................................................................................................................................................... 10
2.3 Environmental Specifications ............................................................................................................................................................................ 12
3Block Diagram ...................................................................................................................................................................................................... 13
4Hardware Configuration ......................................................................................................................................................................................... 14
4.1Jumpers and Connector ................................................................................................................................................................................... 14
4.2 Jumpers Setting .............................................................................................................................................................................................. 15
5Signal Descriptions ............................................................................................................................................................................................... 47
5.1Watch Dog Signal ........................................................................................................................................................................................... 47
5.2GPIO Signal ................................................................................................................................................................................................... 50
6System Resources ................................................................................................................................................................................................ 55
6.1 Intel® Elkhart Lake SoC ................................................................................................................................................................................... 55
6.2 Main Memory .................................................................................................................................................................................................. 55
6.3 Installing the Single Board Computer ................................................................................................................................................................. 55
6.3.1 Chipset Component Driver ..................................................................................................................................................................... 56
6.3.2 Intel® UHD Graphics ............................................................................................................................................................................. 56
6.3.3 RealtekRTL8111H Gigabit Ethernet Controller ......................................................................................................................................... 56
7BIOS Setup Items ................................................................................................................................................................................................. 57
7.1Introduction .................................................................................................................................................................................................... 57

WADE-8173-J6412
Copyright © Portwell 2022 WADE-8173-J6412 User's Guide 4
7.2BIOS Setup .................................................................................................................................................................................................... 57
7.2.1 Main ............................................................................................................................................................................................. 59
7.2.2 Advanced .......................................................................................................................................................................................... 60
7.2.3 H/W Monitor ...................................................................................................................................................................................... 94
7.2.4 Security ............................................................................................................................................................................................ 9 7 
Secure Boot ................................................................................................................................................................................................ 98
Key Management ......................................................................................................................................................................................... 99
7.2.5 Boot................................................................................................................................................................................................ 101
7.2.6 Exit ................................................................................................................................................................................................. 103
8Troubleshooting .................................................................................................................................................................................................. 105
8.1Hardware Quick Installation ........................................................................................................................................................................... 105
8.2BIOS Setting ................................................................................................................................................................................................. 106
8.3FAQ ............................................................................................................................................................................................................. 107
9Portwell Software Service .................................................................................................................................................................................... 113
10Industry Specifications ......................................................................................................................................................................................... 114
10.1Industry Specifications ......................................................................................................................................................................... 114

WADE-8173-J6412
Copyright © Portwell 2022 WADE-8173-J6412 User's Guide 5
Preface
This user’s guide provides information about the components, features, connectors and BIOS Setup menus available on the WADE-8173-J6412. This document
should be referred to when designing Mini-ITX application. The other reference documents that should be used include the following:
 Intel Elkhart Lake Design Guide
 Intel Elkgart Lake Specification
Please contact Portwell Sales Representative for above documents.
Disclaimer
The information contained within this user’s guide, including but not limited to any product specification, is subject to change without notice.
Portwell provides no warranty with regard to this user’s guide or any other information contained herein and hereby expressly disclaims any implied warranties
of merchantability or fitness for any particular purpose with regard to any of the foregoing. Portwell assumes no liability for any damages incurred directly or
indirectly from any technical or typographical errors or omissions contained herein or for discrepancies between the product and the user’s guide. In no event
shall Portwell be liable for any incidental, consequential, special, or exemplary damages, whether based on tort, contract or otherwise, arising out of or in
connection with this user’s guide or any other information contained herein or the use thereof.
Trademarks
Product names, logos, brands, and other trademarks featured or referred to within this User’s guide or the Portwell website, are the property of their respective
trademark holders. These trademark holders are not affiliated with Portwell, our products, or our website.

WADE-8173-J6412
Copyright © Portwell 2022 WADE-8173-J6412 User's Guide 6
Warranty
Portwell makes no representation, warranty or guaranty, express or implied regarding the products except its standard form of limited warranty (“Limited
Warranty”). Portwell may in its sole discretion modify its Limited Warranty at any time and from time to time.
Beginning on the date of shipment to its direct customer and continuing for the published warranty period, Portwell represents that the products are new and
warrants that each product failing to function properly under normal use, due to a defect in materials or workmanship or due to non conformance to the agreed
upon specifications, will be repaired or exchanged, at Portwell’s option and expense.
Certification
Portwell is certified to DIN EN ISO 9001:2000 standard.
Technical Support
Portwell technicians and engineers are committed to providing the best possible technical support for our customers so that our products can be easily used and
implemented.
We request that you first visit our website at http://www.portwell.com.tw/support/ for the latest documentation, utilities and drivers, which have been made
available to assist you. If you still require assistance after visiting our website then contact our technical support department by email at
[email protected]for further assistance. Thank you!

WADE-8173-J6412
Copyright © Portwell 2022 WADE-8173-J6412 User's Guide 7
1 Introduction
The WADE-8173-J6412, designed with Elkhart Lake Intel CeleronJ6412processor, features two DDR43200 MHz SO-DIMM socket equipped with up to 32GB
DDR4 non-ECC memory.
Celeron solution is still popular in the market of Kiosk, Panel PC, Digital Security and Digital Signage which can fulfill most of these applications; therefore, with
high performance and high-end specifications, Elkhart Lake SoC is our first generationCeleron chip architecture on Mini-ITX line.


WADE-8173-J6412
Copyright © Portwell 2022 WADE-8173-J6412 User's Guide 8
2 Specifications
Main Processor ◆Intel® Elkhart lake SoC J6412 Processors
System BIOS ◆AMI UEFI BIOS
Main Memory ◆Up to 32 GB in 2 slots DDR4 SO-DIMM sockets.
◆Supports dual channel DDR43200 MHz SDRAM
Graphics
◆Controller: Intel®UHD Graphics
◆DP: Support 2xDP ports, resolution up to 4096x2160 (DP2 colay with HDMI)
◆HDMI: Support HDMI, resolution up to 3840x2160 (Default)
◆LVDS/eDP: Support LVDS/eDP, LVDS resolution up to 1920x1200 (Default) and eDP: resolution up to
4096x2160 (colay with LVDS)
◆Triple displays: HDMI+DP+LVDS, HDMI+DP+eDP, DP+DP+LVDS, DP+DP+eDP
Expansion Interface
◆One PCIe x1 Gen 3
◆One M.2 Key E 2230 with PCIe x1 and USB 2.0 for Wireless
◆One M.2 Key M 2242/2260/2280 with PCIex2 and SATA signal for SSD
◆One full/half size Mini PCIe socket with PCIe x1(with SIM holder)
◆One Full size SD card slot
SATA Interface ◆One SATA ports(SATA Gen3.06Gb/s)
Input/Output
◆Serial Ports:5x RS-232 on board &1x RS-232/422/485 on board
◆USB Port: 3x USB 3.2 Gen2 on rear I/O,1x USB 2.0 on rear I/O and 4x USB2.0 on board header
◆Audio Interface: Line-In and Line-Out

WADE-8173-J6412
Copyright © Portwell 2022 WADE-8173-J6412 User's Guide 9
Ethernet ◆Supports dual 10/100/1000 Mbps Ethernet port (s) via PCI Express x1
High Drive GPIO ◆One pin-header for GPIO(8bit in &8bit out)
Mechanical and
environmental specifications
◆Operating temperature: 0 ~ 60° C
◆Storage temperature:-20 ~ 80° C
◆Humidity: 5 ~ 95% non-condensing
◆Board size: 170mm x 170 mm
Safety ◆CE, FCC
2.1Supported Operating Systems
The WADE-8173-J6412 supports the following operating systems.
 Windows 10* (64 bit), IoT Core(32/64bit)
 Wind River* 8.0 Linux Distribution(64 bit)
 Yocto* Tool-based Embedded Linux Distribution (64 bit)
 Android* 6.0(64bit)

WADE-8173-J6412
Copyright © Portwell 2022 WADE-8173-J6412 User's Guide 10
2.2 Mechanical Dimensions

WADE-8173-J6412
Copyright © Portwell 2022 WADE-8173-J6412 User's Guide 11
Power Consumption
Test Configuration
CPU Type Intel®Celeron®CPU J6412 @ 2.00GHz
SBC BIOS WADE-81731.02.00
Memory DDR4 SO-DIMM 3200/3000 16GB *2
VGA Card Intel®UHD Graphic
VGA Driver Intel®Display Driver; V30.0.101.1340
LAN Card Realtek 8111 PCI-E Gigabit Ethernet
LAN Driver Realtek driver version: v10.50.511.2021
LAN Card Realtek 8111 PCI-E Gigabit Ethernet
LAN Driver Realtek driver version: v10.50.511.2021
Audio Card Realtek ALC897
Audio Driver Realtek High Definition Audio v6.0.9313.1
Chip Driver Intel®Chipset Device Software Version: V10.1.18768.8273
USB3.0 Driver Intel®USB 3.0 eXtensible Host Controller :V10.1.18768.8273
Power Supply 12V DC-in

WADE-8173-J6412
Copyright © Portwell 2022 WADE-8173-J6412 User's Guide 12
Power consumption
DC-in type 120W Power Consumption (W)
CPU J6412
Full Loading(Run Prime95 small FFT's item) 44.3 (Burn-in test CPU 100% HDD 100%, Media Player Set Vol. Max)
S1(Monitor Auto Off) N/A
S3(Sleep mode) <5Watt 1.076
S5(Shut down) 0.313( ErP enable), 0.925( ErP Disable)
2.3 Environmental Specifications
Storage Temperature : -20~80°C
Operation Temperature : 0~60°C
Storage Humidity : 5~95%
Operation Humidity: 10~90%

WADE-8173-J6412
Copyright © Portwell 2022 WADE-8173-J6412 User's Guide 13
3 Block Diagram

WADE-8173-J6412
Copyright © Portwell 2022 WADE-8173-J6412 User's Guide 14
4 Hardware Configuration
4.1 Jumpers and Connector
This chapter indicates jumpers’, headers’and connectors’locations. Users may find useful information related to hardware settings in this chapter.

WADE-8173-J6412
Copyright © Portwell 2022 WADE-8173-J6412 User's Guide 15
4.2 Jumpers Setting
For users to customize WADE-8173-J6412’s features. In the following sections, Short means covering a jumper cap over jumperpins; Open or N/C (Not
Connected) means removing a jumper cap from jumper pins. Users can refer to Figure 1 for the Jumper allocations.
Jumper Table
The jumper settings are schematically depicted in this manual as follows:
JumperFunctionList
1  ATXPowercon nector (4‐ pin ATX12V)
2 Built‐inIntel®Celeron®Quad‐coreProcessorJ6412
3 SPI_TPMheader(14‐1pinSPI_TPM)
4 DDR4SO‐DIMMslots
5 LVDS/EDPheader(40‐pinLVDS_EDP)
6 LVDSPanelBacklightEnableSignalSelection(BKLTEN_SEL)
7 LVDSBacklightPanelheader(5‐pinLCD_BLKT_PANEL)
8 Chassisfanheader(4‐pinCHA_FAN)
9 LCDPanelmonitorswitchheader(2‐pinPANEL_SW)
10 LVDSPanelVCCPowerSelectionjumper(6‐pinVCC_PWR_SEL)
11 AT/ATXmodeselectionjumper(3‐pinAT_ATX_SEL)
12 COMPortheaders(10‐1pinCOM1~COM6)
13 SATA6.0Gb/sport(7‐pinSATA6G)
14 SATAPowerconnector(SATA_PWR)

WADE-8173-J6412
Copyright © Portwell 2022 WADE-8173-J6412 User's Guide 16
15 Speakerheader(4‐1pinSPEAKER)
16 SystemPanelheader(10‐1pinF_PANEL)
17 COMRING/+5V/+12Vselectionjumpers(6‐pinCOM1_SEL,COM2_SEL)
18 RTCBatteryheader(2‐pinBATT_CON)
19 PS/2KeyboardandMouseheader(8‐pinKBMS_CON)
20 SDCardslot(SD_CARD)
21 ChassisIntrusionheader(4‐pinCHASSIS)
22 USB2.0headers(10‐1pinUSB_12,USB_34)
23 PCIe3.0/2.0x1slot(PCIEX1)
24 ClearRTCRAM(2‐pinCLRTC)
25 GeneralPurposeInput/outputheader(GPIO_CON)
26 FrontPanelAudioheader(10‐1pinAAFP)
27 InternalStereoSpeakerheader(2‐pinSTEREO_OUT_L,STEREO_OUT_R)
28 M.2socket3(M.2_SOCKET3)
29 M.2Wi‐Fislot
30 NanoSIMCardslot
31 MPCIecomboslot(MPCIE)

WADE-8173-J6412
Copyright © Portwell 2022 WADE-8173-J6412 User's Guide 17
1 :ATX Power connector (4-pin ATX12V)
2 :Built-in Intel® Celeron® Quad-core Processor J6412
The motherboard comes with an onboard Intel® processor J6412.

WADE-8173-J6412
Copyright © Portwell 2022 WADE-8173-J6412 User's Guide 18
3 :SPI_TPM header (14-1 pin SPI_TPM)
This header supports a Trusted Platform Module (TPM) system with a Serial Peripheral Interface (SPI), allowing you to securely store
keys,digitalcertificates, passwords, and data. A TPM system also helps enhance network security, protects digital identities, and ensures platform
integrity.
*Connector Type: 2.00mm pitch

WADE-8173-J6412
Copyright © Portwell 2022 WADE-8173-J6412 User's Guide 19
4 :DDR4 SO-DIMM slots

WADE-8173-J6412
Copyright © Portwell 2022 WADE-8173-J6412 User's Guide 20
5 :LVDS/EDP header (40-pin LVDS_EDP)
