WADE-8013
WADE-8014
Mini-ITX Board
User's Manual
Version 1.0
Copyright © Portwell, Inc., 2012. All rights reserved.
All other brand names are registered trademarks of their respective owners.

Preface
Table of Contents
How to Use This Manual
Chapter 1 System Overview.......................................................................................................1-1
1.1 Introduction ....................................................................................................... 1-1
1.2 Check List........................................................................................................... 1-2
1.3 Product Specification........................................................................................ 1-2
1.3.1 Mechanical Drawing................................................................................ 1-4
1.4 System Architecture.......................................................................................... 1-6
Chapter 2 Hardware Configuration...........................................................................................2-1
2.1 Jumper Setting................................................................................................... 2-1
2.2 Connector Allocation........................................................................................ 2-3
Chapter 3 System Installation....................................................................................................3-1
3.1 Intel LGA-1155 Processor................................................................................. 3-1
3.2 Main Memory .................................................................................................... 3-4
3.3 Installing the Single Board Computer............................................................ 3-5
3.3.1 Chipset Component Driver .................................................................... 3-5
3.3.2 Intel® Integrated Graphics Controller.................................................. 3-5
3.3.3 On-board Gigabit Ethernet Controller.................................................. 3-5
3.3.4 Audio Controller...................................................................................... 3-6
3.4 Clear CMOS Operation .................................................................................... 3-6
3.5 WDT Function ................................................................................................... 3-6
3.6 GPIO.................................................................................................................... 3-8
Chapter 4 BIOS Setup Information............................................................................................4-1
4.1 Entering Setup -- Launch System Setup ........................................................ 4-1
4.2 Main .................................................................................................................... 4-2
4.3 Advanced ........................................................................................................... 4-3
4.4 Security ............................................................................................................. 4-26
4.5 Boot ................................................................................................................... 4-27
4.6 Exit..................................................................................................................... 4-28
Chapter 5 Troubleshooting........................................................................................................5-1
5.1 Hardware Quick Installation........................................................................... 5-1
5.2 BIOS Setting ....................................................................................................... 5-3
5.3 Q&A .................................................................................................................... 5-4

Preface
How to Use This Manual
The manual describes how to configure your WADE-8013/WADE-8014 system board
to meet various operating requirements. It is divided into five chapters, with each
chapter addressing a basic concept and operation of Single Host Board.
Chapter 1: System Overview. Presents what you have in the box and give you an
overview of the product specifications and basic system architecture for this series
model of single host board.
Chapter 2: Hardware Configuration. Show the definitions and locations of Jumpers
and Connectors that you can easily configure your system.
Chapter 3: System Installation. Describes how to properly mount the CPU, main
memory and Compact Flash to get a safe installation and provides a programming
guide of Watch Dog Timer function.
Chapter 4: BIOS Setup Information. Specifies the meaning of each setup
parameters, how to get advanced BIOS performance and update new BIOS. In
addition, POST checkpoint list will give users some guidelines of trouble-shooting.
Chapter 5: Troubleshooting. Provide various of useful tips to quickly get
WADE-8013/WADE-8014 running with success. As basic hardware installation has
been addressed in Chapter 3, this chapter will basically focus on system integration
issues, in terms of backplane setup, BIOS setting, and OS diagnostics.
The content of this manual is subject to change without prior notice. These changes
will be incorporated in new editions of the document. The vendor may make
supplement or change in the products described in this document at any time.

System Overview
WADE-8013/WADE-8014 User’s Manual 1-1
Chapter 1
System Overview
1.1 Introduction
Portwell Inc., a world-leading innovator in the Industrial PC (IPC) market and a
member of the Intel® Embedded and Communications Alliance (Intel ECA),
announced today the Portwell WADE-8013/WADE-8014 adopting the Mini-ITX
form factor. The WADE-8013/WADE-8014 of the Intel platform will provide high
performance and flexibility for functional expansion, such as Gaming, Kiosk, DS,
Medical, Defense, Industrial automation and control applications.
Ivy Bridge is the next major architecture from Intel. The
WADE-8013/WADE-8014 supports the latest Intel® Ivy Bridge processors in
LGA1155 package which has memory and PCI Express controller integrated to
support 2-channel DDR3 memory and PCI Express 3.0 lanes providing great
graphics performance. Intel® Ivy Bridge processor is one of the most powerful
and energy efficient CPU in the world. Portwell have taken advantage of such
technology to furnish a series of products that can meet multiple industrial
requirements such as cost-effective of CPU performance or industrial systems.
WADE-8013/WADE-8014 is based on the Intel Ivy Bridge processor and Intel®
Q77/C216 chipset. The Intel Q77/C216 Express Chipset, when combined with a
processor from the Intel® Dual Core/Quad Core processor family, delivers smart
security, cost saving manageability, and intelligent performance for business
platforms. WADE-8013/WADE-8014 is the first Portwell off-the-shelf product for
by Intel® Q77/C216 Express Chipset, it can be an embedded solution and a good
platform for customer to integrate it to the embedded system.
WADE-8013/WADE-8014 showcased one of Portwell upcoming motherboard
for the Intel’s Ivy Bridge processors . The WADE-8013/WADE-8014 is based on
the forthcoming Intel Q77/C216 chipset and supports the new LGA 1155 socket
(socket that will be used by Ivy Bridge processors). This board has lots of features,
including supports total 4x SATA (two SATA 6.0 Gbps and two 3.0 Gbps
ports)storage specification , allows RAID 0/1/5 and 10. supports the latest PCIe
3.0 (one PCI-Express x16 slot) devices for double speed and bandwidth which
enhances system performance, two long-DIMM memory slot for DDR3 SDRAM
up to 16GB, support total 10 USB2.0 ports (4x rear IO by USB3.0 / 6x on board by
USB2.0), VGA / HDMI / DVI-D , two Gigabit Ethernet and one mini-PCIe slot
support mSATA.

System Overview
WADE-8013/WADE-8014 User’s Manual 1-2
1.2 Check List
The WADE-8013/WADE-8014 package should cover the following basic items
9One WADE-8013/WADE-8014 Mini-ITX Main Board
9One SATA Cable
9One I/O Shield bracket
9One Installation Resources CD-Title
If any of these items is damaged or missing, please contact your vendor and keep
all packing materials for future replacement and maintenance.
1.3 Product Specification
zMain Processor
-Intel® Dual Core/Quad Core LGA1155 processor
-CPU clock bus: 1333/1600 MHz
zChipset
-Intel® Q77 chipset(WADE-8013)
-Intel® C216 chipset(WADE-8014)
zSystem BIOS
-Phoenix BIOS
zMain Memory
-Two 204 -pin DDR3 SODIMM socket support up to 16GB dual channel
1333/1600 MHz memory
zExpansion Interface
-One PCIex16
-One Mini-PCIe slot(support mSATA))
zSATA Interface
-Four SATA ports(2x SATA 6Gb/2x SATA 3Gb)
zSerial Port
-Support total six comports(one RS232 and one RS232/422/485 on rear
S/O three RS232 and one RS232/422/485 on board header)
zUSB Interface
-Support Ten USB (Universal Serial Bus) ports, four on rear I/O and Six on
board header for internal devices

System Overview
WADE-8013/WADE-8014 User’s Manual 1-3
zAudio Interface
-Connector for Mic-In, Line-In and Line-Out
zReal Time Clock/Calendar (RTC)
-Support Y2K Real Time Clock/Calendar
zWatch Dog Timer
-Support WDT function through software programming for enable/disable
and interval setting
-General system reset
zOn-board Ethernet LAN
-Two Gigabit Ethernet (10/100/1000 Mbits/sec) LAN ports using Intel
82579LM & 82583V GbE Ethernet Controller
zHigh Drive GPIO
-One pin-header for 16 bit GPIO (8bit in & 8bit out)
zSystem Monitoring Feature
-Monitor system temperature and major power sources.
zOutline Dimension (L x W)
-170mm(6.69’’) x 170mm(6.69’’)
zPower Requirements
Configuration
CPU Type Intel(R) Core(TM) i5-3550 CPU @3.30GHz Level 3 6MBytes
SBC BIOS Portwell,Inc.WADE-8013/WADE-8014 TEST BIOS (21101T00)
VGA Card ONBOARD Intel(R)HD Graphics
VGA Driver Intel(R)HD Graphics Version:9.17.10.2828
LAN Card ONBOARD Intel(R) 825741L Gigabit Network Connection
LAN Driver Intel(R) 825741L Gigabit Network Connection Version:11.17.27.0
LAN Card ONBOARD Intel(R) 82579LM Gigabit Network Connection
LAN Driver Intel(R) 82579LM Gigabit Network Connection Version:11.16.96.0
Audio Card ONBOARD Realtek ALC886 High Definition Audio
Audio Driver Realtek ALC886 High Definition Audio Version:6.0.1.6602
Chip Driver Intel(R) Chipset Device Software Version:9.3.0.1021
USB3.0 Driver Intel(R) USB3.0 eXtensible Host Controller Version:1.0.5.235
SATA HDD Seagate ST380815AS 80GB
Power Supply EMACS HG2-6350P
zOperting Temperature
0 °C ~ 60 °C
zStorage Temperature
-20 ~ 80 °C
zRelative Humidity
0% ~ 90%, non-condensing

System Overview
WADE-8013/WADE-8014 User’s Manual 1-4
1.3.1 Mechanical Drawing

System Overview
WADE-8013/WADE-8014 User’s Manual 1-5

System Overview
WADE-8013/WADE-8014 User’s Manual 1-6
1.4 System Architecture
All of details operating relations are shown in WADE-8013 System Block
Diagram. (WADE-8014 ‘s PCH is C216,support ECC memory)
WADE-8013/WADE-8014 System Block Diagram

Hardware Configuration
WADE-8013/WADE-8014 User’s Manual 2-1
Chapter 2
Hardware Configuration
This chapter gives the definitions and shows the positions of jumpers, headers and
connectors. All of the configuration jumpers on WADE-8013/WADE-8014 are in the
proper position. The default settings shipped from factory are marked with an
asterisk (♣).
2.1 Jumper Setting
In general, jumpers on the single board computer are used to select options for certain
features. Some of the jumpers are designed to be user-configurable, allowing for
system enhancement. The others are for testing purpose only and should not be
altered. To select any option, cover the jumper cap over (SHORT) or remove (NC) it
from the jumper pins according to the following instructions. Here NC stands for
“Not Connect”.
Figure 2-1 WADE-8013 / WAD-8014 Jumper and Connector Locations

Hardware Configuration
WADE-8013/WADE-8014 User’s Manual 2-2
The jumper settings are schematically depicted in this manual as follows:
Ìis mean default
JP1: COM2 function Selection
J
P1 Function
5-6, 9-11, 10-12, 15-17, 16-18 Short RS-232
3-4, 7-9, 8-10, 13-15, 14-16, 21-22 Short RS-422
1-2, 7-9, 8-10, 19-20 Short RS-485
JP2: COM6 function Selection
J
P2 Function
5-6, 9-11, 10-12, 15-17, 16-18 Short RS-232
3-4, 7-9, 8-10, 13-15, 14-16, 21-22 Short RS-422
1-2, 7-9, 8-10, 19-20 Short RS-485
JP3: COM4 Serial Port Pin Header
PIN No. Signal Description
1 DCD
2 DSR
3 RXD
4 RTS
5 TXD
6 CTS
7 DTR
8 RI
9 Ground
10 N/C
JP4:AUTO POWER BUTTON Select
JP4 Function
Short Auto power button enable
Open Auto power button disable
JP5: PCIE Select
JP5 Function
Short[1 0] 2 x8 PCI Express
Open[1 1] 1 x16 PCI Express
2x8 PCI Express for C216 Chipset
JP6: CMOS Clear
J
P6 Function
1-2 Short Normal Operation
2-3 Short Clear CMOS Contents

Hardware Configuration
WADE-8013/WADE-8014 User’s Manual 2-3
JP7: mSATA/miniPCIE
J
P7 Function
1-2 Short mSATA
2-3 Short Mini PCIE
2.2 Connector Allocation
I/O peripheral devices and Flash disk will be connected to these interface connectors
Connector Function List
Connector Function Remark
J1 VGA+DVI-D Connector
J2 Serial Port 0、1 Connector
J3 Audio Connector
J4 RJ-45&USB 3.0×2 Connector 82579LM
J5 RJ-45&USB 3.0×2 Connector 82574L
J6 PS/2 Keyboard/Mouse Pin Header
J7 LPC debug Pin HEADER
J8 Serial Port 5 Pin Header
J9 MiniPCIE/mSATA Connector
J10 TPM Pin Header
J11 Serial Port 6 Pin Header
J12 Serial Port 3 Pin Header
J13 GPIO Pin Header
J14 GPIO Pin Header
J15 ATX Power Connector
J16 Front Panel Pin Header
J17/J18 SATA 2.0 Connector
J19/J20/J21 USB 2.0 Pin Header
J22 +12V Power Connector
J23/J24 SATA 3.0 Connector
J25 FAN (CPU FAN) Power Connector
J26 SMBUS Pin HEADER
J27 PCIE×16 Slot
J28 FAN (SYSTEN FAN) Power Connector
J29/J30 DDR3 Slot
U1 HDMI Connector

Hardware Configuration
WADE-8013/WADE-8014 User’s Manual 2-4
J1:VGA+DVI-D Connector
J1A: DVI-D Connector
PIN No. Signal Description PIN No.
Signal Description
1 D2- 2 D2
3 SHIELD1 4 D4-
5 D4 6 DDCCLK
7 DDCDATA 8 NC
9 D1- 10 D1
11 DHIELD2 12 D3-
13 D3 14 VCC5
15 GND 16 HPDET
17 D0- 18 D0
19 SHIELD3 20 D5-
21 D5 22 SHIELD4
23 CLK 24 CLK-
CG1 CG1 CG2 CG2
J1B: VGA Connector
PIN No. Signal Description PIN No.
Signal Description
1 Red 2 Green
3 Blue 4 NC
5 GND 6 RGND
7 GGND 8 BGND
9 KEY(+5V) 10 SGND
11 NC 12 SDA
13 H Sync 14 V Sync
15 SCL 16
J2: COM1&COM2
J2A:COM1 Serial Port
PIN No. Signal Description
1 DCD#1
2 RXD#1
3 TXD#1
4 DTR#1
5 GND
6 DSR#1
7 RTS#1
8 CTS#1
9 RI#1

Hardware Configuration
WADE-8013/WADE-8014 User’s Manual 2-5
J2B:COM2 Serial Port
PIN No. Signal Description
1 DCD#2/DT-
2 RXD#2/DT+
3 TXD#2/422R+
4 DTR#2/422R-
5 GND
6 DSR#2
7 RTS#2
8 CTS#2
9 RI#2
J6:PS/2 Keyboard/Mouse Pin Header
PIN No. Signal Description PIN No.
Signal Description
1 Mouse Data 2 Keyboard Data
3 N/C 4 N/C
5 Ground 6 Ground
7 PS2 Power 8 PS2 Power
9 Mouse Clock 10 Keyboard Clock
J8:COM5 Serial Port Pin Header
PIN No. Signal Description
1 DCD#5
2 DSR#5
3 RXD#5
4 RTS#5
5 TXD#5
6 CTS#5
7 DTR#5
8 RI#5
9 Ground
10 N/C
J10: TPM Pin Header
PIN No. Signal Description PIN No.
Signal Description
1 PCLK_TPM 2 GND
3 LFRAME# 4 X
5 SIO2_PLTRST# 6 VCC
7 LAD3 8 LAD2
9 VCC3 10 LAD1
11 LAD0 12 GND
13 SMB_CLK_MAIN 14 SMB_DATA_MAIN
15 3VSB 16 SERIRQ
17 GND 18 X
19 LPCPD# 20 X

Hardware Configuration
WADE-8013/WADE-8014 User’s Manual 2-6
J11: Serial Port 6 Pin Header
PIN No Signal Description
RS-232 RS-422 RS-485
1 DCD (Data Carrier Detect) TX- DATA-
2 DSR (Data Set Ready) N/C N/C
3 RXD (Receive Data) TX+ DATA+
4 RTS (Request to Send) N/C N/C
5 TXD (Transmit Data) RX+ N/C
6 CTS (Clear to Send) N/C N/C
7 DTR (Data Terminal Ready) RX- N/C
8 RI (Ring Indicator) N/C N/C
9 GND (Ground) GND GND
10 N/C N/C N/C
J12:COM3 Serial Port Pin Header
PIN No. Signal Description
1 DCD#3
2 DSR#3
3 RXD#3
4 RTS#3
5 TXD#3
6 CTS#3
7 DTR#3
8 RI#3
9 Ground
10 N/C
J13: GPIO Pin Header
PIN No. Signal Description PIN No.
Signal Description
1 GPIO0 2 GPIO4
3 GPIO1 4 GPIO5
5 GPIO2 6 GPIO6
7 GPIO3 8 GPIO7
9 Ground 10 +5V
J14: GPIO Pin Header
PIN No. Signal Description PIN No.
Signal Description
1 GPIO0 2 GPIO4
3 GPIO1 4 GPIO5
5 GPIO2 6 GPIO6
7 GPIO3 8 GPIO7
9 Ground 10 +5V

Hardware Configuration
WADE-8013/WADE-8014 User’s Manual 2-7
J16: Front Panel Pin Header
PIN No. Signal Description PIN No.
Signal Description
1 VCC 2 5VSB
3 SATA_LED# 4 POWER_LED
5 GND 6 Power Button#
7 RSTBTN# 8 GND
9 VCC 10 BUZZER
11 GND 12 GND
13 VCC 14 NC
1-3 SATA LED、2-4 Power LED
5-7 Reset Button、6-8 Power Button、9-10 Buzzer
J19/J20/J21/:USB2.0 Pin Header
PIN No. Signal Description PIN No.
Signal Description
1 5V Dual 2 5V Dual
3 USB- 4 USB-
5 USB+ 6 USB+
7 Ground 8 Ground
Key 10 N/C
J25: CPU Fan Connector
PIN No. Signal Description
1 Ground
2 +12V
3 Sense output
4 FAN PWM_CONTROL
J26: SMBUS Pin Header
PIN No. Signal Description
1 SMBus_CLK
2 N/C
3 Ground
4 SMBus_DAT
5 +5V
J28: System Fan Connector
PIN No. Signal Description
1 Ground
2 FAN PWM_CONTROL
3 Sense output

Hardware Configuration
WADE-8013/WADE-8014 User’s Manual 2-8
U1: HDMI Connector
PIN No. Signal Description PIN No.
Signal Description
1 TMDA Data2+ 2 Data2 Shield Ground
3 TMDA Data2– 4 TMDA Data1+
5 Data1 Shield Ground 6 TMDA Data1–
7 TMDA Data0+ 8 Data0 Shield Ground
9 TMDA Data0– 10 TMDA Clock+
11 Clock Shield Ground 12 TMDA Clock–
13 CEC 14 Reserved
15 SCL 16 SDA
17 DDC/CEC Ground 18 +5V Power
19 Hot Plug Detect

System Installation
WADE-8013/WADE-8014 User’s Manual 3-1
Chapter 3
System Installation
This chapter provides you with instructions to set up your system. The additional
information is enclosed to help you set up onboard PCI device and handle Watch Dog
Timer (WDT) and operation of GPIO in software programming.
3.1 IntelLGA-1155 Processor
LGA-1155 CPU Socket
LGA-1155 CPU
Please remember to locate the alignment keys on the CPU socket of the
motherboard and the notches on the CPU.
Alignment key Alignment key
Pin1 corner of the CPU
Socket
NotchNotch
Yellow Triangle Pin1 of
the CPU

System Installation
WADE-8013/WADE-8014 User’s Manual 3-2
LGA-1155 CPU Installation Steps
Before install the CPU, please make sure to turn off the power first!
1. Open the load lever.
2. Lift the load lever up to fully open.
3. Remove the plastic cap on the CPU socket. Before you install the CPU, always
cover it to protect the socket pin.

System Installation
WADE-8013/WADE-8014 User’s Manual 3-3
4. After confirming the CPU direction for correct
mating, put down the CPU in the
socket housing frame. Note that alignment keys are matched.
5. Make sure the CPU has been seated well into the socket. If not, take out the CPU
and reinstall.
6. Engage the load lever while pressing down lightly onto the load plate.
Alignment key
Alignment key
