Portwell WUX-7300U User manual

WUX-7300U/7100U
Copyright © Portwell 2018 WUX-7XXXU series User's Guide
1
NUCformfactorboard
Version 1.0
WUX‐7300U/7100U

WUX-7300U/7100U
Copyright © Portwell 2018 WUX-7XXXU series User's Guide
2
Revision History
R1.0 Preliminary

WUX-7300U/7100U
Copyright © Portwell 2018 WUX-7XXXU series User's Guide
3
Contents
1Introduction..............................................................................................................................................................................................................................7
2Specifications...........................................................................................................................................................................................................................8
2.1Supported Operating Systems .................................................................................................................................................................. 9
2.2Mechanical Dimensions ......................................................................................................................................................................... 10
2.3Power Consumption .............................................................................................................................................................................. 11
2.4Environmental Specifications ................................................................................................................................................................. 12
3Block Diagram........................................................................................................................................................................................................................13
4Hardware Configuration.........................................................................................................................................................................................................14
4.1Jumpers and Connectors ....................................................................................................................................................................... 14
4.2Jumpers Settings .................................................................................................................................................................................. 15
5Signal Descriptions................................................................................................................................................................................................................19
5.1Watch Dog Signal ................................................................................................................................................................................. 19
5.2GPIO Signal ......................................................................................................................................................................................... 22
6.System Resources.................................................................................................................................................................................................................24
6.1Intel® Kaby Lake-U PCH ....................................................................................................................................................................... 24
6.2Main Memory ........................................................................................................................................................................................ 24
6.3Installing the Single Board Computer ...................................................................................................................................................... 25
6.3.1 Chipset Component Driver ....................................................................................................................................................................... 25
6.3.2 Intel® HD Graphics 620 .......................................................................................................................................................................... 26
6.3.3 Intel LAN I219LM Gigabit Ethernet Controller ............................................................................................................................................ 26
7BIOS Setup Items..................................................................................................................................................................................................................27

WUX-7300U/7100U
Copyright © Portwell 2018 WUX-7XXXU series User's Guide
4
7.1Introduction .......................................................................................................................................................................................... 27
7.2BIOS Setup .......................................................................................................................................................................................... 27
7.2.1 Main ...................................................................................................................................................................................................... 29
7.2.2 Advanced ................................................................................................................................................................................................. 30
7.2.3 H/W Monitor ............................................................................................................................................................................................. 60
7.2.4 Security ................................................................................................................................................................................................... 62
7.2.5 Boot ........................................................................................................................................................................................................ 64
7.2.6 Exit .......................................................................................................................................................................................................... 68
8Troubleshooting.....................................................................................................................................................................................................................70
8.1Hardware Quick Installation ................................................................................................................................................................... 70
8.2BIOS Setting ......................................................................................................................................................................................... 71
8.3FAQ ..................................................................................................................................................................................................... 72
9Portwell Software Service......................................................................................................................................................................................................77
10Industry Specifications...........................................................................................................................................................................................................78
10.1Industry Specifications ........................................................................................................................................................................... 78

WUX-7300U/7100U
Copyright © Portwell 2018 WUX-7XXXU series User's Guide
5
Preface
This user’s guide provides information about the components, features, connectors and BIOS Setup menus available on the WUX-7X00U series. This document
should be referred to when designing Intel®NUC form factor board application. The other reference documents that should be used include the following:
 Intel Kaby Lake - U Design Guide
 Intel Kaby Lake - U Specification
Please contact Portwell Sales Representative for above documents.
Disclaimer
The information contained within this user’s guide, including but not limited to any product specification, is subject to change without notice.
Portwell provides no warranty with regard to this user’s guide or any other information contained herein and hereby expressly disclaims any implied warranties
of merchantability or fitness for any particular purpose with regard to any of the foregoing. Portwell assumes no liability for any damages incurred directly or
indirectly from any technical or typographical errors or omissions contained herein or for discrepancies between the product and the user’s guide. In no event
shall Portwell be liable for any incidental, consequential, special, or exemplary damages, whether based on tort, contract or otherwise, arising out of or in
connection with this user’s guide or any other information contained herein or the use thereof.
Trademarks
Product names, logos, brands, and other trademarks featured or referred to within this User’s guide or the Portwell website, are the property of their respective
trademark holders. These trademark holders are not affiliated with Portwell, our products, or our website.

WUX-7300U/7100U
Copyright © Portwell 2018 WUX-7XXXU series User's Guide
6
Warranty
Portwell makes no representation, warranty or guaranty, express or implied regarding the products except its standard form of limited warranty (“Limited
Warranty”). Portwell may in its sole discretion modify its Limited Warranty at any time and from time to time.
Beginning on the date of shipment to its direct customer and continuing for the published warranty period, Portwell represents that the products are new and
warrants that each product failing to function properly under normal use, due to a defect in materials or workmanship or due to non conformance to the agreed
upon specifications, will be repaired or exchanged, at Portwell’s option and expense.
Certification
Portwell is certified to DIN EN ISO 9001:2000 standard.
Technical Support
Portwell technicians and engineers are committed to providing the best possible technical support for our customers so that our products can be easily used and
implemented.
We request that you first visit our website at http://www.portwell.com.tw/support/ for the latest documentation, utilities and drivers, which have been made
available to assist you. If you still require assistance after visiting our website then contact our technical support department by email at
[email protected]for further assistance. Thank you!

WUX-7300U/7100U
Copyright © Portwell 2018 WUX-7XXXU series User's Guide
7
1 Introduction
WUX-7X00U series based on the Intel® Kaby Lake - U Processor which offers 14nm Hi-K process technology with energy efficient architecture. WUX-7X00U
series support dual channels DDR4 So - DIMM up to 32GB.
Desktop solution is still popular in the market of DVR and FactoryAutomation which can fulfill most of these applications; therefore, with high performance and
high-end specifications, WUX-7X00U series is our first generation Kaby Lake - U chip architecture on NUC form factor board line.

WUX-7300U/7100U
Copyright © Portwell 2018 WUX-7XXXU series User's Guide
8
2 Specifications
Main Processor ◆Intel® Kaby Lake-U Core™ i Processors
System Chipset /
System BIOS ◆AMI UEFI BIOS
Main Memory ◆Up to 32 GB in 2 slots DDR4 So-DIMM sockets. Supports dual channel DDR4_2133 MHz
SDRAM
Graphics ◆Controller: Intel® HD Graphics 620
◆DP: Supports DP up to resolution 4096 x 2304
◆HDMI: Supports HDMI up to resolution 4096 x 2304
Expansion Interface ◆One M.2 (Key E) support WiFi, B T, 3G & 4G
SATA Interface ◆One SATA ports(SATA 6Gb/s)
◆One M.2 (Key M) support SSD
Input/Output ◆ 3x USB 3.0 ports on REAR I/O
◆ 1x USB 3.0 type-C port on REAR I/O
◆Audio Interface: Mic-In / Line-Out
Ethernet ◆Supports single 10/100/1000 Mbps Ethernet port (s) via PCI Express x1 bus which provides 500 MB/s
data transmission rate

WUX-7300U/7100U
Copyright © Portwell 2018 WUX-7XXXU series User's Guide
9
Mechanical and
environmental specifications
◆Operating temperature: 0 ~ 60° C
◆Storage temperature:-20 ~ 80° C
◆Humidity: 5 ~ 90% non-condensing
◆Power supply voltage: ATX
◆Board size: 170mm x 170 mm
2.1 Supported Operating Systems
The WUX-7X00U series supports the following operating systems.
 Windows 10 Enterprise & IOT Enterprise (64b)
 Fedira 24 or later(mid -2016,64b)
 Ubuntu, SuSe, Redhat Enterprise (Kernel 4.14)
 Yocto v2.2 Morty(Kernel 4.8)Tool-based ; Embedded Linux Distribution
 Wind River VxWorks 7(64b)
 Chromium(Chrome)(64b)

WUX-7300U/7100U
Copyright © Portwell 2018 WUX-7XXXU series User's Guide
10
2.2 Mechanical Dimensions

WUX-7300U/7100U
Copyright © Portwell 2018 WUX-7XXXU series User's Guide
11
2.3 Power Consumption Test Configuration
CPU T
yp
e Intel® Core™ i5-7300U CPU
@
2.6GHz
(
ES
)
, 3M Cache
SBC BIOS Portwell, Inc. WUX-7XXXU SERIES TESTBIOS 2018/10/05
Memory WARIS UB-DIMM DDR4 2133 8GB*2 (SEC K4A4G085WD)
LAN Card Onboard Intel® Ethernet Connection(2) I219-LM
LAN Driver Intel® Ethernet Connection(2) I219-LM Version: 12.15.22.6
Audio Card Onboard RealtekALC233 High DefinitionAudio
Audio Driver RealtekALC233 High DefinitionAudio Version: 6.0.1.7647
Chipset Driver Intel® INF Version: 10.1.1.18
VGACard Intel® HD Graphics 620
VGADriver Intel® HD Graphics 620 Version: 24.20.100.6229
USB 3.0 Driver Microsoft Version: 10.0.17134.1
SATAHDD HITACHI Z5K320-250 250GB
Power Supply FSP GROUP INC. FSP120-AHAN1

WUX-7300U/7100U
Copyright © Portwell 2018 WUX-7XXXU series User's Guide
12
Power consumption
ATX:
Item Power ON Full Loading 10Min Full Loading 30Min
CPU +12V 0.98A 2.05A 1.98A
System +12V 0.83A 1.48A 1.26A
System +3.3V 0.55A 0.65A 0.69A
System +5V 1.11A 1.37A 1.34A
System+ Device +12V 0.97A 1.81A 1.56A
System+ Device +5V 1.87A
USB3.0 Loading Test 4.93V/ 990 mA
2.4 Environmental Specifications
Storage Temperature : -20~80°C
Operation Temperature : 0~60°C
Storage Humidity : 5~90%
Operation Humidity: 10~90%
．

WUX-7300U/7100U
Copyright © Portwell 2018 WUX-7XXXU series User's Guide
13
3 Block Diagram

WUX-7300U/7100U
Copyright © Portwell 2018 WUX-7XXXU series User's Guide
14
4 Hardware Configuration
4.1 Jumpers and Connectors
This chapter indicates jumpers’, headers’and connectors’locations. Users may find useful information related to hardware settings in this chapter.


WUX-7300U/7100U
Copyright © Portwell 2018 WUX-7XXXU series User's Guide
15
4.2 Jumpers Settings
For users to customize WUX-7X00U SERIES’s features. In the following sections, Short means covering a jumper cap over jumper pins; Open or N/C (Not
Connected) means removing a jumper cap from jumper pins. Users can refer to Figure 1 for the Jumper allocations.
Jumper Table
The jumper settings are schematically depicted in this manual as follows:
JumperFunctionList
1 ClearCMOSPad(CLRMOS1)
2 AudioJack(AUDIO1)
3 USB3.0Port(USB3_2)
4 USB3.0Type‐CPort(USB3_TC_1)
5 SATAPowerOutputConnector(SATA_PWR1)
6 SATA3Connector(SATA_1)
7 LPCDebugHeader(LPC1)
8 InfraredLED(IR1)
9 DC‐inJack(DC_IN1)
10 HDMIPort(HDMI_2)
11 LANPort(LAN1)
12 Top:DisplayPort(HDMI_DP_1)

WUX-7300U/7100U
Copyright © Portwell 2018 WUX-7XXXU series User's Guide
16
Bottom:HDMIPort(HDMI_1)
13 USB3.0Ports(USB3_3_4)
1: Clear CMOS Pad(CLRMOS1)
2: Audio Jack(AUDIO1)
3: USB3.0 Port(USB3_2)
4: USB3.0 Type-C Port(USB3_TC_1)
5: SATA Power Output Connector(SATA_PWR1)
6: SATA3 Connector(SATA_1)

WUX-7300U/7100U
Copyright © Portwell 2018 WUX-7XXXU series User's Guide
17
7: LPC Debug Header(LPC1)
8: Infrared LED(IR1)
9: DC-in Jack(DC_IN1)
10: HDMI Port(HDMI_2)
11: LAN Port(LAN1)
12: Top : Display Port(HDMI_DP_1)
Bottom: HDMI Port(HDMI_1)
13: USB3.0 Ports(USB3_3_4)

WUX-7300U/7100U
Copyright © Portwell 2018 WUX-7XXXU series User's Guide
18
Back Side:
Power Button Header (PWR_BTN1)

WUX-7300U/7100U
Copyright © Portwell 2018 WUX-7XXXU series User's Guide
19
5 Signal Descriptions
5.1 Watch Dog Signal
void WatchDogTest()
{
int WDTimer = 30;
printf("Please input WatchDog timer:");
scanf("%d", &WDTimer);
ShowError(bSuccess =AsrLibWDSetConfig(WDTimer));
ShowError(bSuccess =AsrLibWDTrigger());
char Key = 0;
int CurrentTime = 0;
int WaitSeconds = WDTimer;
while (WaitSeconds) {
ShowError(CurrentTime =AsrLibWDCounter());
WaitSeconds++;
while (1)
{
while (kbhit())
{
Key = _getch();

WUX-7300U/7100U
Copyright © Portwell 2018 WUX-7XXXU series User's Guide
20
if(Key=='r')
{
AsrLibWDDisable();
ShowError(bSuccess =AsrLibWDSetConfig(WDTimer));
ShowError(bSuccess =AsrLibWDTrigger());
WaitSeconds = WDTimer;
ShowError(CurrentTime =AsrLibWDCounter());
break;
}
elseif(Key=='c'){
AsrLibWDDisable();
WaitSeconds = 0;
_tprintf(_T("\nWatchDog Disable"));
break;
}
}
if (WaitSeconds == 0)
break;
if (CurrentTime !=AsrLibWDCounter()) {
WaitSeconds--;
printf("\rWatchDog timer %d, press 'r' to reset timer, 'c' to disable WatchDog.", WaitSeconds);
