Portwell WADE-8171 User manual

WADE-8171
Copyright © Portwell 2015 WADE-8171 User's Guide 1
IndustrialMini‐ITXBoard
Version 0.1
WADE‐8171

WADE-8171
Copyright © Portwell 2015 WADE-8171 User's Guide 2
Revision History
R0.1 Preliminary

WADE-8171
Copyright © Portwell 2015 WADE-8171 User's Guide 3
Contents
1Introduction ............................................................................................................................................................................................................7
2Specifications .........................................................................................................................................................................................................8
2.1 Supported Operating Systems..................................................................................................................................................................9
2.2 Mechanical Dimensions.........................................................................................................................................................................10
2.3 Power Consumption..............................................................................................................................................................................11
2.4 Environmental Specifications .................................................................................................................................................................12
3Block Diagram......................................................................................................................................................................................................13
4Hardware Configuration.........................................................................................................................................................................................14
4.1 Jumpers and Connector.........................................................................................................................................................................14
4.2 Jumpers Setting....................................................................................................................................................................................15
4.3 Connector Settings................................................................................................................................................................................32
5Signal Descriptions ...............................................................................................................................................................................................42
5.1 Watch Dog Signal .................................................................................................................................................................................42
5.2 GPIO Signal.........................................................................................................................................................................................42
6System Resources................................................................................................................................................................................................44
7BIOS Setup Items.................................................................................................................................................................................................46
7.1 Introduction ..........................................................................................................................................................................................46
7.2 BIOS Setup..........................................................................................................................................................................................46
7.2.1 Main ...........................................................................................................................................................................................................48
7.2.2 Configuration.................................................................................................................................................................................................50

WADE-8171
Copyright © Portwell 2015 WADE-8171 User's Guide 4
7.2.3 Security ........................................................................................................................................................................................................74
7.2.4Boot 76
7.2.5 Exit ...........................................................................................................................................................................................................82
8Troubleshooting....................................................................................................................................................................................................84
8.1 Hardware Quick Installation ...................................................................................................................................................................84
8.2 BIOS Setting.........................................................................................................................................................................................86
8.3 FAQ.....................................................................................................................................................................................................87
9Portwell Software Service......................................................................................................................................................................................92
10 Industry Specifications...........................................................................................................................................................................................93

WADE-8171
Copyright © Portwell 2015 WADE-8171 User's Guide 5
Preface
This user’s guide provides information about the components, features, connectors and BIOS Setup menus available on the WADE-8171. This document should
be referred to when designing Mini-ITX application. The other reference documents that should be used include the following:
Intel Braswell Design Guide
Intel Braswell Specification
Please contact Portwell Sales Representative for above documents.
Disclaimer
The information contained within this user’s guide, including but not limited to any product specification, is subject to change without notice.
Portwell provides no warranty with regard to this user’s guide or any other information contained herein and hereby expressly disclaims any implied warranties
of merchantability or fitness for any particular purpose with regard to any of the foregoing. Portwell assumes no liability for any damages incurred directly or
indirectly from any technical or typographical errors or omissions contained herein or for discrepancies between the product and the user’s guide. In no event
shall Portwell be liable for any incidental, consequential, special, or exemplary damages, whether based on tort, contract or otherwise, arising out of or in
connection with this user’s guide or any other information contained herein or the use thereof.
Trademarks
Product names, logos, brands, and other trademarks featured or referred to within this User’s guide or the Portwell website, are the property of their respective
trademark holders. These trademark holders are not affiliated with Portwell, our products, or our website.

WADE-8171
Copyright © Portwell 2015 WADE-8171 User's Guide 6
Warranty
Portwell makes no representation, warranty or guaranty, express or implied regarding the products except its standard form of limited warranty (“Limited
Warranty”). Portwell may in its sole discretion modify its Limited Warranty at any time and from time to time.
Beginning on the date of shipment to its direct customer and continuing for the published warranty period, Portwell represents that the products are new and
warrants that each product failing to function properly under normal use, due to a defect in materials or workmanship or due to non conformance to the agreed
upon specifications, will be repaired or exchanged, at Portwell’s option and expense.
Certification
Portwell is certified to DIN EN ISO 9001:2000 standard.
Technical Support
Portwell technicians and engineers are committed to providing the best possible technical support for our customers so that our products can be easily used and
implemented.
We request that you first visit our website at http://www.portwell.com.tw/support/ for the latest documentation, utilities and drivers, which have been made
available to assist you. If you still require assistance after visiting our website then contact our technical support department by email at
[email protected]for further assistance. Thank you!

WADE-8171
Copyright © Portwell 2015 WADE-8171 User's Guide 7
1Introduction
WADE-8171 based on the Intel® Core™ Processor which offers 14nm Hi-K process technology with energy efficient architecture. WADE-8171 support dual
channels DDR3LSO- DIMM up to 8GB.
Desktop solution is still popular in the market of DVR and FactoryAutomation which can fulfill most of these applications; therefore, with high performance and
high-end specifications, Braswell SoC is our first generationAtom chip architecture on Mini-ITX line.

WADE-8171
Copyright © Portwell 2015 WADE-8171 User's Guide 8
2Specifications
Main Processor ◆Intel® Braswell SoCProcessors
System BIOS ◆AMI UEFI BIOS
Main Memory ◆Up to 8 GB in 2 slots DDR3L SO-DIMM sockets. Supports dual channel DDR3L 1333/1600 MHz
SDRAM
Graphics
◆Controller: Intel® Gfx Gen 8, HD graphics
◆VGA: Supports VGA up to resolution 1920 x 1200
◆LVDS: Supports DVI-D up to resolution 1920 x 1200 @ 60Hz
◆HDMI: Supports HDMI up to resolution 1920 x 1200 @ 60Hz
Expansion Interface ◆OneMini-PCIe socket
◆One mSATA socket
SATA Interface ◆Two SATA ports(SATA 6Gb/s)
Input/Output
◆Serial Ports: Threeserial ports, 3 x RS-232 & 2 x RS-232/422/485
◆Support Keyboard and PS/2 mouse connector (Rear I/O)
◆USB Port: 4 x USB 3.0
◆GPIO connector: 8GPI + 8GPO
◆Audio Interface: Connector for Mic-In and Line-Out
Ethernet ◆Supports dual 10/100/1000 Mbps Ethernet port (s) via PCI Express x1 bus which provides 500 MB/s
data transmission rate

WADE-8171
Copyright © Portwell 2015 WADE-8171 User's Guide 9
High Drive GPIO ◆One pin-header for GPIO(8bit in &8bit out)
Mechanical
and
environmental specifications
◆Operating temperature: 0 ~ 60° C
◆Storage temperature:-20 ~ 80° C
◆Humidity: 5 ~ 90% non-condensing
◆Power supply voltage: +3.3 V, +5 V, +12 V, 5 Vsb
◆Board size: 170mm x 170 mm
2.1 Supported Operating Systems
The WADE-8171 supports the following operating systems.
Windows* 8.1u (64 bit)
* Windows* Embedded Industry 8.1 (64 bit)
Windows* 7 (32/64 bit)
Windows* 7 (POS ready 7 & WES7) (32/64 bit)
Windows 10* (64 bit)
Fedora* (19 or later) Distribution (64 bit)
Ubuntu*, SuSe Enterprise*, Red hat* Enterprise (64 bit)
** Yocto* Tool-based Embedded Linux Distribution (64 bit)
VxWorks* (RTOS) (64 bit)

WADE-8171
Copyright © Portwell 2015 WADE-8171 User's Guide 10
2.2 Mechanical Dimensions

WADE-8171
Copyright © Portwell 2015 WADE-8171 User's Guide 11
2.3 Power Consumption Test Configuration
CPU T
yp
e Intel® Celeron® N3050 CPU
@
1.60GHz L2:2MB
y
te
BIOS Date 05/15/2015 17:18:39
Memory WARIS DDR3LSO-DIMM 1600 4GB*1 (hynix H5TC2G3EFR)
VGACard Onboard Intel(R) HD Graphics
VGADriver Intel(R) HD Graphics Version 10.18.14.4175
LAN Card Onboard Realtek RTL8111GPCIe GBE Family Controller
LAN Driver Realtek RTL8111GPCIe GBE Family Controller Version 8.25.108.2014
LAN Card #2 Onboard Realtek RTL8111GPCIe GBE Family Controller#2
LAN Driver #2 Realtek RTL8111GPCIe GBE Family Controller#2 Version 8.25.108.2014
Audio Card Onboard RealtekALC887 High DefinitionAudio
Audio Driver RealtekALC887 High DefinitionAudio Version 6.0.1.7464
Chipset Driver Intel® Braswell Chipset Device Software Version: 10.0.13
SATAHDD HITACHI H2T250854SEA7N250GB
SATADOM ASUS DRW-24B3STATADevice
USB DVDROM PIONEER DVD-RW DVR-XD11
Power Supply FSB GROUP FSP460-60PFB 460W

WADE-8171
Copyright © Portwell 2015 WADE-8171 User's Guide 12
Power consumption
ATX:
Item Power ON Full Loading 10Min Full Loading 30Min
System +12V 0.09 0.14 0.07
System +3.3V 0.72 0.74 0.64
System +5V 0.56 0.92 0.88
System+ Device +12V 0.13 0.20 0.07
System+ Device +5V 0.94 0.97 0.82
USB2.0 Loading Test 5.05 V/ 560mA
USB3.0 Loading Test 5.01 V/ 1090mA
DCIN
Item S0 S3 S4 S5
+12V 0.09 0.12 0.12 0.08
+5VSB 0.08 0.11 0,10 0.09
2.4 Environmental Specifications
Storage Temperature : -20~80°C
Operation Temperature : 0~60°C
Storage Humidity : 5~90%
Operation Humidity: 10~90%

WADE-8171
Copyright © Portwell 2015 WADE-8171 User's Guide 13
3Block Diagram

WADE-8171
Copyright © Portwell 2015 WADE-8171 User's Guide 14
4Hardware Configuration
4.1 Jumpers and Connector
This chapter indicates jumpers’, headers’and connectors’locations. Users may find useful information related to hardware settings in this chapter.

WADE-8171
Copyright © Portwell 2015 WADE-8171 User's Guide 15
4.2 Jumpers Setting
For users to customize WADE-8171’s features. In the following sections, Short means covering a jumper cap over jumperpins; Open or N/C (Not Connected)
means removing a jumper cap from jumper pins. Users can refer to Figure 1 for the Jumper allocations.
Jumper Table
The jumper settings are schematically depicted in this manual as follows:
Jumper Function List
1 COM Port PWR Setting Jumpers
2 4-Pin CPU FAN Connector(+12V)
3 USB2 Power Setting Jumper(for USB2_2_3)
4 USB2.0 Connector(USB2_2_3)
5 LVDS Panel Connector
6 ATX Power Connector(Input 12V-24V)
7 Backlight Volume Control(BLT_VOL1)
8 Panel Power Selection (LCD_VCC)(PNL_PWR1)
9 Chassis Intrusion Headers(CI1, CI2)
10 BLT_PWM1
11 20-pinATX Power Input Connector
12 Digital Input/Output Power Select
13 System Panel Header
14 COM Port PWR Setting Jumpers

WADE-8171
Copyright © Portwell 2015 WADE-8171 User's Guide 16
15 4-Pin Chassis FAN Connector(+12V)
16 Power Loss Jumper
17 2-Pin Buzzer Header
18 SATAPower Output Connector
19 COM4, 5, 6 Headers(RS232)
20 Digital Input / Output Default Value Setting(JGPIO_SET1)
21 Printer Port / GPIO Header(LPT_GPIO1)
22 ATX/AT Mode Select
23 SATA3 Connectors (SATA3_1,SATA3_2)
24 LPC Header
25 SPDIF Header
26 USB2 Power Setting Jumper(for USB2_0_1)
27 Clear CMOS Header
28 USB2.0 Connector(USB2_0_1)
29 3WAudio AMP Output Wafer
30 Front PanelAudio Header
31 Audio Output
32 Backlight Power Select(LCD_BLT_VCC)(BKT_PWR1)
33 Top:RJ45 LAN port(LAN2)
34 Backlight Power Connector(BLT_PWR1)
35 Top:RJ45 LAN port(LAN1)
36 LAN LED

WADE-8171
Copyright © Portwell 2015 WADE-8171 User's Guide 17
37 VGAHeader
38 TOP:COM Port 3 (RS232/422/485) Bottom: VGA/D-Sub Port
39 mSATASelect
40 Top: COM Port 1(RS232/422/485)*
Bottom: COM Port 2(RS232/422/485)*
41 PS/2 Mouse/Keyboard Port
42 HDMI Port

WADE-8171
Copyright © Portwell 2015 WADE-8171 User's Guide 18

WADE-8171
Copyright © Portwell 2015 WADE-8171 User's Guide 19

WADE-8171
Copyright © Portwell 2015 WADE-8171 User's Guide 20
