Portwell NANO-6062 User manual

NANO-6062
Copyright © Portwell 2017 NANO-6062 User's Guide 1
NANO‐ITXEmbeddedMotherboard
Version 1.1
NANO‐6062

NANO-6062
Copyright © Portwell 2017 NANO-6062 User's Guide 2
Revision History
R1.0 Preliminary

NANO-6062
Copyright © Portwell 2017 NANO-6062 User's Guide 3
Contents
1 Introduction.................................................................................................................................................................................................................................7
2 Specifications.............................................................................................................................................................................................................................8
2.1 Supported Operating Systems...........................................................................................................................................................................................9
2.2 Mechanical Dimensions...................................................................................................................................................................................................10
2.3 Power Consumption..........................................................................................................................................................................................................11
2.4 Environmental Specifications...........................................................................................................................................................................................12
3 Block Diagram..........................................................................................................................................................................................................................13
4 Hardware Configuration .............................................................................................................................................................................................................1
4.1 Jumpers and Connectors...................................................................................................................................................................................................1
4.2 Jumper Settings...............................................................................................................................................................................................................16
5 Signal Descriptions...................................................................................................................................................................................................................26
5.1 Watch Dog Signal ............................................................................................................................................................................................................26
5.2 Signal GPIO Signal..........................................................................................................................................................................................................28
6 System Resources...................................................................................................................................................................................................................30
6.1 Intel®Apollo Lake SoC....................................................................................................................................................................................................30
6.2 Main Memory...................................................................................................................................................................................................................30
6.3 Installing the Single Board Computer...............................................................................................................................................................................31
6.3.1 Chipset Component Driver......................................................................................................................................................................................31
6.3.2 Intel® HD Graphics 50X..........................................................................................................................................................................................32
6.3.3 Intel LAN I210IT/I219LM Gigabit Ethernet Controller..............................................................................................................................................32
7 BIOS Setup Items..................................................................................................................................................................................................................33

NANO-6062
Copyright © Portwell 2017 NANO-6062 User's Guide 4
7.1 Introduction......................................................................................................................................................................................................................33
7.2 BIOS Setup......................................................................................................................................................................................................................33
7.2.1 Main........................................................................................................................................................................................................................35
7.2.2 Configuration...........................................................................................................................................................................................................37
7.2.3 Security...................................................................................................................................................................................................................79
7.2.4 Boot.........................................................................................................................................................................................................................81
8 Troubleshooting........................................................................................................................................................................................................................86
8.1 Hardware Quick Installation.............................................................................................................................................................................................86
8.2 BIOS Setting....................................................................................................................................................................................................................89
8.3 FAQ…..............................................................................................................................................................................................................................89
9 Portwell Software Service.........................................................................................................................................................................................................92
10 Industry Specifications ...........................................................................................................................................................................................................93

NANO-6062
Copyright © Portwell 2017 NANO-6062 User's Guide 5
Preface
This user’s guide provides information about the components, features, connectors and BIOS Setup menus available on the NANO-6062. This document should
be referred to when designing NANO-ITX application. The other reference documents that should be used include the following:
Intel Apollo Lake Design Guide
Intel Apollo Lake l Specification
Please contact Portwell Sales Representative for above documents.
Disclaimer
The information contained within this user’s guide, including but not limited to any product specification, is subject to change without notice.
Portwell provides no warranty with regard to this user’s guide or any other information contained herein and hereby expressly disclaims any implied warranties
of merchantability or fitness for any particular purpose with regard to any of the foregoing. Portwell assumes no liability for any damages incurred directly or
indirectly from any technical or typographical errors or omissions contained herein or for discrepancies between the product and the user’s guide. In no event
shall Portwell be liable for any incidental, consequential, special, or exemplary damages, whether based on tort, contract or otherwise, arising out of or in
connection with this user’s guide or any other information contained herein or the use thereof.
Trademarks
Product names, logos, brands, and other trademarks featured or referred to within this User’s guide or the Portwell website, are the property of their respective
trademark holders. These trademark holders are not affiliated with Portwell, our products, or our website.

NANO-6062
Copyright © Portwell 2017 NANO-6062 User's Guide 6
Warranty
Portwell makes no representation, warranty or guaranty, express or implied regarding the products except its standard form of limited warranty (“Limited
Warranty”). Portwell may in its sole discretion modify its Limited Warranty at any time and from time to time.
Beginning on the date of shipment to its direct customer and continuing for the published warranty period, Portwell represents that the products are new and
warrants that each product failing to function properly under normal use, due to a defect in materials or workmanship or due to non conformance to the agreed
upon specifications, will be repaired or exchanged, at Portwell’s option and expense.
Certification
Portwell is certified to DIN EN ISO 9001:2000 standard.
Technical Support
Portwell technicians and engineers are committed to providing the best possible technical support for our customers so that our products can be easily used and
implemented.
We request that you first visit our website at http://www.portwell.com.tw/support/ for the latest documentation, utilities and drivers, which have been made
available to assist you. If you still require assistance after visiting our website then contact our technical support department by email at
[email protected]for further assistance. Thank you!

NANO-6062
Copyright © Portwell 2017 NANO-6062 User's Guide 7
1 Introduction
Portwell Inc., a world-leading innovator in the Industrial PC (IPC) market and a member of the Intel®Embedded and CommunicationsAlliance (Intel ECA),
announced today the Portwell NANO-6062 utilizing the NANO-ITX form factor based on the Intel®Atom™ processor E3900 series. The NANO-6062 supports
one DDR3LSODIMM socket up to 8GB system memory and comes with one SATAIII, one Mini-PCIe/mSATAsocket, one M.2 E key socket, triple display by
VGA, DP and LVDS, two GbE Ethernet, one SDsocket and four USB ports. The NANO-6062 can provide the low power consumption for low profile fanless
applications such as POS, Print Imaging,ATM, Kiosk, Medical, Panel PC, Digital Security and Digital Signage.

NANO-6062
Copyright © Portwell 2017 NANO-6062 User's Guide 8
2 Specifications
Main Processor ◆Intel®Atom™ Dual/Quad Core E3900 series Processor
System BIOS ◆AMI UEFI BIOS
Main Memory ◆Up to 8 GB in 1 slots DDR3L SO-DIMM sockets.
◆Supports DDR3L 1866/1600 MHz.
Graphics
◆Controller: Intel®HD Graphics 505
◆LVDS: Supports Dual Channel 24bit up to resolution 1920 x 1200
◆DP: Supports DP up to resolution 4096 x 2160
◆VGA: Supports VGA up to resolution 2560 x 1600
Expansion Interface ◆One M.2(NGFF) E key socket for wireless application
SATA Interface ◆One SATA ports(SATA 6Gb/s)
◆One mSATA socket (Switch mSATA or Mini-PCIe by BIOS)
Input/Output
◆Serial Port: 1x RS-232/422/485, switched by BIOS
◆USB Port: 2x USB 3.0 on REAR I/O, 2x USB 3.0 on board header
◆Audio Interface: Audio jack on rear I/O with Line-out and on board pin header with Line-in, Line- out, and
Mic-in.
Ethernet
◆Supports dual 10/100/1000 Mbps Ethernet port (s) via PCI Express x1 bus.(E3950/E3940 only)
◆Supports single 10/100/1000 Mbps Ethernet port (s) via PCI Express x1 bus.(E3930 only)
◆Controller: Intel I210IT

NANO-6062
Copyright © Portwell 2017 NANO-6062 User's Guide 9
High Drive GPIO ◆One pin-header for GPIO(8bit in / out)
Mechanical
and
environmental specifications
◆Operating temperature: -40 ~ 85° C
◆Storage temperature:-20 ~ 80° C
◆Humidity: 5 ~ 90% non-condensing
◆Power supply voltage: 12~24V DC in
◆Board size: 120mm x 120 mm (4.72" x 4.72")
EMI/ESD
◆ESD: IEC 61000-4-2:2008
◆EMI: EN 55022: 2010/ AC:2011 Class B
2.1 Supported Operating Systems
The NANO-6062 supports the following operating systems.
Windows 10* (64 bit), IoT Core(32/64bit)
Wind River* 8.0 Linux Distribution(64 bit)
Yocto* Tool-based Embedded Linux Distribution (64 bit)
Android* 6.0(64bit)
VxWorks*7.0 (RTOS) (64 bit)

NANO-6062
Copyright © Portwell 2017 NANO-6062 User's Guide 10
2.2 Mechanical Dimensions

NANO-6062
Copyright © Portwell 2017 NANO-6062 User's Guide 11
2.3 Power Consumption
Test Configuration
CPU T
yp
e Intel® Atom™ Processor E3950
@
1.60GHz
SBC BIOS Portwell, Inc. NANO-6062 TEST BIOS (70117T00)
Memory Transcend DDR3L SO-DIMM 8GB/1866 *1
VGA Card Onboard Intel ® HD Graphics
VGA Driver Intel ® HD Graphics ,Version:21.20.16.4526
LAN Card #1 Onboard Intel® I210 Gigabit Network Connection
LAN Driver #1 Intel® I210 Gigabit Network Connection ,Version:12.12.226.0
LAN Card #2 Onboard Intel® I210 Gigabit Network Connection #2
LAN Driver #2 Intel® I210 Gigabit Network Connection #2 ,Version:12.12.226.0
Audio Card Onboard Realtek High Definition Audio
Audio Driver Realtek High Definition Audio ,Version:6.0.1.7541
Chip Driver Intel® Chipset Device Software ,Version:10.1.1
USB 3.0 Driver Intel ® USB 3.0 eXtensible Host Controller – 1.0(Microsoft),Ver:10.0.14393.0
EC Version 70223T00 (02/23/2017)
CDROM BUFFALO DVSM-PC58U2V (USB-DVD)
Power Supply PLUTO-D3501PJ

NANO-6062
Copyright © Portwell 2017 NANO-6062 User's Guide 12
Power consumption(12V)
ATX:
Item Power ON Full Loading 10Min Full Loading 30Min
CPU +12V 1.1A 1.5A 1.5A
Device +12V 0.1A 0.1A 0.1A
CPU+ Device +12V 1.1A 1.5A 1.5A
USB 3.0 Loading Test 4.85 V/ 960 mA
2.4 Environmental Specifications
Storage Temperature : -40~85°C
Operation Temperature : 0~60°C
Storage Humidity : 5~90%
Operation Humidity: 10~90%

NANO-6062
Copyright © Portwell 2017 NANO-6062 User's Guide 13
3 Block Diagram


NANO-6062
Copyright © Portwell 2017 NANO-6062 User's Guide 14
4HardwareConfiguration
4.1 Jumpers and Connectors Figure 1,NANO-6062 Top View

NANO-6062
Copyright © Portwell 2017 NANO-6062 User's Guide 15



This chapter indicates jumpers, headers, and connector’s locations. Users may find useful information related to hardware settings in this chapter.
Figure 2,NANO-6062 Bottom View

NANO-6062
Copyright © Portwell 2017 NANO-6062 User's Guide 16
4.2 Jumper Settings
For users to customize NANO-6062’s features. In the following sections, Short means covering a jumper cap over jumper pins; Open or N/C (Not Connected)
means removing a jumper cap from jumper pins. Users can refer to Figure 1 for the Jumper allocations.
Jumper Table
The jumper settings are schematically depicted in this manual as follows:
Jump Function List:
JumpFunctionRemark
J1DCJack+12VInput
J2AudioJack(Line_out)
J3DP++Port
J4/J5RJ45Connector
J6USB3Connector
J7ExternalAudio(Mic+Line_in+Line_out)PinHDR. 4x2pinheader
J8FrontPanelPinHDR5x2pinheader
J9
V
GAPinHDR.5x2pinheader
J10RS232/422/485PinHDR 5x2pinheader
J11M.2keyESocket2230
J1280PortConnector10x2connector
J13
A
TX4PinConnector+12VInput
J14ExternalUSB3Connector

NANO-6062
Copyright © Portwell 2017 NANO-6062 User's Guide 17
J15BatterySocket 
J16mSATA/miniPCIESocket
J17DDR3SO‐DIMMSocket
J18GeneralPurposeI/OPinHDR5x2pinheader
J19LVDSConnector
J20BacklightConnector
J21SATAGEN3Connector
J22SATAPowerConnector
J23SDCardSocket
U10ECFlash
U11BIOSFlash











NANO-6062
Copyright © Portwell 2017 NANO-6062 User's Guide 18
JP1 : BKLTCTRL Signal Level Selection

JP2 : BKLTCTRL Signal Source Selection

JP3 : CMOS Clear

PINNo.SignalDescription
1‐2Short+3.3V★
2‐3Short+5V
PINNo.SignalDescription
1‐2ShortEC
2‐3ShortSOC★
PINNo.SignalDescription
1‐2ShortNormalOperation★
2‐3ShortClearCMOSContents

NANO-6062
Copyright © Portwell 2017 NANO-6062 User's Guide 19
JP5 : Power On Mode Selection

JP6: GPIO4~7 Voltage Output Level Selection

JP7 : PANEL Voltage Selection

PINNo.SignalDescription
1‐2ShortAT
2‐3ShortATX★
PINNo.SignalDescription
1‐2Short5V
2‐3Short3.3V★
PINNo.SignalDescription
1‐3ShortVCC3
3‐5ShortVCC5★
3‐4Short+12V

NANO-6062
Copyright © Portwell 2017 NANO-6062 User's Guide 20
JP8: BACKLIGHT Enable Voltage Level Selection

J7 : ExternalAudio Connector







PINNo.SignalDescription
1‐3,2‐45V,ActiveHigh★
1‐3,4‐612V,ActiveHigh
3‐5,2‐45V,ActiveLow
3‐5,4‐612V,ActiveLow
PINNo.SignalDescriptionPINNo.SignalDescription
1MIC_L2Line_in_L
3Ground4Line_in_R
5Line_out_L6Ground
7Line_out_R8MIC_R
