Posnet TRIO ONLINE Instruction manual

The POSNET TRIO ONLINE fiscal printer can be optionally
equipped with devices for wireless communication.
POSNET POLSKA S.A. as the manufacturer hereby states that
the following radio devices:
 POSNET MULTIPORT 2 EX BT expansion module,
 WiFi/BT TRIO adapter,
are conform with provisions of the 2014/53/EU directive. Full
text of the EU conformity declaration is available at:
http://www.posnet.com.
Full version of the manual is available at www.posnet.com.
This manual describes basic printer elements, installation of
standard controllers and connecting the printer to a computer.
Description of installation and configuration of controllers
(USB(NET)) for online connections has been described in the
Quick OnLine instruction attached to the package.
Exchanging paper
1
Press the open button so that the lid pops up.
2
Place the roll in the paper chamber. Paper's end should be placed
so that a couple of centimeters extends beyond the stalk.
3
Close the printer's lid.
Manual installation of controllers
Installation of printer's controllers ends with establishing a virtual COM
port to facilitate communication with a computer via USB. This is an
automatic process upon connecting the printer to a computer.
Installation can start by clicking with the right mouse key on the
controller's file featuring INF extension, and next selecting Install from
the menu.
Controllers are on a CD (it should be in the box with the printer) and the
most up-to-date version can be downloaded from the posnet.com
website.
Setting communication interface
Using [UP] / [DOWN] keys select from printer's menu:
„2 Konfiguracja” „2 Konfin. Połączeń” „1 Usługi PC”
„1 Interfejs PC” - each item should be confirmed with [OK].
1
2
Next, using the same keys select an interface (USB, TCP/IP).
3
If the POSNET protocol was selected specify standard of Polish
characters (Windows 1250, Latin 2 or Mazovia).
4
Confirm with [OK].
The printer will restart.
1
2
3
Document version 1.2

Posnet Trio
Online printer
Printer - computer
signal cable CD
Paper roll Service
Record
Quick OnLine
manual
Guarantee
certificate
Package content
Ports
POSNET TRIO ONLINE printer is equipped in:
 USB – power feeding, computer connection, online
connection,
 EXT – multiport interface to connect expansion modules
that a printer can be equipped in.
Ports in expansion modules
Expansion module I:
 RS232,
 multi-voltage drawer,
 USB feeder.
Expansion module II:
 Bluetooth,
 multi-voltage drawer,
 USB feeder.
Expansion module III:
 3 x USB host,
 2 x RS232,
 multi-voltage drawer,
 printer's power socket + feeder.
Control panel
POSNET TRIO ONLINE printer is equipped with operator's panel
allowing to perform basic operations such as device's configuration,
reports, and tests.
 Confirming the function chosen.
 Confirming data entered.
 When entering dates or numbers of daily reports to a
periodic/monthly report and when changing the time in
a printer, it is possible to change the entering position (to
the right).
 Starting/Shutting down the device.
 Cancelling a function choice and moving up the menu.
 Deleting errors.
 When entering dates or numbers of daily reports to a
periodic/monthly report and when changing the time in
a printer, it is possible to change the entering position (to
the left).
 It helps to choose a respective menu function - scrolling
up.
 Change of content in an item (zooming in).
 Paper sliding out.
 It helps to choose a respective menu function - scrolling
down.
 Change of content in an item (zooming out).
Client's/operator's display
POSNET TRIO ONLINE printer is equipped with operator's
panel allowing to perform basic operations such as device's
configuration, reports, and tests.
1
2
3
4
5
6
7
8
Current menu position.
1
2
It is displayed when the USB network card is active or a
device is connected but it is not configured. It is off upon
correct device configuration.
3
It presents Bluetooth connection (printers are equipped in
a Bluetooth module).
It lights when devices are paired.
4
It presents WiFi connection (printers are equipped in a
WiFi/Bluetooth module).
 It lights when a network connection happened.
 It blinks when WiFi is on but there is no network
connection.
5
It lights when:
 an error occurred in the sequence send from the
computer;
 an error or damage to the printer occurred;
 the printer is in OFF-LINE mode (the device is in the
menu);
 it blinks when WiFi is on but there is not network
connection.
6
Icons are displayed interchangeably:
When the printer fails to connect with the repository.
If updates are downloaded at the same time and
there is no connection to a repository.
When downloading updates.
7
Battery level.
8
Current time.
