Potter PVX-RM User manual
8830045 - REV B • 1/15 PAGE 1 OF 2
Potter Electric Signal Company, LLC • St. Louis, MO • Tech Support: 866-956-1211 / Customer Service: 866-572-3005 • www.pottersignal.com
PVX-RM
Voice Evacuation Remote Microphone
Description
The PVX-RM is a supervised remote microphone for use with the
PVX-25, 50, 100, 150 & 200 voice evacuation system. The microphone
provides crystal-clear live voice messages over the system speakers.
Ideal for use when the re alarm panels are in an electrical room, and
the annunciator and microphone are in the lobby.
The PVX-RM is perfectly suited for applications in gymnasiums,
nightclubs, auditoriums, churches, and other places of assembly.
Locate at control rooms, guard stations, and reception areas.
Up to 5 PVX-RM Panels may be connected to a single PVX-SC
Supervisory Card. This provides supervision of the wires to the
PVX-RM and they may be located up to 5000 feet away.
Housed in an attractive surface or semi-ush mounted backbox, with
a hinged locking door. The PVX-RM features dead front construction,
a microphone with a “Press-to-Talk” button, and discreet LEDs to
display “In-Use” and “Fault” status.
Application
In the normal (Standby) mode, announcements can be made from
any remote microphone at any time. Simply keying any remote
microphone will allow a manual paging message to be broadcast in an
“ALL-CALL” mode.
If multiple remote microphones are used, and two or more are
simultaneously keyed, then the rst microphone keyed will have
paging priority. The paging microphone in the master will always have
priority over any and all remote microphones. The PVX-RM can be
wired for general public address, and will be automatically disabled
on alarm.
In the alarm mode, the keying of any remote microphone will interrupt
any pre-recorded tone or message, and will allow manual voice
evacuation messages to take priority. When the microphone Press-
to-Talk key is released, the automatic pre-recorded voice evacuation
message (typically tone and voice) will be replayed from the start.
Technical Specications
Dimensions 8 x 10 x 3” (w x h x d)
Color Red (standard) Charcoal Grey (optional)
Features
• All-Call Remote Microphone
• Overrides alarm tone and automatic message
• Any number of remote microphones
• Dead Front Cover Construction
• Paging Microphone with Press to Talk Button
• “In-Use” and “Fault” LEDs.
• Supervised Wiring
• May be located up to 5,000 feet away from Voice Evac Panel.
6912-0328:0220S25376
PVX-RM Shown With Cabinet Door Removed
8830045 - REV B • 1/15 PAGE 2 OF 2
Potter Electric Signal Company, LLC • St. Louis, MO • Tech Support: 866-956-1211 / Customer Service: 866-572-3005 • www.pottersignal.com
PVX-RM
Voice Evacuation Remote Microphone
Typical Application of Remote Microphone
Ordering Information
Model Number Stock Number Description
PVX-RM 3510002 Remote Paging Microphone
Panel
PVX-SC 3510003 Remote Paging Microphone
Supervisory Card
In Use
Fault
RemoteMicrophone
PVX 25/50
Typical Application of Remote Microphone
5000 feet
Supervisory
Card
PVX-RM
PVX-SC
TB1
TB3 TB2
5
1
2
3
4
6
7
8
1
2
3
4
5
6
7
8
9
10
11
23456781 2 3456781
12 345678
Normal
Alarm
Trouble
System Status LEDs
6CONDUCTORS
SHIELDED
