Power AirFryer AF-530W User manual

When using electrical appliances, basic safety precautions should
always be followed. Do not use the Power AirFryerTM until you
have read this manual thoroughly.
Save These Instructions - For Household Use Only
Owner’s Manual
Guarantee Information Inside
MODEL: AF-530W

Before You Begin
It is very important that you read this entire manual,
ensuring that you are totally familiar with its operation
and precautions.
2Power AirFryer™ | Model: AF-530W

Power AirFryer™ | Model: AF-530W 3
Table of Contents
IMPORTANT SAFEGUARDS 4
Parts & Accessories 6
Using the Control Panel 8
Preset Button Cooking Chart 9
General Operating Instructions 10
Cooking Chart 12
Troubleshooting 13
Frequently Asked Questions 14
Cleaning & Storage 14
60-Day Guarantee 15

4Power AirFryer™ | Model: AF-530W
IMPORTANT SAFEGUARDS
When using electrical appliances, basic safety
precautions should always be followed, including:
• Before initial use, wipe the inside and outside of the
Unit with a warm, moist cloth and mild detergent.
Rinse with a warm, moist cloth. Handwash all
cooking accessories. Before cooking food, preheat
the Power AirFryer for a few minutes to allow
the Unit to burn off the manufacturer's protective
coating of oil. Wipe the Unit with warm, soapy
water and the cloth after the burn-in cycle.
• NEVER IMMERSE the Main Unit Housing, which
contains electrical components and heating
elements, in water. Do not rinse under the tap.
• TO AVOID ELECTRICAL SHOCK, DO NOT put liquid
of any kind into the Main Unit Housing containing
the electrical components.
• This appliance has a polarized plug (one blade is
wider than the other). To REDUCE THE RISK OF
ELECTRIC SHOCK, this plug is intended to fit into
a polarized outlet only one way. If the plug does
not fit fully into the outlet, reverse the plug. If it still
does not fit, contact a qualified electrician. DO NOT
ATTEMPT to modify the plug in any way.
• MAKE SURE the appliance is plugged into a wall
socket. Always make sure that the plug is inserted
into the wall socket properly.
• To prevent food contact with the heating elements,
DO NOT OVERFILL the Fry Basket.
• DO NOT COVER the Air Intake vent or Air Outlet
vent while the Power AirFryer is operating. Doing
so will prevent even cooking and may damage the
Unit or cause it to overheat.
• NEVER POUR oil or any other liquids into the Outer
Basket. Fire and personal injury could result.
• While cooking, the internal temperature of the Unit
reaches several hundred degrees Fahrenheit. TO
AVOID PERSONAL INJURY, never place hands
inside the Unit unless it is thoroughly cooled.
• This appliance is NOT INTENDED FOR USE by
persons with reduced physical, sensory, or mental
capabilities or a lack of experience and knowledge
unless they are UNDER THE SUPERVISION of a
responsible person or have been given proper
instruction in using the appliance. This appliance is
NOT INTENDED FOR USE by children.
• When cooking, DO NOT PLACE the appliance
against a wall or against other appliances. Leave at
least 5 in.free space on the back
and sides and above the appliance. Do not place
anything on top of the appliance.
• DO NOT USE this Unit if the plug, the Power Cable,
or the appliance itself is damaged in any way.
• DO NOT PLACE The Unit on stove top surfaces.
• If the Power Cable is damaged, YOU MUST HAVE
IT REPLACED by the manufacturer, its service
agent, or a similarly qualified person in order to
avoid hazard.
• Keep the appliance and its Power Cable OUT OF
THE REACH of children when it is in operation or in
the cooling process.
• KEEP THE POWER CABLE AWAY from hot
surfaces. DO NOT PLUG in the Power Cable or
operate the Unit controls with wet hands.
• NEVER CONNECT this appliance to an external
timer switch or separate remote-control system.
• NEVER USE this appliance with an extension
cord of any kind. A short power-supply cord
(or detachable power-supply cord) is provided
to reduce the risk of becoming entangled in or
tripping over a longer cord.
• DO NOT OPERATE the appliance on or near
combustible materials, such as tablecloths and
curtains.
• DO NOT USE the Power AirFryer for any purpose
other than described in this manual.
• NEVER OPERATE the appliance unattended.
• When in operation, air is released through the Air
Outlet vent. KEEP YOUR HANDS AND FACE at a
safe distance from the Air Outlet vent. Also avoid
the air while removing the Fry Basket from the
appliance.
• The Unit’s outer surfaces may become hot during
use. The Outer Basket and Fry Basket will be

Power AirFryer™ | Model: AF-530W 5
IMPORTANT SAFEGUARDS
hot. WEAR OVEN MITTS when handling hot
components or touching hot surfaces.
• Should the Unit emit black smoke, UNPLUG
IMMEDIATELY and wait for smoking to stop before
removing oven contents.
• DO NOT MOVE Sliding Button Guard forward until
Fry Basket and Outer Basket are resting on a level,
heat-resistant surface. Discontinue use if Sliding
Button Guard ever becomes detached from Unit.
• When time has run out, cooking will stop but the
fan WILL CONTINUE RUNNING for 20secs. to cool
down the Unit.
• Always operate the appliance on a horizontal
surface that is level, stable, and noncombustible.
• This appliance is intended for normal household
use only. It is not intended for use in commercial or
retail environments.
• If the Power AirFryer is used improperly or for
professional or semiprofessional purposes or if it is
not used according to the instructions in the user
manual, the guarantee becomes invalid and the
Tristar will not be held liable for damages.
• Always unplug the appliance after use.
• Let the appliance cool for approximately 30mins.
before handling, cleaning, or storing.
• Make sure the ingredients prepared in this Unit come
out cooked to a golden-yellow color rather than dark
or brown. Remove burnt remnants.
• The Power AirFryer is equipped with an internal micro
switch that automatically shuts down the fan and
heating element when the Outer Basket is removed.
SAVE THESE INSTRUCTIONS − FOR HOUSEHOLD USE ONLY
Electric Power
If the electrical circuit is overloaded with other appliances,
your new Unit may not operate properly. It should be
operated on a dedicated electrical circuit.
Overheating Protection
Should the inner temperature control system fail, the
overheating protection system will be activated and the
Unit will not function. Should this happen, unplug the
Power Cable. Allow time for the Unit to cool completely
before restarting or storing.
Automatic Shut-Off
The appliance has a built in shut-off device, that will
automatically shut down the Unit when the Timer LED
reaches zero. You can manually switch off the appliance by
selecting the Power Button. The fan will continue running
for 20secs. to cool down the Unit.
Electromagnetic Fields
This appliance complies with all standards regarding
electromagnetic elds. If handled properly and according
to the instructions in this user manual, the appliance is safe
to use based on scientic evidence available today.
This product can expose you to Bisphenol A, which is known
to the State of California to cause birth defects or other
reproductive harm. For more information, go to
www.P65Warnings.ca.gov.
For California Residents
Warning
Model Number Supply Power Rated Power Capacity Net Weight
AF-530W AC 120V 60Hz 1800W 5.3 qt. 12 lb

6Power AirFryer™ | Model: AF-530W
Parts & Accessories
1. FRY BASKET
2. SLIDING BUTTON GUARD
3. BASKET RELEASE BUTTON
4. EASY-GRIP HANDLE
5. OUTER BASKET
6. HOUSING
7. AIR INLET
8. CONTROL PANEL
9. AIR OUTLET
10. POWER CABLE
NOTE: Unpack all listed contents from
packaging. Contents vary by model.
Please remove any clear or blue protective
lm on the components before use.
NOTE: Please make sure that your Power AirFryer has been shipped with the components
that you ordered (some accessories may be sold separately). Check everything carefully before use.
If any part is missing or damaged, do not use this product. Contact Tristar using the customer service
number located in the back of the owner’s manual.
5
2
3
4
1
8
10
6 7 9

Power AirFryer™ | Model: AF-530W 7
Parts & Accessories
TOP VIEW FRONT VIEW BACK VIEW
The Sliding Button Guard helps to ensure you do not press
the Basket Release Button by accident. Pressing the Basket
Release Button causes the Outer Basket to separate from the Fry
Basket and may result in injury if not done on a level, heat-resistant
surface. Do not move Sliding Button Guard forward until the Fry
Basket and Outer Basket are resting on a level, heat-resistant
surface.
SLIDING BUTTON GUARD BASKET RELEASE BUTTON
Sliding Button
Guard & Basket
Release Button
Caution
Discontinue use if Sliding
Button Guard ever becomes
detached from Unit.

8Power AirFryer™ | Model: AF-530W
Using the Control Panel
711
12
4
6
8109
5
1 23

Power AirFryer™ | Model: AF-530W 9
Using the Control Panel
1. Power Button
Once the Outer Basket and Fry Basket
are properly placed in the Main Unit
Housing, the Power Icon will be illuminated.
Pressing the Power Button once will set
the Unit to a default cooking temperature
of 370° F and time of 15 mins. Pressing
the Power Button a second time will start
the cooking process. The Power Icon will
ash during the cooking process. Pressing
the Power Button during the cooking cycle
will turn the Unit off. The Blue Fan Icon will
continue to spin for 20 secs., and the Power
Icon will stop ashing.
2. Temperature Control Buttons
The + and − symbols enable you to increase
or decrease cooking temperature 10° F
at a time. Holding the button down will
rapidly change the temperature. Temperature
control range: 180° F–400° F. Please note in
default mode, once a Time and Temperature
has been selected, the Unit will automatically
begin the cooking process.
3. Timer Control Buttons
The + and - symbols enable you to increase
or decrease cooking time one minute
at a time. Holding the Button down will
rapidly change the time. Maximum cooking
time: 60 mins. Please note in default mode,
once a Time and Temperature has been
selected, the Unit will automatically begin
the cooking process.
4. Time and Temperature Display
This display will keep track of the
temperature and remaining cook time.
5. Blue Fan Icon
The spinning Blue Fan Icon will appear when
the Unit is turned on and will display for up
to 20 secs. after it is turned off. Please Note:
The Unit is only cooking when Power Icon is
ashing.
6–12. Cooking Presets
Seven Presets to choose from: French Fries,
Roast, Shrimp, Bake, Chicken, Steak,
and Fish.
Preset Button Temperature Time
6. French Fries 400° F (205° C) 18 mins.
7. Roast 350° F (175° C) 25 mins.
8. Shrimp 330° F (165° C) 8 mins.
9. Bake 310° F (155° C) 30 mins.
10. Chicken 360° F (182° C) 20 mins.
11. Steak 400° F (205° C) 12 mins.
12. Fish 350° F (175° C) 10 mins.
Preset Button
Cooking Chart
Once you are familiar
with the Unit, you may
want to experiment
with your own recipes.
You do not need to select
a Preset function.
Simply choose the time
and temperature that suit
your personal taste.

• Remove all the packaging material.
• Remove any stickers or labels from the Unit.
• Thoroughly clean the Fry Basket
and the Outer Basket with hot water, some
liquid detergent, and a nonabrasive sponge.
• Wipe the inside and outside of the Unit
with a moist cloth.
• Place the Unit on a stable, horizontal,
and level surface. Do not place the Unit
on a surface that is not heat resistant.
Ensure that the Unit is used in an area
with good air circulation and away from hot
surfaces and any combustible materials.
• Place the Fry Basket in the Outer Basket.
Slide the Fry Basket into the Unit until it
clicks into place. Note: The Unit will not
operate unless the Fry Basket is properly
inserted.
• The Power AirFryer cooks using hot air. Do
not fill the Fry Basket with oil or frying fat.
• Do not put anything on top of the Unit.
This disrupts the airflow and affects the
cooking results.
1. Plug the Unit into a grounded wall socket.
2. Push the Power Button.
3. Push the Temperature Increase and Decrease
Buttons to set the cooking temperature.
4. Push the Time Decrease Button to set
the cooking time to 3 mins. Push the Power
Button to preheat the Unit. Once the cooking
time finishes, the Unit is ready for use.
5. With the cooking time set to 0, carefully
pull the Outer Basket out of the Unit, place
the ingredients inside the Fry Basket
(Caution: Do not exceed the Maximum
line), connect the Fry Basket with the Outer
Basket, and slide the Outer Basket back
into the Unit.
6. Never use the Outer Basket without
the Fry Basket.
7. Always ensure that the Sliding Button Guard
covers the Basket Release Button whenever
the Outer Basket is inside the Unit and when
removing the Outer Basket from the Unit.
8. Do not touch the Outer Basket directly
because the Outer Basket becomes very hot
during operation. Only hold the Outer Basket
by its handle.
9. Push the Preset Button to choose
an appropriate preset cooking time
and temperature or push the Temperature
and Time Increase and Decrease Buttons
to choose an appropriate setting.
10. Push the Power Button to start cooking.
11. When you hear the timer beep, the set
cooking time has elapsed. Pull the Outer
Basket out of the Unit and place it on a heat-
resistant surface.
12. Check the food to see whether
the ingredients are cooked as desired.
If the food is not fully cooked, simply slide
the Outer Basket back into the Unit
and add a few minutes to the cooking time.
Using the Power AirFryer
Before First Use
10 Power AirFryer™ | Model: AF-530W
General Operating Instructions

To ensure even cooking, some foods require
shaking during the cooking process. Remove
the Outer Basket and Fry Basket from the Unit.
Gently shake the contents as needed and
place the Outer Basket back in Unit to continue
cooking. For heavier foods, separate the Fry
Basket from the Outer Basket before shaking.
CAUTION: The Outer Basket will be hot.
Wear an oven mitt during this procedure.
NEVER move the Sliding Button Guard while
shaking or you may press the Basket Release
Button accidentally. Use caution when shaking
the Basket because hot oil may drip from the
Basket.
1. Place the assembled Outer Basket and Fry
Basket on a heat-resistant surface.
2. Move the Sliding Button Guard forward
to expose Basket Release Button.
3. Press the Basket Release Button and gently
lift the Fry Basket.
4. Shake ingredients.
5. Place the Fry Basket in the Outer Basket
and return it to the Unit to finish cooking.
13. If the food is fully cooked, carefully pull out
the Outer Basket, press the Basket Release
Button, and lift the Fry Basket out of the
Outer Basket to remove the food. Do not
turn the Fry Basket upside down with the
Outer Basket still attached because any
excess oil that has collected on the bottom
of the pan will leak onto the ingredients.
14. Empty the Fry Basket into a bowl or onto
a plate. The Unit is instantly ready for
preparing more food.
Shaking
Tips
• Add oil to the ingredients for a crispy result.
• Foods that are smaller in size usually require a
shorter cooking time than larger ones.
• Large batches of food require a slightly longer
cooking time than small quantities.
• Adding a tablespoon of vegetable oil to fresh
potatoes is suggested for a crispier result.
When adding a little oil, do so just before
cooking.
• Snacks normally cooked in an oven can
also be cooked in the Power AirFryer.
• Use premade dough to prepare filled snacks
quickly and easily. Premade dough requires a
shorter cooking time than homemade dough.
• Place a baking tin or oven dish in the Fry
Basket when baking a cake or quiche
or when cooking fragile or stuffed foods.
• You can use the Power AirFryer to reheat
foods. Simply set the temperature to 300° F for
up to 10 mins.
Power AirFryer™ | Model: AF-530W 11
General Operating Instructions

12 Power AirFryer™ | Model: AF-530W
Cooking Chart
Food Item Min–Max Time Temperature Comments
Thin Frozen Fries 1 ¼–3 cups 15–16 mins. 400° F (200° C)
Thick Frozen Fries 1 ¼–3 cups 15–20 mins. 400° F (200° C)
Homemade Fries 1 ¼–3 ¼ cups 10–16 mins. 400° F (200° C) Add ½ tbsp. oil
Homemade Potato Wedges 1 ¼–3 ¼ cups 18–22 mins. 360° F (182° C) Add ½ tbsp. oil
Homemade Potato Cubes 1 ¼–3 cups 12–18 mins. 360° F (182° C) Add ½ tbsp. oil
Hash Browns 1 cup 15–18 mins. 360° F (182° C)
Potato Gratin 2 cup 15–18 mins. 400° F (200° C)
Steak ¼–1.1 lb 8–12 mins. 360° F (182° C)
Pork Chops ¼–1.1 lb 10–14 mins. 360° F (182° C)
Hamburger ¼–1.1 lb 7–14 mins. 360° F (182° C)
Sausage Roll ¼–1.1 lb 13–15 mins. 400° F (200° C)
Chicken Drumsticks ¼–1.1 lb 18–22 mins. 360° F (182° C)
Chicken Breast ¼–1.1 lb 10–15 mins. 360° F (182° C)
Spring Rolls ¼–¾ lb 15–20 mins. 400° F (200° C) Use oven-ready food
Frozen Chicken Nuggets ¼–1.1 lb 10–15 mins. 400° F (200° C) Use oven-ready food
Frozen Fish Sticks ¼–1.1 lb 6–10 mins. 400° F (200° C) Use oven-ready food
Mozzarella Sticks ¼–1.1 lb 8–10 mins. 360° F (182° C) Use oven-ready food
Stuffed Vegetables ¼–1.1 lb 10 mins. 320° F (160° C)
Cake 1 ¼ cups 20–25 mins. 320° F (160° C) Use baking tin
Quiche 1 ½ cups 20–22 mins. 360° F (182° C) Use baking tin/oven dish
Muffins 1 ¼ cups 15–18 mins. 400° F (200° C) Use baking tin
Sweet Snacks 1 ½ cups 20 mins. 320° F (160° C) Use baking tin/oven dish
Frozen Onion Rings 1 lb 15 mins. 400° F (200° C)

Power AirFryer™ | Model: AF-530W 13
Troubleshooting
Problem Possible Cause Solution
The Unit does
not work
1. The appliance is not plugged in.
2. You have not turned the Unit on
by setting the preparation time
and temperature.
1. Plug Power Cable into wall socket.
2. Press the Power Button. Select a Preset
or select Time and Temperature. Press the
Power Button again and cooking will begin.
Food not cooked 1. The Fry Basket is overloaded.
2. The temperature is set too low.
1. Use smaller batches for more even frying.
2. Raise temperature and continue cooking.
Food is not fried evenly 1. Some foods need to be shaken
during the cooking process.
1. See General Operations on page 10
of this manual.
White smoke coming
from Unit
1. Too much oil is being used.
2. Outer Basket has grease residue
from previous operation.
1. Wipe down to remove excess oil.
2. Clean the Outer Basket after each use.
French fries are
not fried evenly
1. Wrong type of potato being used.
2. Potatoes not rinsed properly during
preparation.
1. Use fresh, firm potatoes.
2. Use cut sticks and pat dry to remove
excess starch.
Fries are not crispy 1. Raw fries have too much water. 1. Dry potato sticks properly before misting
oil. Cut sticks smaller. Add a bit more oil.
Outer Basket won't
slide into Unit properly
1. Fry Basket is overloaded.
2. Fry Basket is not placed
in the Outer Basket correctly.
1. Do not fill the Fry Basket above the
maximum level.
2. Gently push Fry Basket into Outer Basket
until it clicks.
Error
Codes
Display Shown Possible Cause Solution
E1 Broken circuit of the thermal sensor Call Customer Service
E2 Short circuit of the thermal sensor Call Customer Service

Clean the Power AirFryer after each use. The Outer
Basket and the Fry Basket are coated with a special non-
stick surface. Never use abrasive cleaning materials
or utensils on these surfaces.
1. Remove the Power Cable from the wall socket
and be certain the appliance is thoroughly cooled
before cleaning. Note: Separating the Outer Basket
from the Fry Basket will allow them to cool quicker.
CAUTION: Do not move Sliding Button Guard forward
until Fry Basket and Outer Basket are resting
on a level, heat-resistant surface. Outer Basket will
separate from the Fry Basket and may cause injury.
2. Wipe the outside of the appliance with a warm, moist
cloth and mild detergent.
3. Clean the Outer Basket and the Fry Basket with hot
water, a mild detergent, and a nonabrasive sponge
NOTE: The Outer Basket and Fry Basket are
dishwasher safe.
TIP: Should Outer Basket and Fry Basket contain
difficult-to-remove food particles, leave the Fry Basket
and Outer Basket assembled, fill with hot, soapy water,
and soak for 10 mins.
4. Clean the inside of the appliance with hot water, a mild
detergent, and a nonabrasive sponge.
5. If necessary, remove unwanted food residue from
the heating element with a cleaning brush.
1. Unplug the appliance and let it cool down thoroughly.
2. Make sure all components are clean and dry.
3. Place the appliance in a clean, dry place.
Cleaning
Storage
14 Power AirFryer™ | Model: AF-530W
Frequently Asked Questions
1. Can I prepare foods other than fried dishes
with my Power AirFryer?
You can prepare a variety of dishes including steaks,
chops, burgers, and baked goods.
See the Power AirFryer Recipe Guide.
2. Is the Power AirFryer good for making
or reheating soups and sauces?
Never cook or reheat liquids in the Power AirFryer.
3. Is it possible to shut off the Unit at any time?
Pressing the Power Button during any cooking cycle
will cancel the cooking cycle and shut off the Power
AirFryer.
4. What do I do if the Unit shuts down while cooking?
As a safety feature, the Power AirFryer has an
Auto Shut-Off device that prevents damage from
overheating. Remove the Outer Basket and set it
on a heat-resistant surface. Allow the Unit to cool.
Remove the Power Cable from the outlet.
Restart using the Power Button.
5. Does the Unit need time to heat up?
If you are cooking from a cold start, add 3 mins.
to the cook time.
6. Can I check the food during the cooking process?
Removing the Outer Basket during the cooking
process will pause the cooking cycle. During this time,
you can shake the contents in the Outer Basket if
needed to ensure even cooking. Returning the Outer
Basket to the Unit will resume the cooking cycle.
7. Is the Power AirFryer dishwasher safe?
Only the Fry Basket and the Outer Basket
are dishwasher safe. The Unit itself containing
the heating coil and electronics should never be
submersed in liquid of any kind or cleaned with
anything more than a hot, moist cloth or nonabrasive
sponge with a small amount of mild detergent.
8. What happens if the Unit still does not work after
I have tried all the troubleshooting suggestions?
Never attempt a home repair. Contact Tristar and
follow the procedures set forth by the guarantee.
Failure to do so could render your guarantee null and
void.
9. What is the purpose of the Sliding Button Guard?
The Sliding Button Guard helps to ensure you do not
press the Basket Release Button accidentally. Pressing
the Basket Release Button causes the Outer Basket
to separate from the Fry Basket and may result
in injury if not done on a level, heat-resistant surface.

Power AirFryer™ | Model: AF-530W 15
60-Day Money-Back Guarantee
If you decide that you don’t love this product, your order is covered by our 60-Day Money-
Back Guarantee. You have 60 days from the day you receive your product to request
a replacement product or refund of the purchase price minus processing and handling fees.
To receive a refund or replacement, you must return the product to us at your expense.
To return the product, call customer service at 1-973-287-5197 and request a return
merchandise authorization number. Pack the product carefully and include in the package
a note with (1) your name, (2) mailing address, (3) phone number, (4) email address,
(5) reason for return, and (6) proof of purchase or order number, and (7) specify on
the note whether you are requesting a refund or replacement. Write the return merchandise
authorization number on the outside of the package.
Send the product to the following return address:
Power AirFryer
Tristar Products
500 Returns Road
Wallingford, CT 06495

We are very proud of the design and quality
of our Power AirFryerTM .
This product has been manufactured to the highest standards.
Should you have any questions, our friendly customer service
staff is here to help you.
973-287-5197
Distributed by:
Tristar Products, Inc.
Faireld, NJ 07004
© 2018 Tristar Products, Inc.
Made in China
PAF-5QT_IB_TP_ENG_V1_181120
