Power Fist 8344103 User manual

User Manual
Please read and understand all instructions before use.
Retain this manual for future reference.
8344103
3/8 in. dr
Composite
Air Ratchet
V 2.0

8344103
3/8 in. dr
Composite
Air Ratchet
V 2.0
3
Visit www.princessauto.com for more information
SPECIFICATIONS
Drive Size 3/8 in.
Air Consumption @ 90 PSI 3 CFM
Max. Torque 50 ft-lb
No Load Speed 175 RPM
Housing Material Composite
Exhaust Style Swivel
Max. Pressure 90 PSI
Air Inlet 1/4 in. NPT
INTRODUCTION
The Powerfist 3/8 in. Composite Air Ratchet is designed to handle all types of repair or assembly
applications. This tool is ergonomically designed for comfort and easy use.
SAFETY
IMPORTANT SAFETY PRECAUTIONS
WARNING! Read and understand all instructions before using this tool. The operator must follow basic
precautions to reduce the risk of personal injury and/or damage to the equipment. Before allowing
someone else to use this tool, make sure they are aware of all safety information.
NOTE: Keep this manual for safety warnings, precautions, operating, inspection and maintenance
instructions.

3/8 in. dr Composite Air Ratchet
4For technical questions call: 1-800-665-8685
8344103V 2.0
WORK AREA
1. Operate in a safe work environment. Keep your work area clean and well lit.
2. Do not use in the presence of flammable gases or liquids.
3. Keep anyone not wearing the appropriate safety equipment away from the work area.
4. Minimize distractions in the work environment. Distractions can cause you to lose control of the
tool.
5. Store tools properly in a safe and dry location to prevent rust or damage.
6. Always lock up tools and keep them out of the reach of children.
PERSONAL SAFETY
CAUTION! Wear protective equipment approved by the Canadian Standards Association (CSA) or
American National Standards Institute (ANSI) when using the tool.
1. Head Protection
a. Always wear impact safety goggles that provide front and side protection for the eyes.
b. Wear earplugs if the power tool or work environment is noisy.
2. Gloves
a. The gloves should provide protection based on the work materials.
b. Wear suitable gloves to reduce the effects of vibration.
3. Control the tool, personal movement and the work environment to avoid personal injury or
damage to tool. Stay alert, watch what you are doing and use your common sense.
a. Keep articles of clothing, jewelry, hair, etc., away from moving parts to avoid entanglement
with a tool.
b. Do not operate any machine/tool when tired or under the influence of drugs, alcohol or
medications.
c. Do not overreach when operating a tool. Proper footing and balance enables better control
of a tool in unexpected situations.
d. Use clamps or other practical ways to support or secure the work piece to a stable
platform. Holding the work piece by hand or against your body is not stable and may lead
to loss of control and injury.
AIR TOOL PRECAUTIONS
1. Air tools produce more noise than their electric counterparts. Extended exposure to this noise
may cause hearing loss.
a. Wear ear protection gear to eliminate or reduce the noise.
b. If possible add a muffling device to the air tool’s exhaust.

3/8 in. dr Composite Air Ratchet
5
Visit www.princessauto.com for more information
8344103 V 2.0
2. Do not operate this tool if the air hose is damaged.
a. Inspect the tool’s air line for cracks, fraying or other faults before each use.
b. Discontinue use if a hissing can be heard from the air line or connectors while operating
the tool.
c. Take the following steps if either of the above situations occur:
i. Tag or mark the tool as “defective” or “out of service” until repaired.
ii. Contact a qualified person repair or replace the defective component/hose.
3. Prevent damage to air hose by observing the following:
a. Never use the hose to carry the tool.
b. Keep the air hose of the tool and the tool’s work path while in operation. The hose should
always stay behind the tool.
c. Keep the hose away from heat, oil, sharp edges or moving parts.
d. Do not allow people, mobile equipment or vehicles to pass over unprotected air hose.
i. Position air hose away from traffic areas.
ii. Place hose in reinforced conduit.
iii. Place planks on either side of the hose to create a protective trench.
e. Do not wrap hose around the tool as sharp edges may pierce the hose or cause cracks if
wound too tight. Gently coil the hose and either hang on a hook or fasten with a device to
keep hose together when storing.
4. An air hose under pressure that is damaged or disconnected from an air tool may whip around
and cause damage to the work area or personal injury. Secure the compressor’s air hose to a
fixed or permanent structure with clamps or cable ties.
VIBRATION PRECAUTIONS
1. This tool vibrates during use. Repeated or long-term exposure to vibration may cause
temporary or permanent physical injury, particularly to the hands, arms and shoulders.
2. Anyone using vibrating tools regularly or for an extended period should first be examined by
a doctor and then have regular medical check ups to ensure medical problems are not being
caused by or worsened from tool use.
3. If you feel any medical symptoms related to vibrations (such as tingling, numbness, and white
or blue fingers), seek medical attention as soon as possible.
4. DO NOT use this tool if one of the following applies:
a. Pregnant
b. Impaired blood circulation to the hands
c. Past hand injuries
d. Nervous system disorders
e. Diabetes
f. Raynaud’s Disease

3/8 in. dr Composite Air Ratchet
6For technical questions call: 1-800-665-8685
8344103V 2.0
5. Do not smoke while operating the tool. Nicotine reduces the blood flow to the hands and
fingers, increasing the risk of vibration-related injury.
6. Wear suitable gloves to reduce the effects of vibration.
7. Use the tool with the least amount of vibration, when there is a choice between different
processes.
8. Do not use for extended periods. Take frequent breaks to when using this tool.
9. Let the tool do the work. Grip the tool as lightly as possible (while still keeping safe control of
it).
10. To reduce vibrations, maintain the tool as explained in this manual. If abnormal vibrations
occur, stop using this tool immediately.
SPECIFIC SAFETY PRECAUTIONS
WARNING! Immediately switch off the tool if any of the following occurs:
• The switch or trigger is broken.
• The tool will not shut off on it own. Disconnect from air source.
• The user sees or smells smoke.
• The user smells the odor of scorched insulation
WARNING! Some dust created by power sanding, spraying, blowing, sawing, grinding, drilling
and other construction activities contains chemicals known to cause cancer, birth defects, and/or
other reproductive harm. Reduce your exposure to these chemicals by wearing appropriate safety
equipment such as dust masks designed to filter out microscopic particles. Avoid inhaling vapours
and dust. Wash hands thoroughly after using this tool.
1. Do not use hand sockets with this tool as they can shatter.
a. Only use impact sockets in good condition.
2. Always use the simplest hook-up possible.
a. Long extension bars and adapters absorb power and can break.
3. Use deep sockets wherever possible.
4. Do not operate this tool when it is not securely attached to the workpiece.
5. Serious injury can result from over torqued or under torqued fasteners.
a. Released assemblies can become dangerous projectiles.
b. Check all assemblies requiring a specific torque setting with a torque wrench.
NOTE: Using a ‘click’ torque wrench does not check for potentially dangerous over-torqued
conditions.

3/8 in. dr Composite Air Ratchet
7
Visit www.princessauto.com for more information
8344103 V 2.0
6. An additional support handle or absorption bar may be needed to resist torque reaction.
a. Position any support handles or absorption bars correctly to avoid injury.
7. Do not exceed an air pressure rating of 90 PSI when using this tool.
TOOL USE AND CARE
1. Use the correct tool for the job. Do not force a tool or attachment to do the work of a larger
industrial tool. Maximize tool performance and safety by using the tool for its intended task.
2. This tool was designed for a specific function. Do not modify or alter this tool or use it for an
unintended purpose.
3. Securely hold this tool using both hands, unless it is designed for single hand use. Using a tool
with only one hand can result in loss of control.
4. Maintain tools with care (see Maintenance).
5. Remove adjusting keys and wrenches from the tool before operation or connecting it to a power
source. A wrench or key that is left attached to a rotating part of the tool increases the risk of
personal injury.
6. Avoid unintentional starts. Be sure that the throttle/ignition switch is in the neutral or OFF
position when not in use and before connecting it to any power source.
7. Do not carry the tool with fingers near or on the trigger/switch.
AIR COMPRESSOR
Ensure the compressor used with the tool can supply the required Cubic Feet per Minute at the required
PSI (see Specifications).
1. Use proper size and type of air pressure line and fittings.
2. Use only clean, dry, regulated compressed air at the rated range as marked on the tool.
CAUTION! Do not use an air source other than an air
compressor to power this tool.
3. Always use an air regulator, an in-line filter and a
moisture trap in your compressed air system. These
accessories will increase the tool’s life and keeps the
tool in good working condition. See the diagram for
recommended components of an air line.

3/8 in. dr Composite Air Ratchet
8For technical questions call: 1-800-665-8685
8344103V 2.0
4. Avoid using an air hose that is too long. The longer the hose, the lower the pressure that
reaches the tool, possibly causing it to cease functioning. As well, a longer hose can become a
tripping hazard.
5. Air tool CFM consumption ratings are based upon a 25% duty cycle. If you require continuous
duty, a larger compressor is required.
AIR SOURCE INSTALLATION
WARNING! Never use pure oxygen, carbon dioxide, combustible gases or any bottled gas as an air
source for a tool. Such gases are capable of causing an explosion and serious injury to persons.
1. Set the air pressure regulator on the air compressor to the recommended PSI level (see
Specifications). Do not exceed the tool recommended air pressure. Excess pressure could
result in damage to the tool, to your workpiece or serious injury.
2. Prepare a standard 1/4 in. air connector for use with your tool. Wrap the threaded portion of
the air connector with thread seal tape. Wrap in a clockwise direction so it will not unravel when
attaching to a quick connector. Attach it to the tool air inlet and tighten.
3. Attach a standard quick connector to the air source’s hose. Attach the air hose to the tool’s air
connector.
4. Check the air line and its connections for air leaks. Do not use the tool until you have repaired
all air leaks.
DISCONNECTING AIR SOURCE
WARNING! Failure to follow these steps could result in severe injury, tool or property damage.
Disconnect tool from air source before cleaning, servicing, changing parts/accessories or when not in
use.
1. Turn the air regulator to the OFF or L position.
2. Turn off the air compressor.
3. Disconnect the air pressure hose.
4. Discharge any residual pressure inside the tool.
AIR TOOL LUBRICATION
CAUTION! NEVER use a penetrating oil to lubricate the tool. Penetrating oil may act as a solvent that
will break down the grease and cause the tool to seize up.

3/8 in. dr Composite Air Ratchet
9
Visit www.princessauto.com for more information
8344103 V 2.0
1. All air tools are packed in grease to prevent corrosion of internal parts during shipping and
storage. We recommend you clean this out to have optimum performance from your new air
tool. Add a generous amount of air tool oil in the air inlet, and then run the tool under no load
until exhaust is clear to remove packing grease.
2. It is very important that the tool is lubricated. Without lubrication, the tool will not work
properly and parts will wear prematurely. Manually adding a drop or two of air tool oil into the
tool’s male connector once a day is better than using an automatic in-line lubricator. In-line
lubricators should only be required when there are multiple users of the same tool.
3. Air tool oil is the only recommended lubricant for use in all air tools. Do not use other types
of lubricants to oil your tools. Using the wrong lubricant will cause premature tool failure and/
or loss of power. Substitutes may harm the rubber compounds in the tool’s O-rings and other
seals.
4. Keep the airline lubricator filled and correctly adjusted. The in-line lubricator should be regularly
checked and filled with air tool oil. Proper adjustment of the in-line lubricator is performed by
placing a sheet of paper next to the exhaust ports and holding the throttle open approximately
30 seconds. The lubricator is properly set when a light stain of oil collects on the paper.
Excessive amounts of oil should be avoided.
5. Avoid adding too much air tool oil during normal use. Too much oil can cause premature power
loss and eventual tool failure. The tool will need to be taken apart by a qualified technician and
cleaned of excess oil.
6. In the event that it becomes necessary to store the tool for an extended period of time
(overnight, weekend, etc.), it should receive a generous amount of lubrication at that time.
The tool should be run for approximately 30 seconds to ensure oil has been evenly distributed
throughout the tool. The tool should be stored in a clean and dry environment.
UNPACKING
1. Carefully remove the parts and accessories from the box. Retain packaging material until you
have carefully inspected and satisfactorily installed or operated the tool.
2. Make sure that all items in the parts list are included.
3. Inspect the parts carefully to make sure the tools and accessories were not damaged while
shipping.
WARNING! Do not operate the tool if any part is missing. Replace the missing part before operating.
Failure to do so could result in a malfunction and serious personal injury.

3/8 in. dr Composite Air Ratchet
10 For technical questions call: 1-800-665-8685
8344103V 2.0
OPERATION
1. Clean the air hose of accumulated dust and moisture before connecting the tool to the air
supply.
a. An in-line filter-regulator-lubricator installed as close to the tool as possible is
recommended for this task.
2. Supply the tool with 90 PSI of clean, dry air. Connect the tool to the air line as per the diagram
in section AIR COMPRESSOR.
3. Squeeze the Lever (#13) to operate the tool. Heed all safety warnings found in this manual.
MAINTENANCE
CAUTION! Ensure that the air line is shut off and drained of air before removing the tool for service or
changing accessories. This will prevent accidental operation of the tool.
1. Maintain the tool with care. A tool in good condition is efficient, easier to control and will
prevent unnecessary problems.
2. Keep the tool handles clean, dry and free from oil/grease at all times.
3. Follow instructions for lubricating and changing accessories.
4. Inspect the tool fittings periodically. Have damaged or worn components repaired or replaced
by an authorized technician.
5. Inspect the tool fittings, alignment and hoses and power supply cord and components
periodically. Have damaged or worn components repaired or replaced by an authorized
technician.
6. Maintain the tool’s label and name plate. These carry important information. If unreadable or
missing, contact Princess Auto Ltd. for replacements.
CAUTION! Only qualified service personnel should repair the tool.
LUBRICATION
Only use the lubricants supplied with the tool or specified by the manufacturer. Other lubricants may not
be suitable and may damage the tool or cause a malfunction during use.
CAUTION! NEVER use a penetrating oil to lubricate. Penetrating oils can act as a solvent that will
break down the grease and may cause the tool to seize up.
1. Use an air line lubricator with air tool oil adjusted to two (2) drops per minute.
2. If an air line lubricator cannot be used, add air motor oil to the inlet once per day.

3/8 in. dr Composite Air Ratchet
11
Visit www.princessauto.com for more information
8344103 V 2.0
3. Once a month, lubricate the drive bushing and the ratchet yoke with a high quality bearing
grease.
4. Periodically remove, clean and re-grease the ratchet head assembly. How often this should be
done depends on the frequency of use.
STORAGE
When not in use for an extended period, apply a thin coat of lubricant to the steel parts to avoid rust.
Remove the lubricant before using the tool again.
DISPOSING OF TOOL
If your tool has become damaged beyond repair, do not throw it out. Bring it to the appropriate recycling
facility.
TROUBLE SHOOTING
If the tool does not function properly or if it is missing parts, contact Princess Auto Ltd. for a solution. If
unable to do so, have a qualified technician service the tool.
Problem(s) Possible cause(s) Suggested solution(s)
Tool runs at normal speed but
loses power under load.
Motor parts worn Have a qualified technician
replace worn parts.
Lack of air tool oil. Pour air tool oil into air inlet per
instructions.
Tool runs slowly. Air flows
slightly from exhaust.
Motor parts jammed with dirt
particles.
1. Check air inlet filter for
blockage.
2. Pour air tool oil into air inlet
as per instructions.
3. Operate tool in short bursts
quickly reversing rotation
back and forth where
applicable.
4. Disconnect air supply. Free
motor by rotating drive
shank manually where
applicable.
5. Repeat above as needed. If
this fails, bring to service
centre.

3/8 in. dr Composite Air Ratchet
12 For technical questions call: 1-800-665-8685
8344103V 2.0
Problem(s) Possible cause(s) Suggested solution(s)
Air flow blocked by dirt. Excessive air tool oil in tool or
buildup of shipping grease.
Run tool under no load for short
periods of time until exhaust
clears.
Tool will not run. Air flows freely
from exhaust.
O-rings throttle valve dislodged
from seat inlet valve.
Have a qualified technician
replace the O-ring.
Damage to, or excessive wearing
of internal parts.
Bring to service centre.
Tool will not shut off. O-rings throttle valve dislodged
from seat inlet valve.
Have a qualified technician
replace the O-ring.
Loss of power or erratic
performance.
Excessive drain on the air line. Check the air supply. Ensure the
tool is connected to the proper
diameter air hose with no kinks
or restrictions and that the
fittings are connected properly.
Moisture or restriction in the air
hose.
Incorrect size or type of hose
connectors.
Air compressor has insufficient
flow.
Ensure that the tool is
connected to a compressor that
has a rated flow matching the
tool.

3/8 in. dr Composite Air Ratchet
13
Visit www.princessauto.com for more information
8344103 V 2.0
PARTS BREAKDOWN

3/8 in. dr Composite Air Ratchet
14 For technical questions call: 1-800-665-8685
8344103V 2.0
PARTS LIST
No. DESCRIPTION QTY.
1. Screw 1
2. O-Ring (P12) 1
3. O-Ring (P8) 2
4. Air Regulator 1
5. Spring 1
6. Valve Stem Bushing 1
7. Valve Stem 1
8. O-Ring (3.5 x 1.4) 1
9. Air Inlet 1
10. Exhaust Sleeve 1
11. O-Ring (26.7 x 1.78) 1
12. Spring Pin 1
13. Lever 1
14. Protecting Rubber 1
15. Housing 1
16. Bearing 1
17. Rear Plate 1
18. Pin 2
19. Rotor Blade 4
20. Rotor 1
21. Cylinder 1
22. Cone Muffler 1
23. Front Plate 1
24. Bearing (608ZZ) 1
25. Washer 1
No. DESCRIPTION QTY.
26. Thread Ring Gear (41T) 1
27. Gear (16T) 2
28. Idler Gear Pin 2
29. Idler Gear Plate 1
30. Clamp Nut 1
31. Bushing 1
32. Needle Bearing 1
33. Ratchet Housing 1
34. Crankshaft 1
35. Drive Bushing 1
36. Ratchet Yoke 1
37. Pin 1
38. Ratchet Pawl 1
39. Lock Pin 1
40. Spring 1
41. Reverse Button 1
42. Ratchet Anvil (3/8 in.) 1
43. Wave Washer 1
44. Washer 1
45. Retainer Ring 1
46. Bearing (6001Z) 1
47. Bearing (6000ZZ) 1
48. Spring 2
49. Pin 2

8344103
Manuel d'utilisateur
Clé à cliquet
pneumatique en
composite de 3/8 po
Vous devez lire et comprendre toutes les instructions avant d'utiliser l'appareil.
Conservez ce manuel afin de pouvoir le consulter plus tard.
V 2,0

3Visitez www.princessauto.com pour plus d'informations
8344103
Clé à cliquet
pneumatique en
composite de 3/8 po
V 2,0
SPÉCIFICATIONS
Taille de prise 3/8 po
Consommation d’air à 90 lb/po carré 3 pi cubes/min
Couple max. 50 lb·pi
Vitesse à vide 175 tr/min
Matériau du boîtier Composite
Type d’échappement Pivotant
Pression max. 90 lb/po carré
Entrée d’air 1/4 po NPT
INTRODUCTION
Le cliquet pneumatique composite Powerfist de 3/8 po a été conçu pour réaliser tous les types de
réparation ou d’assemblage. Cet outil est doté d’une conception ergonomique à des fins de confort et
d’utilisation facile.
SÉCURITÉ
CONSIGNES DE SÉCURITÉ IMPORTANTES
AVERTISSEMENT ! Lisez et assurez-vous de comprendre toutes les instructions avant d’utiliser cet
outil. L’utilisateur doit respecter les précautions de base afin de réduire le risque de blessure et/ou de
dommage à l’équipement. Avant de permettre à une autre personne d’utiliser cet outil, assurez-vous
qu’elle est au courant de toutes les consignes de sécurité.
REMARQUE : Conservez ce manuel qui contient les avertissements de sécurité, les précautions, les
instructions de fonctionnement, d’inspection et d’entretien.

Clé à cliquet pneumatique en composite à prise de 3/8 po
4En cas de questions techniques, appelez le 1-800-665-8685
8344103
V 2,0
AIRE DE TRAVAIL
1. Travaillez dans un environnement de travail sécuritaire. Gardez votre aire de travail propre et
bien éclairée.
2. N’utilisez pas d’outils électriques en présence de gaz ou de liquides inflammables.
3. Assurez-vous que les personnes qui ne portent pas l’équipement de sécurité approprié ne se
trouvent pas à proximité de l’aire de travail.
4. Minimisez les distractions au sein de l’environnement de travail. Les distractions peuvent
causer une perte de contrôle de l’outil.
5. Rangez les outils correctement dans un lieu sécurisé et sec pour empêcher la rouille ou les
dommages.
6. Gardez toujours les outils dans un endroit verrouillé et hors de la portée des enfants.
SÉCURITÉ PERSONNELLE
ATTENTION ! Portez de l’équipement de protection homologué par l’Association canadienne de
normalisation (CSA) ou l’American National Standards Institute (ANSI) quand vous utilisez l’outil.
1. Protection de la tête
a. Portez toujours des lunettes antiprojections qui offrent une protection frontale et latérale
pour les yeux.
b. Portez des bouchons d’oreilles si l’outil électrique ou l’environnement de travail est
bruyant.
2. Gants
a. Les gants doivent protéger en fonction des matériaux travaillés.
b. Portez des gants appropriés pour réduire les effets des vibrations.
3. Gardez le contrôle de l’outil, de vos mouvements et de l’environnement de travail pour éviter
les blessures ou le bris de l’outil. Restez alerte, portez attention à vos gestes et faites preuve de
bon sens.
a. Tenez les vêtements, les bijoux, les cheveux, etc. à l’écart des pièces mobiles pour éviter
q’elles ne se coincent dans l’outil.
b. N’utilisez pas d’appareils ou d’outils si vous êtes fatigué ou sous l’effet de drogues,
d’alcool ou de médicaments.
c. N’utilisez pas l’outil si vous devez étirer les bras pour vous en servir. Une stabilité et un
équilibre appropriés sont nécessaires afin d’avoir un meilleur contrôle de l’outil en cas de
situations inattendues.
d. Utilisez des pinces ou un autre moyen pratique pour fixer la pièce à travailler sur une plate-
forme stable. Une pièce à travailler tenue dans les mains ou appuyée contre le corps n’est
pas stable et risque d’entraîner une perte de contrôle et des blessures.
PRÉCAUTIONS RELATIVES AUX OUTILS PNEUMATIQUES
1. Les outils pneumatiques produisent plus de bruit que leurs semblables électriques. L’exposition
prolongée à ce bruit peut causer la perte auditive.
a. Portez une protection d’oreille afin d’éliminer ou de réduire le bruit.
b. Si c’est possible, ajoutez un dispositif au niveau de l’échappement de l’outil pneumatique
pour assourdir le bruit.

Clé à cliquet pneumatique en composite à prise de 3/8 po
5
Visitez www.princessauto.com pour plus d'informations
8344103 V 2,0
2. N’utilisez pas cet outil si le tuyau à air est endommagé.
a. Inspectez le tuyau d’air de l’outil pour déceler des fissures, des effilochures et tout autre
défaut avant chaque utilisation.
b. Arrêtez l’utilisation si un sifflement se fait entendre provenant du tuyau à air ou des
connecteurs pendant le fonctionnement de l’outil.
c. Si une des situations décrites ci-dessus se produit, prenez les mesures suivantes :
i. Attachez sur l’outil une étiquette indiquant qu’il est « défectueux » ou qu’il est « hors
service », jusqu’à ce qu’il soit réparé.
ii. Contactez une personne qualifiée pour réparer ou remplacer le composant/tuyau
défectueux.
3. Prévenez les dommages au tuyau à air en respectant les consignes suivantes :
a. Ne transportez jamais l’outil en le tenant par le tuyau.
b. Maintenez le tuyau à air à l’écart de l’outil et de la zone de travail de l’outil pendant son
utilisation. Le tuyau doit toujours se trouver derrière l’outil.
c. Gardez le tuyau à l’écart des sources de chaleur, de l’huile, des rebords coupants ou des
pièces mobiles.
d. Veillez à ce que ni des personnes, ni du matériel mobile, ni des véhicules n’écrasent un
tuyau à air non protégé.
i. Disposez le tuyau à air loin des zones d’achalandage.
ii. Placez le tuyau dans le boîtier renforcé.
iii. Placez des planches de chaque côté du tuyau pour créer un couloir protecteur.
e. N’enroulez pas le tuyau autour de l’outil car les bords tranchants risquent de percer le
tuyau ou causer des fissures s’il est enroulé trop serré. Enroulez délicatement le tuyau et
suspendez-le à un crochet ou attachez-le sur un support pour qu’il reste enroulé pendant
son rangement.
4. Un tuyau à air sous pression endommagé ou débranché d’un outil pneumatique peut se
comporter de la même façon qu’un fouet et endommager ainsi l’aire de travail ou entraîner des
blessures corporelles. Fixez le tuyau à air du compresseur à une structure fixe ou permanente
au moyen de brides ou d’attache-câbles.
PRÉCAUTIONS RELATIVES AUX VIBRATIONS
1. Cet outil vibre pendant son usage. Une exposition répétitive ou prolongée aux vibrations peut
causer des blessures temporaires ou permanentes, surtout aux mains, aux bras et aux épaules.
2. Toute personne qui utilise des outils vibrateurs sur une base régulière ou durant des périodes
prolongées doit d’abord consulter un médecin et se prêter régulièrement à des examens de
santé pour s’assurer que des problèmes médicaux ne sont pas causés ou aggravés par l’usage
de tels outils.
3. Si vous ressentez des symptômes reliés aux vibrations (comme un fourmillement, un
engourdissement, des doigts blancs ou bleus), consultez un médecin le plus tôt possible.
4. N’utilisez PAS cet outil si vous avez une des conditions suivantes :
a. Grossesse
b. Mauvaise circulation sanguine aux mains
c. Blessures antérieures aux mains
d. Troubles neurologiques
e. Diabète
f. Maladie de Raynaud

Clé à cliquet pneumatique en composite à prise de 3/8 po
6En cas de questions techniques, appelez le 1-800-665-8685
8344103
V 2,0
5. Ne fumez pas pendant que vous utilisez cet outil. La nicotine réduit la circulation sanguine vers
les mains et les doigts et augmente le risque de blessure reliée aux vibrations.
6. Portez des gants appropriés pour réduire les effets des vibrations.
7. Utilisez l’outil qui produit le moins de vibration possible si vous pouvez choisir entre différents
processus.
8. N’utilisez pas l’outil pendant des périodes prolongées. Prenez souvent des pauses lorsque vous
utilisez cet outil.
9. Laissez l’outil faire le travail. Tenez l’outil le moins serré possible (tout en le contrôlant de
manière sécuritaire).
10. Pour réduire les vibrations, entretenez l’outil selon les directives figurant dans ce manuel. En
cas de vibrations anormales, cessez d’utiliser cet outil immédiatement.
CONSIGNES DE SÉCURITÉ SPÉCIFIQUES
AVERTISSEMENT ! Arrêtez l’outil immédiatement si une des conditions suivantes se produit :
• L’interrupteur ou la gâchette est brisé.
• L’outil ne s’arrête pas de lui-même. Débranchez-le de la source d’air.
• L’utilisateur voit ou sent de la fumée.
• L’utilisateur sent une odeur d’isolant qui roussit.
AVERTISSEMENT ! Certaines poussières créées par le ponçage à l’aide d’un outil électrique, la
pulvérisation, l’évacuation, le sciage, le meulage, le perçage et d’autres activités de construction
contiennent des produits chimiques qui peuvent causer le cancer, des anomalies congénitales et/
ou d’autres troubles reproductifs. Réduisez votre exposition à ces produits chimiques en portant
un équipement de sécurité approprié, comme un masque antipoussières conçu pour filtrer les
particules microscopiques. Évitez d’inhaler les vapeurs et les poussières. Lavez-vous les mains après
l’utilisation de cet outil.
1. N’utilisez pas de douilles à main avec cet outil, car elles risquent de se briser.
a. N’utilisez que des douilles à chocs en bon état.
2. Utilisez toujours le raccordement le plus simple possible.
a. Les longues barres de rallonge et les adaptateurs sont énergivores et peuvent se briser.
3. Utilisez des douilles profondes chaque fois que possible.
4. N’utilisez pas cet outil s’il n’est pas solidement fixé à la pièce à travailler.
5. Un couple excessif ou insuffisant des attaches peut causer de graves blessures.
a. Les pièces desserrées peuvent devenir de dangereux projectiles.
b. Vérifiez toutes les pièces qui nécessitent un réglage de couple particulier à l’aide d’une clé
dynamométrique.
REMARQUE : L’utilisation d’une clé dynamométrique à cliquet ne permet pas de vérifier s’il y a
des pièces trop serrées au point d’être potentiellement dangereuses.
