Aimco SIW-P3225Q User manual

18V Cordless Shut-Off Impact Tool
(Brushless Motor)
Model Numbers
SIW-P2525Q
SIW-P3225Q
SIW-P3238
SIW-P5538
SIW-P5550
SIW-P10050
SIW-P12050
PO Box 16460, Portland OR 97292-0460
1-800-852-1368 •Fax [phone]
www.aimco-global.com
Instruction Manual

2
WRENCH FUNCTION GUIDE
(A)
LED indicator provides simple process information to the operator.
The signal is visible from any angle.
(B)
LED light for working in dark area.
(C)
Variable speed control trigger. Non-contact switch provides longer life
with less downtime.
(D)
F/R button for easy ergonomic operation.
(E)
Shock absorbing, ergonomic grip provides less fatigue with well-bal-
anced operation.
(F)
Li-ion battery offers longer life with no memory effect.
(G)
Smart battery with capacity indicator.
An optional programmer is available that allows you to make changes to tool
functions. See SPC-2-PGM programmer manual for details.
(A)
(B)
(E)
(C)
(G)
(D)
(F)

3
SCREWDRIVER FUNCTION GUIDE
(A)
LED indicator provides simple process information to the operator.
The signal is visible from any angle.
(B)
LED light for working in dark area.
(C)
Variable speed control trigger. Non-contact switch provides longer
life with less downtime.
(D)
F/R button for easy ergonomic operation.
(E)
Shock absorbing, ergonomic grip provides less fatigue with well-bal-
anced operation.
(F)
Li-ion battery offers longer life with no memory effect.
(G)
Smart battery with capacity indicator.
(H)
1/4” hex with quick change chuck.
An optional programmer is available that allows you to make changes to tool
functions. See SPC-2-PGM programmer manual for details.
(A)
(B)
(E)
(C)
(G)
(D)
(F)
(H)

4
WARNING! READ ALL INSTRUCTIONS. Always observe the safety regula-
tions applicable in your country to reduce the risk of fire, electric shock, and
personal injury. Understand the following safety instructions before attempt-
ing to operate this product. Always wear eye protection when working with
power tools. Keep these instructions in a safe place.
READ AND SAVE THESE INSTRUCTIONS
Work Area Safety
Keep your work area clean and
well lit. Cluttered benches and
dark areas invite accidents.
Do not operate power tools in
explosive atmospheres, such
as in the presence of flammable
liquids, gases, or dust. Power
tools create sparks which may ig-
nite the dust or fumes.
Keep bystanders, children, and
visitors away while operating a
power tool. Distractions can
cause you to lose control.
Personal Safety
Stay alert, watch what you are
doing, and use common sense
when operating a power tool.
Do not use tool while tired or
under the influence of drugs, al-
cohol, or medication. A moment
of inattention while operating
power tools may result in serious
personal injury.
Dress properly. Do not wear
loose clothing or jewelry. Con-
tain long hair. Keep your hair,
clothing, and gloves away from
moving parts. Loose clothes,
jewelry, or long hair can be caught
in moving parts.
Do not overreach. Keep proper
footing and balance at all times.
Proper footing and balance ena-
bles better control on the tool in
unexpected situations.
Use safety equipment. Always
wear eye protection. Dust mask,
non-skidsafetyshoes, hard hat, or
hearing protection must be used
for appropriate conditions.
Tool Use and Care
Use clamps or other practical
ways to secure and support the
work piece to a stable platform.
Holding the work piece by hand or
against your body is unstable and
may lead to loss of control.
Do not force tools. Use the cor-
rect tool for your application.
The correct tool will do the job bet-
ter and safer at the rate for which
it is designed.
General Safety Rules

5
Do not use tool if switch does
not turn it on or off. Any tool that
cannot be controlled with the
switch is dangerous and must be
repaired.
Store idle tools out of reach of
children and other untrained
persons. Tools are dangerous in
the hands of untrained users.
Check for misalignment or
binding of moving parts, break-
age of parts, and any other con-
dition that may affect the tool
operation. If damaged, have the
tool serviced before using.
Many accidents are caused by
poorly maintained tools.
Use only Signature Series rec-
ommended accessories for
your tool model. Accessories
that may be suitable for one tool,
may become hazardous when
used on another tool.
Service
Tool service must be performed
only by qualified repair person-
nel. Service or maintenance per-
formed by unqualified personnel
could result in a risk of injury.
When servicing an AIMCO Sig-
nature Series tool, it is im-
portant to use AIMCO Signature
Series Parts, and all work
should be undertaken by a qual-
ified AIMCO Signature Series
Authorized Technician. Use of
unauthorized parts or work per-
formed by a non-authorized tech-
nician will void warranty and may
create a risk of damage to the tool,
risk of electric shock, or injury to a
user.
Battery Charger
 Caution: To reduce risk of injury,
charge only the authorized batteries.
Other types of batteries may burst,
causing personal injury and damage.
Before using battery charger, read
all instructions and cautionary
markings on batteries, chargers,
and products using batteries.
Do not allow anything to cover or
clog the charger vents.
Do not expose charger to rain,
snow or wet conditions.
To reduce the risk of damage to
electric plug and cord, pull by plug
rather than cord when disconnect-
ing charger.
Additional Safety Rules for Shut-Off Impact Tool

6
Use of an attachment not recom-
mended or sold by the manufac-
turer may result in a risk of fire,
electric shock, or injury to per-
sons.
Make sure cord for charger is lo-
cated so that it will not be stepped
on, tripped on, tripped over, or oth-
erwise subjected to damage or
stress.
Do not abuse the power cord.
Never use the cord to carry the
charger. Keep cord away from
heat, oil, water, sharp edges, or
moving parts. Replace damaged
cords immediately.
Do not operate charger if it has
been damaged in any way, take it
to a qualified service center for re-
pair.
To reduce risk of electric shock,
unplug charger from outlet before
attempting any maintenance or
cleaning. Turning off controls will
not reduce this risk.
Do not disassemble charger or
battery cartridge. Take it to a qual-
ified service center when repair is
required. Incorrect reassembly
may result in risk of electric shock
or fire.
Battery Pack
Do not charge battery pack when
temperature is below 0oC (32oF)
or above 40oC (104oF).
Do not attempt to use a step-down
transformer, an engine generator,
or DC power receptacle.
Do not short the battery pack: Do
not touch the terminals with any
conductive material. Avoid storing
battery cartridge in a container
with other metal objects such as
nails, coins, paper clips, etc.
Do not expose battery cartridge to
water or rain. A battery short can
cause large current flow, over-
heating, possibly burns and even
a break-down.
Do not store the machine and bat-
tery pack in locations where the
temperature may reach or exceed
50oC (122oF).
Do not incinerate the battery pack
even if it is severely damaged or
completely worn out. The battery
pack can explode in a fire.
Be careful not to drop, shake, or
strike the battery.
Do not charge inside a box or con-
tainer of any kind. The battery
must be placed in a well-ventilated
are during charging.
Do not dispose of battery packs
into household waste, fire, or wa-
ter. Battery packs should be col-
lected, recycled or disposed of in
an environmentally-friendly man-
ner. Call the authorized warranty
centers for locations to dispose of
damaged or inoperable batteries.

7
WRENCH FUNCTIONS
This industrial shut off wrench is de-
signed for nut tightening/loosening
and screw driving/loosening. It is
not appropriate to use for wood/mild
steel drilling. Please refer to the fig-
ure to familiarize yourself with the
major components of this tool be-
fore use.
1. Power Switch
Depressing the power switch will
energize the LED light (2) in front,
and the tool starts to rotate. When
released, power to the motor
ceases and the tool stops working
immediately. The LED light will re-
main for 5 seconds, then shut off.
2. LED Light
3. Forward/Reverse Button
The tool is always in forward oper-
ation unless the Forward/Reverse
button is pressed. When the but-
ton is pressed, the blue LED light
sustains, and the yellow and
green LED lights flash together.
This indicates the tool is in reverse
operation mode. To get the tool
back in forward operation, simply
press the button again, the LED
lights shut off, and the tool is back
in forward operation mode.
4. Anvil (Drive Shaft)
The anvil will accept drive hex
socket. Be sure the socket is fully
inserted before operating tool.
Otherwise, the socket may fly off
and cause property damage or
personal injury.
WARNING: Use only impact-
grade sleeve sockets.
5. Li-ion Battery
This battery provides electrical
power to the motor. Please charge
it according to the charging in-
struction listed in this manual.
WARNING: Use the tool to either
tighten or loosen nuts and screws
ONLY in stipulated torque and volt-
age ranges.
4
3
2
1
5
IMPORTANT INFORMATION
1) No lights on the tool indicates
the tool is in SLEEP mode. To
wake up the tool, just press the
trigger. The tool will be ready to
use.
2) After operating the tool, the im-
pulse setting number will re-
main on the display for 5 mins.
As the number disappears, the
tool goes into SLEEP mode.

8
SCREWDRIVER FUNCTIONS
This industrial shut off screwdriver is
designed for nut tightening/loosen-
ing and screw driving/loosening. It is
not appropriate to use for wood/mild
steel drilling. Please refer to the fig-
ure on the page to familiarize your-
self with the major components of
this tool before use.
1. Power Switch
Depressing the power switch will
energize the LED light (2) in front,
and the tool starts to rotate. When
released, power to the motor
ceases and the tool stops working
immediately. The LED light will re-
main for 5 seconds, then shut off.
2. LED Light
3. Forward/Reverse Button
The tool is always in forward oper-
ation unless the Forward/Reverse
button is pressed. When the but-
ton is pressed, the yellow and
green LED lights flash together,
and the tool switches to reverse
operation. To switch the tool back
to forward operation, simply press
the button again. The LED lights
shut off and the tool is back in for-
ward operation.
4. Quick Change Holder
This driver accepts only 1/4” (6.35
mm) hex bits. Be sure the bit is
fully engaged by the chuck before
operating tool. Otherwise, the bit
may fly off and cause property
damage or personal injury.
5. Li-Ion Battery
This battery provides electrical
power to the motor. Please charge
it according to the charging in-
struction listed in this manual.
WARNING: Use the tool to either
tighten or loosen nuts and screws
ONLY in stipulated torque and volt-
age ranges.
4
3
2
1
5
IMPORTANT INFORMATION
1) No lights on the tool indicates
the tool is in SLEEP mode. To
wake up the tool, just press the
trigger. The tool will be ready to
use.
2) After operating the tool, the im-
pulse setting number will re-
main on the display for 5 mins.
As the number disappears, the
tool goes into SLEEP mode.
8

9
ASSEMBLY
Check for damage to the tool, parts,
or accessories that may have oc-
curred during transport. Take the
time to thoroughly read and under-
stand this manual prior to operation.
This tool kit contains:
1 –18V Cordless Shut-Off Impact
Tool
1 –Battery
1 –Bail
1 –Body Jacket
1 –Instruction Manual
Attaching or Removing Battery
Pack
1. To connect battery, line up the
tracks and attach the battery
pack. Slide battery pack toward
tool until it locks into position with
a click.
2. To remove the battery pack,
press the button on the top of the
battery pack and release the bat-
tery.
2. RELEASE
1. PRESS
SLIDE

10
OPERATION
This product has been carefully in-
spected prior to leaving the factory.
It should provide you with years of
satisfying service under normal op-
erating conditions. Do not, however,
force the tool to perform outside its
design parameters. Such usage will
void the warranty.
1. Slide battery into the bottom of
the housing handle until a click
sound occurs. Do not force bat-
tery: It should slide easily into
place with nominal force. Any dif-
ficulty doing so indicates an in-
correct alignment.
2. Select proper size drive bit and in-
sert into the quick-change holder.
3. Depress the trigger to engage the
LED light and start the tool. Check
the torque on the digital tester to
see if the desired torque reached.
Torque can also be adjusted by
using the torque setting button.
4. When torque is reached, the tool
will shut off automatically.
Forward / Reverse Rotation
Switch Operation
To prevent damage, do not press
Forward/Reverse button until the
anvil comes a complete stop.
Forward Rotation Operation:
The tool is in forward operation if the
blue light is unlit.
Reverse Rotation Operation:
Reverse operation can be adjusted
by pressing the Forward/Reverse
button.
Tool needs to be adjusted manually
to return to Forward operation after
reverse operation.
Lock the Reverse
1. Remove the battery pack
2. Press one of the F/R switches.
3. Insert the battery pack.
4. After 6 sec. release the F/R
switch while the warning noise
sounds.
5. When the warning noise sounds
again, the setting is complete.
Note: When the Reverse Locked
mode is set, the tool will always
run in a forward direction —the
reverse switches will be inopera-
tive.
6. To remove the reverse lock func-
tion, repeat the same process.
WARNING! Read the manual instruction before operating the tool. Always
wear safety glasses or face shields when operating this product. Failure to do
so can result in dust, shavings, or loose particles being thrown into your eyes.

11
TORQUE ADJUSTMENTS
Adjusting the Torque Setting
Press the torque setting button until
the number blinks. Set proper num-
ber, then press the trigger or wait for
5 secs to complete the torque set-
ting.
Number "00" indicates Non Shut-Off
mode and Number "01" –"50" indi-
cate Auto Shut-Off mode. The larger
the number, the higher the torque.
Lock the Torque Setting
1. Remove the battery pack
2. Press the trigger and one of the
F/R switches at the same time.
3. Insert the battery pack.
4. Wait for 6 sec. until you hear a
beep sound. Release the trigger
and F/R switch together. The
torque setting is then locked.
5. To unlock the torque setting, re-
peat the same process.
Torque stage and error display
If a point appears, it means the torque
setting is locked.
Torque setting button

12
TESTING TORQUE
Status of the Tool LED Indicator
and Beeper
Tool Status
Action to be Taken
LED lights RED, YELLOW, and
GREEN together for one second.
A long beep for one second.
Tool is OK to use
-
LED lights RED for one second.
A long beep for one second
Preset torque is not
reached
Screwing fastener must
be performed again.
LED lights GREEN
Preset torque is
reached and tight-
ening is OK.
-
LED blinks YELLOW five times
Five short beeps
Battery power is
low.
Recharge battery or
replace with fully
charged battery.
LED lights YELLOW for five seconds
A long beep for five seconds
Battery power is
depleted. Tool
stops immediately.
Recharge battery or
replace with fully
charged battery.
LED lights BLUE and blinks in
YELLOW and GREEN
Tool is in reverse
operation mode.
-
If audited torque is low, then increase torque adjustment (page 11). If audited torque
is high, then decrease torque adjustment (page 11). Retest after adjustment.
Your actual joint
Digital Torque wrench
Check the torque installed

13
CHARGING THE LI-ION BATTERY
Li-ion Battery Pack
NOTE: Your battery pack is not fully
charged at time of purchase. Be sure
to charge the battery before first use.
Remove the battery pack when
the tool is idle for a long time.
Recharge the battery pack once
every 6 months even if the battery
is not in use.
Batteries should be charged in
ambient temperatures between
0°C (32°F) and 40°C (104°F).
Charging outside this range will
result in either less than full
charge or damage to battery pack.
Allow the charger to cool when
charging more than two battery
packs consecutively.
Do not insert your fingers/body
parts into contact area of charger.
Charging the Battery
1. Place charger in a relatively cool
and well-ventilated area.
2. Plug charger into the AC outlet.
CAUTION: Ensure that the power
source to be utilized conforms to
the power requirement specified
on the product nameplate.
3. Turn the battery upside down and
slide it into the charger while keep-
ing the alignment marks aligned.
Slide forward in the direction of the
arrow. Do not force battery: It
should slide easily into place with
nominal force. Any difficulty doing
so indicates incorrect alignment.
4. If the power lamp (red) does not
light immediately or goes out
soon after the charger is plugged
in, consult a Signature Series au-
thorized dealer.
5. During charging, the charging lamp
(green) will flash. When charging is
complete, an internal electronic
switch will automatically be trig-
gered to prevent overcharging.
–Charging will not start if the
battery pack is warm; for exam-
ple, immediately after heavy-
duty operation. The yellow
standby lamp will flash until the
battery cools down.
6. If the temperature of the battery
pack is 0
o
C (32°F) or less, charg-
ing will take longer to fully charge
the battery pack than standard
charging time. At this low temper-
ature, even when the battery is
fully charged, it will have approxi-
mately 50% of the power of a fully
charged battery at normal opera-
tion temperature.
7. Once battery is fully charged, the
green lamp will light to indicate
the charge has entered into a
trickle charge mode

14
TROUBLESHOOTING
LED Error
Mode
Error Cause
Solution
E2
Motor overheated
Remove battery pack and let cool
E3
Motor damaged
Send to repair center for service
E4
Connector wire has failed.
Send to repair center for service
E8
Excess of current and tool is stuck.
Send to repair center for service
SPECIFICATIONS
Model
SIW-P2525Q
Model
SIW-P3225Q
Voltage
18 VDC
18 VDC
Drive Size
6.35 mm Hex. (1/4”)
6.35 mm Hex. (1/4”)
Screw Size
M5, M6
M6
Torque Range
3 ~ 25 Nm (2 ~ 18 ft-lb)
6 ~ 32 Nm (4 ~ 24 ft-lb)
Max. Torque
40 Nm (30 ft-lb)
90 Nm (66 ft-lb)
Free Speed
2,400 rpm
2,400 rpm
Weight W/O Battery
1.0 kg (2.2 lb)
1.0 kg (2.2 lb)
Noise Level
71 dB(A)
71 dB(A)
Battery Type
Li-Ion 2.0 / 4.0 Ah
Li-Ion 2.0 / 4.0 Ah
Model
SIW-P3238
Model
SIW-5538
Voltage
18 VDC
18 VDC
Drive Size
9.5 mm Sq. (3/8”)
9.5 mm Sq. (3/8”)
Screw Size
M6
M8
Torque Range
6 ~ 32 Nm (4 ~ 24 ft-lb)
15 ~ 55 Nm (11 ~ 41 ft-lb)
Max. Torque
90 Nm (66 ft-lb)
120 Nm (90 ft-lb)
Free Speed
2,400 rpm
2,400 rpm
Weight W/O Battery
1.0 kg (2.2 lb)
1.1 kg (2.4 lb)
Noise Level
71 dB(A)
71 dB(A)
Battery Type
Li-Ion 2.0 / 4.0 Ah
Li-Ion 2.0 / 4.0 Ah
Model
SIW-P5550
Model
SIW-P10050
Model
SIW-P12050
Voltage
18 VDC
18 VDC
18 VDC
Drive Size
12.7 mm Sq. (1/2”)
12.7 mm Sq. (1/2”)
12.7 mm Sq. (1/2”)
Screw Size
M8
M8, M10
M10, M12
Torque Range
15 ~ 55 Nm
(11 ~ 41 ft-lb)
25 ~ 100 Nm
(18 ~ 74 ft-lb)
30 ~ 120 Nm
(22 ~ 89 ft-lb)
Max. Torque
120 Nm
(90 ft-lb)
180 Nm
(133 ft-lb)
210 Nm
(155 ft-lb)
Free Speed
2,400 rpm
2,400 rpm
2,400 rpm
Weight W/O Battery
1.1 kg (2.4 lb)
1.1 kg (2.4 lb)
1.3 kg (2.9 lb)
Noise Level
71 dB(A)
71 dB(A)
71 dB(A)
Battery Type
Li-Ion 2.0 / 4.0 Ah
Li-Ion 2.0 / 4.0 Ah
Li-Ion 2.0 / 4.0 Ah

15
LAMP INDICATIONS
Red Light
Charger is plugged into the AC outlet. Ready to charge.
Yellow Flashing Light
(1)When the temperature of the battery is too low (<0oC(<32oF)), it
is in a trickle charge mode until the temperature of the battery
goes up to over 0oC(<32oF). The lamp will change from Yellow
Flashing to Green Flashing automatically and start to charge. (If
after 70 minutes, the lamp changes from yellow flashing to yellow
light, consult an authorized dealer.)
(2)When the temperature of the battery is too high (>40oC(104oF)),
it is in a trickle charge mode until the temperature of the battery
drops to under 40oC(104oF). The lamp will change from Yellow
Flashing to Green Flashing automatically and start to charge. (If
after 70 minutes, the lamp changes from yellow flashing to yellow
light, consult an authorized dealer.)
(3) When the voltage of the battery is too low (below 14.4 voltage),
it is in a trickle charge mode until the voltage of the battery
reaches to the standard value. The lamp will change from Yellow
Flashing to Green Flashing automatically and start to charge. (If
after 20 minutes, the lamp changes from yellow flashing toyellow
light, consult an authorized dealer.)
Yellow Light
Green Flashing Light
Now start charging Light
Green Flashing Light
Battery is approximately 50% charged.
Green Flashing Light
Battery is approximately 80% charged.
Green Light
Charging is complete. (Fully charged.)

16
AIMCO CORPORATION DE MEXICO SA DE CV AIMCO EUROPE
Ave. Cristobal Colon 14529 C/ Rio Gallo, 431 urb. Montelar
Chihuahua, Chihuahua. 31125 19174 Galápagos / Guadalajara
Mexico Spain
Phone: [phone] Phone: + 34 673 34 99 25
Fax: [phone]
AIMCO CHINA AIMCO SOUTH AMERICA
Room 607, No. 3998 Hongxin Rd Carrera 29A, #7B-91 Origami Building Int604
Minhang District, Shanghai Medellin; Colombia 050021
China
Phone: [phone]
Fax: [phone] LIT-MAN257 Rev. 11/2016
Printed in USA ©2016 AIMCO
CORPORATE HEADQUARTERS
10000 SE Pine Street
Portland, Oregon 97216
Phone: [phone]
Toll Free: 1-800-852-1368
