Power Probe Tek Pro Series User manual

TABLE OF CONTENTS
Intoduction
Specifications
Features
PPMWL1000 is a professional-grade, hands-free Modular Work Light. This light will deliver
ecient, dependable service when used correctly and with care. As with any fine light,
for best performance, the manufacturer’s instructions must be followed. Please study this
manual before operating the light, and understand the safety warnings and instructions. The
instructions on operation and maintenance should be read carefully, and the manual kept for
reference.
NOTE: Additional safety measures may be required because of your particular application
of the light. Contact your Power Probe Tek representative or distributor with any questions
concerning the light and its use.
Power Probe Tek Products undergo a strict quality control inspection for workmanship,
function, and safety before leaving the factory. From the date of purchase, we will warranty/
repair Power Probe Tek products for one (1) year against defects in parts and workmanship.
All repair due to misuse will be charged a fee not to exceed the cost of the tool. All warranty
units must be accompanied by a copy of the original sales receipt. In the event of a
malfunction or defective unit, please contact your Power Probe Tek dealer.
For the latest production information and updated manuals, please go to powerprobetek.com
This product has been designed and manufactured using high quality,
recyclable materials and components. The cross wheeled bin symbol
applied to the product indicates that it complies with European Directive
2012/19/UE. Please inquire about the collection of electrical and electronic
products in your area. Please comply with the local regulations. Do not
dispose of this product with your normal household waste.
introduction
limited warranty
2
3
5
Limited Warranty
Getting Started
2
4

specications
Module Lumens (High, Low) .............................................................................................. 250, 125
Total Light Lumens .............................................................................................................. 1000
Lux @ 1m (High, Low) ......................................................................................................... 410, 205
Beam Distance (High, Low) ............................................................................................... 40m, 29m
CRI ......................................................................................................................................... > 80
Constant Current ................................................................................................................ Ye s
Runtime (High, Low) .......................................................................................................... 3h, 6h
Battery ................................................................................................................................. 3.7V 1800mAh x 4
Charger ................................................................................................................................ 100-240V, 5V3A
Charging Time ..................................................................................................................... 3-4 h
Magnets ............................................................................................................................... Ye s
Hook ..................................................................................................................................... Ye s
Threaded Hole .................................................................................................................... 1/4”-20
CSA Certified ...................................................................................................................... Ye s
DOE / CEC6 ......................................................................................................................... Ye s
Dust & Water Resistance ................................................................................................... Base Unit IP54
Modules IP65
CE Certified ......................................................................................................................... Ye s
EMC ...................................................................................................................................... Ye s
LVD ....................................................................................................................................... Ye s
ROHS ................................................................................................................................... Ye s
Battery IEC .......................................................................................................................... Ye s
REACH ................................................................................................................................. Ye s
WEEE .................................................................................................................................... Ye s
IEC 6247 & 62778 .............................................................................................................. Ye s
Weight .................................................................................................................................. 2.7 lbs (1.2 kg)
Dimensions ......................................................................................................................... 14 x 3.3 x 3”

GETTING STARTED
CHARGING-
* Unit should be fully charged before first use. Allow 3 to 4 hours for a full charge.
* To charge plug the charger into any 100V-240V AC power source, such as a wall receptacle,
then plug the charger cord into the charging port on the base/charging module.
* Individual light modules must be installed into base/charging module to be recharged.
* The light rings on the lighting modules will glow red while the modules are charging.
* Allow the unit to fully charge until the charging indicating lights on the light modules turn
from red to green.
* Charge this light every month if not in constant use, and after each use when used often to
ensure battery longevity.
OPERATING-
* The light base/charging module has a master power button that controls all of the individual
light modules when they are installed in the base module.
* The unit has four individual and removable lighting modules that can operate independently
of the base module.
* Pressing the red tab beneath each lighting module releases the module from the base unit.
* To re-install the lighting module into the base unit, push into base unit slot until it latches.
* Press the button once for low brightness, twice for high brightness, and thrice to turn it o.
* If the individual modular lights become out of sync with each other, while all the modular
lights are in the base, press and hold the POWER button on the light base for 3 seconds. This
will re-sync all the light modules together.

light features
COB LED
1,000 Lumens Total
(250 x 4)
IP54 Dust And Water
Resistant Housing
1/4” Threaded Hole
For Mounting
4 Removable
Modules
2 Magnets
2 Magnets on the backside
of the light
module features
Charging Status
indicator in each Module
COB LED 250 Lumens each module
Magnet and Hook
on each Module
Individual Power
Button on each
Module
Power Button
IP65 Dust and water
resistant modules
1/4” Threaded Hole
For Mounting
