Powercast Powerspot TX91503 User manual

User Manual
TX91503 –915 MHz PowerSpotTransmitter
Rev 2.0 –2017/12 User’s Manual - TX91503 Transmitter Page 1
www.powercastco.com
PRODUCT DESCRIPTION
The Powercast TX91503 Powercaster
transmitter is specially designed to provide
both power and data to end devices
containing the Powercast’s power
harvesting technology. The TX91503
contains receiver that can hear when a
harvesting device is in range, allowing the
TX91503 to stop power transmission when
no harvesting devices are around. The
TX91503 can also be controlled by an app
that can set periods of use. The TX91503 is
housed in a durable plastic case with
several mounting options. Operational
power is provided to the DC power
connector. The TX91503 includes a status
LED to provide feedback on functional
state. The TX91503 has a factory set, fixed
power output of 3W EIRP.
FEATURES
FCC and IC approved
Flexible wall mounting options
Fully integrated system
Transmits power and data
Factory configurable for custom
applications
Wide temperature range
PRODUCT CONTENTS
The following items are included:
Qty
Description
1
915 MHz transmitter
1
Power supply
1
US plug for Power supply (must be
snapped in to the Power supply)
1
Quick Start instruction card
POWERING APPLICATIONS
Wireless battery charging
-Headphones
-Headsets
-Game Controllers
-Keyboards and Mice
-Fitness Trackers
-Smart Watches
-Wearables
-Smart Cards
Battery-free wireless sensors
- Industrial Monitoring
- Smart Grid
- Structural Health Monitoring
- Defense
- Building automation
- Agriculture
- Oil & Gas
- Location-aware services
Powercast®, Lifetime Power®, Powerharvester®, and Powercaster® are registered trademarks of Powercast Corporation.
All other trademarks are the property of their respective owners.
Powercast products and technology are covered by one or more of the following patents and other patents pending:
6,289,237 | 6,615,074 | 6,856,291 | 7,027,311 | 7,057,514 | 7,639,994 | 7,643,312 | 7,812,771 | 7,844,306 | 7,868,482 | 7,898,105
7,925,308 | 8,159,090 | 8,350,255 | 8,432,062 | 8,461,817 | 8,621,245 | 9,000,616 | 9,021,277 | 9,107,579 | 9,251,699 | 9,706,924

User Manual
TX91503 –915 MHz PowerSpotTransmitter
Rev 2.0 –2017/12 User’s Manual - TX91503 Transmitter Page 2
www.powercastco.com
SET-UP AND OPERATION
1. Mount the TX91503 at the back of a desk or counter to create a PowerSpot® recharging
zone. For wall mounted applications, use the keyholes on the back of the unit to hang
the TX91503 for recharging devices like closet hung wearables.
2. Plug the DC connector of the power supply into the connector on the TX91503. Plug
the power supply into a 120V outlet.
3. The TX91503 will remain off until one of the following occurs1:
a. An authorized device enters the PowerSpot recharging zone.
b. The button on the unit is pressed to recharge a device with a completely
discharged battery. The unit will activate for 30 minutes from a button press and
then will turn off if an authorized device is not present.
4. When the TX91503 is active and transmitting radio frequency (RF) energy, data is
automatically included in the transmission and can be received and used to authorize
the device.
The status LED indicates the following operating conditions:
LED
Status
Description
Off
Off
5VDC is not applied
Green
Active
Transmitting normally
Red
Idle
TX91503 is powered but not actively transmitting
Blinking Red
Fault
TX91503 is in a fault condition such as overheating
1The app can override these conditions and keep the transmitter in an OFF state.
SPECIFICATIONS
Item
Description
Modulation
Power: Direct Sequence Spread Spectrum (DSSS)
Data: Amplitude Shift Keying (ASK)
Frequency
915 MHz Center Frequency
Power output
3 watts EIRP
Beam pattern
70° width, 130° height
Horizontal Polarization (tabletop mounting)
Approvals
United States - FCC ID: YESTX91503
Canada - IC ID: 8985A-TX91503
Firmware Version
Located on the TX91503 label
Data Communications
An 8-bit, factory-set, TX91503 identification (ID) number is broadcast with
the wireless power. The ID number can be found on the TX91503 label.
Operating Temperature
-20°C to 40°C
Environment
Indoor use only
Mounting
Mount at the back of a desktop or countertop to create a PowerSpot
recharging area
2 keyholes (See mechanical drawing for dimensions) for wall mounting
Power
5VDC/1A through included Power Supply
Color
Black/Blue
Dimensions
7.3” × 2.1”× 1.4”(185.4 x 53.3 x 35.6 mm)

User Manual
TX91503 –915 MHz PowerSpotTransmitter
Rev 2.0 –2017/12 User’s Manual - TX91503 Transmitter Page 3
www.powercastco.com
MECHANICAL (REAR VIEW)
*Dimensions in inches

User Manual
TX91503 –915 MHz PowerSpotTransmitter
Rev 2.0 –2017/12 User’s Manual - TX91503 Transmitter Page 4
www.powercastco.com
SUPPORT
Technical support for Powercast products can be initiated through the following methods:
Website contact form: http://www.powercastco.com/contact/
Telephone: [phone]
COMPLIANCE STATEMENTS
Changes or modifications not expressly approved by Powercast could void the user’s authority
to operate the equipment. Use and maintain device only as specified in this manual.
This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential installation. This equipment generates,
uses, and can radiate radio frequency energy and, if not installed and used in accordance with
the instructions, may cause harmful interference to radio communications. However, there is
no guarantee that interference will not occur in a particular installation. If this equipment does
cause harmful interference to radio or television reception, which can be determined by
turning the equipment off and on, the user is encouraged to try to correct the interference by
one of the following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
Consult the dealer or an experienced radio/TV technician for help.
This device complies with Industry Canada licence-exempt RSS standard(s). Operation is subject
to the following two conditions: (1) this device may not cause interference, and (2) this device
must accept any interference, including interference that may cause undesired operation of the
device.
Le présent appareil est conforme aux CNR d'Industrie Canada applicables aux appareils radio
exempts de licence. L'exploitation est autorisée aux deux conditions suivantes : (1) l'appareil ne
doit pas produire de brouillage, et (2) l'appareil doit accepter tout brouillage radioélectrique
subi, même si le brouillage est susceptible d'en compromettre le fonctionnement.
