Powercraft PDS-180 User manual

GB Subject to change
GB USERS MANUAL
Art.No. PSM6019
PDS-180
Detail Sander
www.servotool.nl GB/IRE-0610-30
3 YEARS WARRANTY
The guarantee period begins on the date of purchase
(shown on the ALDI till receipt) and is valid for 3 years.
The guarantee rights are under applicable national legislation,
based on the EC directives and do not affect
the consumers statutory rights.
We assume responsibility for functional defects and faulty
construction or material.
Any misuse causing consequential damage falls outside this responsibility.
In case of necessary replacement parts or repair work, please
contact our HELP LINE:
UK HELP DESK LINE:
0870-7323023
IRELAND HELP DESK LINE:
1800-481005
Omega, Interex House, Prospect Close, Lowmoor Business Park
NG17 7LF Kirkby In Ashfield, England
Replacements or repairs under guarantee are free of charge.

2UK Help Line: 0870 - 7323023 / IRELAND Help Line: 1800-481005 - Powercraft UK Help Line: 0870 - 7323023 / IRELAND Help Line: 1800-481005 - Powercraft 11
Exploded view
4
3
1
5
2
4
5
Fig.1
Fig.2

UK Help Line: 0870 - 7323023 / IRELAND Help Line: 1800-481005 - Powercraft 3
DETAIL SANDER
The numbers in the following text correspond with the pictures at page 2
Read this operators guide carefully, before using the machine. Ensure that you
know how the machine works, and how it should be operated. Maintain the
machine in accordance with the instructions, and make certain that the machine
functions correctly. Keep this operator's guide and other enclosed documentation
with the machine.
Introduction
The Detail sander is designed for dry sanding on surfaces of wood, plastic and filler as well as
for painted surfaces. It is particularly suitable for working on profiles, in corners or hard-to-reach
areas.
Contents
1. Machine data
2. Safety instructions
3. Assembly
4. Use
5. Service & maintenance
Technical specification
Package contents
1 Detail sander
5 Pcs. sanding paper
1 Vacuum cleaner adaptor
1 User manual
Features
Fig.1
1. On/off switch
2. Handle
3. Ventilating apertures
Voltage 230V~
Frequency 50 Hz
Input power 180 W
Tool class II
No load speed 13000/ min
Weight 1.2 kg
Lpa (Sound pressure level) 74.8 dB(A)
Lwa (Sound power level) 85.8 dB(A)
Vibration 1.13 m/s2
1. MACHINE DATA
GB
10 UK Help Line: 0870 - 7323023 / IRELAND Help Line: 1800-481005 - Powercraft
Spare parts list
No. Description Position
408225 Carbon brush (set) 3
408228 Long support bar 12
408226 Sand sole 15
408255 Short support bar 21
408227 Switch + cover 22+23

UK Help Line: 0870 - 7323023 / IRELAND Help Line: 1800-481005 - Powercraft 9
We declare under our sole responsibility that this product, PDS-180 Detail Sander, is in
conformity with the following standards or standardised documents:
EN60745-1, EN60745-2-4, EN55014-1, EN55014-2, EN61000-3-2, EN61000-3-3
in accordance with the regulations.
98/37/EC , 73/23/EEC , 89/336/EEC, 2002/95/EC, 2002/96/EC
from 01-10-2006
ZWOLLE NL
J.A. Bakker - van Ingen J. Lodewijk
CEO Ferm BV Quality Manager Ferm Global
It is our policy to continuously improve our products and we therefore reserve the right to
change the product specification without prior notice.
Servotool BV • Lingenstraat 6 • 8028 PM Zwolle • The Netherlands
CE DECLARATION OF CONFORMITY (GB)
GB
4UK Help Line: 0870 - 7323023 / IRELAND Help Line: 1800-481005 - Powercraft
4. Sandpaper
5. Sanding-sole
In this manual and/or on the machine the following symbols are used:
Read instructions carefully
In accordance with essential applicable safety standards of European directives
Class II machine – Double insulation – You don’t need any earthed plug.
Denotes risk of personal injury, loss of life or damage to the tool in case of non-
observance of the instructions in this manual.
Indicates electrical shock hazard.
Wear a dust mask
Immediately unplug from the mains during maintenance and if the cord gets
damaged.
Faulty and/or discarded electrical or electronic apparatus must be collected at the
appropriate recycling locations.
General safety instructions
Attention! When using electric machines always observe the safety regulations applicable in
your country to reduce the risk of fire, electric shock and personal injury. Read the following
safety instructions. Keep these instructions in a safe place!
1) Work area
a. Keep work area clean and well lit. Cluttered and dark areas invite accidents.
b. Do not operate power tools in explosive atmospheres, such as in the presence of
flammable liquids, gasses or dust. Power tools create sparks which may ignite the dust of
fumes.
c. Keep children and bystanders away while operating a power tool. Distractions can cause
you to lose control.
2) Electrical safety
a. Power tool plugs must match the outlet. Never modify the plug in any way. Do not use any
adapter plugs with earthed (grounded) power tools. Unmodified plugs and matching
outlets will reduce the risk of electric shock.
2. SAFETY INSTRUCTIONS
GB

UK Help Line: 0870 - 7323023 / IRELAND Help Line: 1800-481005 - Powercraft 5
b. Avoid body contact with earthed or grounded surfaces such as pipes, radiators, ranges
and refrigerators. There is an increased risk of electric shock if your body is earthed or
grounded.
c. Do not expose power tools to rain or wet conditions. Water entering a power tool will
increase the risk of electric shock.
d. Do not abuse the cord. Never use the cord for carrying, pulling or unplugging the power
tool. Keep cord away from heat, oil, sharp edges or moving parts. Damaged or entangled
cords increase the risk of electric shock.
e. When operating a power tool outdoors, use an extension cord suitable for outdoor use.
Use of a cord suitable for outdoor use reduces the risk of electric shock. Always use power
tools in conjunction with a residual circuit breaker device.
3) Personal safety
a. Stay alert, watch what you are doing and use common sense when operating a power tool.
Do not use a power tool while you are tired or under the influence of drugs, alcohol or
medication. A moment of inattention while operating power tools may result in serious
personal injury.
b. Use safety equipment. Always wear eye protection. Safety equipment such as dust mask,
non-skid safety shoes, hard hat and hearing protection used for appropriate conditions will
reduce personal injuries.
c. Avoid accidental starting. Ensure the switch is in the off position before plugging in.
Carrying power tools with your finger on the switch or plugging in power tools that have the
switch on invites accidents.
d. Remove any adjusting key or wrench before turning the power tool on. A wrench or a key
left attached to a rotating part of the power tool may result in personal injury.
e. Do not overreach. Keep proper footing and balance at all times. This enables better control
of the power tool in unexpected situations.
f. Dress properly. Do not wear loose clothing or jewellery. Keep your hair, clothing and
gloves away from moving parts. Loose clothes, jewellery or long hair can be caught in
moving parts.
g. If devices are provided for the connection of dust extraction and collection facilities, ensure
these are connected and properly used. Use of these devices can reduce dust related
hazards.
h. Use clamps or a vice to hold the item you are working on. It’s safer than using your hand
and it frees both hands to operate tool.
4) Power tool use and care
a. Do not force the power tool. Use the correct power tool for your application. The correct
power tool will do the job better and safer at the rate for which it was designed.
b. Do not use the power tool if the switch does not turn it on and off. Any power tool that cannot
be controlled with the switch is dangerous and must be repaired.
c. Disconnect the plug from the power source before making any adjustments, changing
accessories, or storing power tools. Such preventative safety measures reduce the risk of
starting the power tool accidentally.
d. Store idle power tools out of the reach of children and do not allow persons unfamiliar with
the power tool or these instructions to operate the power tool. Power tools are dangerous in
the hands of untrained users.
e. Maintain power tools. Check for misalignment or binding of moving parts, breakage of
parts and any other condition that may affect the power tools operation. If damaged, have
the power tool repaired before use. Many accidents are caused by poorly maintained
power tools.
GB
8UK Help Line: 0870 - 7323023 / IRELAND Help Line: 1800-481005 - Powercraft
These machines have been designed to operate over a long period of time with a minimum of
maintenance. Continuous satisfactory operation depends upon proper machine care and
regular cleaning.
Cleaning
Clean the housing regularly with a soft cloth, preferably after every use. Keep the ventilating
apertures free from dust and dirt.
Remove stubborn dirt with a soft rag moistened in soapy water. Do not use any solvents such
as petrol, alcohol, ammonia, etc. as such substances can damage the plastic parts.
Lubrication
This machine requires no additional lubrication.
Faults
Should a fault occur, e.g. after wear of a part, please contact the adress on the guarantee card.
In the back of this manual you find an exploded view showing the parts that can be ordered.
Troubleshooting
Environment
In order to prevent the machine from damage during transport, it is delivered in sturdy
packaging. Most of the packaging materials can be recycled. Take these materials to the
appropriate recycling locations.
Faulty and/or discarded electrical or electronic apparatus must be collected at the
appropriate recycling locations.
Guarantee
The guarantee conditions can be found on the guarantee card on the back of this users manual.
• The electric motor heats up
• The abrasive paper is filled with
adhesive/paint or a similar material
• Clean the ventilating apertures
• Paint or adhesive is not really dry.
• Some paints stick more to the abrasive
paper than others / clean the abrasive
paper at regular intervals
GB

UK Help Line: 0870 - 7323023 / IRELAND Help Line: 1800-481005 - Powercraft 7
• The sandpaper (4) is fixed by Velcro fastening.
• Simply pull off the sanding paper
• Press the new one onto the centre of the sand-sole (5)
Coarse sand-paper (grain 60) removes in general the bigger part of the material and fine
sand-paper (grain 120) is used for finishing.
Replacing the sand-sole
The sole has to be replaced when the Velcro has worn out. Please contact your Powercraft
service point for spare parts: UK Help Line: 0870 - 7323023 / IRELAND Help Line: 1800-
481005
Before replacing the sand-sole disconnect the sander from the mains.
• Remove the sandpaper from the sole.
• Remove the screws which fix the sole to the sander.
• Remove the sole.
• Install the new sole on the sander.
• Tighten the screws in the sand-sole.
Operation
• Hold the sander with the handle (2), to gain the best possible control over your sanding
operations.
• The ventilating apertures (3) on the housing must remain uncovered to ensure optimum
cooling of the motor.
• Push the on/off switch (1) to start the machine.
• Move the sander over the surface of your workpiece.
• Push the on/off switch to stop the machine.
Prevent putting too much pressure on the machine during sanding. Excessive
sanding pressure does not lead to increased sanding capacity, but increases wear
of the machine and the sandpaper.
User tips
• Apply long uniform movements to the item you are sanding to obtain the best possible
results.
• The quality of the surface after sanding is determined by the selected grain.
Make sure that the machine is not plugged in when carrying out maintenance work
on the motor.
5. SERVICE & MAINTENANCE
4. USE
GB
6UK Help Line: 0870 - 7323023 / IRELAND Help Line: 1800-481005 - Powercraft
f. Keep cutting tools sharp and clean. Properly maintained cutting tools with sharp cutting
edges are less likely to bind and are easier to control.
g. Use the power tool, accessories and tool bits etc., in accordance with these instructions
and in the manner intended for the particular type of power tool, taking into account the
working conditions and the work to be performed. Use of the power tool for operations
different from those intended could result in a hazardous situation.
5) Service
a. Have your power tool serviced by a qualified repair person using only identical
replacement parts. This will insure that the safety of the power tool is maintained.
Specific safety instructions
• Contact or inhalation of dust coming free during sanding (e.g. lead painted surfaces,
woods and metals), can endanger the health of the operator and bystanders. Always wear
the appropriate safety equipment such as a dust mask and use the dust bag during
sanding.
• Check that the switch is not in the “ON” position before connecting the machine to the
mains voltage.
• Always keep the mains lead away from moving parts of the machine.
• Use safety glasses, especially when sanding above head hight.
Electrical safety
When using electric machines always observe the safety regulations applicable in your country
to reduce the risk of fire, electric shock and personal injury. Read the following safety
instructions. Keep these instructions in a safe place!
Always check that the power supply corresponds to the voltage on the rating plate.
Your machine is double insulated; therefore no earthwire is required.
When replacing old cables or plugs
Throw away old cables or plugs immediately as soon as new ones have replaced these. It is
dangerous to put the plug of a loose cable into an electrical socket.
When using extension cables
Only use an approved extension cable that is suitable for the machine’s power. The cables
must have a diameter of at least 1.5 mm2. When the extension cable is on a reel, unroll the cable
in its entirety.
Replacing worn sanding paper
Fig. 2
Before sanding paper is attached always remove the plug from the mains.
3. ASSEMBLY
GB
