PowerPac PPMC677 User manual

Model: PPMC677
210589-24

PARTS & DESCRIPTION
1. Power Cable Consisting of a Plug connected to the electric mains at one end,
with the other end connected to the Socket on the appliance
2. BBQ Pan Heavy-duty Aluminium casting plate with non-stick coating –
the linear raised embossments provide an excellent contact
surface for grilling
3. Glass Lid Tempered glass lid to prevent contents of Suki (Inner Pot) from
splashing out
4. Lid Handle Cool-touch knob for holding Glass Lid
5. Suki
(Inner Pot)
Deep heavy-duty Aluminium casting pot with non-stick coating
– ideal for heating soup/stews, vegetables and other ingredients
Sukiyaki is a Japanese dish, of the soup or stew type, prepared
and served in the nabemono style. It consists of meat which is
slowly cooked or simmered at the table, alongside vegetables
and other ingredients, in a shallow iron pot in a mixture of soy
sauce, sugar, and mirin. Before being eaten, the ingredients are
usually dipped in a small bowl of raw, beaten eggs
6. Handle Cool-touch housing is comfortable for carrying the appliance
and is safe to touch
7. BBQ Indicator
Light
Lights up when the BBQ Pan is being heated
8. Suki Indicator
Light
Lights up when the Suki or Inner Pot (Soup Pot) is being heated
9. BBQ Control
Knob
Control knob which provides control for turning on the BBQ Pan
with settings – OFF, LOW, MIDDLE, MAX
10. Suki Control
Knob
Control knob which provides control for turning on the Suki or
Inner Pot (Soup Pot) with settings – OFF, LOW, MIDDLE, MAX
11. Drain Hole Hole where oil, water and other liquids drain out of the BBQ Pan
12. Drain Hole Tray Slide-out tray that is safe to touch and where oil, water and
other liquids which drain out of the BBQ Pan end up
13. Power Cable
Socket
To be connected to one end of the Power Cable
14. Glass Lid
Steam Vent
Hole on the glass lid where steam and other hot gases escape
1

8. Suki Indicator
11. Drain Hole Tray
7. BBQ Indicator Light 8. Suki Indicator Light
9. BBQ Control Knob 10. Suki Control Knob
7. BBQ Indicator
6. Handle
2. BBQ Pan
3. Glass Lid
4. Lid Handle
5. Suki (Inner Pot)
2

ATTENTION :
Read this booklet carefully it contains important instructions for a safe installation,
use and maintenance.
Important instructions to be kept for future reference.
The following basic precautions should always be followed when using electrical
appliances:
1.
2.
3.
4.
5.
6.
7.
8.
9.
10.
11.
12.
Read all instructions before using the appliance.
This appliance must be used only for the purpose it was expressly designed; any
use NOT complying with the instructions contained in the manual is considered
inappropriate and dangerous. The manufacturer is NOT responsible for possible
damages caused by the inappropriate and/or unreasonable use.
The appliance is designed for heating water only. DO NOT put other liquids into it.
Different liquids have different boiling points, with volatile liquids having boiling
points lower than 100°C, the boiling point of water.
This appliance is NOT suitable to be used in an explosive environment (in the
presence of flammable substances such as gas, vapour, mist or dust, in atmospheric
conditions when, after ignition, the combustion is spread in the air). Items
containing these substances should never be placed in the appliance, and never be
used to clean the appliance in order to avert the risk of fire or explosion.
The packing materials (plastic bags, expanded polystyrene, etc.) must be kept out
of the reach of children or disabled persons since they represent potential sources
of danger.
The installation/assembly of the appliance will be made in accordance with the
indications of the manufacturer. A wrong procedure may cause damages to persons,
animals or objects, for which the manufacturer cannot be considered responsible.
Before use, check the integrity of the appliance and power cable. In case you are not
sure, contact a qualified person. If the power cable is damaged, it must be replaced
by the manufacturer or its service agent or a qualified technician in order to avoid a
shock hazard.
Before powering the appliance make sure the rating (voltage and frequency)
corresponding to the grid and the socket is suitable for the plug of the appliance,
and that the wall socket is properly grounded.
DO NOT power the appliance using multiple sockets. If possible, avoid the use of
adapters and/or extension cables; if their use is absolutely necessary, use only
materials in compliance with the current safety regulations and according to the
electrical parameters of the adapters.
The appliance must NOT be switched on using external timers and/or other remote
control appliances which are not specified in this manual.
Only use original components & accessories provided by the manufacturer. Any
non-original components & accessories NOT recommended by the manufacturer
may cause injuries to persons or damage to the appliance.
During use and storage, the appliance must be kept at a safe distance from heat
sources (open flame, heaters, stoves, etc.) or any flammable and/or potentially
explosive substances.
WARNINGS
3

13.
14.
15.
If you are using the appliance for the first time, you should:
a.
b.
c.
d.
Make sure to remove any label or protective sheet which may prevent its proper
functioning.
DO NOT:
•
•
•
•
•
•
•
•
•
•
•
•
•
Before plugging & unplugging the appliance, turn the Control Knobs on the
appliance to‘OFF’. Plug and unplug the power cable holding it firmly with dry hands.
Always unplug the power cable to avoid overheating and avoid stretching it (DO
NOT pull it, tug it or use it to drag the appliance to which is connected).
During operation, DO NOT touch the appliance with wet body parts, and it is
recommended to have between you and the standing surface, an isolating element
(for example, wearing shoes with rubber soles).
Clean the Glass Lid, BBQ Pan & Suki Pot thoroughly with hot water & detergent
with a non-abrasive sponge. DO NOT use metal scouring pads. Wipe the surfaces
of the BBQ Pan & Suki Pot and the Glass Lid dry. Check that the BBQ Pan & Suki
Pot is securely placed onto the appliance before you start using the appliance.
Notice: you can use a dishwasher to clean the Glass Lid
Clean the exterior of the appliance with a damp cloth, and immediately wipe dry.
A “trial run”at high temperatures to eliminate substances like oil that may be
present can be conducted. Place and use the appliance on a horizontal, stable
and heat-resistant surface. Fill about 80% of the Suki Pot with water and place it
into the body on top of the Heating plate. Cover the Suki Pot with the Glass Lid.
Plug the power cable into the electric mains and switch it on. Turn both Control
Knobs to ‘MAX’. Both the Indicator Lights will light up, and the heating will
commence. Smoke and odour may be emitted due to the combustion of these
substances and this is normal. Wait for the water to cool after boiling. Discard the
water. Then the appliance is safe to use.
Should there be a need to stop the appliance from heating, simply turn both of
the Control Knobs to‘OFF’. The Indicator Lights will turn off, and the heating will
cease. Turn off the main switch and remove the plug from the electric mains and
the Power Cable from the Power Cable Socket.
cover the appliance during functioning;
turn on the BBQ Control Knob if no food is placed onto the BBQ Pan;
turn on the Suki Control Knob if no liquid is put into the Suki Pot, or whilst in the
process of adding liquids;
turn on any Control Knob in the process of cleaning or moving the appliance;
obstruct totally nor partially the Glass Lid;
insert objects or body parts inside the protection cover of the appliance;
place large amounts of food onto the BBQ Pan;
overfill the Suki Pot to avoid overflow of hot liquids;
switch the appliance on if the Suki Pot is dry - however, should the pot be found
empty during operation, immediately unplug the power cable and add water to
avoid dry-boil;
touch the Glass Lid, the BBQ Pan or Suki Pot of the appliance, except the Lid
Handle, Handles, Control Knobs or Drain Hole Tray when in operation or just after
switching it off as it will still be very hot and may cause scalding. The bottom of
the cooker becomes exceedingly hot as the cooker operates;
turn the Control Knobs too hard so as to avoid any damage;
place the appliance in the microwave oven or refrigerator, so as to avoid breaking
or damaging it;
leave the appliance unsupervised during operation.
4

16.
17.
18.
19.
20.
21.
22.
23.
24.
25.
DO NOT soak the main body of the appliance in water or other liquids except for
the Glass Lid, wash it under the tap, or let any liquid flow into the internal casing of
the appliance to prevent electric shock. In case of accidental fall in water, DO NOT
try to take it out, but first of all unplug immediately the power cable from the socket.
Place the appliance at a proper distance from other objects such as curtains &
textiles or surrounding walls, making sure that its functioning will not cause
accidental damages. There should be at least 10 cm of free space from the back, left
& right sides, and the top of the appliance. Never put things on top of the Glass Lid.
The appliance should NOT be placed on a surface or in the vicinity of objects which
can be damaged by heat, such as carpets or plastics. When using the appliance, the
surface that the appliance is placed upon may become very hot. If the appliance is
operated on wooden furniture, use a protective pad to prevent damage to delicate
finishes.
Avoid placing the power cable on abrasive or sharp surfaces or in positions where it
can be damaged easily.
Always remember to unplug the power cable of the appliance if it is NOT used for a
long period, before storing, cleaning or performing any maintenance operation.
Avoid carrying out operations which are NOT specified in this manual (such as
disassembling and/or altering).
In case of malfunction or anomaly during the functioning, switch off the appliance
immediately, turn off the power and check the cause of the anomaly, if possible,
with the support of a qualified person.
During the period of operation, high temperature steam may escape from the
container. To avoid scalding:
DO NOT
•
•
•
•
•
•
•
•
•
•
Switch off the appliance and unplug the socket from the electric mains when not in
use and before filling, emptying and cleaning the appliance. Before cleaning or
storing the appliance, leave to cool for at least 30 minutes.
Wash the Glass Lid, BBQ Pan & Suki Pot and utensils after usage to avoid build-up of
bacteria.
fill the Suki Pot with hot water;
fill water below 50% & beyond 80% of the maximum volume of the Suki Pot;
allow all of the water to be boiled away;
remove the Glass Lid while heating & ensure that the lid is tightly closed during
heating;
use the appliance to heat oil or melt butter;
add food with its packaging (plastic wrapper, paper, foil, metal can, etc.) still
attached without first removing the packaging;
place any container onto or inside the appliance;
move the appliance using the Glass Lid. Wait until boiling is completed, the
power turned off, then unplug the socket from the electric mains and move the
appliance using the Handles carefully. Always wear protective, insulated oven
gloves when performing such actions;
touch any part of the appliance, except the Lid Handle, Handles, Control Knobs
or Drain Hole Tray when the appliance is hot;
direct steam at any person or animal & one’s hands and face should be angled
away from the BBQ Pan and Glass Lid at all times.
5

26.
27.
28.
29.
30.
If smoke is observed coming out of the appliance, unplug the power cable
immediately. Remove the Glass Lid or any other utensil placed on the appliance
after it has stopped smoking.
This appliance is NOT intended for commercial use but to be used in households
and similar applications, such as:
• Staff kitchen areas in shops, offices and other working environments;
• Dormitories;
• By clients in hotels, motels and other residential environments;
• Bed and breakfast type environments.
DO NOT use or store the appliance outdoors. Store and use the appliance only
indoors, or in any case, protected from weathering such as rain, direct radiation of
the sun and dust.
This appliance can be used by children aged from 8 years and above and persons
with reduced physical, sensory or mental capabilities or lack of experience and
knowledge if they have been given supervision or instruction concerning use of the
appliance in a safe way and understand the hazards involved. Children shall NOT
play with the appliance. Cleaning and user maintenance shall NOT be made by
children unless they are older than 8 and supervised. Keep the appliance and its
cable out of reach of children less than 8 years old.
Save these instructions.
6

1.
2.
3.
4.
5.
6.
7.
Place and use the appliance on a dry, horizontal, stable and heat-resistant surface.
Add the food ingredients onto the BBQ Pan or Suki Pot and add suitable amounts
of water, between 50% and 80% of the height of the Suki Pot. Allow about 4 to 5
minutes for the appliance to reach the ideal temperature for cooking. Adjust the
quantity of water to your personal taste. As pouring liquids into an empty container
is dangerous (the container may be very hot and this may cause the liquid to splash
out), always pour water or soup into the Suki Pot first before switching on the
appliance.
Cover the Suki Pot with the Glass Lid. If the Glass Lid is not positioned correctly,
cooking might be affected. Overspill could occur which may lead to injuries like
scalding or damage to the surroundings.
Plug the power cable into the electric mains and switch it on. Turn on the BBQ
Control Knob, Suki Control Knob (or both) on the appliance. The respective
Indicator Lights will light up, and the heating will commence. Turning the Power
Control Knob to ‘OFF’ will cease heating immediately. The Control Knobs provide
easy control for switching on the BBQ Pan or Suki Pot individually & simultaneously.
You may alter the rate of heating by adjusting the Control Knobs while cooking.
The appliance will automatically stop heating when the temperature reaches the
maximum set temperature, and it will automatically reheat when the temperature
decreases after a few minutes.
Once cooking is completed, turn the Control Knobs to ‘OFF’, switch off the appliance,
and unplug the power cable from the electric mains. Be cautious when checking on
the food or taking it out. Lift the Glass Lid by the Lid Handle, and expect that a lot of
steam will rush out. One’s hands and face should be angled away from the opening
between the Glass Lid and the Suki Pot.
Always use a wooden spatula for stir frying or stirring so as not to damage the
non-stick coating on the BBQ Pan and Suki Pot.
HOW TO USE
7

1.
2.
3.
4.
5.
Descaling
From time to time, boiled scale deposit will naturally form on the BBQ Pan & Suki Pot,
thus reducing heating efficiency. The frequency of descaling depends on the quality
of tap water in your region and the frequency of use of the appliance.
1.
2.
3.
4.
5.
6.
7.
8.
9.
10.
11.
Switch off the appliance and unplug from the electric mains. Allow sufficient time
for the appliance to cool.
Clean the Glass Lid, BBQ Pan & Suki Pot thoroughly with hot water & detergent with
a non-abrasive sponge. DO NOT use corrosive cleaners or a steel brush to avoid
damaging the non-stick coating.
Wipe the exterior of the appliance using a soft, damp cloth or sponge.
Remove stubborn spots with a cloth moistened with mild liquid detergent.
DO NOT use abrasive scouring pads or powders
Never immerse the appliance in water or other liquids, except for the Glass Lid.
If the appliance is not used for a long time, clean and put it in the packing box.
Store in a dry and ventilated place.
Suki Pot
Fill the Suki Pot to its maximum volume using a mixture of one part ordinary
vinegar and two parts water.
Boil the mixture as per normal.
Leave the mixture in the Suki Pot overnight, and discard it the next morning.
Fill the Suki Pot to its maximum volume with water.
Boil the water as per normal.
Discard the boiled water to remove any remaining scale and vinegar.
Rinse the inside of the Suki Pot with water.
The descaling is complete and the Suki Pot is ready to be used.
BBQ Pan
Add a mixture of one part ordinary vinegar and two parts water onto the surface of
the BBQ Pan until the linear raised embossments are covered with liquid for a day
and then discard.
Rinse the BBQ Pan with water.
The descaling is complete and the BBQ Pan is ready to be used.
HOW TO CLEAN
8

PROBLEM SOLVING
Problem Possible Causes How to Solve
The appliance is not
plugged in or the
Control Knobs on the
appliance are not turned
ON.
Plug the appliance into the
electric mains and switch it on.
Turn the Control Knobs on the
appliance to‘LOW’, MIDDLE’ or
‘HIGH’.
Household power circuit
has blown.
Check the household circuit
breaker for any tripped wires.
Call for a qualified electrician.
Fuse on appliance is
blown.
Send the appliance to the service
centre for checks.
The appliance fails to
convert water into
steam.
Indicator Light/s on
appliance does/
do not illuminate.
Mineral build-up in the
appliance.
Follow the steps listed in the
‘Descaling’ instructions contained
in the Instruction Manual.
Control Knob/s on
appliance is/are
damaged.
Send the appliance to the service
centre for checks.
Heating element on
appliance is damaged.
Send the appliance to the service
centre for checks.
The appliance contains
no water.
Refill the appliance with water.
The appliance fails to
convert water into
steam.
Indicator Light/s on
appliance illuminates.
The appliance fails to
convert water into
steam.
Indicator Light/s on
appliance illuminates
intermittently.
The appliance is
working.
Indicator Light/s on
appliance does/do not
illuminate.
9

The manufacturer provides warranty in accordance with the legislation of the
customer’s own country of residence, with a minimum of 1 year, starting from the date
on which the appliance is sold to the end user.
The warranty covers defects in material and workmanship.
The repairs under warranty may only be carried out by an authorised service centre.
When making a claim under the warranty, the original bill of purchase (with purchase
date clearly indicated) must be submitted.
The warranty will not apply in cases of:
•
•
•
•
•
•
normal wear and tear
if the steps (as laid out in the section regarding Warnings) have not been observed
e.g. overloading of the appliance, use of non-approved accessories
if the appliance has not been properly maintained, if force has been used against it
or if it has been damaged in any other way
damage caused by non-observance of the user manual or non-compliance with the
installation instructions
errors or faults owing to defects in the distribution system
if the appliance has been repaired or modified or changed in any way or by any
person not properly authorised
WARRANTY
This appliance, along with all other electronic appliances, should, when it is no longer
capable of functioning, be disposed with the least possible environmental damage
according to the local regulations in your area. In most cases you can discard the
appliance at your local recycling center.
DISPOSAL: Do not dispose this product as unsorted municipal waste. Collection of
such waste separately for special treatment is necessary.
ENVIRONMENTAL TIP
SPECIFICATION
PPMC677
MODEL
220-240V ~ 50/60Hz
VOLTAGE
1500W
POWER
1L + 32CM BBQ
CAPACITY
10
