PowerPac PP3403A User manual

Model: PP3403A
220637-24

RECIPES
The PowerPac Juice PP3403A is a fast juicer (or centrifugal juicer) which utilisers a fast rotating centrifugal
mesh fitted with metal blades which breaks down fruits, vegetables and some greens into the juice. The
pulp is sorted and placed into a separate receptacle. It is easier to clean, juices a lot faster, is capable of
producing a large quantity of juice, and the appliance itself is much cheaper compared with a Slow Juicer.
The PowerPac Juice PP3403A 405 extracts juice quickly and efficiently. With a dedicated design fitted with a
large Loading Tube, use of high quality materials such as food-grade Stainless Steel Filter mesh and blade
and outstanding functions like a 2-speed gear and a skid-resistant base which holds steady during operations,
you will be making delicious and nutritious fruit juices for yourself and your loved ones for years to come.
Notes : DO NOT extract soft fruits (banana, peach), fruits with hard nuts, ice.
DO NOT juice vegetables such as carrot, beetroot and broccoli with other vegetables as they contain a lot of
starch. Remove seeds from citrus fruits before juicing as they will make juice taste bitter.
Thick-skinned fruits such (orange, grapefruit, pineapple) should be peeled before juicing; thin-skinned fruits
and vegetable DO NOT need to be peeled.
Suitable fruits and vegetables include: apple, carrots, celery, cucumber, ginger, grapefruit, orange, pineapple,
spinach, squash, sugar beet, tomato, and watermelon.
A little lemon will help reduce the bitter taste of vegetables, while a little honey will sweeten the taste. You
can add cinnamon or mint to spice up the taste of the juice.
It is advisable to drink fruit juice immediately (or store it in the refrigerator) after extraction, as oxygen in air
oxidises the juice quickly and nutrients present in the juice will be lost.
The pulp can be saved and used as a plant fertiliser.
Apple & Carrot Juice Apples
Carrots
Lemon
Honey
1.
2.
3.
Cut apples & carrots into small pieces.
Put it into the juicer.
Put the juice into a cup, add a few drops
of honey & a few drops of lemon, and stir.
Chill it in a refrigerator. Serve with a slice
of fresh lemon.
1.
2.
3.
Cut 2 carrots & 1 fresh ginger into small
pieces. Put it into the juicer.
Put the juice into a cup, add yoghurt,
and stir.
Chill it in a refrigerator. Serve with
fragrant mint leaves.
1.
2.
3.
Peel orange and cut into small pieces.
Slice tomato. Put them into the juicer.
Put the juice into a cup, add sugar,
and stir.
Add ice cubes.
1.
2.
3.
Cut pineapple into small pieces.
Put it into the juicer.
Put the juice into a cup, add 2
tablespoons of honey, and stir.
Add ice cubes.
1.
2.
3.
Peel squash and cut into small pieces.
Put it into the juicer.
Put the juice into a cup, add 2
tablespoons of sugar, 2 tablespoons
condensed milk, and stir.
Add ice cubes.
2 carrots
1 fresh ginger
½ cup of
unsweetened
yoghurt
1 orange
1 tomato
Sugar
Ice cubes
1 pineapple
2 tablespoons
honey
Ice cubes
¼ squash
2 tablespoons
sugar
2 tablespoons
condensed milk
Carrot & Ginger Juice
Orange & Tomato Juice
Pineapple Juice
Squash Juice
1

PARTS & DESCRIPTION
LIST OF COMPONENTS
1.
2.
3.
4.
5.
6.
7.
8.
9.
10.
Pusher
Lid
Filter
Motor Wheel
Holder
Handle
Base
Speed Dial
Collector
Cup
Gently feeds food pieces into the Filter
Holds the Filter and Holder to the Base
Slices large pieces into small ones
Rotates the Filter
Separates juice and dry fibrous husk
Locks Base, Filter and Holder together
Contains the motor engine
Controls the speed of juicing
Collects the dry fibrous husk
Collects the Juice
-
-
-
-
-
-
-
-
-
-
1
6 10879
2
4
5
3
2

ATTENTION :
Read this booklet carefully as it contains important instructions for a safe installation, use and
maintenance. Important instructions to be kept for future reference.
The following basic precautions should always be followed when using electrical appliances:
1.
2.
3.
4.
5.
6.
7.
8.
9.
10.
11.
12.
13.
Read all instructions before using the appliance.
The Appliance
This appliance must be used only for the purpose it was expressly designed; any use NOT
complying with the instructions contained in the manual is considered inappropriate and
dangerous. DO NOT use this appliance as a grinder or a masher. It DOES NOT puree foods,
grind meat, whip dairy or process vegetables. The manufacturer is NOT responsible for
possible damages caused by the inappropriate and/or unreasonable use.
The installation/assembly of the appliance will be made in accordance with the indications
of the manufacturer. A wrong procedure may cause damages to persons, animals or objects,
for which the manufacturer cannot be considered responsible.
Before use, check the integrity of the appliance and power cable. DO NOT operate the
appliance at all when the Motor unit, Lid, Filter or Holder is damaged. In case you are not sure,
contact a qualified person. If the power cable is damaged, it must be replaced by the
manufacturer / service agent or a qualified technician in order to avoid a shock hazard.
Before powering the appliance make sure the rating (voltage and frequency) corresponding
to the grid and the socket is suitable for the plug of the appliance, and that the wall socket is
properly grounded.
Avoid the use of adapters and/or extension cables; if their use is absolutely necessary, use only
materials in compliance with the current safety regulations and according to the electrical
parameters of the adapters.
The appliance must NOT be switched on using external timers and/or other remote control
appliances which are not specified in this manual.
Only use original components & accessories provided by the manufacturer. Any non-original
components & accessories made by other manufacturers or by the same manufacturer but for
other models of the same capacity or otherwise, may cause injuries to persons or damage to
the appliance. Doing so will void the warranty and may cause serious injury.
The packing materials (plastic bags, expanded polystyrene, etc.) must be kept out of the reach
of children or disabled persons since they represent potential sources of danger.
Location
This appliance is NOT suitable to be used or stored near heat sources (open flame, ovens,
heaters, stoves, etc.) and/or in an explosive environment (in the presence of flammable
substances such as gas, vapour, mist or dust, in atmospheric conditions when, after ignition,
the combustion is spread in the air). Items containing these substances should never be
placed in the appliance, and never be used to clean the appliance to avert the risk of fire or
explosion.
Place the appliance at a proper distance from objects or surrounding walls making sure that
its functioning will not cause accidental damages. The appliance should NOT be placed on a
surface, or in the vicinity of objects, which can be damaged by heat such as carpets or plastics.
Never use the appliance near curtains or textiles. If the appliance is operated on wooden
furniture, use a protective pad to prevent damage to delicate finishes.
Avoid placing the power cable on abrasive or sharp surfaces or in positions where it can be
damaged easily. Avoid placing heavy objects on the cable. The cable must NOT be placed
under carpets, or covered with throw rugs, runners or similar. Arrange the cable away from
the high traffic area, and where it will NOT be tripped over. DO NOT pull or carry the appliance
by the cable.
DO NOT use or store the appliance outdoors. Store and use the appliance only indoors, or in
any case, protected from weathering such as rain, direct radiation of the sun and dust.
WARNINGS
3

14.
15.
16.
17.
18.
19.
20.
21.
22.
Operation
If you are using the appliance for the first time, you should:
a.
b.
c.
d.
e.
DO NOT:
•
•
•
•
•
•
•
•
•
•
•
During operation, DO NOT touch the appliance with wet body parts, and it is recommended
to have between you and the standing surface, an isolating element (for example, wearing
shoes with rubber soles).
DO NOT soak the Base, which contains the main engine of the appliance, in water or other
liquids, wash it under the tap, or let any liquid flow into the internal casing of the appliance to
prevent electric shock. In case of accidental fall in water, DO NOT try to take it out, but first of
all switch the appliance off.
Switch the appliance OFF before unplugging the appliance. Plug and unplug the power cable
firmly holding it with dry hands. Always unplug the power cable to avoid overheating; if it is
NOT used for a long period and before storing, cleaning or performing any maintenance
operation. Remember that the blades may still be moving after the power cable is unplugged!
Prior to the latter, leave to cool for at least 10 minutes.
To operate, the Filter should contain sufficient quantity of food – cut fruits and vegetables
should be NO larger than 2 inch (5 cm) in length and thickness – and must NOT contain dry
food, food with insufficient amount of water, hard substances or liquids with a temperature
greater than 60°C.
Wash the Pusher, Lid, Filter, Holder, Handle, Base, Collector, Cup under running water
immediately after usage to avoid build-up of bacteria with water & detergent with a
non-abrasive sponge. (Warning: Blades are sharp!).
In the event the mixing of the food items produce bubbles, stop the operation immediately
and wait until the production of bubbles ceases before resuming juicing.
In case of malfunction or anomaly during the functioning such as smoke coming out of the
appliance, switch the appliance off immediately, turn off the power and check the cause of
the anomaly, if possible, with the support of a qualified person.
This appliance is NOT intended for commercial use but to be used in households and similar
applications, such as:
• Staff kitchen areas in shops, offices and other working environments;
• By clients in dormitories hotels, motels and other residential environments;
• Bed and breakfast type environments.
Clean the exterior & interior of the appliance with water & detergent with a non-abrasive
sponge. DO NOT use metal scouring pads nor use solvents like paint thinners or acetone.
Dry the accessories thoroughly.
Assemble the components to the Base according to the instructions listed in the section
(“How to Use”) below.
Juice for 3 minutes and then let the appliance rest for 2 minutes between processing
cycles. After 3 processing cycles, allow an interval of 15 minutes to let the appliance
cool down before the next use.
Before adding ingredients, make sure the Filter is in place and is running smoothly.
Make sure to remove any label or protective sheet which may prevent its proper functioning.
overload the Filter by adding too much ingredients;
cover the appliance during functioning;
place foods or liquids which are hotter than 60°C, or use boiling water for cleaning;
insert objects or body parts inside the protection cover of the appliance;
touch the blades of the Filter or the motor with your fingers or any utensil during the
operation of the appliance, so as to avoid personal injury or damage to the appliance;
touch the blades, for they are VERY SHARP! Hold the smooth rim of the Filter while installing,
removing or cleaning;
use the appliance to process very hard ingredients or fruits containing hard seeds (remove
the seeds first), ice cubes or other frozen foods, fruits or vegetables with thick skins (peel
the skins off first), soft ingredients, such as coffee beans, soybeans, rice;
operate without the Lid being locked in place;
detach the Lid while the appliance is in operation;
turn the Speed Dial too forcefully to avoid any damage
leave the appliance unsupervised during operation.
4

23.
24.
This appliance can be used by children aged from 8 years and above and persons
with reduced physical, sensory or mental capabilities or lack of experience and
knowledge if they have been given supervision or instruction concerning use of the
appliance in a safe way and understand the hazards involved. Children shall NOT
play with the appliance. Cleaning and user maintenance shall NOT be made by
children unless they are older than 8 and supervised. Keep the appliance and its
cable out of reach of children less than 8 years old.
Save these instructions.
Safety Protection
If the appliance overheats, the thermal switch will be activated, leading to the
motor being shut off. Turn the Speed Dial to ‘0’ (OFF). Switch the appliance off and
unplug the power cable from the wall socket. Allow the appliance to cool for at
least 15 minutes before using the appliance.
5

HOW TO USE
1.
2.
3.
4.
5.
6.
7.
8.
9.
10.
11.
12.
13.
Clean the exterior & interior of the appliance with water &
detergent with a non-abrasive sponge.
DO NOT use metal scouring pads.
Put the Holder on the Base.
Put the Filter into the Holder and secure the Motor Wheel
onto the Rotor.
Place the Collector under the Holder.
Put the Lid on top of the Filter and secure it to the Holder.
a. Swing the Handle onto the Lid, and press down the Handle
till a “click” is heard.
b. Place the Cup under the Juice outlet.
Wash the fruits and vegetables, then peel and cut into pieces.
Remove kernels, hard seeds, thick skin or hard shells, if present.
Ensure the Speed Dial is set to‘0’. Holding the plug firmly it with
dry hands, firmly insert the Plug of the power cable into the
wall socket.
Turn the Speed dial from ‘0’ to ‘1’ or ‘2’.
Safety measure: This appliance will only work if all components
are installed properly. Should the appliance not work, turn the
Speed dial back to ‘0’ and unplug the power cable.
Dissemble the appliance and go through steps 2 – 6 again.
Drop the pieces of fruits and vegetables into the Feed Tube of
the Lid, and use the Pusher to push them into the Filter.
DO NOT use the appliance for more than 3 minutes without
interruption. Let the appliance rest for 2 minutes between
processing cycles. After 3 processing cycles, allow an interval of
15 minutes to let the appliance cool down before the next use,
so as to prolong its service life. DO NOT allow the appliance to
idle while in operation.
Safety measure: This appliance is designed with Overheat
Protection function which automatically stops the appliance
from operating when the motor is hot. Turn the Speed dial back
to ‘0’ and unplug the power cable. Let the appliance cool down
before the resumption of juicing.
(only if a blockage occurs: DO NOT continue pushing if the Filter is
blocked. Turn the Speed dial back to‘0’and unplug the power cable.
To clear the blockage:
a. Remove the Pusher.
b. Remove the Cup under the Juice outlet.
c. Remove the Collector under the Holder.
d. Swing the Handle off the Lid.
e. Lift the Lid off the Holder.
f. Clear the blockage from the Filter.
Perform steps 4 – 7 again.)
Upon the completion of the juicing, turn the Speed dial back to‘0’and unplug the power
cable. Enjoy your drink.
1 Low-speed gear for processing soft fruits and
vegetables such as watermelon, tomato, cucumber
and strawberry
2 High-speed gear for processing harder fruits and
vegetables
6

HOW TO CLEAN AND MAINTAIN
1.
2.
3.
4.
5.
6.
Turn the Speed dial back to ‘0’ and unplug the power cable.
Dissemble the appliance with the following steps:
a.
b.
c.
d.
e.
f.
g.
Use a wet cloth to wipe the Base dry. DO NOT immerse this in water or other liquids,
and avoid spraying water, in order to avoid damage or leakage.
Wash the Pusher, Lid, Filter, Holder, Handle, Base, Collector, Cup under running water
immediately after usage to avoid build-up of bacteria & detergent with a non-abrasive
sponge. DO NOT use metal scouring pads, abrasive cleaners or corrosive liquids such
as gasoline or acetone to clean this appliance. DO NOT clean any of the components
in a dishwasher. After washing, air-dry the components. Blades are sharp!
To store the appliance, reassemble the components as follows:
a.
b.
c.
d.
e.
f.
g.
Ensure that the appliance is clean, dry, and placed in dry and well ventilated storage.
Avoid direct sunlight.
Remove the Pusher.
Remove the Cup under the Juice outlet.
Remove the Collector under the Holder.
Swing the Handle off the Lid.
Lift the Lid off the Holder
Lift the Filter off the Motor Wheel and remove it from the Holder.
Lift the Holder off the Base.
Put the Holder on the Base.
Put the Filter into the Holder and secure it into the right position of the Motor Wheel.
Put the Lid on top of the Filter and secure it to the Holder.
Swing the Handle onto the Lid, and press down the Handle till a “click” is heard.
Place the Collector under the Holder.
Place the Cup under the Juice outlet.
Insert the Pusher into the Feed Tube.
SPECIFICATION
PP3403A
MODEL
220-240V
VOLTAGE
50/60Hz
FREQUENCY
250 – 400 W
POWER
7

PROBLEM SOLVING
Fault symptom
The appliance
does not work
after
connecting the
power cable to
the electric
mains and
switching the
appliance on
The Holder is not
correctly installed
The Handle is not
correctly installed
The Filter is not
correctly installed
The Filter is stuck
with ingredients
The appliance
stops working
while in use
The Pusher is forced
in too violently
Overheat Protection
function automatically
stops the appliance from
operating when the
motor is hot
Insert the Pusher gently
Safety measure: Turn the Speed dial back
to ‘0’ and unplug the power cable.
Let the appliance cool down before the
resumption of juicing
It is a normal
phenomenon when a
new motor is initially
used
The smell will disappear with useThe motor
gives off an
unpleasant
smell while in
operation
Install theHolder correctly
Install the Handle correctly
Install the Filter correctly
Cause analysis Troubleshooting
DO NOT continue pushing if the filter is
blocked. Turn the Speed dial back to ‘0’
and unplug the power cable. To remove
the ingredients:
a. Remove the Pusher
b. Remove the Cup under the Juice outlet
c. Remove the Collector under the Holder
d. Swing the Handle off the Lid
e. Lift the Lid off the Holder
f. Clear the blockage from the Filter
g. Put the Lid on top of the Filter
and secure it to the Holder
h. Swing the Handle onto the Lid, and
press down the Handle till a“click” is
heard
i. Place the Collector under the Holder
j. Place the Cup under the Juice outlet
k. To prevent further blockage, cut the
ingredients into smaller pieces or put
less ingredients
8

This appliance, along with all other electronic appliances, should, when it is no longer capable of
functioning, be disposed with the least possible environmental damage according to the local
regulations in your area. In most cases you can discard the appliance at your local recycling centre.
DISPOSAL: Do not dispose this appliance as unsorted municipal waste.
Collection of such waste separately for special treatment is necessary.
Risk of child or animal entrapment
Before you discard this appliance, please remove all doors and leave the shelves inside so that
children or animals may not easily get trapped inside.
ENVIRONMENTAL TIP
Warranty Conditions
1.
2.
3.
4.
5.
6.
7.
8.
9.
10.
This warranty provides against defective materials and manufacturing faults throughout for
two years from the date of purchase of the appliance. The warranty on the Compressor is 10
years subject to the same conditions as above.
This warranty also does not cover normal wear and tear, replacement of consumable
materials and accessories, and the cost of maintenance of the appliance.
This warranty does not cover the repair or replacement of part/s damaged by misuse,
accidents, negligence, alterations, or modifications in any way, or repairs done by any repair
organisation without the prior consent of PowerPac Electrical Pte Ltd.
Repair and service are to be performed at: 5 Changi South Lane #03-01 Singapore 486045.
A transport fee will be charged for personal doorstep service.
The original purchaser of the appliance must furnish proof of purchase to our Service Centre
with the email or number as registered during submission of warranty when this appliance is
sent for repair/service. Failure to do so may delay the receipt of said repair/service by the
customer.
Under no circumstances whatsoever shall the serial number be erased, defaced or altered by
the customer and/or his representatives, or the dealer and/or his agents. Failure to ensure
this shall invalidate the warranty.
This warranty is deemed to be void if the defect is cause by the attack of household pests,
fire, lightning, natural disasters, pollution, abnormal voltage or the usage of generators.
This warranty is valid in Singapore only.
This warranty will be honoured subject to the customer’s registration of the warranty
inclusive of original invoice or valid purchase receipt. Failure to present these documents will
result in denial of service. However, if the customer still requests that the defective appliance
be repaired, PowerPac Electrical Pte Ltd may, at its discretion, repair the appliance but impose
a labour charge, as well as the costs of the replacement parts, to be borne solely by the
customer.
Please refer to the attached picture for the location of one of our appliance’s serial number,
as an example.
Please complete the on-line registration warranty form available
on our website. There is no further requirement to send us any
hard copy as part of our efforts to save the environment.
In accordance with the terms and conditions of this limited
warranty as stated above, PowerPac Electrical Pte Ltd, at its
expense shall provide free services for the appliance within the
warranty period from its date of purchase from our Authorised
dealers.
WARRANTY
E-Register scan
9
