PowerShield PSDCMin12 User manual

1. Package Contents
Thank you for purchasing the PowerShield 12V DC 18W Mini UPS (PSDCMin12/18).
Please check for the following items inside of the packaging:
- PowerShield PSDCMin12/18 DC UPS adaptor with a wide variety of DC connectors
- Quick Guide
If anything is missing or damaged, please contact your dealer.
2. Product Overview
ARestart/OFF Button CDC output with a wide variety of interchangeable tips
BLED indicator DAC input
3. Installation and Operation
Please inspect the PSDCMin12/18 for any damage before installation.
Battery Access: Battery cover screw is located under the manufacturing date code label.
Rechargeable Lion
Battery Cover access screw
Connecting to Utility and Charging
The PSDCMin12/18 will automatically turn on when (D) is plugged into the powered wall
socket. The PSDCMin12/18 will turn on and switch on the green LED. If the battery is not
fully charged, the DC UPS will auto charge the battery and the green LED will flash on/off
until fully charged.
Connecting the Loads
Insert the desired DC connector in the DC output adaptor (C) of the PSDCMin12/18 and
connect to the load. The connected 12VDC device will then be protected up to a maximum
power of 18 Watt by the PSDCMin12/18.
Restart/OFF Button Operation
If the PSDCMin12/18 experiences overload, it enters fault mode and switches the RED LED
ON. Remove the fault by disconnecting the load and press restart button to restart the UPS.
To turn OFF the DC UPS, unplug from the wall outlet, press the OFF button and hold for 5
seconds.
1
2

LED Indication
This LED is a two-color indicator: green or red color depending on operation status.
Status
Color
On/Flash
Power on with battery fully charged.
Green
On
Power on with charging the battery.
Green
Slow Flash
UPS is on but power failure occurs. UPS will transfer to
backup mode and battery is discharging.
Green
Quick Flash
Any fault occurs on UPS.
Red
On
4. Applications
The DC UPS is designed for indoor use to provide emergency power backup to all kinds of 12V
DC-powered equipment up to a maximum power of 18 Watt such as routers, modems, set-top
box, VOIP phone systems, surveillance system, alarm system, access control system and many
critical telecom equipment.
5. Important Safety Warning (PLEASE SAVE THESE INSTRUCTIONS)
To safely operate this DC UPS, please read and follow all instructions carefully.
Read this manual thoroughly before attempting to unpack, install, or operate.
Please keep this quick guide for further reference.
CAUTION! Do NOT use this device in hot and humid environments.
CAUTION! Do NOT disassemble this product.
CAUTION! If the battery level is low, please recharge battery immediately.
CAUTION! When installing or replacing a new battery, be sure positive (+)
and negative (-) are correctly connected. Otherwise, DC UPS will be damaged.
CAUTION! Replace the Lithium-ion battery with the same type as stated in
specifications.
6. Trouble Shooting
Use the table below to solve minor problems.
Problem
Possible Cause
Solution
Red LED is on.
Overload or short circuit occurs
on UPS and UPS transfers to fault
mode.
Remove fault (disconnect load). Press
button for more than 1 second and
release to restart unit.
Battery backup time is
shorter than nominal
value.
Battery is far too low.
Contact your dealer for a replacement
battery.
No output and LED
indicator is off.
Internal fault has occurred.
Contact your dealer.
7. Specifications
MODEL
PSDCMin12/18
AC INPUT
Voltage Range
90 VAC ~ 264 VAC
Frequency
50 or 60 Hz
Surge protection
125J @ 4500A
DC OUTPUT
Voltage
12VDC ± 5%
Max. Power
18W (1.5A)
BATTERY
Type
Lithium-ion Battery
Nominal Voltage
3.7VDC
Capacity
2600mAh
Typical Charging time
3 hours recover to 90% capacity
PHYSICAL
Input Plug
Mounted on housing (Australia/New Zealand)
Output cable
2m cable with user selectable DC Male Jacks
Dimension, L x W x H (mm)
76.2 x 46 x 78.8
Net Weight
280g
8. Approximate Load versus Battery Back-up Run Times
Load (Watts)
Load (%)
Approximate Time on battery (in Minutes)
4
22
114
9
50
49
13
72
32
18
100
15
3
4
