PowerWalker VFI CG PF1 Series User manual

ENGLISH
Quick Guide
PowerWalker VFI CG PF1 Series
I. LCD Panel
Display
Function
Indicates the estimated backup time. H: hours, M: minute, S: second.
Indicates the configuration items
Indicates the warning and fault codes
Indicates that the UPS alarm is disabled.
Indicates the input voltage, input frequency, input current, battery voltage,
battery current, battery Power, ambient temperature, output voltage,
output frequency, load current and load percent.
Indicates the load level by 0-24%, 25-49%, 50-74% and 75-100%.
Indicates overload.
Indicates that programmable management outlets are working.
Indicates the UPS connects to the mains.
Indicates the battery is working.
Indicates charging status
Indicates the bypass circuit is working.
Parameter 1 Parameter 2

ENGLISH
Indicates the ECO mode is enabled.
Indicates the AC to DC circuit is working.
Indicates the PFC circuit is working.
Indicates the inverter circuit is working.
Indicates the UPS is working in converter mode.
Indicates the output is working.
Indicates the battery level by 0-24%, 25-49%, 50-74%, and 75-100%.
Indicates low battery.
II. Rear panel view
1K/1.5K 2K 3K
1. Programmable outlets:
connect to non-critical loads.
2. Output receptacles:
connect to mission-critical loads.
3. AC input
4. Network/Fax/Modem surge protection
5. USB communication port
6. RS-232 communication port
7. SNMP intelligent slot
8. Emergency Power Off connector (EPO)
9. External battery connection
III. Communication connection
USB port
RS-232 port
Intelligent slot
Network Surge Protection

ENGLISH
Apart from standard USB Port, the UPS is equipped with RS-232. Those two ports do not work
at the same time.
IV. Modes and warnings
Warning
Icon
Alarm
Muted
Online mode
No Alarm
N/A
ECO mode
No Alarm
N/A
Frequency Converter
mode
No Alarm
N/A
Battery mode
Sounding every 5 seconds
Yes
Bypass mode
Sounding every 10
seconds
Yes
Standby mode
No Alarm
N/A
Low Battery
Sounding every 2 seconds
No
Overload
Sounding every second
No
Over input current
Sounding 2 beep every 10
seconds
No
Battery is not
connected
Sounding every 2 seconds
No
Over Charge
Sounding every 2 seconds
No
Site wiring fault
Sounding every 2 seconds
No
EPO enable
Sounding every 2 seconds
No
Over temperature
Sounding every 2 seconds
No
Charger failure
Sounding every 2 seconds
No

ENGLISH
Battery fault
Sounding every 2 seconds
(At this time, UPS is off to
remind users something
wrong with battery)
No
Out of bypass voltage
range
Sounding every 2 seconds
No
Bypass frequency
unstable
Sounding every 2 seconds
No
Battery replacement
Sounding every 2 seconds
No
EEPROM error
Sounding every 2 seconds
No
V. Frequency Converter Mode
When input frequency is within 40 Hz to 70 Hz, the UPS can be set at a constant output
frequency, 50 Hz or 60 Hz. The UPS will still charge battery under this mode. Frequency
Converter requires de-rating of the UPS Power to 80%.
VI. Button operation
ON/Mute Button
Press and hold ON/Mute button for at least 2 seconds to turn on the UPS.
When the UPS is on battery mode, press and hold this button for at least 3 seconds to
disable or enable the alarm system. But it’s not applied to the situations when warnings
or errors occur.
Press this button to display previous selection in UPS setting mode (up key)
Press and hold ON/Mute button for 3 seconds to enter UPS self-testing while in AC
mode, ECO mode, or converter mode.
OFF/Enter Button
Press and hold this button at least 2 seconds to turn off the UPS. UPS will be in standby
mode under power normal or transfer to Bypass mode if the Bypass enable setting by
pressing this button.
Press this button to confirm selection in UPS setting mode.
Select Button
Press this button to change the LCD message for input voltage, input frequency, battery
voltage, output voltage and output frequency. It will return back to default display when
pausing for 10 seconds.
Press and hold this button for 3 seconds to enter UPS setting mode when UPS is in
standby mode or bypass mode.
Press this button to display next selection in UPS setting mode. (down key)
ON/Mute + Select Button
When the main power is normal, press the two buttons simultaneously for 3 seconds.
Then UPS will enter to bypass mode. This action will be ineffective when the input
voltage is out of acceptable range.
In setting mode, press the two buttons simultaneously for 0.2s to exit the setting mode.
VII. UPS Setting

ENGLISH
Parameter 1
Parameter 2
01
Output voltage setting
200/208/22
0 /230/240
Value in V AC
02
Frequency Converter Mode
ENA/dIS
Enable or Disable (default)
03
Output frequency setting
50 / 60
Value in Hz
50 / 60
Value in Hz
04
ECO Mode
ENA/dIS
Enable or Disable (default)
05
ECO voltage range setting
HLS
Upper Limit for Input Voltage
LLS
Bottom Limit for Input Voltage
HS
Upper Limit for Input
Voltage
Nominal
+7V to +24V
Value in V AC
LS
Bottom Limit for Input
Voltage
Nominal
-7V to -24V
Value in V AC
06
Bypass
ENA/diS
Enable or Disable (default) bypass mode
07
Bypass Input Voltage setting
HLS
Upper Limit for Input Voltage
LLS
Bottom Limit for Input Voltage
HS
Upper Limit for Input
Voltage
Nominal
+7V to +24V
Value in V AC
LS
Bottom Limit for Input
Voltage
Nominal
-7V to -24V
Value in V AC
08
Bypass frequency range setting
HLS
Upper Limit for Input Frequency
LLS
Bottom Limit for Input Frequency
HS
Upper Limit for Input
Voltage
Nominal
+1 to +5 Hz
Value in Hz
LS
Bottom Limit for Input
Voltage
Nominal
-1 to -5 Hz
Value in Hz
09
Programmable outlets
ENA/dIS
Enable or Disable (default)
10
Programmable outlets setting
0-999
Backup time limit in minutes for
programmable outlets. 0 actually means
10s and 999 means disabled
11
Autonomy limitation setting
0-999/dIS
Backup time limit in minutes. 0 actually
means 10s
12
Battery total AH setting
7-999
Total Power of batteries in Ah (2 strings of
9Ah means 18Ah regardless of the length
of the string)
13
Maximum charger current setting
1 / 2 / 4 / 6
/ 8 / 10 / 12
Total Power of batteries in Ah (2 strings of
9Ah means 18Ah regardless of the length
of the string)
14
Charger boost voltage setting
2.25-2.40V
Boost Charging voltage per cell. Each
battery has 6 cells.Default is 2.36V/cell
means 14.16V/bat
15
Charger float voltage setting
2.20-2.33V
Float Charging voltage per cell. Each
battery has 6 cells.Default is 2.28V/cell

ENGLISH
means 13.68V/bat
16
EPO logic setting
AO
Active Open (default). EPO will be
activated if pins 1 and 2 are not shorted
AC
Active Close. EPO will be activated if pins
1 and 2 are shorted
17
External output isolation
transformer connection
ENA/dIS
Allow or disallow (default) external
output isolation transformer connection.
18
Display setting for autonomy time
EAT/RAT
EAT will display the remaining autonomy
time (Default). RAT will show
accumulated autonomy time.
19
Acceptable input voltage range
setting
HLS
Upper Limit for Input Voltage
LLS
Bottom Limit for Input Voltage
HS
Upper Limit for Input
Voltage
280 / 290 /
300
Value in V AC
LS
Bottom Limit for Input
Voltage
110 / 120 /
130 / 140 /
150 / 160
Value in V AC
00
Exit Settings
Maximum charger current setting
Please set the appropriate charger current based on battery Power used. The recommended
charging current is 0.1C~0.3C of battery Power as following table for reference.
Charging current (A)
2
4
6
8
10
12
Battery Power(AH)
7-20Ah
20-40Ah
40-60Ah
60-80Ah
80-100Ah
100-150Ah
VIII. Technical Specification
MODEL
VFI 1000 CG
PF1
VFI 1500 CG
PF1
VFI 2000 CG
PF1
VFI 3000 CG
PF1
POWER*
1000VA/1000
W
1500VA/1500
W
2000VA/2000
W
3000VA /
3000W
INPUT
Voltage
Low Line Transfer
160VAC/140VAC/120VAC/110VAC ± 5 %
Low Line
Comeback
175VAC/155VAC/135VAC/125VAC ± 5 %
High Line Transfer
300 VAC ± 5 %
High Line
Comeback
290 VAC ± 5 %
Frequency Range
40Hz ~ 70 Hz
Power Factor
>0.99 @ full load
THDi
<5% @ 205-245VAC
THDU < 1.6% @ input and full linear load condition
OUTPUT
Output voltage
200/208/220/230/240VAC

ENGLISH
AC Voltage
Regulation
± 1% (Batt. Mode)
Frequency
Synchronized
Range
47 ~ 53 Hz or 57 ~ 63 Hz
Frequency Range
50 Hz ± 0.1 Hz or 60Hz ± 0.1 Hz (Batt. Mode)
Current Crest Ratio
3:1
Harmonic
Distortion
<2 % THD (Linear Load) ; < 4 % THD (Non-linear Load)
Transfer Time
Zero from AC Mode to Battery Mode
Below 4ms from Inverter to Bypass
Waveform
Pure Sinewave
EFFICIENCY
AC Mode
>89% @ full charged battery
>91% @ full charged battery
ECO Mode
>96% @ full charged battery
Battery Mode
>88%
>90%
BATTERY
Battery Type
12V/7AH
12V/9AH
12V/7AH
12V/9AH
Numbers
3
6
Recharge Time
3 hours recover to 95% Power for internal battery@ 2A charging
current
Charging Current
Default 2A, max. 12A
adjustable
Default: 2A, Max: 8A adjustable
PHYSICAL
Dimension, D x W x
H
397 X 145 X 220
421 X 190 X 318
Net Weight (kgs)
13.0
14.6
23.2
28.0
ENVIRONMENT
Operation
Humidity
20-95 % RH @ 0- 40°C (non-condensing)
Noise Level
Less than 50dBA @ 1 Meter (With fan speed control)
MANAGEMENT
USB with HID
PowerWalker ViewPower
* Derate Power to 80% of Power when the output voltage is adjusted to 200VAC or 208VAC.
