PowerWalker VFI ICT/ICR IoT Series
USER MANUAL
Service and support:
Call your local service representative

SAFETY INSTRUCTIONS
SAVE THESE INSTRUCTIONS. This manual contains important instructions that should be
followed during installation and maintenance of the UPS and batteries.
UPS Tower models are considered acceptable for use in the ambient of 0 ~ 45°C;
UPS RT models are considered acceptable for use in the ambient of 0 ~ 40°C;
Certification standards
• Safety: IEC/EN 62040-1
• EMC: IEC/EN 62040-2
• Performance: IEC/EN 62040-3.
• ISO 9001:2015.
• ISO 14001:2015.
Special symbols
RISK OF ELECTRIC SHOCK - Observe the warning associated with the risk of electric
shock symbol.
Important instructions that must always be followed.
EU separate collection and lead content mark for lead acid batteries. Indicates that
the battery must not be disposed of to the ‘normal’ household waste but be
separately collected and recycled.
EU separate collection mark for waste electrical and electronic equipment (WEEE).
Indicates that the item must not be disposed of to the ‘normal’ household waste
but be separately collected and recycled.
Information, advice, help.
Refer to the user manual.
Safety of persons
Dangerous voltage levels are present within the system. It should be opened exclusively
by qualified service personnel.
The system must be properly grounded.
The battery supplied with the system contains small amounts of toxic materials. To avoid
accidents, the directives listed below must be observed:
- Servicing of batteries should be performed or supervised by personnel

knowledgeable about batteries and the required precautions.
- Risk of explosion if battery is replaced by an incorrect type. When replacing batteries,
replace with the same type and number of batteries or battery packs. Instructions
shall carry sufficient information to enable the replacement of the battery with a
suitable recommended type.
- CAUTION: Do not dispose of batteries in a fire. The batteries may explode. Dispose
of used batteries according to the instructions.
-Do not open or mutilate batteries. Released electrolyte is harmful to the skin and
eyes. It may be toxic.
- CAUTION – A battery can present a risk of electrical shock and high short circuit
current. The following precautions should be observed when working on batteries:
Remove watches, rings, or other metal objects.
Use tools with insulated handles.
Wear rubber gloves and boots.
Do not lay tools or metal parts on top of batteries.
Disconnect charging source prior to connecting or disconnecting battery
terminals.
Determine if battery is inadvertently grounded. If inadvertently grounded,
remove source from ground. Contact with any part of a grounded battery can
result in electrical shock. The likelihood of such shock can be reduced if such
grounds are removed during installation and maintenance.
Failed batteries can reach temperatures that exceed the burn thresholds for
touchable surfaces
Product safety
The UPS connection instructions and operation described in the manual must be
followed in the indicated order.
UPS enclosure IP rating IP20.
CAUTION - To reduce the risk of fire, the unit connects only to a circuit provided with
branch circuit overcurrent protection for:
20A rating, for Tower 3ks models, trip curve C .
The upstream circuit breaker for Normal AC/Bypass AC must be easily accessible.
for PERMANENTLY CONNECTED EQUIPMENT, a readily accessible disconnect device shall
be incorporated external to the equipment
for PLUGGABLE EQUIPMENT, the socket-outlet shall be installed near the equipment and
shall be easily accessible
Check that the indications on the rating plate correspond to your AC powered system

and to the actual electrical consumption of all the equipment to be connected to the
system.
Never install the system near liquids or in an excessively damp environment.
Never let a foreign body penetrate inside the system.
Never block the ventilation grates of the system.
Never expose the system to direct sunlight or source of heat.
If the system must be stored prior to installation, storage must be in a dry place.
The admissible storage temperature range is -25°C to +55°C without batteries, 0°C to
+40°C with batteries, suggest to storage the battery below 25°C.
This UPS can be used in TN/IT/TT power system
Special precautions
The unit is heavy: wear safety shoes and use vacuum lifter preferentially for handling
operations.
All handling operations will require at least two people (unpacking, lifting, installation in
rack system).
Before and after the installation, if the UPS remains de-energized for a long period, the
UPS must be energized for a period of 24 hours, at least once every 6 months (for a
normal storage temperature less than 25°C). This charges the battery, thus avoiding
possible irreversible damage.
During the replacement of the Battery Module, it is imperative to use the same type and
number of elements as the original Battery Module provided with the UPS to maintain
an identical level of performance and safety.
This is a category C2 UPS product. In a residential environment, this product may cause
radio interference, in which case the user may be required to take additional measures.

Contents
1Introduction......................................................................................................................................... 1
1.1 Electronic equipment protection........................................................................................... 1
1.2 Environmental protection ....................................................................................................... 2
2Product Overview............................................................................................................................... 3
2.1 Weight and Dimension............................................................................................................. 3
2.2 Rear panels ................................................................................................................................. 5
3Installation ........................................................................................................................................... 9
3.1 Inspecting the equipment ....................................................................................................... 9
3.2 Checking the accessory kit ...................................................................................................... 9
3.3 Install the Unit .........................................................................................................................11
3.4 Connecting the EBM(s) ..........................................................................................................14
4Operation ...........................................................................................................................................16
4.1 LCD panel ..................................................................................................................................16
4.2 LCD description........................................................................................................................17
4.3 Display functions .....................................................................................................................19
4.4 User settings.............................................................................................................................19
4.5 Starting the UPS with utility.................................................................................................. 20
4.6 Starting the UPS on Battery ..................................................................................................21
4.7 UPS Shutdown .........................................................................................................................21
5Communication ................................................................................................................................22
5.1 RS232 and USB.........................................................................................................................22
5.2 UPS remote control functions ..............................................................................................22
5.3 IoT...............................................................................................................................................23
5.4 Modbus TCP .............................................................................................................................24
5.5 Intelligent Card (Optional).....................................................................................................24
5.6 UPS Management Software..................................................................................................25
6UPS maintenance .............................................................................................................................27
6.1 Equipment care........................................................................................................................27
6.2 Transporting the UPS..............................................................................................................27
6.3 Storing the equipment...........................................................................................................27
6.4 Replacing batteries .................................................................................................................27
6.5 Recycle.......................................................................................................................................29
7Troubleshooting................................................................................................................................30
8Specifications ....................................................................................................................................32
8.1 UPS Block Diagram..................................................................................................................32
8.2 UPS Specification.....................................................................................................................32

1
1Introduction
Thank you for selecting PowerWalker VFI ICT/ICR IoT UPS to protect your electrical
equipment. We recommend that you take the time to read this manual to take full
advantage of the many features of the UPS (Uninterruptible Power System).
Before installing the UPS, please read the booklet presenting the safety instructions.
Then follow the indications in this manual.
1.1 Electronic equipment protection
The UPS protects your sensitive electronic equipment from the most common power
problems, including power failures, power sags, power surges, brownouts, line noise,
high voltage spikes, frequency variations, switching transients, and harmonic
distortion.
Special characteristic:
• Double converter with pure sine waveform output
• Full digital control
• Higher power density, and output PF = 1
• Wider input voltage range: 110Vac~300Vac
• Higher efficiency: 93% for 2K/3k, 89% for 1k
• Input THDI<5%
• Bigger charger current for long backup mode:8A, adjustable from 2A to 8A through
LCD
• EBM quantity auto detection
• Communication ports: RPO, Dry in, Dry out, intelligent slot, USB, RS232
• IoT: Ethernet(default) and Wireless (Optional)
• Dot-matrix LCD, it supports Multi-Language
• ECO Mode
• Start-able without battery.

2
1.2 Environmental protection
Products are developed according to an eco-design approach.
Substances
This product does not contain CFCs, HCFCs or asbestos.
Packing
To improve waste treatment and facilitate recycling, separate the various packing
components.
• The cardboard we use comprises over 50% of recycled cardboard.
• Sacks and bags are made of polyethylene.
• Packing materials are recyclable.
Follow all local regulations for the disposal of packing materials.
Product
The product is mainly made up of recyclable materials.
Dismantling and disassembly must take place in compliance with all local regulations
concerning waste. At the end of its service life, the product must be transported to
recycling centers, re-use and treatment facilities for waste electrical and electronic
equipment (WEEE).
Battery
The product contains lead-acid batteries that must be processed according to
applicable local regulations concerning batteries.
The battery may be removed to comply with regulations and in view of correct disposal.

3
2Product Overview
2.1 Weight and Dimension
The weights in this table is reference only, please see the labels on the carton for details.
Tower models：
Description
Net Weights (kg)
Dimensions: D x W x H (mm)
Tower 1K
12.8
404 X 145 X 220
Tower 1KS
6.4
404 X 145 X 220
Tower 1.5K
14.3
404 X 145 X 220
Tower 1.5KS
6.7
404 X 145 X 220
Tower 2K
26.0
428 X 192 X 318
Tower 2KS
11.0
428 X 192 X 318
Tower 3K
26.4
428 X 192 X 318
Tower 3KS 11.4 428 X 192 X 318
Tower 36V EBM 16.8 404 X 145 X 220
Tower 72V EBM 38.7 428 X 192 X 318
W
H
D
W
H
D

4
RT models
Description
Net Weights (kg)
Dimensions: D x W x H (mm)
RT 1K
14.3
445*438*85.5
RT 1KS 8.0 445*438*85.5
RT 1.5K
15.8
445*438*85.5
RT 1.5KS 8.2 445*438*85.5
RT 2K
23.3
600*438*85.5
RT 2KS 10.6 600*438*85.5
RT 3K
26.2
600*438*85.5
RT 3KS 11.0 600*438*85.5
RT 36V EBM
22.6
445*438*85.5
RT 72V EBM 39.9 600*438*85.5
D
D
W
W
H
H

5
2.2 Rear panels
Tower 1K/1KS/1.5K/1.5KS
Tower 2K/2KS

6
Tower 3K
Tower 3KS

7
Tower EBM
RT 1K/1KS/1.5k/1.5KS
RT 2K/2KS
36V
72V
5
5
88
10
5 3 1 7 8
4 6 2
13
11

8
RT 3K/3KS
RT 36V EBM
RT 72V EBM
1
WLAN(HDMI)
2
USB
3
Ethernet (RJ45)
4
RPO/Dry in/Dry out
5
EBM auto detection
6
RS232
7
Slot Card Box
8
EBM Connector
9
Input Breaker(optional)
10
Input Socket/
Input Terminal
11
Output Socket/
Output Terminal
12 Output Fuse (optional)
13
Programmable
Output Socket

9
3Installation
3.1 Inspecting the equipment
If any equipment has been damaged during shipment, keep the shipping cartons and
packing materials for the carrier or place of purchase and file a claim for shipping
damage. If you discover damage after acceptance, file a claim for concealed damage.
To file a claim for shipping damage or concealed damage:
1. File with the carrier within 15 days of receipt of the equipment;
2. Send a copy of the damage claim within 15 days to your service representative.
3.2 Checking the accessory kit
Tower model
1 UPS 2 Input cable
(Except for 3KS models)
3 Output cable
(only for IEC models)
4 USB cable 5 RS232 cable (optional) 6 Slot card (optional)
7 User manual (English) 8 User manual (Multi-Language) (optional)
2
1
3
5
4
67
8

10
RT model
1
UPS
2
Input cable
3
Output cables
4
USB cable
5
Tower stands
6
User manual (English)
7
User manual (Multi-Language) (optional)
8
RS232 cable (optional)
9
Cable lockers (optional)
10
Slot card (optional)
11
Rail kit (optional)
5
2
1
3
9
4
67
8
11
10

11
3.3 Install the Unit
Always keep 200 mm of free space behind the UPS rear panel.
Check that the indications on the name plate located on the top cover of the UPS
meets to the AC-power source and the true electrical consumption of the total load.
1. Connect the UPS input socket
to the AC-power source using
the cable of the protected
equipment.
2. Connect the loads to the UPS
using the cables.
Note: The UPS charges the battery as soon as it is connected to the AC-power source,
even if button is not pressed.
Once the UPS is connected to the AC-power source, 8 hours of charging are required
before the battery can supply the rated backup time.

12
Recommended upstream protection
UPS model
Upstream circuit breaker
Tower 3KS
C curve-20A
Input terminal and output terminal connection:
Tower 3KS
Minimum of section required/ Torque
Termi nal -block capacity
Input L, N, G
conductor cross section
2.5 mm²/(0.3 N·m)
4 mm²
Output L, N, G
conductor cross section
4 mm²/(0.8 N
·
m)
10 mm²
Note: For Tower 3KS, the output cable should less than 3m.
When the cables connected to terminal block, the inner copper wire must not be
exposed to avoid the risk of electric shock.

13
3.3.1 RT models
Rack installation
Follow steps 1 to 4 for module mounting on the rails.
1
1
2
3
3
4
4

14
Tower installation
3.4 Connecting the EBM(s)
A small amount of arcing may occur when connecting an EBM to the UPS. This is
normal and will not harm personnel.
Up to 4 EBMs can be connected to the UPS.
3.4.1 Tower models
1k/1.5k

15
2k/3k
3.4.2 RT models
