Assembly of VI/VFI RT HID Series
I. Installing the UPS

ENGLISH
II. Connecting the EBM in Tower form:
1. Slide down the UPS and EBM vertically and place two UPS stands with the extend
part at the end of the tower.
2. Tighten the screw on the metal
sheet for stabilization
3. Connect the Earth line from UPS
(port A ) to EBM (port B)
4. Take off the front panel, and connect the battery terminal (A) from UPS to EBM
terminal (B) shown as below. Users need to remove the small gate(C) on side of
the front panel to allow the outlet wire of the EBM to pass through the gate and
then reassemble front panel.
B
A
B
AC

ENGLISH
III. Connecting the EBM in a rack form
1. Using the same method as assembling
UPS in a rack form, assemble EBM into
the rack-mounting on the top or
bottom of the UPS.
2. Connect the earth line from UPS (port
A ) to EBM (port B )
3. Take off the LCD box, and unscrew the
internal screws.
4. Take off the front panel, and connect
the battery terminal (A) from UPS to
EBM terminal (B) shown as below.
Users need to remove the small gate(C)
on side of the front panel to allow the
outlet wire of the EBM to pass through
the gate and then reassemble front
panel.
5. After installing the UPS into rack, the load can then be connected to UPS. Please
A
B
Unscrew
Unscrew
BA
C

ENGLISH
make sure the load equipment is turned off before plugging all loads into the output
receptacle.
IV. Connecting the Multiple EBMs
1000VA/1500VA/2000VA and 3000VA UPS include external battery port that allows users
to connect multiple EBM in order to provide additional backup time. Follow the
procedure to install multiple EBM as below.
V. Connecting multiple EBMs in Tower form
1. Connect Earth line between UPS and the
first EBM, and then connect Earth Line
between the first EBM and the second
EBM.
2. Take off the front panel, and connect the
battery terminal (A) from UPS to EBM
terminal (B) shown as below. And then
connect the battery terminal (D) from the
first EBM to the battery terminal (E) from
the second EBM. Users need to remove
the small gate(C) on side of the front
panel to allow the outlet wire of the EBM
to pass through the gate and then
reassemble front panel.
VI. Connecting the Multiple EBMs in rack form
1. Connect Earth line between UPS and the first EBM, and then connect Earth Line between
the first EBM and the second EBM.
B
C
A
D
E

ENGLISH
2. Take off the front panel, and connect the battery terminal (A) from UPS to EBM terminal
(B) shown as below. And then connect the battery terminal (D) from the first EBM to the
battery terminal (E) from the second EBM. Users need to remove the small gate(C) on side
of the front panel to allow the outlet wire of the EBM to pass through the gate and then
reassemble front panel.
Note: Three or more EBMs can be connected to the UPS in the same way as shown above.
VII. Replacing UPS Internal Batteries
Follow the steps and Charts as below to replace batteries:
1. Take off the LCD box, and remove the
screws.
2. Slide and Pull the front panel leftward
and then take it off.
E
B
C
A
D

ENGLISH
3. Disconnect the cable from the UPS and
battery pack.
4. Remove the right inner battery bracket.
5. Pull the battery pack out onto flat area.
6. Install new battery pack into UPS.
7. Screw up the battery bracket and
reconnect the battery cable A and B
8. Re-install the front panel back to UPS.
