Powerwerks PW40BAT User manual

BATTERY POWERED PA
PW40BAT / PW40BATBT
Congratulations on the purchase of your Powerwerks Battery Powered PA.
Powerwerks PW40BAT and PW40BATBT Models draw on decades of amp design and manufacturing experience at Powerwerks.
These products were built from the ground up to offer world-class tone, useful features and reliable performance. Inside this manual,
you’ll nd valuable information about your product’s controls and specications. Being familiar with its features will help you effectively
use your system. We wish you many years of enjoyment with your Powerwerks Battery Powered PA.

IMPORTANT SAFETY INSTRUCTIONS
Danger
Exposure to extremely high noise levels may cause a
permanent hearing loss. Individuals vary considerably to noise
induced hearing loss but nearly everyone will lose some
hearing if exposed to sufficiently intense noise for a sufficient
time.
The U.S. Government's Occupational Safety and Health
Administration (OSHA) has specified the following
permissible noise level exposures:
DURATION PER DAY (HOURS) 8 6 4 3 2 1
SOUND LEVEL (dB) 90 93 95 97 100 103
According to OSHA, any exposure in the above permissible
limits could result in some hearing loss. Earplugs or protectors
in the ear canal or over the ears must be worn when operating
this amplification system in order to prevent a permanent
hearing loss. If exposure in excess of the limits as put forth
above, to insure against potentially harmful exposure to high
sound pressure levels, it is recommended that all persons
exposed to equipment capable of inducing high sound pressure
levels, such as this amplification system, be protected by
hearing protectorswhile this unit is in operation.
THIS SYMBOL IS INTENDED TO ALERT THE
USER TO THE PRESENCE OF NON-INSULATED
"DANGEROUS VOLTAGE" WITHIN THE
PRODUCT'S ENCLOSURE THAT MAY BE OF
SUFFICIENT MAGNITUDE TO CONSTITUTE A
RISK OF ELECTRIC SHOCK TO PERSONS.
THIS SYMBOL IS INTENDED TO ALERT THE
USER TO THE PRESENCE OF IMPORTANT
OPERATING AND MAINTENANCE
(SERVICING) INSTRUCTIONS IN THE
LITERATURE ACCOMPANYING THE UNIT.
APPARATUS SHALL NOT BE EXPOSED TO
DRIPPING OR SPLASHING ANDTHAT NO
OBJECTS FILLED WITH LIQUIDS, SUCH AS
VASES, SHALL BE PLACED ON THE
APPARATUS.
1. Read all safety and operating instructions before
using this product.
2. All safety and operating instructions should be kept
for future reference.
3. Read and understand all warnings listed on the
operating instructions.
4. Follow all operating instructions to operate this
product.
5. This product should not be used near water, i.e.
Bathtub, sink, swimming pool, wet basement, etc.
6. Only use dry cloth to clean this product.
7. Do not block any ventilation openings, It should not
be placed flat against a wall or placed in a built-in
enclosure that will impede the flow of cooling air.
8. Do not install this product near any heat sources;
such as, radiators, heat registers, stove or other
apparatus (including heat producing amplifiers) that
produce heat.
9. Do not defeat the safety purpose of the polarized or
grounding-type plug. A polarized plug has two blades
with one wider than the other. A grounding-type plug
has two blades and a third grounding prong. The
wide blade or the third prong are provided for your
safety if the provided plug does not fit into your
outlet, consult an electrician for replacement of the
obsolete outlet.
10. Protect the power cord being walked on or pinched,
particularly at Plugs, convenience receptacles and the
point where they exit from the
apparatus. Do not break the
ground pin of the power supply
cord.
11. Only use attachments specified by
the manufacturer.
12. Use only with the cart, stand, tripod, bracket, or table
specified by the manufacturer or sold with the
apparatus. When a cart is used, use caution when
moving cart/apparatus combination to avoid injury
from tip-over.
13. Unplug this apparatus during lightning storms or
when unused for long periods of time.
14. Care should be taken so that objects do not fall and
liquids are not spilled into the unit through the
ventilation ports or any other openings.
15. Refer all servicing to qualified service personnel.
Servicing is required when the apparatus has been
damaged in any way; such as, power-supply cord or
plug is damaged, liquid has been spilled or objects
have fallen into the apparatus, the apparatus has been
exposed to rain or moisture, does not operate
normally or has been dropped.
16. WARNING: To reduce the risk of fire or electric
shock, do not expose this apparatus to rain or
moisture.
17. When the MAINS plug, or an appliance coupler is
used as the disconnect device, the disconnect device
shall remain readily operable.
18. Protective Ground Terminal: The apparatus shall be
connected to an AC main socket with a protective
earth ground connection.
Laite on liitettävä suojakoskettimilla varustettuun pistorasiaan
Apparatet må tilkoples jordet stikkontakt
Apparaten skall anslutas till jordat uttag
Battery Warning:Do not expose to extreme temperatures
Keep out of direct sunlight
Keep away from Open Flames

IMPORTANT SAFETY INSTRUCTIONS
FRENCH
Danger
L‘exposition a des niveaux eleves de bruit peut provoquer une
perte permanente de l’audition, Chaque organisme humain
reagit differemment quant a la perte de l’audition, mais
quasiment tout le monde subit une diminution de I’acuite
auditive lors d’une exposition suffisamment longue au bruit
intense. Les autorites competentes en reglementation de bruit
ont defini les expositions tolerees aux niveaux de bruits:
DURATION PER DAY (HOURS) 8 6 4 3 2 1
SOUND LEVEL (dB) 90 93 95 97 100 103
Selon les autorites, toute exposition dans les limites citees ci-
dessus,peuvent provoquer certaines pertes d’audition. Des
bouchons ou protections dans l’appareil auditif ou sur l’oreille
doivent etre portes lors de l’utilisation de ce systeme
d’amplification afin de prevenir le risque de perte permanente
de l’audition, Dans le cas d’expositions superieures aux
limites precitees il est recommande, afin de se premunir contre
les expositions aux pressions acoustiques eIevees
potentielIement dangeureuses, aux personnes exposees aux
equipements capables de delivrer de telles puissances, tels ce
systeme d’amplification en fonctionnement, de proteger
l’appareil auditif.
CE SYMBOLE A POUR BUT D'AVERTIR
L'UTILISATEUR DE LA PRESENCE DE VOLTAGE
DANGEREUX NON-ISOLE A L'INTERIEUR DE CE
PRODUIT QUI PEUT ETRE DE PUISSANCE
SUFFISAMMENT IMPORTANTE POUR
PROVOQUER UN CHOC ELECTRIQUE AUX
PERSONNES.
CE SYMBOLE A POUR BUT D'AVERTIR
L'UTILISATEUR DE LA PRESENCE
D'INSTRUCTIONS D'UTILISATION ET DE
MAINTENANCE DANS LES
DOCUMENTS FOURNIS AVEC CE PRODUIT.
AFIN DE REDUIRE LES RISQUÉ D'INCENDIE
ET DE DECHARGE ELECTRIQUE, NE PAS
EXPOSER CET APPAREIL A LA PLUIE OU A
L'HUMIDITE.
1. Lire avec attention toutes les recommandations et
précautions d'emploi avant d'utiliser ce produit.
2. Toutes les recommandations et précautions d'emploi
doivent être conservées afin de pouvoir s'y reporter si
nécessaire.
3. Lire et comprendre tous les avertissements énumérés dans
les précautions d'emploi.
4. Suivre toutes les précautions d'emploi pour utiliser ce
produit.
5. Ce produit ne doit pas être utilisé près d'eau, comme par
exemple baignoires, éviers, piscine, sous-sol humides ...
Etc.
6. Utiliser exclusivement un chiffon sec pour nettoyer ce
produit.
7. Ne bloquér aucune ouverture de ventilation. Ne pas placer
le produit tout contre un mur ou dans une enceinte fernée,
cela gênerait le flux d'air nécessaire au refroidissement.
8. Ne pas placer le produit près de toute source de chaeur telle
que radiateurs, arrivées d'air chaud, fourneaux ou autres
appareils générant de la chaleur (incluant les amplificateurs
producteurs de chaleur) .
9. Ne pas négliger la sécurité que procure un branchement
polarisé ou avec raccordement à la terre, Un branchement
polarisé comprend deux fiches dont l'une est plus large que
l'autre. Un branchement à la terre comprend deux fiches
plus une troisième reliée à la terre. Si la fiche secteur
fournie ne s'insert pas dans votre prise de courant. consulter
un 'électricien afin de remplacer votre prise obsolète.
10. Protéger le cordon d'alimentation de tout écrasement ou
pincement, particulièrement au niveau des fiches, des
réceptacles utilisés et à l'endroit de sortie de l'appareil. Ne
pas casser la fiche de terre du cordon d'alimentation.
11. Utiliser uniquement les accessoires spécifiés par le
constructeur.
12. Utiliser uniquement avec le chariot de
transport, le support, le trépied, la
console ou la table spécifiés par le
constructeur ou vendus avec l'appareil.
Lors de l'utilisation d'un chariot, bouger
avec précaution l'ensemble
chariotlappareil afin d'éviter les dommages d'un
renversement.
13. Débrancher cet appareil lors d'orages ou s'il n'est pas utilisé
pendant une longue période.
14. Des précautions doivent être prises afin qu'aucun objet ne
tombe et qu'aucun liquide ne se répande à l'intérieur de
l'appareil par les orifics de ventilation ou n'importe quelle
autre ouverture.
15. Pour toutes interventions techniques s'adresser à un
technicien qualifié.L'intervention technique est nécessaire
lorsque l'appareil a été endommagé de n'importe quelle
façon, comme par exemple si le cordon secteur ou sa fiche
sont détériorés,si du liquide a coulé ou si des objets sont
tombés à l'intérieur de l'apparei1,si l'appareil a été exposé à
la pluie ou à l'humidité, s'il ne fonctionne pas normalement
ou s'il est tombé.
16. ATTENTI0N:Pour réduire le risque d'incendie ou de choc
electrique ne pas exposer l'appareil à la pluie ou à
l'humidité.
17. Quand La prise MAINS, au coupler, est utilisé pour la
source d'alimentation êlectrique. Il est conseillê de garder
cette prise facilement accessible.
18. Borne de terre de protection: L'appareil doit être connecté à
un connecteur AC principale avec un raccordement à la
terre de protection.
Laite on liitettävä suojakoskettimilla varustettuun pistorasiaan
Apparatet må tilkoples jordet stikkontakt
Apparaten skall anslutas till jordat uttag
Ne pas exposer à une température extrême. Protéger du rayonnement solaire. Tenir à l’écart de la des ammes.
Avertissement de batterie

1. AUX IN: Use this stereo input to connect an external audio device such as an MP3, CD player or computer for playback. Note: Right
and Left channels are summed to mono on this input.
2. MIC Input: This XLR input is designed for low-impedance microphones or equipment that has a mic-level, balanced output.
Note: This input sends 9-volt phantom power. This is used to provide power to condenser microphones. Phantom power will not
damage any dynamic or non-condenser microphone.
3. LINE Inputs: These ¼-inch unbalanced inputs may be used to connect high-impedance microphones, keyboards, drum
machines and other audio devices.
4. Volume: Use these controls to adjust the volume level of each channel and the relative balance between them.
Note: This control affects POWERLINK Output level.
5. Low: Determines the emphasis of bass frequencies. Turning this knob clockwise creates a deeper, warmer tone. If you
need a brighter sound, reduce the bass by turning counterclockwise.
6. High: Turned clockwise, this control accents treble frequencies to produce clearer, crisper sound. Turn counterclockwise to make the
sound softer and less bright.
7. Master Volume: Controls the overall volume of all channels and the input of POWERLINK.
Note: Does not affect POWERLINK Output level.
Additional Features: Here are a few additional features designed to prolong the life of your Battery Powered PA.
Standby Mode: Power amplier goes into Standby Mode after 20 minutes of non-use with POWER ON to extend battery life. Power
Amp turns back on 1/2 second after input signal is detected.
Protection Mode: When driven to extreme distorted levels the amplier will go into Protection Mode (Amplier will momentarily mute
audio to protect speakers and electronics).
CONTROLS & FUNCTIONS OVERVIEW
2
3 4 5 6 7
1

1. POWERLINK IN: This balanced XLR Jack accepts the POWERLINK output from another PW unit using a standard mic cable.
Channels from both units are summed together. Use the channel volume controls to get the mix of the channels (If a channel is not
used turn the volume all the way down). MASTER volume controls the loudness of the mix. It does not affect volume of a linked PW
product.
Note: The shield connection (pin 1) on this jack is connected to chassis ground. It is not lifted.
2. POWERLINK OUT: This balanced XLR Jack accepts the POWERLINK input from another PW unit using a standard mic cable.
Channels from both units are summed together. Use the channel volume controls to get the mix of the channels (If a channel is not
used turn the volume all the way down). MASTER volume controls the loudness of the mix through the primary unit, not the linked unit.
This jack may also be used to connect the PW product to the balanced line input of a power amp.
Note: The shield connection (pin 1) on this jack does not connect to chassis ground, it is lifted.
3. Bluetooth LED (PW40BATBT ONLY): Indicates that a Bluetooth equipped device has successfully paired with the PW40BATBT.
4. CHARGING LED: Indicates the battery is charging. It is recommended to charge for 12 hours after use. Battery charges even if the
unit is ON under normal volume conditions. When played loud, the battery will stop charging to allow higher power demand. To resume
charging, uplug AC power cord, then reconnect after 10 seconds.
Note: LED indicates “rapid charge” stage and will turn off when unit enters “oat charge” stage.
5. BATTERY LEVEL INDICATOR: During use, the BATTERY LEVEL indicator LED’s show the remaining battery power. When the red
light on the left is on, turn off the unit and recharge to avoid excessive battery drain.
6. AC Power Cord Receptacle: Insert the AC cord rmly into the AC receptacle. Power circuit is on whenever AC cable is connected to
unit and plugged into wall. Be sure to use the cable provided with your PW40BAT or PW40BATBT. The power cord can be removed for
storage or replacement if damaged.
Note: Replace the AC cord if its protective jacket is damaged or ground pin is damaged or removed.
7. Power: This switch activates power to the Battery Powered PA.
Note: Power is supplied to the unit for charging even if Power switch is off.
21
4
6
5
3
7
PW40BATBT:
BLUETOOTH PAIRING INSTRUCTIONS
To connect your Bluetooth device to the
Powerwerks Bluetooth receiver for the rst
time, navigate to the Bluetooth settings menu
on you Bluetooth enabled device. Ensure that
Bluetooth is enabled and your Powerwerks
product is powered on. Perform a scan for
available devices. Select and pair to the
Powerwerks product in the list of available
devices. Enter 0000 for the passcode if
prompted. Once paired, a connection can be
established. Depending on the device, future
connections may be established automatically
when a previously paired Bluetooth device is in
range of the Powerwerks Bluetooth receiver.
The Bluetooth receiver in Powerwerks Bluetooth
products is an A2DP device and will work with
other A2DP compatible Bluetooth devices
including most smart phones. Additional
hardware and/or driver software may be
required for computers with integrated Bluetooth
adaptors due to a lack of support for A2DP
devices by some operating systems.
A2DP protocol only allows for one to one device
connections. Therefore, only one Bluetooth
device can be connected to a Powerwerks
Bluetooth product at one time. Similarly, a
Bluetooth device can only be connected to one
Powerwerks Bluetooth product at one time.
Plugging a 1/8” connector into the AUX jack
disables the Powerwerks Bluetooth receiver.

BATTERY:
IT IS RECOMMENDED THAT THE BATTERY BE RECHARGED AFTER USE TO PROLONG THE BATTERY LIFE.
FREQUENT CHARGING WILL NOT HARM YOUR BATTERY, AND WILL ENSURE THAT THE BATTERY IS FULLY
CHARGED AND READY FOR ITS NEXT USE. STORING BATTERY NOT FULLY CHARGED WILL SHORTEN
BATTERY LIFE.
-Always charge for 12 full hours after heavy use.
-The battery does not need to be fully discharged before recharging.
-It is recommended to stop using the unit under battery power when red Battery Level LED is on.
-For best results, recharge the unit as soon as possible after use.
-It is best if battery is fully charged before storing for long periods of time. Store in a cool, dry place.
40W AC powered with fully charged battery
36W Battery powered
1/8" Headphone/line Level Stereo, mixed mono
Line level 1/4" Un-balanced
Mic XLR Balanced
Line level 1/4" Un-balanced
-56dB Residual Noise, all level controls 0% (minimum)
-52dB Nominal System Noise, all level controls at 50%
+70dB Mic to Speaker Output (CH 1 & 2)
+50dB Line to Speaker Output (CH 1 & 2)
+40dB AUX IN to Speaker Output
Channel EQ (high, low)
Phantom Power +9V Mic Input
USA/Canada 120VAC/60Hz, 80W nominal
Europe/UK/Australia 230~240VAC/50Hz, 80W nominal
China 220VAC/50Hz, 80W Nominal
Speakers Two 4½" 50W 4 Ohm each
Horn
Power Capacity 40W RMS total system
Frequency Response system 70HZ-20kHz 92dB 1W-1M nominal
Nominal Impedance 2x4 Ohms Not designed for external speakers
mm/kg 180 (width), 525 (height), 190 (depth), 9.6 kg
Inches/Pounds 7 (width), 20 ¾ (height), 7½ (depth), 21¼ lb
Output Power
Hum & Noise
Dimensions & Weight
Bluetooth Module Features.
(Available on PW40BATBT only)
20HZ-20kHz Actual response is tailored to speaker cabinet for
accurate acoustical response.
Bluetooth 3.0+ERD compliant. Typical +2dBm Class 2 power.
Audio DAC: 94dB SNR.A2DP profile support
Accepted Inputs
One 3½" piezo driver
CH 1
CH 2
PW40BAT & PW40BATBT Powered PA Specifications
4kHz and above , 800Hz and below.
Power Requirements
Powerlink (IN and OUT) System
Linking Circuit
Both jacks accept a balanced input and send a pre-master volume output mix of
channels. Recommended use: Linking two PW40BAT(BT) together.
System Gain
(Measurements made at 1kHz)
Frequency Response

BATTERY REPLACEMENT
The battery will need to be replaced when the unit fails to charge. Carefully follow the installation instructions for battery replacement.
Perform battery replacement in a safe
place, away from children.
Remove the four screws in the lower
portion of the rear of the cabinet & remove
the battery panel. Holding the cabinet
securely, carefully tilt the it backwards. The
battery should slide out of it’s compartment.
Disconnect the two wires attached to the
battery.
Use a soft piece of cloth or paper towel to
wipe any remnants of battery discharge
from the compartment before installing
the new battery. To avoid inammation
of the skin, make sure that none of the
battery discharge gets onto your hands
or skin. Exercise the utmost caution so
that none of the discharge gets near your
eyes. Immediately rinse the affected area
with running water if any of the discharge
makes contact with eyes or skin.
Used batteries must be disposed of in
compliance with regulations for safe
disposal in your region.
Attach the wires to the new battery
accordingly:
Connect the white wire to the positive (+)
terminal. Connect the black wire to the
negative (-) terminal.
Slide battery into the compartment, being
careful to not pinch or damage the wires.
Reinstall the battery panel and tighten the
four screws.
Charge for twelve (12) full hours before
use.

1
GAIN
volume
MAIN BUS
LINE 1/4"
low high
2
GAIN
volume
MIC XLR LINE 1/4"
low high
Phantom Power 9V
CHANNELS
MASTER
Conditioning
LINKING BUS
IN OUT
POWERLINK
MASTER
+ _ + _
+ _
SPEAKERS
POWER AMPs
SPEAKER
HORN
Crossover
T R S CN CS
AUX 1/8"
Bluetooth Pwr
BLUETOOTH Feature on PW40BATBT only
PW40BAT & PW40BATBT SIGNAL FLOW DIAGRAM
