Powr-Flite WONDER WAND Product manual

Commercial
Carpet Wand
3101 Wichita Court
Fort Worth, TX 76140
Phone: [phone]
[phone] X8698
Rev. 00 (04-05)
Operator and Parts Manual
WW1000 manual 4/15/05 8:43 AM Page 1
https://harrissupplyind.com-ToOrderPartsCall608-268-8080

OPERATING INSTRUCTIONS
ROLLER/GLIDE WAND
SAVE THESE INSTRUCTIONS
A: Connect vacuum hose to wand tube
B: Connect solution line to solution valve
C: Adjust carrying handle
D: To apply solution, depress trigger
Place carpet wand on surface to be cleaned and move it at the
rate of a slow walk. Apply cleaning fluid by depressing on the
valve lever. When using carpet wands, cleaning fluid is applied
on the back or pull stroke only. Use only enough downward pres-
sue on the wand to move effectively (oush and pull stroke). Use
of excessive downward pressure on the wand will decrease effi-
ciency. Always finish cleaning with a dry stroke (closed valve
condition). It is very important to keep tools properly seated to
the surface being cleaned to produce maximum cleaning effec-
tiveness and minimum drying times. Multiple wet and dry strokes
may be used on excessively soiled areas.
If you prefer to use the wand without the foller feature, it can be
removed as shown below.
1: To remove roller bar, remove two screws on either side
with Phillips screw driver. Remove the roller and both side
plates, replace the screws
2: Wand will now operate as a glide wand.
A
1
2
B
C
D
WW1000 manual 4/15/05 8:43 AM Page 2
https://harrissupplyind.com-ToOrderPartsCall608-268-8080

CLEANING/MAINTENANCE INSTRUCTIONS
1: To clean solution line filter, disconnect QD on both ends
of filter.
2: Unscrew cap and rinse filter
3: To clean spray jets, remove spray bar
A: Jets are quick disconnect, a quarter turn will
allow removal.
4: Periodically, check solution and recovery chamber, rinse as
necessary to remove debris
1
A
3
2
4
SAVE THESE INSTRUCTIONS
WW1000 manual 4/15/05 8:43 AM Page 3
https://harrissupplyind.com-ToOrderPartsCall608-268-8080

©Tacony, All Rights Reserved
X8698 04.05
LIMITED WARRANTY
Tacony will repair or exchange parts for your wand in the event of a manufactur-
ing defect as follows:
PARTS: New or comparable rebuilt parts, for one year after original purchase.
LABOR: Carry-in service can be obtained during the warranty period by taking
your dryer to an Authorized Tacony Warranty Service Center.
IMPORTANT WARRANTY CONDITIONS: A purchase receipt or other proof of
date of original consumer purchase also will be required before warranty service
is rendered.
This warranty covers normal use and does not cover damage which occurs in
shipment or failure resulting from alteration, accident, misuse, abuse, neglect, or
improper maintenance.
STATEMENT: This warranty is not transferable and extends only to the original
purchaser when a new Wonder Wand is purchased from an Authorized Tacony
Dealer. This warranty gives you specific legal rights, and you may have other
rights that vary from state to state.
Date Purchased: _ _ _ _ _____ _ _ _ _____ _ _ _ _ ____ _ _ _ _ _
M o d e l N u m b e r : _____ _ _ _ _____ _ _ _ _ ____ _ _ _ _ _____
S e r i a l N u m b e r : _____ _ _ _ _____ _ _ _ _ ____ _ _ _ _ _____ _
Make sure to record this information.
This information will be necessary for future warranty claims.
