Powr-Flite Newton User manual

Newton Canister Vacuum
Operations and Maintenance Manual
For Commercial Use Only
PV610-Q10-U

2
CONTENTS
Getting Started
Introduction 3
Warranty 3
Grounding Instructions 4
Important Safety Instructions 5
Technical Specifications 7
Box Contents 8
Template
Operations 9
Transport 16
Storage 16
Maintenance 16
Recommended Spares & Accessories 17
Fault Diagnosis 18

3
INTRODUCTION
Warranty
Within 30 days of purchase, to activate product warranty,
go to: https://www.powr-flite.com/warranty-registration
Warning Labels
Prior to operating the Portable Battery Powered Mister, read and
understand completely this owner’s manual paying special attention to
warning labels. These labels indicate a potentially hazardous situation
that could result in death or serious injury if not avoided. Use only as
described in this manual.
Important
There are no owner serviceable parts inside this machine. Removal
of screws and accessing internal components will void all warranty
claims.
Your new Powr-Flite unit is a high quality, precision-made product. All parts used in the
manufacturing of this unit have passed rigid quality control standards prior to assembly. Please
safeguard the original receipt/invoice given at the time of purchase. If you experience any
problems with your unit during the warranty period, the original receipt/invoice will act as proof of
purchase.
Upon receipt, inspect outer box for exterior damage. Unpack all internal parts, ensure all items
are present according to the owner’s manual, and review components for damage.
Each unit is tested and thoroughly inspected prior to shipping. If damage is discovered,
immediately notify the transportation company that delivered your machine and request an
inspection. As a manufacturer, we are unable to act upon any claim for concealed damage and
you must originate the claim. Be sure to keep the carton, packing inserts, and carrier’s receipt
until the inspector has verified your claim.

4
GROUNDING INSTRUCTIONS
This appliance must be grounded. If it should malfunction or breakdown, grounding provides
a path of least resistance for electric current to reduce the risk electric shock. This machine
is equipped with a cord having an equipment-grounding conductor and grounding plug. The
plug must be inserted into an appropriate outlet that is properly installed and grounded in
accordance with all local codes and ordinances.
This appliance is for use on a nominal 115-volt circuit, and has a grounding plug that looks like
the plug illustrated in sketch A.
A
DANGER: Improper use of the grounding plug can result in a risk of electric shock.
WARNING!
Improper connection of the equipment-grounding conductor can result in a risk of electric shock.
Check with a qualified electrician or service person if you are in doubt as to whether the outlet
is properly grounded. DO NOT modify the plug provided with the appliance. If it will not fit the
outlet, have a proper outlet installed by a qualified electrician.
GROUNDING METHODS

5
SAVE THESE INSTRUCTIONS
IMPORTANT SAFETY INSTRUCTIONS
READ AND UNDERSTAND ALL INSTRUCTIONS BEFORE USING THIS UNIT
Read and understand this owner’s manual and all labels on the unit before operating. Safety is a
combination of common sense,staying alert, and knowing how your unit works. Use this unit only
as described in this manual. Use only manufacturer’s recommended attachments. To reduce the
risk of personal injury or damage to your unit use only recommended accessories.
WARNING To avoid fire, DO NOT use with a flammable or combustible liquid or floor cleaner.
WARNING To avoid electric shock, DO NOT expose to rain. Store Indoors.
When using this unit, basic precautions should always be followed, including the following:
• DO NOT leave unit when plugged in. Unplug from outlet when not in use and before servicing.
• DO NOT allow unit to be used as a toy. Close attention is necessary when used around or near
children.
• Use only as described in this manual. Use only manufacturer’s recommended attachments.
• DO NOT use with damaged cord or plug. If unit is not working properly because it has been
dropped, dropped into water, left outdoors, or damaged in any way, contact a service center
• DO NOT handle plug or appliance with wet hands.
• DO NOT put any objects into openings.
• DO NOT use with any opening blocked: keep free of dust, lint, hair, or anything that may
reduce air flow.
• Keep hair, loose clothing, fingers, and all parts of body away from openings and moving parts.
• DO NOT pick up anything that is smoking or burning such as cigarettes, matches, or hot
ashes.
• DO NOT use to pick up hazardous chemicals.
• Turn off all controls before unplugging.
• Turn unit off immediately if foam or liquid comes from machine exhaust. Empty & clean out
recovery (dirty) tank and use defoamer to correct the problem.
• DO NOT use to pick up flammable or combustible liquids such as gasoline or use in areas
where they may be present.
• DO NOT use where oxygen or anesthetics are used.
• Replace damaged or worn parts immediately with genuine original equipment parts to
maintain safety.
• This unit must be connected to a properly grounded outlet only. See grounding instructions.
• DO NOT use equipment out of doors or in the rain.
• DO NOT use equipment near or around flammable or explosive materials, fuels, or solvents.
• DO NOT allow the unit to freeze.
• Anyone designated to operate this equipment must, without fail, read and thoroughly
understand all instructions and precautions prior to use.
• Never lift the machine by pressure regulator (on heated model).
• Wear safety equipment and clothing to protect from extremely hot water.
• Do not operate in standing water.
• Do not operate equipment under any unsafe condition.

6
IMPORTANT SAFETY INSTRUCTIONS
State of California Proposition 65 Warnings
WARNING: This product contains one or more chemicals
known to the state of California to cause cancer.
WARNING: This product contains one or more chemicals known to the
state of California to cause birth defects or other reproductive harm.
Intended Use
Do NOT modify this unit in any way or adapt it for any other use.
Modification of this unit in any way will void all warranties and could
create safety hazards.

7
SPECIFICATIONS
Model
Product Code PV610-Q10-U
Voltage AC (~)/ Frequency V/Hz 115/60
Construction Class II
Vacuum Motor Power W 1200
Filtration 3-stage (w/ H13 Filter Bag)
Airflow Rate l/s/cfm 30.5/65
Water lift mm/inches 2529/100
Capacity litres/gallons 10/2.6
Productivity Rate m²/h/sq.ft./hr 232/2497
Sound pressure level dB(A) 65
Sound power level dB(A) 72
Dimensions (L x W x H) mm/inches 364 x 240 x 200/14.3 x 19.5 x 7.9
Weight kg/lbs. 6/13
Wand length mm/inches 576/956/22.5/37.5
Hose length m/inches 2/78
Cable length m/ft 10.6/35
Ingress Protection Rating IP20
• Above dimensions are approx. Since the company’s policy is to continuously improve the
product, there could be changes without prior notice.
• Noise levels measured at a distance of 1 meter from machine and 1.6 meters above floor, when
operating on a hard floor. Measurements recorded using a hand held meter.
• Handle vibration does not exceed 2.5 m/s² when operating on a smooth floor surface.

8
BOX CONTENTS
Upon initial receipt of unit, open box and ensure all parts are included as shown below.
NEED PICTURE(S) OF BOX CONTENTS

9
OPERATING INSTRUCTIONS

10
OPERATING INSTRUCTIONS

11
OPERATING INSTRUCTIONS

12
OPERATING INSTRUCTIONS
3

13
OPERATING INSTRUCTIONS

14
OPERATING INSTRUCTIONS

15
OPERATING INSTRUCTIONS

16
TRANSPORTING THE MACHINE
• Take extreme care when moving the machine up or down steps or stairs.
• Incorrect lifting techniques may result in personal injury. We advise that the manual
handling regulations are followed. Carefully wrap the power cord and store in dry indoor
location.
• DO NOT expose the machine to rain or moisture.
• When transporting the machine ensure that all components, tanks and removable parts are
securely fastened, and that the power cord and plug are not trailing.
STORAGE
• Always switch off the machine after use.
• Store the machine in a dry indoor area only.
• Wrap the power cord around the cable winder ensuring that the plug is not trailing on the
floor.
• Always switch off, empty, wipe down and dry the machine after use.
MAINTENANCE
WARNING - Before undertaking maintenance operations or adjustments switch off machine
and unplug from the electrical supply.
IMPORTANT – All other servicing and repairs should only be performed by an Authorized
Service Agent.
IMPORTANT – Should the machine fail to operate please refer to the fault diagnosis section in the
back of this instruction manual. If the problem / remedy is not listed, please contact Customer
Service Department.
The machine requires minimum maintenance apart from the following checks by the operator
prior to use:
• Body of the machine - Clean with a damp cloth.
• Power cord - Regularly inspect sheath, plug and cord ends for damage or loose connection.
• Air vents - Check for dust accumulation around the air inlet and outlet vents of the motor
cooling-air system and clean if necessary. Blocked vents will cause the motor to overheat and
may lead to premature failure. Warranty claims for this type of damage will not be accepted.
• Vacuum filter – Check that the vacuum filter is clean and replace as appropriate.
• Hose, wand and vacuum accessories – Check and remove any debris or lint build-up from the
head.

17
RECOMMENDED SPARES & ACCESSORIES
Item Part No.
F9 Rinseable Filter X6101
25 Pack HEPA Filter Bags X6100
Hose X6102
Telescopic wand X6103
Floor tool X6104
Dusting Brush and Crevice Tool X6105
Basket Filter X6107

18
Trouble Reason Remedy
Machine is not working Lack of voltage/electrical supply Check fuse *, power cord, plug
and socket outlet
Loss of vacuum suction Dust bag full.
Blocked hose or wand.
Motor is not running.
Replace bag.
Remove obstruction.
Contact Service Agent
Motor is not running Broken switch.
Defective power cord.
Defective motor.
Contact Service Agent.
FAULT DIAGNOSIS
The following simple checks may be performed by the operator. If the machine is still not
working, please contact your local Service Agent:
* If the fuse blows several times, the machine should be checked by an authorized Service Agent

19
