OPERATOR’S MANUAL & PARTS LIST
WARNING: OPERATOR MUST READ AND UNDERSTAND THIS MANUAL
COMPLETELY BEFORE OPERATING THIS EQUIPMENT.
©Tacony, Inc., All rights reserved
Save These Instructions
WIDE AREA VACUUM
MODEL PF2030
PF2030-MAN 4/2016
https://harrissupplyind.com-ToOrderPartsCall608-268-8080

2
CUSTOMER'S RECORD
Model Number: ________________________________________________________________________________________
Serial Number: _________________________________________________________________________________________
Date Purchased: _______________________________________________________________________________________
WHEN THE MACHINE IS DELIVERED
If machine is damaged, notify the carrier immediately and request an inspection. Be sure to keep the carton, packing
inserts, packing lists, and carrier’s receipt until the inspector has verified your claim.
https://harrissupplyind.com-ToOrderPartsCall608-268-8080

3
When using an electrical wide area vacuum cleaner, basic precautions should be followed.
READ ALL INSTRUCTIONS BEFORE USING VACUUM CLEANER.
WARNING!
To reduce the risk of fire, electric shock or injury:
Do not leave machine unattended when plugged in. Unplug from
outlet when not in use and before changing bags or attempting any
maintenance or adjustment.
Do not use outdoors or on wet surfaces.
Use only as described in this manual. Use only manufacturer’s
recommended attachments.
Do not use with damaged cord or plug. If machine is not working as
it should, has been dropped, damaged, left outdoors, or dropped into
water, return it to a service center.
Do not pull or carry by cord, use cord as a handle, close a door on cord,
or pull cord around sharp edges or corners. Do not run machine over
cord. Keep cord away from heated surfaces. Do not unplug by pulling
on cord. To unplug, grasp the plug not the cord. Do not handle plug or
machine with wet hands.
Keep hair, loose clothing, fingers, and all parts of body away from
openings and moving parts.
Do not put any object into openings. Do not use with any opening
blocked; keep free of dust, lint, hair, and anything that may reduce
air flow.
Turn off all controls before unplugging.
Connect to a properly grounded outlet only. See Grounding Instructions.
Do not put hands under base. Rotating parts could cause injury. Always
keep hands feet and loose fitting clothing away from moving parts to
prevent possible injuries. Use care to keep electrical supply cable from
contacting moving parts, such as floor brushes.
Risk of explosion: Use this machine only in a well ventilated area, free
from any flame or match. Do not use machine in areas where flammable
and/or explosive vapors or dust are present.
Make sure voltage and frequency at the wall power receptacle
correspond with that indicated on name plate before plugging in machine.
A 15 amp circuit is recommended. Connect only to a dedicated individual
branch circuit.
Never use a device to lock the switch lever in the ON position.
Do not use without dust bag and/or filters in place.
Do not allow to be used as a toy. Close attention is necessary when used
by or near children.
Do not use to pick up flammable or combustible liquids, such as gasoline,
or use in areas where they may be present.
Do not pick up anything that is burning or smoking, such as cigarettes,
matches, or hot ashes.
SAFETY PRECAUTIONS
BEFORE OPERATING MACHINE
WARNING: Failure to adhere to these instructions could result in serious
bodily injury or property damage.
Read this manual completely before attempting to operate machine. This
manual has important information for the use and safe operation of the
machine. Keep this manual on file and handy.
GROUNDING INSTRUCTIONS
This appliance must be grounded. If it should malfunction or breakdown,
grounding provides a path of least resistance for electric current to
reduce the risk of electric shock. This machine is equipped with a cord
having an equipment-grounding conductor and grounding plug. The plug
must be inserted into an appropriate outlet that is properly installed and
grounded in accordance with all local codes and ordinances.
WARNING: Improper connection of the equipment-grounding conductor
can result in a risk of electric shock. Check with a qualified electrician
or service person if you are in doubt as to whether the outlet is properly
grounded. Do not modify the plug provided with the appliance-if it will not
fit the outlet, have a proper outlet installed by a qualified electrician.
This appliance is for use on a nominal 120 volt circuit and has a
grounding plug that looks like the plug illustrated in sketch A. Make
sure that the appliance is connected to an outlet having the same
configuration as the plug. No adaptor should be used with this appliance.
GROUNDING
PIN
GROUNDING
OUTLET
RECOMMENDED
GROUNDED
OUTLET BOX
(A)
2
SAVE THESE INSTRUCTIONS
IMPORTANT SAFETY INSTRUCTIONS
https://harrissupplyind.com-ToOrderPartsCall608-268-8080

4
HANDLE ADJUSTMENT
1. Loosen handle lock lever and adjust handle to comfortable operation
height
2. Tighten lever to lock handle in place.
BAG INSTALLATION
1. Position the handle in normal operating position.
2. Open bag compartment lid and rest it on the handle.
3. Unzip cloth bag and install paper bag inside.
4. Attach both bag openings together onto vacuum intake housing.
5. Make sure bag is properly deployed inside machine housing.
6. Completely close zipper on cloth bag and close lid of machine.
ATTENTION: Never operate machine without cloth bag.
Always use cloth and paper bags together.
BRUSH HEIGHT ADJUSTMENT
1. This machine has 5 brush adjustment levels.
2. To raise brush height level: lift up height adjustment bar until desired
brush height is attained.
3. To lower brush height level: push down on height adjustment bar until
desired brush height is attained.
OPERATION OF MACHINE
1. Plug power cord into properly grounded power outlet.
2. Click the on/off switch on to the ON position to turn on machine.
3. To operate brush squeeze the brush start triggers.
4. Adjust brush height for proper pick-up.
CIRCUIT BREAKER
Your new wide area vacuum comes equipped with two manual circuit
breakers, a 15 amp breaker for the vacuum motor and a 2.5 amp breaker
for the brush motor. If the machine does not turn on you will need to
check the circuit breakers.
To reset circuit breakers:
1. Unplug the wide area vacuum cleaner
2. Check machine for the following:
Full bag, obstructions, clogged filters, clogged brush, brush
height set too low, etc.
3. Press the affected circuit breaker button to reset.
4. Resume operation
MACHINE MAINTENANCE
CAUTION: Unplug the vacuum cleaner
before performing the following steps.
FOR BEST PERFORMANCE
• Keep machine and all accessories clean and in good operating
condition.
• Change vacuum bags and filters as recommended to maintain
optimum cleaning efficiency.
• Always use genuine bags, filters and parts, as use of other products
may result in poor cleaning or filtration performance. OEM filtration
products are designed for maximum performance.
• Have machine checked periodically by an authorized service
representative.
• Store machine carefully in dry area.
• For optimum cleaning performance and safety, follow your owner’s
manual.
• After each use, carefully wrap power cord around handle and check
cord for wear or damage. If cord is damaged, have power cord
replaced by an authorized service representative immediately.
https://harrissupplyind.com-ToOrderPartsCall608-268-8080

5
EXHAUST FILTER REPLACEMENT
1. Carefully turn machine on its side and remove exhaust cover from
bottom of machine.
2. Remove the two nuts holding filter onto machine.
3. Replace filter in proper position and tighten nuts.
4. Reinstall exhaust cover.
*Replace exhaust filter every 6 months.
BELT ADJUSTMENT AND REPLACEMENT
1. Remove belt cover on left side of machine.
2. Loosen the motor belt adjusting screws on motor bracket.
3. Remove belt.
4. Install new belt and reposition motor to eliminate excess slack.
5. Once proper tension is set, tighten motor adjusting screws.
6. Replace belt cover on side of machine.
VACUUM MOTOR FILTERS
VACUUM MOTOR FILTERS
• Position the handle in normal operating position.
• Open Wide Area Vacuum lid and rest it on the handle.
• Remove clamp with a screwdriver to gain access to filter
• Remove plastic cap covering the motor
• Remove plastic retainer in cap
• Replace filters in their original positions.
• Reinstall plastic retainer in cap
• Reinstall cap onto motors
• Reinstall clamp.
*Replace the vacuum motor filter every 6 months.
MACHINE SPECIFICATIONS
ELECTRICAL DIAGRAM
Model PF2030
Voltage / Frequency 120 V / 60 Hz
Brush Motor rating 1/4 hp / 2 A
Total power consumption` 14 A
Vacuum motor rating 1512W / 12.6 A
Bag capacity – dry 45.5 qt / 43 L
Airflow 226 cfm / 384 m3/h
Vacuum – water lift at sealed orifice 71 in / 1804 mm
Filtration - HEPA 99.97% @0.3 micron
Vibration at controls < 2.5 m/s2
Brush width 30 in / 762 mm
Cable length 75 ft / 23 m
Weight (including cord) 74 lb / 33.6 kg
Noise level 69.9 dB(A)
Construction class I
Protection IP20
Machine dimensions
Folded: 33" X 31" X 19"
Operating Position:
33" X 31" X 39"
https://harrissupplyind.com-ToOrderPartsCall608-268-8080

6
PARTS LISTS
1
2
3
4
5
88
6
98
96
91
58
46
8
9
10
20
11
99
12
13
14
74
16
17
18
19
21
22
23
24
25
26
27
28
29
30
31
33
34
35 36
37
38
40
41
43
49
50
51
52
53
54
55
56
45
62
63
66
67
68
69
70
71
72
73
74
75
76 77
78
79
80
81 82
83
85
86
15
87
100
32 57
47
89
48
61
92
93
94
95
97
101
44
39
59
60
64
65
84
54
https://harrissupplyind.com-ToOrderPartsCall608-268-8080

7
MODEL PARTS
N0. PART NO. DESCRIPTION QTY
1 33036-V CHASSIS BLACK 1
2 30077 GASKET, BRUSH SHOE 2
3 33193 FILTER CHUTE 1
4 33195 SCREW, #10-16 X 3/4"L, PNHD, PH, BO, TAP-AB 4
5 19798 BRACKET, GROOVED 4
6 15162 SCREW, 1/4"-20 X 1/2"L, FHD, PH, ZP 2
7 30080 GASKET, HOOD 1
8 19836 MOUNT, BRUSH MOTOR 1
9 33061 BRIDGE RECTIFIER, 25 A 1
10 33451 SCREW, #10-24 X 5/8"L, PNHD, PH, ZP, TAP-F 1
11 01978 SCREW, 1/4"-20 X 1-1/2"L, RHDHD, PH, ZP 3
12 33197 BRUSH MOTOR, 115V 1
13 7CY002 WASHER, 0.25", LOCK, INTERNAL TOOTH, ZP 2
14 19835 PULLEY, BRUSH, DRIVE 1
15 30079 GASKET, LID WAV 1
16 PD8 STRAIN RELIEF, LIQ TITE 2
17 30090 GASKET, 5.8" MOTOR 2
18 30092 MOTOR, VACUUM, 120V 2
19 19834 FILTER, VAC INTAKE, 5.8" 2
20 00086 SCREW, 1/4"-20 X 1/2"L, RNDHD, PH, ZP 12
21 30620 SCREW, #10-16 X 3/4"L, PNHD, PH, ZP, TAPTITE 8
22 30491 BRACKET, AXLE ASS'Y, WAV 1
23 19841 ARM, WHEEL PIVOT 2
24 30461 PIVOT SLEEVE, WHEEL 2
25 30617 SCREW, 1/4"-20, SHCS, SHOULDER 5/16"D X 3/4"L 2
26 19818 SPRING, WAHSER, 1/2" 2
27 30466 SPRING, TENSION 2
28 19797 WHEEL, 10", PLASTIC HUB 2
29 30507 SNAP RING, 1/2", EXTERNAL 2
30 33037 LID BLUE 1
31 19864 PIN, LID HINGE 2
32 33105 CAM LEVER PIN 2
33 15357 SPRING, LATCH RELEASE 2
34 33191 STRAIN RELIEF, LIQ. TITE 2
35 03536 WASHER, 0.375", LOCK, SPLIT, ZP 2
36 30358 NUT, 3/8"-16, HEX, JAM, ZP 2
37 31209 WHEEL, CASTER 2
38 33057A BELT COVER 1
39 30618 DECAL, CARPET LEVEL * 1
40 19473 POWER CORD, 14AWG, 3COND, 75'L, MALE PLUG 1
41 19816 FILTER BAG, CLOTH 1
42 90701 FILTER BAG PAPER 1
43 18706 WIRE TIE, 15", BLACK 1
44 30084 STRAIN RELIEF, LIQ TITE 1
45 07535 SCREW TFT (A) R.H. 4
46 19616 WASHER, 0.563", PLAIN, SS 4
47 33106 CAM METAL WASHER 2
48 16924 SCREW, #6-32 X 3/4"L, PNHD, PH, ZP 4
49 19854G COVER, EXHAUST 1
50 11385 WASHER-SEALING 1/4 2
N0. PART NO. DESCRIPTION QTY
51 01604 NUT-FINISHED HEX #10-32 2
52 19855 EXHAUST FILTER 1
53 19975 NUT-WING (10-32) ZINC PL 2
54 30018 THUMB SCREW, #10-32 X 1/2"L 5
55 X8008N NUT-CONDUIT 2
56 33502 GASKET, CHUTE 1
57 33103 CAM PLASTIC WASHER 2
58 03321 WASHER, 0.391", PLAIN, ZP 2
59 F5P SWITCH PUSH BUTTON SPST 1
60 17376 NUT-HEX. LOCK (KEPS) #6-32 2
61 14142 WASHER, 0.265", PLAIN, ZP 1
62 B123-2700 WIRE CONNECTOR 2
63 33192 NUT, LOCK, STRAIN RELIEF, NI-PLATE 1
64 33048 DECAL, RECTANGLE 1
65 33049 DECAL LARGE ROUND 1
66 19808 AXLE, BRUSH 1
67 19811 BRUSH, 28" 1
68 19805 BEARING BLOCK 2
69 19809 BEARING, SEALED, 6201-2RS 2
70 19810 SHOE, BRUSH MOUNT, WAV 1
71 19848 THREAD GUARD 2
72 32896 GASKET 2
73 19804A PULLEY, BRUSH, DRIVEN 1
74 02011 SCREW, 1/4"-20 X 5/16"L, SET, ALLEN, CUPPNT 3
75 19802 BELT, BRUSH DRIVE 1
76 19829 HANDLE, MAIN 1
77 33190 SWITCH BOX, BOTTOM 1
78 19849 TRIGGER, BRUSH SWITCH 1
79 X9582 SCREW, #8-32 X 1/2"L, FHD, PH, ZP, TAP-F 4
80 33189 SWITCH BOX, TOP 1
81 X9499 DECAL, SMALL CIRCLE 1
82 32966 SWITCH, ROCKER, DPST, 20A 1
83 19990 CIRCUIT BREAKER, PUSH BUTTON, 15A 1
84 33108 CIRCUIT BREAKER, PUSH BUTTON, 2.5A 1
85 33452A HARNESS CABLE WAV 1
86 30464 PIVOT SLEEVE, WHEEL 2
87 00851 WASHER-PLAIN 1/4" 4
88 11276A SCREW, 1/4"-20 X 7/8"L, FHD, PH, ZP 2
89 30074 NUT, HEX #8-32 ZP 4
91 11007 WASHER, 0.199", PLAIN, ZP 4
92 10892 NUT-HEX LOCK #10-24 2
93 X9214 GROUND LABEL 1
94 16142B SCREW, #8-18 X 3/8"L, PNHD ,PH ,ZP, TAP-AB 4
95 03261 SCREW, TCT(F) PAN HEAD, #10-32 2
96 33114 SCREW, #8-32 X 1/2"L, FHD, SOCKET, BO 8
97 33104 METAL STUD, CAM LEVER 2
98 33630 SCREW, #10-32 X 1-3/4"L, FHD, PH, ZP 2
99 19999 SCREW, 1/4"-20 X 1-1/4"L, RHDHD, PH, ZP 2
100 33102 CAM LEVER HANDLE 2
101 30085 STRAIN RELIEF NUT 1
https://harrissupplyind.com-ToOrderPartsCall608-268-8080

A Tacony Company
3101 Wichita Court • Ft. Worth, TX 76140-1755
1-800-880-2913 • Fax: [phone] • www.Powr-Flite.com
PF2030-MAN 4/2016
https://harrissupplyind.com-ToOrderPartsCall608-268-8080
