PR 5715 User manual

5715
SIGNALS THE BEST
Programmable
LED Indicator
No. 5715V102-UK
From serial number:
121496001 (B)
131077001 (D)

1318
PR electronics A/S tilbyder et bredt program af analoge og digitale
signalbehandlingsmoduler til industriel automation. Programmet
består af Isolatorer, Displays, Ex-barrierer, Temperaturtransmittere,
Universaltransmittere m. Vi har modulerne, du kan stole på i selv
barske miljøer med elektrisk støj, vibrationer og temperaturud-
sving, og alle produkter opfylder de strengeste internationale stan-
darder. Vores motto »Signals the Best« er indbegrebet af denne
loso – og din garanti for kvalitet.
PR electronics A/S offers a wide range of analogue and digital
signal conditioning devices for industrial automation. The product
range includes Isolators, Displays, Ex Interfaces, Temperature
Transmitters, and Universal Devices. You can trust our products
in the most extreme environments with electrical noise, vibrations
and temperature uctuations, and all products comply with the
most exacting international standards. »Signals the Best« is the
epitome of our philosophy – and your guarantee for quality.
PR electronics A/S offre une large gamme de produits pour le
traitement des signaux analogiques et numériques dans tous
les domaines industriels. La gamme de produits s’étend des
transmetteurs de température aux afcheurs, des isolateurs aux
interfaces SI, jusqu’aux modules universels. Vous pouvez compter
sur nos produits même dans les conditions d’utilisation sévères,
p.ex. bruit électrique, vibrations et uctuations de température.
Tous nos produits sont conformes aux normes internationales les
plus strictes. Notre devise »SIGNALS the BEST« c’est notre ligne
de conduite - et pour vous l’assurance de la meilleure qualité.
PR electronics A/S verfügt über ein breites Produktprogramm
an analogen und digitalen Signalverarbeitungsgeräte für die in-
dustrielle Automatisierung. Dieses Programm umfasst Displays,
Temperaturtransmitter, Ex- und galvanische Signaltrenner, und
Universalgeräte. Sie können unsere Geräte auch unter extremen
Einsatzbedingungen wie elektrisches Rauschen, Erschütterungen
und Temperaturschwingungen vertrauen, und alle Produkte von
PR electronics werden in Übereinstimmung mit den strengsten
internationalen Normen produziert. »Signals the Best« ist Ihre
Garantie für Qualität!
DK
UK
FR
DE

5715V102-UK 1
PROGRAMMABLE LED INDICATOR
5715
CONTENTS
Warning .............................................................................. 2
Symbol identification.......................................................... 2
Safety instructions.............................................................. 3
Declaration of conformity................................................... 5
Front and back layout ........................................................ 6
Application ......................................................................... 7
Technical characteristics.................................................... 7
Mounting / installation........................................................ 7
Applications........................................................................ 8
Order: 5715 ........................................................................ 9
Electrical specifications...................................................... 9
Sensor error detection inside and outside range............... 13
Connections ....................................................................... 14
Block diagram .................................................................... 15
Routing diagram................................................................. 17
Scrolling help texts............................................................. 18
Configuration / operating the function keys ...................... 20
Programming via PC .......................................................... 21
Graphic depiction of the relay function setpoint................ 21

2 5715V102-UK
SYMBOL IDENTIFICATION
Triangle with an exclamation mark: Warning / demand. Potentially
lethal situations.
The CE mark proves the compliance of the module with the essential
requirements of the directives.
WARNING
This module is designed for connection to hazardous electric
voltages. Ignoring this warning can result in severe personal
injury or mechanical damage. To avoid the risk of electric shock
and fire, the safety instructions of this manual must be observed
and the guidelines followed. The specifications must not be
exceeded, and the module must only be applied as described
in the following. Prior to the commissioning of the module, this
manual must be examined carefully. Only qualified personnel
(technicians) should install this module.
If the equipment is used in a manner not specified by the
manufacturer, the protection provided by the equipment may be
impaired.
WARNING
Until the module is fixed, do not connect hazardous voltages to
the module.
The following operations should only be carried out on a
disconnected module and under ESD safe conditions:
Troubleshooting the module.
Repair of the module must be done by PR electronics A/S
only.
HAZARD-
OUS
VOLTAGE
GENERAL

5715V102-UK 3
SAFETY INSTRUCTIONS
DEFINITIONS
Hazardous voltages have been defined as the ranges: 75 to 1500 Volt DC, and
50 to 1000 Volt AC.
Technicians are qualified persons educated or trained to mount, operate, and
also troubleshoot technically correct and in accordance with safety regulations.
Operators, being familiar with the contents of this manual, adjust and operate
the knobs or potentiometers during normal operation.
RECEIPT AND UNPACKING
Unpack the device without damaging it. The packing should always follow the
device until this has been permanently mounted. Check at the receipt of the
device whether the type corresponds to the one ordered.
ENVIRONMENT
Avoid direct sunlight, dust, high temperatures, mechanical vibrations and shock,
as well as rain and heavy moisture. If necessary, heating in excess of the stated
limits for ambient temperatures should be avoided by way of ventilation.
All modules fall under Installation Category II, Pollution Degree 1, and Insulation
Class II.
MOUNTING
Only technicians who are familiar with the technical terms, warnings, and
instructions in the manual and who are able to follow these should connect the
module.
Should there be any doubt as to the correct handling of the module, please
contact your local distributor or, alternatively,
PR electronics A/S
www.prelectronics.com
Mounting and connection of the module should comply with national legislation
for mounting of electric materials, i.e. wire cross section, protective fuse, and
location. Descriptions of Input / Output and supply connections are shown in
the block diagram and side label.

4 5715V102-UK
The following apply to fixed hazardous voltages-connected modules:
The max. size of the protective fuse is 10 A and, together with a power
switch, it should be easily accessible and close to the module. The
power switch should be marked with a label telling it will switch off the
voltage to the module.
UL INSTALLATION REQUIREMENTS
For use on a flat surface of a type 1 enclosure
Use 60/75°C copper conducters only
Enclosure rating (face only).................... Type 4X, UL50E
Max. ambient temperature..................... 60°C
Max. wire size, pins 41...46.................... AWG 30-16
Max. wire size, others ............................ AWG 30-12
UL file number........................................ E248256
CALIBRATION AND ADJUSTMENT
During calibration and adjustment, the measuring and connection of external
voltages must be carried out according to the specifications of this manual. The
technician must use tools and instruments that are safe to use.
NORMAL OPERATION
Operators are only allowed to adjust and operate modules that are safely fixed
in panels, etc., thus avoiding the danger of personal injury and damage. This
means there is no electrical shock hazard, and the module is easily accessible.
CLEANING
When disconnected, the module may be cleaned with a cloth moistened with
distilled water.
LIABILITY
To the extent the instructions in this manual are not strictly observed, the
customer cannot advance a demand against PR electronics A/S that would
otherwise exist according to the concluded sales agreement.

5715V102-UK 5
DECLARATION OF CONFORMITY
As manufacturer
PR electronics A/S
Lerbakken 10
DK-8410 Rønde
hereby declares that the following product:
Type: 5715
Name: Programmable LED indicator
is in conformity with the following directives and standards:
The EMC Directive 2004/108/EC and later amendments
EN 61326-1
For specification of the acceptable EMC performance level, refer to the
electrical specifications for the module.
The Low Voltage Directive 2006/95/EC and later amendments
EN 61010-1
Rønde, 17 December 2009 Kim Rasmussen
Manufacturer’s signature

6 5715V102-UK
FRONT AND BACK LAYOUT
Picure 1: Front of PReview 5715.
Picture 2: Back of PReview 5715.

5715V102-UK 7
PROGRAMMABLE LED INDICATOR
PREVIEW 5715
• 4-digit 14-segment LED display
• Input for mA, V, potentiometer, Ohm, RTD and TC
• 4 relays and analogue output
• Universal supply
• Programmable via front keys and PC
Application
• Displayfordigitalreadoutofcurrent/voltage/resistance/temperatureor
3-wire potentiometer signals.
• Processcontrolwith4pairsofpotential-freechange-overrelaysand
analogue output.
• Fortanklevelcontrol,withthepossibilityofcustomerlinearisationensuring
correct level measurement and control in non-linear tanks.
Technical characteristics
• 4-digitLEDindicatorwith13.8mm14-segmentcharacters.Max.display
readout -1999...9999 with programmable decimal point and relay ON / OFF
indication.
• Allstandardoperationalparameterscanbeadjustedtoanyapplicationby
way of the front function keys. When programming is carried out by way of
a PC and the configuration program PReset, additional configuration options
are available, such as customer-defined linearisation and special input signals.
• Helptextsineightlanguagescanbeselectedviaamenuitem.
• Amenuitemallowstheusertominimisetheinstallationtesttimefortherelay
outputs by activating/deactivating each relay independently of the input signal.
Mounting / installation
• Tobemountedinpanelfront.Theincludedrubberpackingmustbemounted
between the panel cutout hole and the display front to obtain a protection
degree of IP65 (type 4X). For extra protection in extreme environments,
PReview 5715 can be delivered with a specially designed splash-proof cover
as accessory.

46
45
44
43
42
41
4 3 2
1 2 3 4
1 2 3 4 12
11
26
25
24
23
22
21
66
65
64
63
62
61
32
31
1 2 3 4
-
+
-
+
-
+
-
+
-
+
8 5715V102-UK
APPLICATIONS
Input signals:
Current
Potentio-
meter
Output signals:
4 change-over relays
Analogue, 0/4...20 mA
Supply:
21.6...253 VAC
or
19.2...300 VDC
Voltage
RTD & Lin R -
Connection, wires
2-twire transmitter
TC

5715V102-UK 9
Electrical specifications
Specifications range:
-20°C to +60°C
Common specifications:
Supply voltage, universal ............................ 21.6...253 VAC, 50...60 Hz or
19.2...300 VDC
Consumption:
Isolation voltage, test / operation ............... 2.3 kVAC / 250 VAC
Signal / noise ratio ...................................... Min. 60 dB (0...100 kHz)
Communications interface .......................... USB Loop Link
Response time (0...90%, 100...10%):
Temperature input.................................... < 1 s
Current / voltage input............................. < 400 ms
Calibration temperature............................... 20...28°C
Accuracy, the greater of general and basic values:
General values
Input type Absolute accucary Temperature coefficient
All ≤±0.1% of reading ≤±0.01% of reading / °C
Type Internal consumption Max. consumption
5715B 3.0 W 3.3 W
5715D 3.5 W 3.8 W
Type Version
5715 4 relays ....................: B
Analogue output and 4 relays ..: D
Order: 5715

10 5715V102-UK
Auxiliary supply:
2-wire supply (pin 46...45) ....................... 25...15 VDC / 0...20 mA
Wire size, pin 41...46 (max.)........................ 1 x 1.5 mm2stranded wire
Wire size, others (max.)............................... 1 x 2.5 mm2stranded wire
Relative humidity......................................... < 95% RH (non cond.)
Dimensions (HxBxD) ................................... 48 x 96 x 120 mm
Cutout dimensions ...................................... 44.5 x 91.5 mm
Protection degree (mounted in panel)......... IP65 / Type 4X, UL50E
Weight ......................................................... 260 g
RTD, linear resistance and potentiometer input:
Input for RTD types:
Pt10, Pt20, Pt50, Pt100, Pt200, Pt250, Pt300, Pt400, Pt500, Pt1000
Ni50, Ni100, Ni120, Ni1000, Cu10, Cu20, Cu50, Cu100
EMC immunity influence ..................................... < ±0,5% of reading
Basic values
Input
type Basic accuracy Temperature coefficient
mA ≤±4 µA ≤±0.4 µA / °C
Volt ≤±20 µV ≤±2 µV / °C
Pt100 ≤±0.2°C ≤±0.01°C / °C
Linear resistance ≤±0.1 Ω ≤ ±0.01 Ω/ °C
Potentiometer ≤±0.1 Ω ≤ ±0.01 Ω/ °C
TC type:
E, J, K, L, N, T, U ≤±1°C ≤±0.05°C / °C
TC type: R, S, W3,
W5, LR ≤±2°C ≤±0.2°C / °C
TC type: B
160...400°C
≤±4.5°C ≤±0.45°C / °C
TC type: B
400...1820°C
≤±2°C ≤±0.2°C / °C
Input
type Min. value Max. value Standard
Pt10...Pt1000
Ni50...Ni1000
Cu10...Cu100
Lin. R
Potentiometer
-200°C
-60°C
-200°C
0 Ω
10 Ω
+850°C
+250°C
+260°C
10000 Ω
100 kΩ
IEC 60751
DIN 43760
α= 0.00427
-
-

5715V102-UK 11
Cable resistance per wire, RTD (max.)........ 50 Ω
Sensor current, RTD.................................... Nom. 0.2 mA
Effect of sensor cable resistance
(3- / 4-wire), RTD......................................... < 0.002 Ω/ Ω
Sensor error detection, RTD ....................... Yes
Short circuit detection, RTD........................ < 15 Ω
TC input:
Cold junction compensation (CJC)
via internal sensor................................... ±(2.0°C + 0.4°C * Δt)
Δt = internal temperature - ambient temperature
Sensor error detection, all TC types ........... Yes
Sensor error current:
when detecting ....................................... Nom. 2 μA
else.......................................................... 0 μA
Current input:
Measurement range .................................... 0...20 mA
Programmable measurement ranges.......... 0...20 and 4...20 mA
Input resistance........................................... Nom. 20 Ω+ PTC 25 Ω
Sensor error detection:
loop break 4...20 mA ............................... Yes
Voltage input:
Measurement range .................................... 0...12 VDC
Programmable measurement ranges.......... 0...1, 0.2...1,
0...10 and 2...10 VDC
Input resistance........................................... Nom. 10 MΩ
Type Min. value Max. value Standard
B
E
J
K
L
N
R
S
T
U
W3
W5
LR
+0°C
-100°C
-100°C
-180°C
-200°C
-180°C
-50°C
-50°C
-200°C
-200°C
0°C
0°C
-200°C
+1820°C
+1000°C
+1200°C
+1372°C
+900°C
+1300°C
+1760°C
+1760°C
+400°C
+600°C
+2300°C
+2300°C
+800°C
IEC 60584-1
IEC 60584-1
IEC 60584-1
IEC 60584-1
DIN 43710
IEC 60584-1
IEC 60584-1
IEC 60584-1
IEC 60584-1
DIN 43710
ASTM E988-90
ASTM E988-90
GOST 3044-84

12 5715V102-UK
Outputs:
Display:
Display readout ........................................... -1999...9999 (4 digits)
Decimal point .............................................. Programmable
Digit height .................................................. 13.8 mm
Display updating ......................................... 2.2 times / s
Input outside input range is
indicated by................................................. Explanatory text
Current output:
Signal range (span)...................................... 0...20 mA
Programmable signal ranges ...................... 0...20, 4...20,
20...0 and 20...4 mA
Load (max.).................................................. 20 mA / 800 Ω/ 16 VDC
Load stability............................................... ≤0.01% of span / 100 Ω
Sensor error detection ................................ 23 / 0 / 3.5 mA / none
NAMUR NE 43 Up- / Downscale ................ 23 mA / 3.5 mA
Output limitation:
on 4...20 and 20...4 mA signals............... 3,8...20.5 mA
on 0...20 and 20...0 mA signals............... 0...20.5 mA
Current limit................................................. ≤28 mA
Relay outputs:
Relay function.............................................. Setpoint
Hysteresis.................................................... 0...100%
On and Off delay......................................... 0...3600 s
Sensor error detection ................................ Make / Break / Hold
Max. voltage................................................ 250 VRMS
Max. current ................................................ 2 A / AC
Max. AC power ........................................... 500 VA
Max. current at 24 VDC............................... 1 A
Marine approval:
Det Norske Veritas, Ships & Offshore ......... Standard for Certification No. 2.4
GOST R approval:
VNIIM, Cert. no............................................ See www.prelectronics.com
Observed authority requirements: Standard:
EMC 2004/108/EC ...................................... EN 61326-1
LVD 2006/95/EC.......................................... EN 61010-1
UL, Standard for Safety .............................. UL 508

5715V102-UK 13
Sensor error detection inside and outside range
Sensor error check in 5715 variants:
Variant: Configuration Sensor error detection:
5715B ERR1, ERR2, ERR3 and ERR4 = NONE OFF
Else: ON
5715D ERR1, ERR2, ERR3 and ERR4=NONE, O.ERR=NONE. OFF
Else: ON
Readout at hardware error
! Error indications in the display blink once a second. The help text explains the error
Error search Readout Error cause
Test of internal communication uC / ADC HW.ER Permanent error in ADC
Test of internal CJC sensor CJ.ER CJC sensor defect
Check-sum test of the configuration in RAM RA.ER Error in RAM
Check-sum test of the configuration in EEprom EE.ER Error in EEPROM
Outside range readout (IN.LO, IN.HI):
If the valid range of the A/D converter or the polynomial is exceeded
Input Range Readout Limit
VOLT
0...1 V / 0,2...1 V IN.LO < -25 mV
IN.HI > 1,2 V
0...10 V / 2...10 V IN.LO < -25 mV
IN.HI > 12 V
CURR 0...20 mA / 4...20 mA IN.LO < -1,05 mA
IN.HI > 25,05 mA
POTM - IN.LO < -0,5%
IN.HI > 100,5%
TEMP TC / RTD IN.LO < temperature range -2°C
IN.HI > temperature range +2°C
LIN R
0...800 ohm IN.LO < 0 ohm
IN.HI > 1 kohm
0...10 kohm IN.LO < 0 ohm
IN.HI > 15 kohm
Sensor error detection (SE.BR, SE.SH):
Input Range Readout Limit
CURR Loop break (4..20mA) SE.BR <= 3,6 mA; > = 21 mA
TEMP
TC SE.BR > ca. 750 kohm / (1,25 V)
RTD, 2-, 3- & 4-wire
No SE.SH for Cuxx, Pt10, Pt20 & Pt50
SE.BR > 12 kohm
SE.SH < 15 ohm
LIN R 0...800 ohm SE.BR > 875 ohm
0...10 kohm SE.BR > 12 kohm
Display readout below min. / above max. (-1.9.9.9, 9.9.9.9):
Input Range Readout Limit
CURR /
VOLT / Lin R All -1.9.9.9 Display readout <-1999
9.9.9.9 Display readout >9999
POTM - -1.9.9.9 Display readout <-1999
9.9.9.9 Display readout >9999

Tx
31 32
41 42 43 44 45 4641 42 43 44 45 4641 42 43 44 45 46
41 42 43 44 45 46 41 42 43 44 45 46 41 42 43 44 45 46
41 42 43 44 45 46 41 42 43 44 45 46
mA
11 12
R2
R1
21 22 23 24 25 26
R3 R4
41 42 43 44 45 4661 62 63 64 65 66
- +
- +
- + - + - +
14 5715V102-UK
CONNECTIONS
RTD & Lin R, 2-wire RTD & Lin R, 3-wire RTD & Lin R, 4-wire
PotentiometerVoltage
TC 2-wire transmitter Current
Current Relays
Inputs:
Output:
Supply:
Relays

I+
21 22 23 11 12 31 32 24 25 26 61 62 63 64 65 66
CPU
AD
EEPROM
PTC
20 Ω
5715
1 2 3 4
46 45 44 43 42 41
TC+V
4 3 2
R1 R2 R3 R4
1
3
2
Tx
+
+
+
mA
5715V102-UK 15
BLOCK DIAGRAM
I
Output
Common Relay 1 N.O. Relay 1 N.C. Common Relay 2 N.O. Relay 2 N.C. Common Relay 3 N.O. Relay 3 N.C. Common Relay 4 N.O. Relay 4 N.C. Supply Supply 21.6...253 VAC
or
19.2...300 VDC
Version D
0.2 mA
Int. CJC
2-wire supply
> 15 VDC
Input +,
mA
Input gnd.
RTD & Lin R
wires
Potm.
PC communication
Gnd.

Power up
50.0
3
F.SET
REL1
REL2
REL3
REL4
3
1.0
1.2
1 2 1 2
SETP
-1999
9999
/OFF 3
1 2
DI.LO PERC
DI.HI
1.1
0000
9999
1 2
3
CURR 3RANG
0-20 4-20
1 2
VOLT 3RANG
1 2
0-1 0.2-1
0-10 2-10
IN
1 2
1111
1.1.1.1
1 2
POTM
TEMP TYPE
PT.TY
TC
CONN
TC.TY
PT 3
1 2 1 2
NI NI.TY CONN
50-1000
1 2
2W 3W 4W
1 2
1 2
3
3
3
PASS
3a999
9999
1 2
3a999
9999
1 2
3PERC
DISP
1 2
3
1.3
DEC.P
TC.B TC.E TC.J TC.K TC.L TC.N TC.R
TC.S TC.T TC.U TC.W3 TC.W5 TC.LR
1111
111.1
1 2
UNIT
'C
'F
1 2
ADV
NO
YES
1 2
3
10-1000 2W 3W 4W
3
LIN.R 3LR.LO
0-9998
1 2
LR.HI
1-9999
1 2
CONN
1 2
2W 3W 4W
3
3
3
CU.TY CONN
CU 3
1 2 1 2
10-100 2W 3W 4W
3
3
3
1 2
3
3
3
333
3
3
ADV.SET
YES
3
C.LIN
1.4
DEC.P
16 5715V102-UK
1.0 = Default state
1.1 = Only if password-protected
1.2 = Only is FastSet is enabled
1.3 = Setpoint adjustment and
relay test disabled at pass-
word 5000...9999.
1.4 = Only for special configura-
tion via PC
1.5 = Not valid for these input
signals: Potentiometer,
0...20 mA and voltage
1.6 = Only if input signal is tem-
perature
1.7 = No analogue output
1.8 = In default state press and
hold 1or 2to change
display intensity between
damped and full
(7 = full intensity)
Fast setpoint adjustment and relay test
1Increase setpoint
2Decrease setpoint
3Save and exit the menu
1and 2simultaneously =
relay changes state

REL.1
SET
SKIP
OFF
1 2
3
SETP
0.0
100.0
1 2
3
ACT1
INCR
DECR
1 2
3
HYS1
0.0
100.0
1 2
3
ERR1
HOLD
ACTI
DEAC
NONE
1 2
3
ON.DE
0000
3600
1 2
3
OF.DE
0000
3600
1 2
3
3
1.5
REL.X
SET
SKIP
OFF
1 2
3
SETP
0.0
100.0
1 2
3
ACTX
INCR
DECR
1 2
3
HYSX
0.0
100.0
1 2
3
ERRX
HOLD
ACTI
DEAC
NONE
1 2
3
ON.DE
0000
3600
1 2
3
OF.DE
0000
3600
1 2
3
3
1.5
A.OUT
4-20
0-20
20-4
20-0
1 2
3
O.LO
a999
9999
1 2
3
O.HI
a999
9999
1 2
3
O.ERR
0/3.5mA
23mA
NONE
1 2
3
RESP
0.0
60.0
1 2
3
E.PAS
YES
NO
1 2
3
N.PAS
0000
9999
1 2
3
NO
----
1.51.6 1.6
1.7 1.7
DE DK
ES FR
IT SE
UK CZ
X = 2...4
ADV.SET
LANG
DISP
CAL
1.8 7
LIGH
3
1...7
1 2
LANG
DISP
CAL
1 2
3
3UK
HLP.T
1 2
3YES
CA.LO
3
YES NO
1 2
2.0
VAL.L
3
100.0
0.0
1 2
NO
3
YES
CA.HI
3
1 2
90.0
VAL.H
3
100.0
0.0
1 2
NO
YES
USE.C
3
1 2
YES NO YES NO
3
5715V102-UK 17
ROUTING DIAGRAM
If no key is activated for 2 minutes, the display returns to default state
1.0 without saving configuration changes.
1Increase value / choose next parameter
2Decrease value / choose previous parameter
3Accept the chosen parameter and go to the next menu
Hold 3Back to previous menu / return to default state 1.0 without saving
To default state 1.0

18 5715V102-UK
SCROLLING HELP TEXTS
Display in default state xxxx, hardware error:
SE.BR --> SENSOR WIRE BREAKAGE
SE.SH --> SENSOR SHORT CIRCUIT
IN.HI --> INPUT OVERRANGE
IN.LO --> INPUT UNDERRANGE
9.9.9.9 --> DISPLAY OVERRANGE
-1.9.9.9 --> DISPLAY UNDERRANGE
HW.ER --> HARDWARE ERROR
EE.ER --> EEPROM ERROR -
CHECK CONFIGURATION
RA.ER --> RAM MEMORY ERROR
CJ.ER --> CJC SENSOR ERROR
Fastset (Enabled):
F.SET
REL1 --> FAST SET MENU -
REL2 --> SELECT RELAY
REL3
REL4
SETP
xxxx --> RELAY SETPOINT - PRESS OK TO SAVE
Fastset (Disabled):
SETP
xxxx --> RELAY SETPOINT - READ ONLY
Configuration menus:
ADV
YES --> ENTER ADVANCED SETUP MENU?
NO
PASS
xxxx --> SET CORRECT PASSWORD
IN
C.LIN* --> TEXT ENTERED BY USER IN PRESET
CURR --> CURRENT INPUT
VOLT --> VOLTAGE INPUT
POTM --> POTENTIOMETER INPUT
LIN.R --> LINEAR RESISTANCE INPUT
TEMP --> TEMPERATURE SENSOR INPUT
RANG When current selected:
0-20 --> INPUT RANGE IN mA
4-20 --> INPUT RANGE IN mA
RANG When voltage selected:
0-10 --> INPUT RANGE IN VOLT
2-10 --> INPUT RANGE IN VOLT
0.0-1 --> INPUT RANGE IN VOLT
0.2-1 --> INPUT RANGE IN VOLT
DEC.P
1111 --> DECIMAL POINT POSITION
111.1 --> DECIMAL POINT POSITION
11.11 --> DECIMAL POINT POSITION
1.111 --> DECIMAL POINT POSITION
LR.LO
xxxx --> SET RESISTANCE VALUE LOW
LR.HI
xxxx --> SET RESISTANCE VALUE HIGH
DI.LO
xxxx --> DISPLAY READOUT LOW
DI.HI
xxxx --> DISPLAY READOUT HIGH
REL.U
PERC --> SET RELAY IN PERCENTAGE
DISP --> SET RELAY IN DISPLAY UNITS
TYPE
CU --> SELECT CU SENSOR TYPE
PT --> SELECT PT SENSOR TYPE
NI --> SELECT NI SENSOR TYPE
TC --> SELECT TC SENSOR TYPE
CU.TY
10 --> SELECT CU SENSOR TYPE
20 --> SELECT CU SENSOR TYPE
50 --> SELECT CU SENSOR TYPE
100 --> SELECT CU SENSOR TYPE
PT.TY
10 --> SELECT PT SENSOR TYPE
20 --> SELECT PT SENSOR TYPE
50 --> SELECT PT SENSOR TYPE
100 --> SELECT PT SENSOR TYPE
200 --> SELECT PT SENSOR TYPE
250 --> SELECT PT SENSOR TYPE
300 --> SELECT PT SENSOR TYPE
400 --> SELECT PT SENSOR TYPE
500 --> SELECT PT SENSOR TYPE
1000 --> SELECT PT SENSOR TYPE
NI.TY
50 --> SELECT NI SENSOR TYPE
100 --> SELECT NI SENSOR TYPE
120 --> SELECT NI SENSOR TYPE
1000 --> SELECT NI SENSOR TYPE
CONN When Cu, Pt and Ni sensor is selected
2W --> SELECT 2-WIRE SENSOR CONNECTION
3W --> SELECT 3-WIRE SENSOR CONNECTION
4W --> SELECT 4-WIRE SENSOR CONNECTION
TC.TY
TC. B --> SELECT TC SENSOR TYPE
TC. E --> SELECT TC SENSOR TYPE
TC. J --> SELECT TC SENSOR TYPE
TC. K --> SELECT TC SENSOR TYPE
TC. L --> SELECT TC SENSOR TYPE
TC. N --> SELECT TC SENSOR TYPE
TC. R --> SELECT TC SENSOR TYPE
TC. S --> SELECT TC SENSOR TYPE
TC. T --> SELECT TC SENSOR TYPE
TC. U --> SELECT TC SENSOR TYPE
TC.W3 --> SELECT TC SENSOR TYPE
TC.W5 --> SELECT TC SENSOR TYPE
TC.LR --> SELECT TC SENSOR TYPE
DEC.P When temperature selected
1111 --> DECIMAL POINT POSITION
111.1 --> DECIMAL POINT POSITION
UNIT
°C --> DISPLAY AND RELAY SETUP IN CELSIUS
°F --> DISPLAY AND RELAY SETUP IN
FAHRENHEIT
