PR 5714 User manual

5714
Programmable
LED Indicator
No. 5714V103-UK
From serial number:
121496001 (A+B)
131077001 (C+D)

1651
PR electronics A/S tilbyder et bredt program af analoge og digitale
signalbehandlingsmoduler til industriel automation. Programmet
består af Isolatorer, Displays, Ex-barrierer, Temperaturtransmittere,
Universaltransmittere mfl. Vi har modulerne, du kan stole på i selv
barske miljøer med elektrisk støj, vibrationer og temperaturudsving,
og alle produkter opfylder de strengeste internationale standarder.
Vores motto »Signals the Best« er indbegrebet af denne filosofi – og
din garanti for kvalitet.
PR electronics A/S oers a wide range of analog and digital
signal conditioning devices for industrial automation. The product
range includes Isolators, Displays, Ex Interfaces, Temperature
Transmitters, and Universal Devices. You can trust our products in
the most extreme environments with electrical noise, vibrations and
temperature fluctuations, and all products comply with the most
exacting international standards. »Signals the Best« is the epitome
of our philosophy – and your guarantee for quality.
PR electronics A/S ore une large gamme de produits pour le
traitement des signaux analogiques et numériques dans tous
les domaines industriels. La gamme de produits s’étend des
transmetteurs de température aux acheurs, des isolateurs aux
interfaces SI, jusqu’aux modules universels. Vous pouvez compter
sur nos produits même dans les conditions d’utilisation sévères,
p.ex. bruit électrique, vibrations et fluctuations de température.
Tous nos produits sont conformes aux normes internationales les
plus strictes. Notre devise »SIGNALS the BEST« c’est notre ligne
de conduite - et pour vous l’assurance de la meilleure qualité.
PR electronics A/S verfügt über ein breites Produktprogramm
an analogen und digitalen Signalverarbeitungsgeräte für die in-
dustrielle Automatisierung. Dieses Programm umfasst Displays,
Temperaturtransmitter, Ex- und galvanische Signaltrenner, und
Universalgeräte. Sie können unsere Geräte auch unter extremen
Einsatzbedingungen wie elektrisches Rauschen, Erschütterungen
und Temperaturschwingungen vertrauen, und alle Produkte von
PR electronics werden in Übereinstimmung mit den strengsten
internationalen Normen produziert. »Signals the Best« ist Ihre
Garantie für Qualität!
DK
UK
FR
DE

5714V103-UK 1
PROGRAMMABLE LED INDICATOR
PREVIEW 5714
TABLE OF CONTENTS
Warning....................................................................................................... 2
Symbol identification ............................................................................ 2
Safety instructions................................................................................. 3
Front and back layout........................................................................... 5
Application................................................................................................. 6
Technical characteristics...................................................................... 6
Mounting.................................................................................................... 6
Applications............................................................................................... 7
Order: 5714............................................................................................... 8
Electrical specifications........................................................................ 8
Sensor error detection /
sensor error detection outside range......................................... 12
Connections .............................................................................................. 14
Block diagram........................................................................................... 15
Routing diagram...................................................................................... 17
Scrolling help text .................................................................................. 18
Configuration / operating the function keys............................... 20
Graphic depiction of the relay function setpoint....................... 21

2 5714V103-UK
SYMBOL IDENTIFICATION
Triangle with an exclamation mark: Warning / demand. Potentially
lethal situations.
The CE mark proves the compliance of the device with the essen-
tial requirements of the directives.
WARNING
This device is designed for connection to hazardous electric vol-
tages. Ignoring this warning can result in severe personal injury
or mechanical damage. To avoid the risk of electric shock and fire,
the safety instructions of this manual must be observed and the
guidelines followed. The specifications must not be exceeded,
and the device must only be applied as described in the follo-
wing. Prior to the commissioning of the device, this manual must
be examined carefully. Only qualified personnel (technicians)
should install this device.
If the equipment is used in a manner not specified by the
manufacturer, the protection provided by the equipment may be
impaired.
WARNING
Until the device is fixed, do not connect hazardous voltages to
the device.
The following operations should only be carried out on a discon-
nected device and under ESD safe conditions:
Troubleshooting the device.
Repair of the device must be done by PR electronics A/S only.
GENERAL
HAZARD-
OUS
VOLTAGE

5714V103-UK 3
SAFETY INSTRUCTIONS
DEFINITIONS:
Hazardous voltages have been defined as the ranges: 75 to 1500 Volt DC, and 50
to 1000 Volt AC.
Technicians are qualified persons educated or trained to mount, operate, and also
troubleshoot technically correct and in accordance with safety regulations.
Operators, being familiar with the contents of this manual, adjust and operate the
knobs or potentiometers during normal operation.
RECEIPT AND UNPACKING:
Unpack the device without damaging it. The packing should always follow the
device until this has been permanently mounted. Check at the receipt of the
device whether the type corresponds to the one ordered.
ENVIRONMENT:
Avoid direct sunlight, dust, high temperatures, mechanical vibrations and shock,
as well as rain and heavy moisture. If necessary, heating in excess of the stated
limits for ambient temperatures should be avoided by way of ventilation.
All devices fall under Installation Category II, Pollution Degree 1, and Insulation
Class II.
MOUNTING:
Only technicians who are familiar with the technical terms, warnings, and instruc-
tions in the manual and who are able to follow these should connect the device.
Should there be any doubt as to the correct handling of the device, please con-
tact your local distributor or, alternatively,
PR electronics A/S
www.prelectronics.com.
Mounting and connection of the device should comply with national legislation
for mounting of electric materials, i.a. wire cross section, protective fuse, and
location. Descriptions of Input / Output and supply connections are shown in the
block diagram and side label.

4 5714V103-UK
The following apply to fixed hazardous voltages-connected devices:
The max. size of the protective fuse is 10 A and, together with a power
switch, it should be easily accessible and close to the device. The power
switch should be marked with a label telling it will switch off the vol-
tage to the device.
UL INSTALLATION REQUIREMENTS:
For use on a flat surface of a type 1 enclosure
Use 60/75°C copper conducters only
Enclosure rating (face only)........................... Type 4X, UL50E
Max. ambient temperature ............................ 60°C
Max. wire size, pins 41...46........................... AWG 30-16
Max. wire size, others...................................... AWG 30-12
UL file number .................................................... E248256
CALIBRATION AND ADJUSTMENT:
During calibration and adjustment, the measuring and connection of external
voltages must be carried out according to the specifications of this manual. The
technician must use tools and instruments that are safe to use.
NORMAL OPERATION:
Operators are only allowed to adjust and operate devices that are safely fixed in
panels, etc., thus avoiding the danger of personal injury and damage. This means
there is no electrical shock hazard, and the device is easily accessible.
CLEANING:
When disconnected, the device may be cleaned with a cloth moistened with
distilled water.
LIABILITY:
To the extent the instructions in this manual are not strictly observed, the
customer cannot advance a demand against PR electronics A/S that would other-
wise exist according to the concluded sales agreement.

5714V103-UK 5
FRONT AND BACK LAYOUT
Picture 1: Front of PReview 5714.
Picture 2: Back of PReview 5714.

6 5714V103-UK
PROGRAMMABLE LED INDICATOR
PREVIEW 5714
• 4-digit 14-segment LED indicator
• Input for mA, V, potentiometer, Ohm, RTD and TC
• 2 relays and analogue output
• Universal voltage supply
• Front key programmable
Application
• Display for digital readout of current, voltage, resistance, temperature or
potentiometer signals.
• Process control with 2 pairs of potential-free relays and / or analogue output.
• For local readout in extremely wet atmospheres with a specially designed
splash-proof cover.
Technical characteristics
• 4-digit LED indicator with 13.8 mm 14-segment characters. Max. display read-
out -1999...9999 with programmable decimal point, relay ON / OFF indication.
• All operational parameters can be adjusted to any application by use of the
front keys.
• PReview 5714 is available fully-configured acc. to specifications ready for
process control and visualisation.
• Help texts in eight languages can be selected via a menu item.
• In versions with relay outputs the user can minimise the installation test time
by activating / deactivating each relay independently of the input signal.
Mounting
• To be mounted in front panel. The included rubber packing must be mounted
between the panel cutout hole and the display front to obtain a protection
degree of IP65 (type 4X). For extra protection in extreme environments,
PReview 5714 can be delivered with a speially designed splash-proof cover as
accessory.

12
11
26
25
24
23
22
21
1 2
32
31
1 2
46
45
44
43
42
41
4 3 2
TC
1 2
-
+
-
+
-
+
-
+
-
+
5714V103-UK 7
APPLICATIONS
Input signals:
Current
Poten-
tiometer
Output signals:
2 change over relays
Analogue, 0/4...20 mA
Supply:
21.6...253 VAC
or
19.2...300 VDC
Voltage
RTD & Lin R -
connection, wires
2-wire transmitter

8 5714V103-UK
NB! Please order the splash-proof cover seperately. Order No. 8335.
Electrical specifications
Specifications range:
-20°C to +60°C
Common specifications:
Supply voltage, universal..................................... 21.6...253 VAC, 50...60 Hz or
19.2...300 VDC
Consumption
Isolation voltage, test / operation................... 2.3 kVAC / 250 VAC
Signal- / noise ratio................................................ Min. 60 dB (0...100 kHz)
Response time (0...90 %, 100...10 %), programmable:
Temperature input.......................................... 1...60 s
Current / voltage input ................................. 0.4...60 s
Calibration temperature ....................................... 20...28°C
Accuracy, the greater of general and basic values:
General values
Input type
Absolute
accuracy
Temperature
coefficient
All ≤±0.1% of reading ≤±0.01% of reading / °C
Type Internal consumption Max. consumption
5714A 2.2 W 2.5 W
5714B/C 2.7 W 3.0 W
5714D 3.2 W 3.5W
Type Version
5714 Standard.......................: A
2 relays........................: B
Analogue output ...............: C
Analogue output and 2 relys ....: D
Order: 5714

5714V103-UK 9
Auxiliary supply:
2 wire supply, pin 46...45 ............................. 25...15 VDC / 0...20 mA
Vibration...................................................................... IEC 60068-2-6 Test FC
2...13.2 Hz........................................................... ±1 mm
13.2...100 Hz ..................................................... ±0.7 g
Wire size, pin 41...46 max. .................................. 1 x 1.5 mm2stranded wire
Wire size, others max. ........................................... 1 x 2.5 mm2stranded wire
Relative humidity..................................................... < 95% RH (non cond.)
Dimensions (HxWxD).............................................. 48 x 96 x 120 mm
Cutout dimensions .................................................. 44.5 x 91.5 mm
Protection degree (mounted in panel)............ IP65 / Type 4X, UL50E
Weight .......................................................................... 230 g
RTD, linear resistance and potentiometer input:
Basic values
Input
type
Basic
accuracy
Temperature
coefficient
mA ≤±4 µA ≤±0.4 µA / °C
Volt ≤±20 µV ≤±2 µV / °C
Pt100 ≤±0.2°C ≤±0.01°C / °C
Linear resistance ≤±0.1 Ω ≤ ±0.01 Ω/ °C
Potentiometer ≤±0.1 Ω ≤ ±0.01 Ω/ °C
TC type:
E, J, K, L, N, T, U ≤±1°C ≤±0.05°C / °C
TC type: R, S, W3,
W5, LR ≤±2°C ≤±0.2°C / °C
TC type: B
85...200°C
≤±4°C ≤±0.4°C / °C
TC type: B
200...1820°C
≤±2°C ≤±0.2°C / °C
Input
type Min. value Max. value Standard
Pt10...Pt1000
Ni50...Ni1000
Cu10...Cu100
Lin. R
Potentiometer
-200°C
-60°C
-200°C
0 Ω
10 Ω
+850°C
+250°C
+260°C
10000 Ω
100 kΩ
IEC 60751
DIN 43760
α= 0.00427
-
-
EMC immunity influence .................................... < ±0.5% of readout

10 5714V103-UK
Input for RTD types:
Pt10, Pt20, Pt50, Pt100, Pt200, PT250, Pt300, Pt400, Pt500, Pt1000
Ni50, Ni100, Ni120, Ni1000, Cu10, Cu20, Cu50, Cu100
Cable resistance pr. wire, RTD (max.).............. 50 Ω
Sensor current, RTD................................................ Nom. 0.2 mA
Effect of sensor cable resistance
(3- / 4-wire), RTD..................................................... < 0.002 Ω/ Ω
Sensor error detection, RTD................................ Yes
Short curcuit detection, RTD............................... < 15 Ω
TC input:
Cold junction compensation (CJC)
via internal sensor........................................... ±(2.0°C + 0.4°C * Δt)
Δt = internal temperature - ambient temperature
Sensor error detection, all TC types................. Yes
Sensor error detection........................................... Yes
Sensor error current:
when detecting................................................. Nom. 2 μA
else......................................................................... 0 μA
Current input:
Measurement range................................................ 0...20 mA
Programmable measurement ranges............... 0...20 and 4...20 mA
Input resistance........................................................ Nom. 20 Ω+ PTC 25 Ω
Sensor error detection:
loop break 4...20 mA....................................... Yes
Type
Min.
value
Max.
value Standard
B
E
J
K
L
N
R
S
T
U
W3
W5
LR
0°C
-100°C
-100°C
-180°C
-200°C
-180°C
-50°C
-50°C
-200°C
-200°C
0°C
0°C
-200°C
+1820°C
+1000°C
+1200°C
+1372°C
+900°C
+1300°C
+1760°C
+1760°C
+400°C
+600°C
+2300°C
+2300°C
+800°C
IEC 60584-1
IEC 60584-1
IEC 60584-1
IEC 60584-1
DIN 43710
IEC 60584-1
IEC 60584-1
IEC 60584-1
IEC 60584-1
DIN 43710
ASTM E988-90
ASTM E988-90
GOST 3044-84

5714V103-UK 11
Voltage input:
Measurement range................................................ 0...12 VDC
Programmable measurement ranges............... 0...1 / 0.2...1 /
0...10 / 2...10 VDC
Input resistance........................................................ Nom. 10 MΩ
Outputs:
Display:
Display readout......................................................... -1999...9999 (4 digits)
Decimal point............................................................. Programmable
Digit height ................................................................ 13.8 mm
Display updating ...................................................... 2.2 times / s
Input outside input range is
indicated by................................................................ Explanatory text
Current output:
Signal range (span) ................................................. 0...20 mA
Programmable signal ranges............................... 0...20 / 4...20 /
20...0 / 20...4 mA
Load (max.)................................................................. 20 mA / 800 Ω/ 16 VDC
Load stability............................................................. ≤0.01% of span / 100 Ω
Sensor error detection........................................... 0 / 3.5 / 23 mA / none &
NAMUR NE 43 up / downscale........................... 23 mA / 3.5 mA
Output limitation:
on 4...20 and 20...4 mA signals.................. 3,8...20.5 mA
on 0...20 and 20...0 mA signals.................. 0...20.5 mA
Current limit ............................................................... ≤28 mA
Relay outputs:
Relay function........................................................... Setpoint
Hysteresis................................................................... 0...100%
On and Off delay...................................................... 0...3600 s
Sensor error detection........................................... Make / Break / Hold
Max. voltage .............................................................. 250 VRMS
Max. current............................................................... 2 A / AC
Max. AC power .......................................................... 500 VA
Max. current at 24 VDC......................................... 1 A
Marine approval:
Det Norske Veritas, Ships & Offshore............. Standard for Certification No. 2.4
Observed authority requirements: Standard:
EMC 2004/108/EC .................................................. EN 61326-1
LVD 2006/95/EC...................................................... EN 61010-1
UL, Standard for Safety......................................... UL 508
EAC TR-CU 020/2011............................................ EN 61326-1

12 5714V103-UK
Sensor error detection / sensor error detection outside range
Sensor error check in 5714 variants
Variant: Configuration Sensor error detection:
5714A Always: ON
5714B ERR1=NONE, ERR2=NONE: OFF
else: ON
5714C O.ERR=NONE: OFF
else: ON
5714D ERR1=NONE, ERR2=NONE, O.ERR=NONE: OFF
else: ON
Outside range readout (IN.LO, IN.HI):
If the valid range of the A/D converter or the polynomial is exceeded
Input Range Readout Limit
VOLT
0...1 V / 0,2...1 V IN.LO < -25 mV
IN.HI > 1,2 V
0...10 V / 2...10 V IN.LO < -25 mV
IN.HI > 12 V
CURR 0...20 mA / 4...20 mA IN.LO < -1,05 mA
IN.HI > 25,05 mA
POTM - IN.LO < -0,5%
IN.HI > 100,5%
TEMP TC / RTD IN.LO < temperature range -2°C
IN.HI > temperature range +2°C
LIN R
0...800 ohm IN.LO < 0 ohm
IN.HI > 1 kohm
0...10 kohm IN.LO < 0 ohm
IN.HI > 15 kohm
Sensor error detection (SE.BR, SE.SH):
Input Range Readout Limit
CURR Loop break (4..20mA) SE.BR <= 3,6 mA; > = 21 mA
TEMP
TC SE.BR > ca. 750 kohm / (1,25 V)
RTD, 2-, 3- & 4-wire
No SE.SH for Cuxx, Pt10, Pt20 & Pt50
SE.BR > 12 kohm
SE.SH < 15 ohm
LIN R 0...800 ohm SE.BR > 875 ohm
0...10 kohm SE.BR > 12 kohm
Display readout below min. / above max. (-1.9.9.9, 9.9.9.9):
Input Range Readout Limit
CURR
VOLT All -1.9.9.9 Display readout <-1999
9.9.9.9 Display readout >9999
LIN R All -1.9.9.9 Display readout <-1999
9.9.9.9 Display readout >9999
POTM - -1.9.9.9 Display readout <-1999
9.9.9.9 Display readout >9999

5714V103-UK 13
Readout at hardware error
Error search Readout Error cause
Test of internal communication uC / ADC HW.ER Permanent error in ADC
Test of internal CJC sensor CJ.ER CJC sensor defect
Check-sum test of the configuration in RAM RA.ER Error in RAM
Check-sum test of the configuration in EEPROM EE.ER Error in EEPROM
! Error indications in the display blink once a second. The help text explains the error.

Tx
31 32
41 42 43 44 45 4641 42 43 44 45 4641 42 43 44 45 46
41 42 43 44 45 46 41 42 43 44 45 46 41 42 43 44 45 46
41 42 43 44 45 46 41 42 43 44 45 46
mA
11 12
R2
R1
21 22 23 24 25 26
- +
- +- + - +
- +
14 5714V103-UK
CONNECTIONS
RTD & Lin R, 2-wire RTD & Lin R, 3-wire RTD & Lin R, 4-wire
PotentiometerVoltage
TC 2-wire transmitter Current
Current Relays
Inputs:
Output:
Supply:

I+
11 12 31 32
CPU
AD
EEPROM
PTC
20 Ω
5714
1 2 3 4
46 45 44 43 42 41
+V
4 3 2
21 22 23 24 25 26
R1 R2
1
3
2
Tx
+
+
+
mA
5714V103-UK 15
BLOCK DIAGRAM
I
Output
Common Relay 1 N.O. Relay 1 N.C. Common Relay 2 N.O. Relay 2 N.C. Supply Supply 21.6...253 VAC
or
19.2...300 VDC
Version D
Int. CJC
2-wire supply
> 15 VDC
Input +,
mA
Input gnd.
RTD & Lin R,
wires
Potm.

Power up
50.0
3
F.SET
REL1
REL2 3
1.0
1.2
1 2 1 2
SETP
-1999
9999
/OFF 3
1 2
DI.LO PERC
DI.HI
1.1
0000
9999
1 2
3
CURR 3RANG
0-20 4-20
1 2
VOLT 3RANG
1 2
0-1 0.2-1
0-10 2-10
IN
1 2
DEC.P
1111
1.1.1.1
1 2
POTM
TEMP TYPE
PASS
3a999
9999
1 2
3a999
9999
1 2
3PERC
DISP
1 2
3
1.3
DEC.P
1111
111.1
1 2
UNIT
'C
'F
1 2
ADV
NO
YES
1 2
3
3
LIN.R 3LR.LO
0-9998
1 2
LR.HI
1-9999
1 2
CONN
1 2
2W 3W 4W
3
3
3
CU.TY CONN
CU 3
1 2 1 2
10-100 2W 3W 4W
3
3
1 2
3
333
3
1.4
1.4
1.6
ADV.SET
YES
PT.TY
TC
CONN
TC.TY
PT 3
1 2 1 2
NI NI.TY CONN
50-1000
1 2
2W 3W 4W
1 2
1 2
3
3
3
TC.B-E-J-K-L-N-R
S-T-U-W3-W5-LR
10-1000 2W 3W 4W
33
3
3
16 5714V103-UK
1.0 = Default state
1.1 = Only if password-
protected
1.2 = Only is FastSet is enabled
1.3 = FastSet and relay test disab-
led at password 5000...9999.
1.4 = No relay outputs
1.5 = Not valid for these input
signals: Potentiometer, 0...20
mA and voltage
1.6 = No analogue output
1.7 = Only if input signal is
temperature
1.8 = In default state press and
hold 1or 2to change
display intensity between
damped and full
(7 = full intensity).
Fast setpoint adjustment
and relay test
1Increase setpoint
2Decrease setpoint
3Save and exit the menu
1and 2simultaneously = change relay state

REL.1
SET
SKIP
OFF
1 2
3
SETP
0.0
100.0
1 2
3
ACT1
INCR
DECR
1 2
3
HYS1
0.0
100.0
1 2
3
ERR1
HOLD
ACTI
DEAC
NONE
1 2
3
ON.DE
0000
3600
1 2
3
OF.DE
0000
3600
1 2
3
3
1.5
REL.2
SET
SKIP
OFF
1 2
3
SETP
0.0
100.0
1 2
3
ACT2
INCR
DECR
1 2
3
HYS2
0.0
100.0
1 2
3
ERR2
HOLD
ACTI
DEAC
NONE
1 2
3
ON.DE
0000
3600
1 2
3
OF.DE
0000
3600
1 2
3
3
1.5
A.OUT
4-20
0-20
20-4
20-0
1 2
3
O.LO
a999
9999
1 2
3
O.HI
a999
9999
1 2
3
O.ERR
0/3.5mA
23mA
NONE
1 2
3
RESP
0.0
60.0
1 2
3
E.PAS
YES
NO
1 2
3
N.PAS
0000
9999
1 2
3
NO
----
1.51.7 1.7
1.6
1.6
DE DK
ES FR
IT SE
UK CZ
1.4
ADV.SET
LANG
DISP
CAL
1.8 7
LIGH
3
1...7
1 2
LANG
DISP
CAL
1 2
3
3UK
HLP.T
1 2
3YES
CA.LO
3
YES NO
1 2
2.0
VAL.L
3
100.0
0.0
1 2
NO
3
YES
CA.HI
3
1 2
90.0
VAL.H
3
100.0
0.0
1 2
NO
YES
USE.C
3
1 2
YES NO YES NO
5714V103-UK 17
ROUTING DIAGRAM
If no keys are activated for 2 minutes the display returns to default state
1.0 without saving configuration changes..
1Increase value / choose next parameter
2Decrease value / choose previous parameter
3Accept the chosen parameter and go to the next menu
Hold 3Back to previous menu / return to menu 1.0 without saving
To default state 1.0

18 5714V103-UK
SCROLLING HELP TEXT
Display in default state xxxx, hardware error:
SE.BR --> SENSOR WIRE BREAKAGE
SE.SH --> SENSOR SHORT CIRCUIT
IN.HI --> INPUT OVERRANGE
IN.LO --> INPUT UNDERRANGE
9.9.9.9 --> DISPLAY OVERRANGE
-1.9.9.9 --> DISPLAY UNDERRANGE
HW.ER --> HARDWARE ERROR
EE.ER --> EEPROM ERROR -
CHECK CONFIGURATION
RA.ER --> RAM MEMORY ERROR
CJ.ER --> CJC SENSOR ERROR
Fastset (Enabled):
F.SET
REL1 --> FAST SET MENU -
REL2 --> SELECT RELAY
SETP
xxxx --> RELAY SETPOINT - PRESS OK TO SAVE
Fastset (Disabled):
SETP
xxxx --> RELAY SETPOINT - READ ONLY
Configuration menus:
ADV
YES --> ENTER ADVANCED SETUP MENU?
NO
PASS
xxxx --> SET CORRECT PASSWORD
IN
C.LIN* --> TEXT ENTERED BY USER IN PRESET
CURR --> CURRENT INPUT
VOLT --> VOLTAGE INPUT
POTM --> POTENTIOMETER INPUT
LIN.R --> LINEAR RESISTANCE INPUT
TEMP --> TEMPERATURE SENSOR INPUT
RANG When current selected:
0-20 --> INPUT RANGE IN mA
4-20 --> INPUT RANGE IN mA
RANG When voltage selected:
0-10 --> INPUT RANGE IN VOLT
2-10 --> INPUT RANGE IN VOLT
0.0-1 --> INPUT RANGE IN VOLT
0.2-1 --> INPUT RANGE IN VOLT
DEC.P
1111 --> DECIMAL POINT POSITION
111.1 --> DECIMAL POINT POSITION
11.11 --> DECIMAL POINT POSITION
1.111 --> DECIMAL POINT POSITION
LR.LO
xxxx --> SET RESISTANCE VALUE LOW
LR.HI
xxxx --> SET RESISTANCE VALUE HIGH
DI.LO
xxxx --> DISPLAY READOUT LOW
DI.HI
xxxx --> DISPLAY READOUT HIGH
REL.U
PERC --> SET RELAY IN PERCENTAGE
DISP --> SET RELAY IN DISPLAY UNITS
TYPE
CU --> SELECT CU SENSOR TYPE
PT --> SELECT PT SENSOR TYPE
NI --> SELECT NI SENSOR TYPE
TC --> SELECT TC SENSOR TYPE
CU.TY
10 --> SELECT CU SENSOR TYPE
20 --> SELECT CU SENSOR TYPE
50 --> SELECT CU SENSOR TYPE
100 --> SELECT CU SENSOR TYPE
PT.TY
10 --> SELECT PT SENSOR TYPE
20 --> SELECT PT SENSOR TYPE
50 --> SELECT PT SENSOR TYPE
100 --> SELECT PT SENSOR TYPE
200 --> SELECT PT SENSOR TYPE
250 --> SELECT PT SENSOR TYPE
300 --> SELECT PT SENSOR TYPE
400 --> SELECT PT SENSOR TYPE
500 --> SELECT PT SENSOR TYPE
1000 --> SELECT PT SENSOR TYPE
NI.TY
50 --> SELECT NI SENSOR TYPE
100 --> SELECT NI SENSOR TYPE
120 --> SELECT NI SENSOR TYPE
1000 --> SELECT NI SENSOR TYPE
CONN When Cu, Pt and Ni sensor is selected
2W --> SELECT 2-WIRE SENSOR CONNECTION
3W --> SELECT 3-WIRE SENSOR CONNECTION
4W --> SELECT 4-WIRE SENSOR CONNECTION
TC.TY
TC. B --> SELECT TC SENSOR TYPE
TC. E --> SELECT TC SENSOR TYPE
TC. J --> SELECT TC SENSOR TYPE
TC. K --> SELECT TC SENSOR TYPE
TC. L --> SELECT TC SENSOR TYPE
TC. N --> SELECT TC SENSOR TYPE
TC. R --> SELECT TC SENSOR TYPE
TC. S --> SELECT TC SENSOR TYPE
TC. T --> SELECT TC SENSOR TYPE
TC. U --> SELECT TC SENSOR TYPE
TC.W3 --> SELECT TC SENSOR TYPE
TC.W5 --> SELECT TC SENSOR TYPE
TC.LR --> SELECT TC SENSOR TYPE
DEC.P When temperature selected
1111 --> DECIMAL POINT POSITION
111.1 --> DECIMAL POINT POSITION
UNIT
°C --> DISPLAY AND RELAY SETUP IN CELSIUS
°F --> DISPLAY AND RELAY SETUP IN
FAHRENHEIT
