R
Model name Peppy Pro - MG247
Specifications Base unit, Wet jar - 1.5L, Dry jar - 1L, Chutney jar - 0.4L, Rapid chop 10 jar
(Chopper jar) - 0.7L, Gear box - 1 unit
Power consumption
Protection
Insulation
Motor
No load speed of motor
Material of jars
Blade assemblies
Speed controls
Flexi cord
Rating
Protection against ingress
of water
Protection against dust and
moisture
Country of origin
Preethi brings to you a new mixer grinder, Peppy Pro
Gross weight
Size of carton (mm)
Guarantee
Warranty
750W
Class I
Class F
Universal
19500 - 20500 RPM
Stainless steel, machine ground polished
Rotary switch with 3 speeds and pulse
PVC flexi cord with plugtop and earthing - 3core pin
Ordinary total rated ON time 30 minutes (max.),
Continuous ON for 5 minutes (max.) and off for 2 minutes (min.)
Rest time 45 minutes.
IPXO
Ordinary
INDIA
6 kg
2 years guarantee on the product
5 years warranty on the motor
Stainless steel,
Plastic (Chopper jar)
503 (L) x 220 (W) x 350 (H)
Instruction manual - MG247
Chop 10 categories of soft ingredients each in less than 25 Secs **
Grind & Chop with ease
** Tested and Validated by NABL accredited external lab for 10 categories of soft ingredients like Fruits, Vegetables, Boneless Meat etc.
Not recommended for hard ingredients like Turmeric, Coconut, nuts, seeds, meat with bone etc.
Efficiency of chopping will vary with respect to quality and quantity of ingredients and processing time.
# Lifelong free service (applicable only on products purchased in India). Charges apply for replacement of spares/accessories. For detailed terms and
conditions please refer the warranty card.
Images are for illustrative purposes only.
Voltage 230V~50Hz
Scan for
exciting recipes Rapid
Chop 10
Jar

1. Base unit with universal motor
2. Switch knob
3. Over load protector
4. Anti-slip rubber feet
5. 1.5 L Wet jar with fixed blade and lid
6. 1.0 L Dry jar with fixed blade and lid
8
9
7. 0.4 L Chutney jar with fixed blade and lid
8. 0.7 L Rapid chop 10 jar (Chopper jar) with lid
9. Removable chopper blade for Rapid chop 10 jar
(Chopper jar)
10. Gear box for Rapid chop 10 jar (Chopper jar)
11. Spatula
Wet jar
Dry jar
Chutney jar
Rapid chop 10 jar (Chopper jar)
Peppy Pro - MG 247
1.5 L
1.0 L
0.4 L
0.7 L
6
Caution:
Do not operate the chopper jar without the lid
Do not operate the chopper jar without closing the lid
Do not touch the blade directly with fingers. Handle with the blade holder while assembly, chopping
and cleaning.
11
10
3.1 Don’ts
Note: Do not hold the chopper blade at the sharp edges. Handle carefully while assembly,
disassembly and cleaning
1. Do not place the appliances on an unstable surface.
2. Do not move the appliances during operation.
3. Do not touch the moving parts when operating the mixer grinder.
4. Do not overload the mixer grinder. When hot air emanates from the openings of the top cap.
Switch off the motor and wait for 3-5 minutes before re-starting.
5. Do not add solid ingredients when the motor is running.
6. Do not operate with a damaged power cord.
7. Do not tamper with or attempt to repair the appliance. Contact your nearest Preethi Customer care.
8. Do not grind hot ingredients in the mixer grinder.
9. Do not lock the jar on the base unit when the Knob is in ‘ON ‘ condition.
10. Do not put your hand inside the mixer grinder/ chopper jar when the appliance is switched ON.
11. Do not run the unit without locking the jars and lid properly.
12. Do not use accessories other than those provided with the products.
13. Do not clean the mixer grinder accessories using a dishwasher. Always rinse under tap water.
14. This appliance should not be used 2000 metres above the sea level.
15. Children should be supervised to ensure that they do not play with the appliance.
16. Children should not be involved in cleaning and user maintenance. Keep the appliance and its
cord out of reach of children.
17. Do not use the appliance when the mains cord, the plug or other components are damaged. Only
the company or service center authorized by Preethi must replace it.
18. Never touch food in the jar by hand. Always use a spatula.
19. Never leave the appliance running unattended.
20. Keep the appliance away from the source of heat like gas or electric stove.
21. Do not run the appliance with the jar empty.
22. Never load the jar with ingredients beyond the maximum level (See "Maximum jar capacity" and
"Standard recipe" tables for more details).
23. Do not use any attachment other than those provided or recommended by the manufacturer.
It may cause hazards.
3.0 Do’s
1. When operating the mixer grinder for the first time after long storage or when the mixer grinder
has been shifted from the long distance, rotate the motor shaft by hand through the motor
coupler, until the motor shaft rotates freely.
2. Unplug the appliance from the main socket before fixing or removing accessories, when cleaning
and when not in use.
3. Ensure that the jar is locked properly in the locking grooves provided inside the top cap.
4. Ensure the blades are fitted properly before running.
5. Ensure proper locking of jar on the power unit and proper locking of lid on the jars to switch on
the appliance. Ensure to hold the lids of the jars firmly while grinding.
6. If the supply cord is damaged, it must be replaced by the manufacturer or authorized service
centre only in order to avoid hazards. On violation, the warranty becomes void.
7. Check if the voltage indicated on the base of the appliance, corresponds to the local electrical
main voltage before connecting the appliance.
8. Always unplug the appliance after use, and ensure the knob remains at 0 (OFF) position when not
in use / power outage.
CHOP
Note : The provided chopper blade has to be used only with the Rapid chop 10 jar (chopper jar)
Not recommended for hard ingredients like coconuts, almonds, nuts as blade may get damaged.
Use only boneless meat for mincing as bone in the meat causes damage to the blade
For chopping use speed 1 and pulse option only.
For coarse grinding of dips preparation use speed 1
Refer recipe book for exciting recipes
Dry Jar
Wet Jar
Chutney Jar
Idli, dosa, uthappam, appam, pesarattu, vadai
Coconut, tomato, onion, coriander, mint chutney
Ensure blade, jar, lid and ingredients are totally dry
Run on speed 1,2,3 as required
If you need finer powder, wait for 1 minute and grind again for 1 to 2 minutes.
For Onion paste grinding , it is highly recommended to use dry jar
Fig1
Base Unit
Gear Box
Chopper jar
Chopper blade
Lid
4.3 Quick guide for usage of Chopper jar
4.2.1 How to assemble chopper jar
1. Lock the gear box to the base unit.
2. Place the Rapid chop 10 jar on the gear box.
3. Lock the Rapid chop 10 jar on gear box by
rotating it in clockwise direction.
4. Now place the Rapid chop 10 blade on the
blade holder inside the jar.
4.2.2 How to use Rapid chop10 jar (chopper jar)
1. Add the ingredients and close the chopper jar
with lid before chopping.
2. For chopping use speed 1or pulse option only.
3. For coarse grinding of dips preparation use speed 1
4. Now your chopped ingredients are ready
5. Remove the Rapid chop 10 jar from the gear box
6. Open the lid and carefully remove the blade
7. Collect the chopped ingredients
8. Clean the jar,lid and blade for reuse
CHOP
Rapid chop 10 jar (Chopper jar)
NA : Not Applicable
Minimum quantities of all jars should be at least up to the blade level.
7.0 Overload protection (OLP)
Preethi mixer grinder is fitted with an automatic power shut off
mechanism to avoid motor burning due to overloading. If mixer
grinder stops due to overloading, OLP reset button at the
bottom will come out. Switch off the mixer grinder. Remove
excess load from the jar. Wait for 3-5 mins. Press OLP reset
button at the bottom of the base unit and start mixer grinder
again.
5.0 Cleaning and maintenance
Cleaning the mixer grinder body and top cap
• Remove mains plug from wall socket
• Clean body and top cap with a damp cloth and wipe dry
• Do not use abrasives or water for cleaning
Cleaning the stainless steel jars and blades
• Empty the contents from the jar and fill in 0.5 liter of water and a teaspoon of any mild cleaning powder.
• Run the mixer grinder on speed 1 for 30 seconds, leaving the blade fixed to the spindle of the stainless steel jar.
• Rinse and dry.
• Always store the jars in inverted position to allow water to drain off.
Cleaning the rapid chop 10 jar and blade
1.Ensure the rapid chop 10 jar is disassembled from gear box before cleaning
2.Ensure to remove the blade from the jar before cleaning
3.Ensure the fingers are not in contact with the sharp ends of blade while cleaning especially after mincing
meat as fat from the meat gets deposited around the blade
4. Rinse and dry
5. Store in inverted position to allow water to drain offf
Important instruction:
• Do not immerse the base unit in water for cleaning
• Do not immerse gear box in water for cleaning
• Sharp blades ,handle carefully while assembly, grinding and cleaning
• Do not operate the chopper jar without closing the lid
1.5 L 0.7 L NA
1.0 L NA 0.4 L
Wet jar
Dry jar
Chutney jar 0.4 L NA 0.17 L
0.7 L 0.15 L 0.15 L
8.0 Standard recipes
0.4L
This appliance is not suitable for whisking egg whites
Chopper jar not recommended for hard ingredients like turmeric ,coconut,nuts,seeds, meat with
bone etc
0.7L
2:30 min
2:30 min
1:30 min
2:15 min
2:00 min
2:00 min
1:30 min
1:30 min
NA
NA
15-20 secs
4-6 secs
Speed 1
Speed 1
2-3 Pulse
2-3 Pulse
P, 1,2 3
P, 1,2 3
P, 1,2 3
P, 1,2 3
P, 1,2 3
P, 1,2 3
P, 1,2 3
P, 1,2 3
Onion
Cabbage
Chicken/Mutton
mincing
Fine chopping
of carrot and
beetroot
150g
100g
150g
150g
