Preethi ECO Twin User manual

I M & W Cnstruction anual arranty ard
2
2
4
4

TECHNICAL SPECIFICATIONS
In pursuance of our policy of continuous product improvement,
specifications are subject to change without notice.
Model & No. : Eco Twin - MG 146
Voltage : 110 V AC 60 Hz.
Power Consumption : 550 Watts
Insulation : Class F
Protection : Class I
Rating : 30 Minutes
Motor : Universal 550 Watts High Power Motor.
No load speed 18,000 RPM (approx.)
With load speed 10,500 RPM (approx.)
Material of Body : A.B.S.
Material of Jars : Stainless Steel
Material of Dome : Polycarbonate
Blade Assemblies : Stainless Steel, Machine Ground and Polished.
Speed Controls : Rotary Switch with 3 Speed and Incher.
Flex Cord : PVC approx. 2 metres length with 10 Amps 3-pin Plug.
Country of Origin : India
Gross Weight : 4.0 kgs (approx.)
Size of Carton : 33 cm (L) x 22 cm (W) x 31 cm (H)
Standard : Conforms to IS-4250
Warranty : 1 Year
Maya Appliances (P) Ltd.
ESTABLISHED IN 1978
70 CUSTOMER CARE CENTRES
360 AUTHORISED SERVICE CENTRES
OVER 4500 DEALERS
7 MILLION CUSTOMERS
EXPORTS TO USA, CANADA,
MIDDLE EAST, FAR EAST
AND SRI LANKA.
2
JAR CAPACITIES
Minium Capacity for all the above - At least up to Blade level
Big Jar with FlexiLid
CG Jar with FlexiLid

Stirrer
Handle
Housing
S.S. Jar
Hold Jar Coupler and fix
required Blade onto
S p i n d l e b y g e n t l y
screwing down in an anti-
clockwise direction with
the Spanner provided on
the Stirrer, until it is firm.
DO NOT OVER TIGHT.
3
FlexiLid
Dome Lid
FlexiLid Gasket
1.50 Litres Jar
Basic unit
Chutney Jar
FlexiLid
Dome Gasket
Turn Rotary Switch clockwise for Speed 1, 2 or 3 as desired.
Inching - Turn Rotary Switch anti-clockwise for a few seconds and release for momentary operation.
(This is especially useful for wet grinding of chutneys, mincing meat,
grating vegetables, crushing ice, etc.)

Do’s
1. When operating the Mixie for the first
time or after long storage or when the
Mixie has been shifted over a long
distance, rotate the Motor Shaft by
hand through the Motor Coupler, until
the Motor Shaft rotates freely.
2. Unplug from power source before
fixing, removing attachments and also
while cleaning or when not in use.
3. Ensure that the locks of the
Stainless Steel Jar are properly
seated in the grooves provided
inside the Top Cap.
Don’ts
1. Do not touch moving parts, while
operating Mixie.
2. Do not overload Mixie. When hot air
emanates from the openings on the
Top Cap, switch off the Motor and wait
for 3 minutes, before re-starting.
3. Do not add solid ingredients, when the
Motor is running.
4. Do not operate with damaged Power
Cord.
5. Do not tamper or attempt to repair
“Preethi” Mixie.
6. Do not grind hot ingredients in the
Mixie.
ROASTED CEREALS, RAW RICE, DAL, CHILLI COCONUT, TOMATO, ONION,
POWDER, GARAM MASALA, MOLAGAI PODI, CORIANDER, MINT CHUTNEY...
DHANIYA JEERA POWDER,
CURRY LEAF POWDER, COFFEE POWDER, 1. Inch 5 to 7 times to powder ingredients.
SAMBAR / RASAM POWDER.... 2. Then add water as required.
3. Grind on Speed 2.
1. Ensure Blade, Jar, Dome and ingredients
are totally dry.
2. Run on Speed 2.
3. If you need finer powder, wait for 1 minute
and grind again for 1 to 2 minutes.
IDLI, DOSA, UTHAPPAM, APPAM,
PESARATTU, VADAI...
1. Soak Rice/Dal for 4 to 5 hours as required.
2. Drain water from ingredients.
3. Run on Speed 2 adding water gradually
through Dome Lid.
4. If Material sticks to the sides of the Jar,
stop and stir using Stirrer, run again.
5. Ensure free circulation by adding enough water.
6. Do not allow batter to get heated up.
7. Do not add too much water, where thick
paste is required.
8. Grind twice if quantity is more.
Note: While wet grinding tough batter, air bubbles may
enter the paste. This will result in the blade rotating
freely and an increase in noise. If so, stop, stir the
paste and restart.
GRINDING INSTRUCTIONS
FUNCTIONS
1.50 LITRES JAR
Dry & Wet Grind and Liquidise.
CHUTNEY JAR
Dry & Wet Grind
small quantities
In the event your Mixie needs
further attention, take it to one
of our Customer Care Centres.
4
Add the required quantity of the ingredient
into the Jar.
Place the FlexiLid onto the Jar, and press
till it seats firmly on the Jar (Refer figure).
Start grinding. Hold the FlexiLid firmly while
grinding.
NOTE : Ensure that the gasket is fitted properly to
the FlexiLid.
Converts your 1.50 Litre
Jar to 1.0 Litre Jar
2
2
4
4
PREETHI is provided with a 10 Amps 3-pin Plug and a 2 Metres Cord. Plug the Power Cord to a 110 V AC supply only.
“This appliance is not intended for use by persons (including children) with reduced physical,
sensory or mental capabilities, or lack of experience and knowledge, unless they have been given
supervision or instruction concerning use of the appliance by a person responsible for their safety. ”
Note:
Converts your 0.5 Litre
Jar to 0.3 Litre Jar

TERMS & CONDITIONS OF WARRANTY AND SERVICE POLICY
01. Retain the original sale bill and the Card, which should be shown to our
Service Personnel for Scrutiny while sending your Mixie for service to ourAuthorised
Service Centre.
02. The One Year Warranty does not cover damage to the Mixie due to mishandling,
negligence, breakage or cracking of Polycarbonate Jars, Domes, Lids, Mixie Body and
Cap and denting of Stainless Steel Jar.
03. All repairs within the One Year period (arising from manufacturing defects) will
be done ‘Free of Charge’. Our Customer Care Centres will not charge you for
components or labour.
04. Free service and replacement under does not affect the expiry date of
the .
05. For repairs after the expiry of the Warranty period our Customer Care Centre will levy a
nominal charge on components replaced.
06. The is valid only in the country of purchase.
07. Defective components which are exchanged both under ‘Chargeable’ & ‘Free
of Charge’ basis, become the property of the Company.
09. If the supply cord is damaged, it must be replaced by the manufacturer, its
service agent or similarly qualified persons in order to avoid a hazard.
Warranty
Warranty
Warranty
Warranty
Warranty
08. If the Mixie is tampered with or opened by any unauthorised person, other
than personnel of Customer Care Centres (mentioned in page no.) the
Warranty is void.
10. Warranty is void if the Mixie is used for any purpose other than domestic use.
Date Sold: ............................................. SI. No.: ..................................................
Purchaser’s Name & Address: ............................................................................
.................................................................................................................................
..................................................................................................................................
Dealer’s Name & Address: ...................................................................................
.................................................................................................................................
..................................................................................................................................
Signature: Stamp:
Warranty Card Tel. No.: 91-44-2432 8822 (Chennai).
MG-146 MG-146
MG-146

SERVICE RECORD
DATE
To be retained by customer
COMPLAINTS & REMARKS
VERY IMPORTANT:
THE ONE YEAR WARRANTY
IS VALID ONLY IN THE
COUNTRY OF PURCHASE.
India.

Maya Appliances (P) Ltd.
H.O.: 2, Boat Club I Avenue, CHENNAI 600 028. INDIA. Tel: [phone]. Fax: [phone].
email: [email protected] Website: www.preethi.biz
7
UAE:
ELEMENT MIDDLE EAST LLC,
P.O. Box 6218, Dubai.
Tel: [phone].
Fax: [phone].
email: [email protected]
USA:
PERFECT PENINSULA INC.
1041, Sweet Grass Trail, Flower Mound, TX 75028.
Tel: [phone]. Fax: [phone].
KUWAIT
FIVE STAR EST.
Salhiya Fahed Al-Salem Street,
Al-Salamah Tower- Mezzanine Floor
Shop No. 10, 11, 13, 14,
PO Box : 4734 Safat Code No. - 13048. Kuwait.
Tel : [phone]
Fax: [phone].
email: [email protected]
[email protected]
BAHRAIN:
F.F. WATCH CO. WLL,
P.O. Box 164,
Manama, Kingdom Of Bahrain.
Tel: [phone], 215 937.
Fax: [phone].
email: [email protected]
QATAR
GOLDEN HOUSE
Blue Salon Building,
Suhaim Bin Hamad Street,
P.O. Box 3750, Doha, Qatar.
Tel: [phone].
Fax: [phone].
INDONESIA:
PT ANEKA DIMARCO,
Komplek Grenvil, Blok AS-38,
Kelurahan Duri Kepa, Jakarta 11510.
Tel: [phone].
Fax: [phone].
email: [email protected]
SRI LANKA:
ESWARAN BROTHERS MARKETING PVT. LTD.
Head Office:
267, Sea Street, Colombo 11.
Tel: [phone], 432599.
email: [email protected]
Branches:
536, R.A. De Mel Mawatha, Colombo 03.
Tel: [phone], 587240.
104/11, Grandpass Road, Colombo 14.
Tel: [phone], 796796.
OVERSEAS SERVICE CENTRES

Maya Appliances (P) Ltd.
3/140, I.T. Highway, Oggiam Thoraipakkam, CHENNAI 600 097. INDIA.
Tel: [phone]. Fax: [phone].
email: [email protected] Website: www.preethi.biz
MADE IN INDIA
