INSTALLATION INSTRUCTIONS
Rotary Tilt Mount
Model: RTM-S
NORTH AMERICA
3130 East Miraloma Avenue
Anaheim, CA 92806 USA
USA and Canada –
Phone: [phone]
Fax: [phone]
EUROPE
Swallow House,
Shilton Industrial Estate,
Shilton, Coventry, England CV79JY
Phone: [phone]
Fax: [phone]
AUSTRALIA, NEW ZEALAND, OCEANIA
(DISTRIBUTOR)
P.O. Box 295
Mordialloc Victoria 3195
Australia
Phone: [phone]
www.premiermounts.com.au
Other Locations – Phone: [phone]; Fax: [phone]
©Premier Mounts 2008
9531-009-021-03

Page 2 Installation Instructions
Table of Contents
Warning Statements
RTM-S
PRIOR TO THE INSTALLATION OF THIS PRODUCT, THE INSTALLATION INSTRUCTIONS SHOULD BE READ AND
COMPLETELY UNDERSTOOD. THE INSTALLATION INSTRUCTIONS MUST BE READ TO PREVENT PERSONAL
INJURY AND PROPERTY DAMAGE. KEEP THESE INSTALLATION INSTRUCTIONS IN AN EASILY ACCESSIBLE
LOCATION FOR FUTURE REFERENCE.
PREMIER MOUNTS DOES NOT WARRANT AGAINST DAMAGE CAUSED BY THE USE OF ANY PREMIER MOUNTS
PRODUCT FOR PURPOSES OTHER THAN THOSE FOR WHICH IT WAS DESIGNED OR DAMAGE CAUSED BY
UNAUTHORIZED ATTACHMENTS OR MODIFICATIONS, AND IS NOT RESPONSIBLE FOR ANY DAMAGES, CLAIMS,
DEMANDS, SUITS, ACTIONS OR CAUSES OF ACTION OF WHATEVER KIND RESULTING FROM, ARISING OUT OF OR
IN ANY MANNER RELATING TO ANY SUCH USE, ATTACHMENTS OR MODIFICATIONS.
THE SURFACE MUST BE CAPABLE OF SUPPORTING AT LEAST FIVE TIMES THE WEIGHT OF THE DISPLAY. IF NOT,
THE SURFACE STRUCTURE MUST BE REINFORCED. THE MAXIMUM WEIGHT THAT CAN BE USED WITH THIS
PRODUCT IS 160LBS. PROPER INSTALLATION PROCEDURE BY A QUALIFIED SERVICE TECHNICIAN, AS OUTLINED
IN THE INSTALLATION INSTRUCTIONS, MUST BE ADHERED TO. FAILURE TO DO SO COULD RESULT IN SERIOUS
PERSONAL INJURY, OR EVEN DEATH.
SAFETY MEASURES MUST BE PRACTICED AT ALL TIMES DURING THE ASSEMBLY OF THIS PRODUCT. USE
PROPER SAFETY GEAR AND TOOLS FOR THE ASSEMBLY PROCEDURE TO PREVENT PERSONAL INJURY.
At least two qualified people should perform the assembly procedure. Injury and/or damage can result from dropping or mishandling
the display.
If mounting to studs, make sure that the mounting screws are anchored into the center of the studs. Use of an edge-to-edge stud finder
is recommended.
Be aware of the mounting environment. If drilling and/or cutting into the mounting surface, always make sure that there are no elec-
trical wires in wall. Cutting/drilling into an electrical line may cause serious injury.
Make sure there are no water lines inside the wall where the mount is to be located. Cutting/drilling into a water line may cause
severe water damage to the mounting surface.
This product is intended for indoor use only. Use of this product outdoors could lead to product failure and personal injury.
Do not install near sources of high heat. Do not install on a structure that is prone to vibration, movement or chance of impact
Contact Premier Mounts with any questions
[phone]
[email protected]
Warning Statements 2
Parts List 3
Installation Tools 3
Thread Depth Indicator 6
Mount Installation 7
Universal Mounting Bracket Assembly 8
Display Orientation 10
Optional Configurations 11
Technical Specifications 11
Warranty 12

Installation Instructions Page 3
Parts List
This wall mount is shipped with all proper installation hardware and components. Make sure that none of these parts
are missing and/or damaged before beginning installation. If there are parts missing and/or damaged, please stop the
installation and contact Premier Mounts (800-368-9700).
Installation Tools
Phillips Head Screw Driver Soft Material/ Blanket Pencil
Tape Measure Thread Depth Indicator (Supplied) Level (Supplied)
5/32” Allen Wrench (Supplied)
Griplate™ (Qty 8)
Universal Mounting Brackets (Qty 2) Rotary Tilt Mount (Qty 1)
M6 Knurl Knob (Qty 1) Hand Crank (Qty 1)
RTM-S

Page 4 Installation Instructions
RTM-S

Installation Instructions Page 5
The nylon spacers may be stacked to achieve proper spacing.
RTM-S

Page 6 Installation Instructions
Thread Depth Indicator
1. Insert the thread depth indicator (supplied) through the thread inserts found on the back of the flat panel to make sure the inserts
measure the same full depth and mark it (Figure 1).
2. Locate the correct diameter screw for the thread insert. Compare your marking to the screws (supplied).
3. If your selected screw is longer than the marking on the thread depth indicator, DO NOT USE this screw.
4. The screw length must not bypass the marking. Select another screw size (Figure 2 and 3), until you find one that comes closest to
your mark without going past.
Thread Depth
Indicator
Marking
Screw
Marking
Screw
Thread Depth
Indicator
Inverted Flat
Panel Display
Marking the
Depth
Thread Insert
Thread Depth
Indicator
RTM-S

Installation Instructions Page 7
Mount Installation
The installation instructions that are contained in this manual refer only to the RTM-S. The installation instructions for
the various bases that are used with the RTM-S will be included with those products.
RTM-S
Prior to installing the RTM-S, the mounting configuration must already be assembled (base, support poles, etc.).
Step 1. Slide the mounting block over and
down the support poles.
Mounting
Block
Cradle
Support
Poles
Step 2.To secure the mounting block to the support
poles, tighten the four set screws (located on
each side of the mounting block), using the 5/32”
Allen wrench (supplied).
Set Screws

Page 8 Installation Instructions
RTM-S
For the two upper mounting points, the Griplate™ flat side must be facing up. For the two lower mounting points, the
Griplate™ flat side must be facing down.
IT WILL TAKE TWO PEOPLE TO COMPLETE THE NEXT INSTALLATION STEP.
Step 5. At this time, center the universal bracket bar and tighten the set screws that are located on the universal brackets.
Universal Mounting Bracket Assembly
Step 1. Place the universal bracket bar and the universal brackets on a flat surface.
Step 2. Slide the universal brackets onto the universal bracket bar (as shown below) with the set screws facing up. At this time, do
not tighten the set screws that are located on the universal bracket.
M4
M8
M6
M5
THE CONGFIGURATION THAT THE UNIVERSAL MOUNTING BRACKETS ARE IN ABOVE MUST RE-
MAIN THE SAME. ANY DEVIATION FROM THE LAYOUT ABOVE COULD AFFECT THE OPERATION
OF THE MOUNT.
Griplate™ Universal Bracket Bar Griplate™
Set Screw
Universal Mounting Brackets
Step 3. Place the display on a soft, flat surface, face-down. Next, place the universal bracket assembly on the back of the display,
with the universal brackets resting directly over the display mounting points.
Step 4. Once the desired position has been determined, place the Griplate™ washers over each mounting point and secure them using
the appropriate hardware (see Page 4 and 5).
If you havean un-even mounting surface, or a recessed mounting point, place the appropriately sized nylon washer
between the display and the universal mounting brackets (page 5).

Installation Instructions Page 9
RTM-S
Step 6. Lower the universal bracket bar and display into the cradle (as shown
to the left).
The circular portion of the universal bracket bar must rest inside
the nylon sleeve. If seated improperly, the operation of the RTM-S
will be hindered and the nylon sleeve will become damaged.
Nylon
Sleeve
Step 7. Insert an M6 knurl knob into the knurl knob mounting point and
tighten.
Step 8. OPTIONAL - Insert a M6 x 12mm security screw and M6 lock washer
into the mounting point and tighten using the M5 Allen wrench
(supplied).
Knurl Knob Mounting Points (a knurl knob may be placed in either mounting
hole).
M6 x 12mm Security Head and M6 Lock Washer Mounting Points (a security
screw may be placed in either mounting hole).
Step 9. OPTIONAL - Tighten the two (2) Phillips head screws (located on the
side of the mounting block) to prevent the mount from rotating.

Display Orientation
The RTM-S will allow the user to adjust the display a full 360°.
Page 10 Installation Instructions
RTM-S
BEFORE ROTATING THE RTM-S, MAKE SURE THAT THE M6 KNURL KNOB IS
SECURELY FASTENED TO THE RTM-S. ALSO, PLEASE MAKE SURE YOU ALLOW
ENOUGH CABLE AND WIRE CLEARANCE FOR FULL ROTATION.
Step 1. To adjust the RTM-S, rotate
the display either clockwise
or counter-clockwise.
Step 2. Tighten the two Phillips
head locking screws (see
Step 5, Page 10).
Tilt Positioning
M6 Knurl Knob
Step 1. Once the position has been locked down, use an Allen wrench to take off the crank handle.
Step 2. Once the crank handle has been removed, re-attach the crank handle, facing the opposite direction. This is the storage
position for the handle.
The RTM-S has the ability to tilt 10°
down. The RTM-S has the ability to tilt
35° up.
Rotate the crank handle to tilt the
RTM-S:
Down - Clockwise
Up - Counter-Clockwise
Crank Handle Storage Position

Installation Instructions Page 11
RTM-S
Technical Specifications
All measurements are in inches (mm).
Optional Configurations
PSD-TS PSD-BW PSD-EB

Page 12 Installation Instructions
RTM-S
