Premier Mounts CTM-MS3-1 User manual

INSTALLATION MANUAL
CTM-MS3-1
Premier Mounts
3130 E. Miraloma Avenue
Anaheim, CA 92806
Phone: [phone] Fax: [phone]
[email protected] www.mounts.com
Rev. 01

PBL-110 Projector Mount
Page 2 Installation Manual

CTM-MS3-1
Table of Contents
Warning Statements ............................................................................................................................................... 4
Parts List ................................................................................................................................................................ 5
Installation Tools ................................................................................................................................................... 5
Mounting Bracket Installation ............................................................................................................................... 9
CTM-MS3-1 Installation ..................................................................................................................................... 12
Installing the Flat Panel Display (CTM-MS3-1) ................................................................................................. 14
Technical Specifications ...................................................................................................................................... 17
Warranty .............................................................................................................................................................. 18
Contact Premier Mounts ...................................................................................................................................... 18
Notes .................................................................................................................................................................... 19
Installation Manual Page 3

CTM-MS3-1
Warning Statements
WARNING: THE WALL STRUCTURE MUST BE CAPABLE OF SUPPORTING 210 LBS. IF NOT, THE WALL
STRUCTURE MUST BE REINFORCED. PROPER INSTALLATION PROCEDURE BY A QUALIFIED
SERVICE TECHNICIAN, AS OUTLINED IN THE INSTALLATION INSTRUCTIONS, MUST BE
ADHERED TO. FAILURE TO DO SO COULD RESULT IN SERIOUS PERSONAL INJURY, OR EVEN
DEATH.
WARNING: SAFETY MEASURES MUST BE PRACTICED AT ALL TIMES DURING THE INSTALLATION OF
THIS PRODUCT. USE PROPER SAFETY GEAR AND TOOLS FOR THE INSTALLATION
PROCEDURE TO PREVENT PERSONAL INJURY.
WARNING: PRIOR TO THE INSTALLATION OF THIS PRODUCT, THE INSTALLATION INSTRUCTIONS
SHOULD BE READ AND COMPLETELY UNDERSTOOD. THE INSTALLATION INSTRUCTIONS
MUST BE READ TO PREVENT PERSONAL INJURY AND PROPERTY DAMAGE. KEEP THESE
INSTALLATION INSTRUCTIONS IN AN EASILY ACCESSIBLE LOCATION FOR FUTURE
REFERENCE.
Indicates that the power plug is to be
disconnected from the power outlet.
Contact Premier Mounts with any
questions.
Safety precautions must be taken at all
times.
Warning and Caution statements.
Do not install on a structure that is prone to vibration, movement or chance of impact. Failure to
do so could result in damage to the flat panel display and/or damage to the mounting surface.
Do not install near heater, fireplace, direct sunlight, air conditioning or any other source of direct
heat energy. Failure to do so may result in damage to the flat panel display and could increase the
risk of fire.
At least two qualified people should perform the installation procedure. Injury and/or damage can
result from dropping or mishandling the flat panel display.
Page 4 Installation Manual

CTM-MS3-1
Parts List
NOTE: This wall mount is shipped with all proper installation hardware and components. Make sure that
none of these parts are missing and/or damaged before beginning installation. If there are parts
missing and/or damaged, please stop the installation and contact Premier Mounts
(800-368-9700).
CTM-MS3-1
Wall Plate (1ea)
30” Mounting
Brackets (1pr)
5/16” Flat
Washers (9ea)
5/16” x 3” Lag
Bolts (wooden
studs only) –
(9ea)
M6 x 30mm
Lateral Shift
Locking Screws
(2ea)
Griplates™ (8ea)
M6 x 12mm
Safety Knobs
(2ea)
Thread Depth
Indicator
Installation Tools
Phillips Head Screw Driver Soft Material/ Blanket 5/16” Socket and Wrench
Pencil Tape Measure Drill Gun
Level
Installation Manual Page 5

CTM-MS3-1
Page 6 Installation Manual
M5 x 25 (Qty 8) M8 x 20 (Qty 8)
M5 x 30
(Qty 8) M8 x 25
(Qty 8)
M6 x 20 (Qty 8) M8 x 30 (Qty 8)
M6 x 25
(Qty 8) M8 x 35 (Qty 8)
M6 x 30
(Qty 10) M8 x 70 (Qty 8)
M6 x 35 (Qty 8)

CTM-MS3-1
Nylon spacers and flat washers actual size
NOTE: The nylon spacers may be staked to achieve proper spacing.
¼” Nylon
Sleeves (Large,
Qty 8)
9/16” Nylon
Spacers (Qty 8)
½” Nylon
Sleeves (Large,
Qty 8)
Nylon Sleeves
(Qty 8)
5/16” Flat
Washers (Metal,
Qty 8)
1” Nylon Sleeves
(Qty 8)
¼” Nylon
Sleeves (Small,
Qty 8)
Installation Manual Page 7

CTM-MS3-1
Thread Depth Indicator
1. Insert the thread depth indicator (supplied) through the thread inserts found on the back of the flat
panel to make sure the inserts measure the same full depth and mark it (Figure 1).
2. Locate the correct diameter screw for the thread insert. Compare your marking to the screws (supplied).
3. If your selected screw is longer than the marking on the thread depth indicator, DO NOT USE this screw.
4. The screw length must not bypass the marking. Select another screw size (Figure 2 and 3), until you
find one that comes closest to your mark without going past.
Figure 1
Figure 2 Figure 3
Thread depth
indicator
Thread insert
M
arking the depth
Inverted flat panel
display
Screw Thread depth
indicator
M
arking
Screw Thread depth
indicator
M
arking
Page 8 Installation Manual

CTM-MS3-1
Mounting Bracket Installation
NOTE: Proper installation procedure by qualified personnel as outlined in the installation instructions must
be adhered to. Failure to do so could result in serious personal injury and possible damage to the
flat panel.
WARNING: INVERT THE FLAT PANEL PLACE IT ON A SOFT, FLAT SUFRACE TO PREVENT DAMAGE TO
THE FLAT PANEL. USE A BLANKET, FOAM, ETC. FAILURE TO DO SO WILL RESULT IN
DAMAGING THE FLAT PANEL. DO NOT LAY THE FLAT PANEL ON THE FLOOR WITHOUT ANY
PROTECTION TO THE GLASS. THE FLAT PANEL IS HEAVY AND FRAGILE. AT LEAST (2)
QUALIFIED PERSONNEL ARE STRONGLY RECOMMENDED FOR INSTALLATION OF THIS
PRODUCT. FAILURE TO DO SO COULD RESULT IN SERIOUS INJURY AND POSSIBLE DAMAGE
TO THE FLAT PANEL.
1. Once the flat panel is inverted, use a measuring tape to find the center of your flat panel, measuring
from outside to outside of the chassis (Figure 4).
2. Using a pencil lightly mark the center of your flat panel (Figure 5).
Figure 4 Figure 5
C
LL
C
Top of flat panel
Measuring tape
Inverted flat panel
Inverted flat panel
Mark the center
of the flat
p
anel
Bottom of flat panel
Installation Manual Page 9

CTM-MS3-1
3. Install the nylon spacers (if needed) to the mounting points on the flat panel (Figure 6).
4. Lay the left and right mounting brackets (stamped arrows facing out) - (Figure 7).
Figure 6 Figure 7
Nylon Spacers, If Applicable
Inverted Flat Panel
Mounting Brackets
Bottom of Flat Panel
Arrows Facing Out
Center Mark
5. Match the center of viewing guide with the centerline you marked in Step 1 (Figure 8).
6. The mounting brackets are designed with a center of viewing guide on the outside (Figure 9).
Page 10 Installation Manual

CTM-MS3-1
Figure 8 Figure 9
L
C
7. The Griplates™ have M4, M5 M6 and M8 hole patterns to fit the hardware that your flat panel requires.
EXAMPLE: If your plasma uses M8 x 20 Phillip screws. Use the M8 mounting points (Figure 10).
8. Once the mounting brackets are aligned secure the Griplate™ to the flat panel. Use (1) Griplate™ per
mounting point (Figure 11).
NOTE: The dimples of the top plates have to be facing up and the bottom dimples must be facing down.
Figure 10 Figure 11
DIMPLES
FACING UP
DIMPLES
FACING DOWN
DIMPLES
FACING UP
DIMPLES
FACING DOWN
B
ottom of the
F
lat Panel
Align the Mounting
B
rackets
B
ottom of Flat
P
anel
Center of
V
iewin
g
Guide
Center of Flat
P
anel
B
ottom of Flat
P
anel
Dimples Facing
Up
M
4
M
5
M
8
M
6
Screw Driver
M
ounting Bracket
Installation Manual Page 11

CTM-MS3-1
CTM-MS3-1 Installation
1. Using a (commercially available) wood stud finder, locate the 16" or 24" stud centers behind the wall
(Figure 12).
2. Once found, make a pencil marking on the center of the wood studs (Figure 13).
NOTE: The wall plates have 16" and 24" mounting slot positions.
3. Place the wall plate to the reference line and mark the nine (9) lag bolt mounting points through the
wall plate slots on the wall.
CENTEROFVIEWINGHEIGHTDESIRED
Figure 12 Figure 13
M
ark the wall
and the center
of the wood
studs.
W
ood Stud Finder
(Commerciall
y
available)
M
easure and
mark the
v
iewing height
desired on the
w
all.
W
ood studs
behind the
w
all
structure.
Page 12 Installation Manual

CTM-MS3-1
6. Level the wall plate with the reference arrow pointing up to the ceiling (Figure 13).
7. Drill nine (9) ¼" pilot holes to the marked wall.
8. Secure the plate using the nine (9) 5/16" lag bolts and flat washers (Figure 14).
Figure 14. Wood Installation
Mark the nine (9) mounting
slot o
p
enin
g
s
W
all Plate
Installation Manual Page 13

CTM-MS3-1
Installing the Flat Panel Display (CTM-MS3-1)
WARNING: AT LEAST (2) QUALIFIED PERSONNEL ARE STRONGLY RECOMMENDED FOR INSTALLATION
OF THIS PRODUCT. FAILURE TO DO SO COULD RESULT IN SERIOUS INJURY AND POSSIBLE
DAMAGE TO THE FLAT PANEL.
1. Raise the flat panel with the LEFT and RIGHT mounting brackets secured to the flat panel and insert
the top hooks over the upper rod. The lower hooks should rest on the lower rod (Figure 15).
Figure 15
W
all Plate
Top
B
ottom
Page 14 Installation Manual

CTM-MS3-1
2. Make any lateral shift adjustment and lock it by tightening the two (2) M6 x 30mm Phillips screws
found on the bottom of the mounting brackets. Use the foot leveler to adjust your plasma.
CAUTION: Do not over tighten the M6 x 30mm screws to the rods (Figure 16).
NOTE: To remove the display from the wall simply back off the M6 x 30mm screws using a Phillips
screwdriver and lift the unit of the wall carefully.
Figure 16
L
ateral Shift
W
all Plate
Installation Manual Page 15

CTM-MS3-1
3. Tilt the flat panel and secure the two (2) M6 x 12mm safety knobs to each of the mounting brackets
(Figure 17).
NOTE: To remove the display from the wall simply extend the display to its maximum tilt range, remove
the two 6 (mm) safety knurl knobs push the flat panel back to it’s flat position, loosen or remove
the two (2) M6 x 30 lateral shift screws and lift the unit of the wall.
Figure 17
Page16 Installation Manual Page

CTM-MS3-1
Technical Specifications
Figure 18
Installation Manual Page 17

CTM-MS3-1
Warranty
Limited Lifetime Warranty
All Premier Mounts products carry a limited lifetime warranty from ship date against defects in materials and
workmanship. Premier Mounts is not liable for improper installation that results in damage to mounts,
adapters, display equipment or personal injury.
Contact Premier Mounts
In the event of missing and/or damage equipment, or technical questions, the following information can help
in the completion of the installation.
Customer Service – [phone]
Technical Support – [email protected]
Page 18 Installation Manual

CTM-MS3-1
Notes
