Prestige medical DT-7 User manual

INTENDED USE
A digital thermometer is a device used to measure the body temperature of a patient by means
of a transducer coupled with an electric signal amplication, conditioning, and display unit.
SAFETY INFORMATION
WARNING: High, prolonged fever requires medical attention especially for young children.
Please contact your physician.
WARNING: Do not allow children to take their temperatures unattended.
WARNING: Read the enclosed instructions carefully to ensure accurate temperature readings.
Temperature readings are aected by many factors including exercise, drinking
hot or cold beverages prior to taking a reading as well as technique.
WARNING: Do not allow children to walk or run during temperature taking. The rigid probe
could present a hazard. Oral, underarm (axillary), and rectal temperatures may
vary by approximately +/- 1°F (0.5°C).
WARNING: Ensure that children do not use this device unsupervised; some parts are small
enough to be swallowed.
WARNING: Keep battery out of children’s reach. Swallowing battery could be harmful.
Battery should not be recharged or exposed to extreme heat as it may explode.
CAUTION: Do not take an underarm (axillary) temperature through patient’s clothing.
Direct probe cover to skin contact is required.
CAUTION: Biting the probe tip while temperature taking may result in damage to the probe.
CAUTION: Do not autoclave. Please note cleaning procedures described in this manual.
CAUTION: Dispose of batteries in accordance with locally applicable regulations. Do
not dispose with with domestic waste.
OVERVIEW
To the right is a
diagram of the
thermometer and
its important
features.
HOW TO TAKE TEMPERATURE
1. Place a probe cover carefully over the tip
(see illustration, right). (This is optional)
2. Select oral, underarm or rectal as your
measurement site based on the individual
requiring a temperature measurement.
3. Push the Multi-Function button. The display will read °F or °C (right).
This is a function check indicating the unit is working properly.
The last measured temperature will be displayed for approximately
2 seconds. Next the thermometer will read L°F (or L°C).
4. The °F or °C symbol will ash when the unit is ready to measure temperature.
Note that the symbol (right) indicates a low battery. Do not expect an
accurate temperature reading if this low battery indicator is present. An
“ERR” message in the window indicates your unit is not functioning properly.
5. Depending on the measurement site, the unit will complete measurement in 40
(rectal), 60 (oral), or approximately 90 (axillary) seconds. When the F° or C° symbol
stops ashing and the display reads a consistent temperature, the peak tempera-
ture has been reached.
6. Read and record the temperature and time for reference. The reading will auto-
matically be stored in the memory.
7. Push the Multi-Function button to turn the unit o. This will prolong the battery
life. If you do not turn the unit o, it will shut o automatically in approximately
10 minutes.
ORAL USE (for children 4 years or older)
1. Do not drink hot or cold uids, exercise or perform other activities that will raise or
lower temperature readings when compared to your normal, average temperature.
The mouth should remain closed up to 5 minutes before attempting a reading.
2. Place the probe tip well under the tongue as indicated (right).
3. Instruct children not to bite down on the probe. The peak
temperature should be reached in approximately 60 seconds.
4. Opening of the mouth or improper placement of the probe
tip could result in a longer reading time.
MODEL DT-7
DIGITAL THERMOMETER
Please read this instruction manual carefully before using this device, especially
the safety information, and keep the instruction manual for future use.

RECTAL USE
1. Commonly used for babies, young children or when it is dicult to take an oral or
underarm temperature.
2. After placing the probe cover on the thermometer, lubricate with a water-soluble
jelly or petroleum jelly.
3. Gently insert the probe tip no more than 1/2 inch or 1.3 cm into the rectum. Do not
force the tip into the rectum if resistance is encountered.
4. Dispose of the used probe cover and wash the thermometer as recommended. The
peak temperature should be reached in approximately 40 seconds.
UNDERARM (AXILLARY) USE
1. Wipe underarm with a dry towel.
2. Place probe tip in armpit and bring arm down against the body.
3. The probe should point upward in the same direction as your body if possible.
4. An accurate underarm temperature may take 90 seconds or longer depending on
placement of the probe and closure of the arm against the body.
CHANGING MEASUREMENT SCALE
From the “OFF”position, hold down the Multi-Function button for 5 seconds. An“°F”
or “°C” will appear on the display, blinking. Press the ON/OFF button to toggle to the
opposite temperature setting. After 4 seconds your thermometer will be ready for use.
STANDARDS Complies with EN 12470-3:2000, ASTM E 1112-00, and IEC60601-1-11.
HOW TO CARE FOR THIS PRODUCT
• Use of probe covers is recommended to help avoid spreading germs, and to keep
the thermometer clean. The thermometer should be cleaned after use.
• Clean the thermometer tip using only isopropyl alcohol or soap and water.
• Store the unit in the protective case while not in use.
• Do not store the unit under direct sunlight, at a high temperature, or in high
humidity or dust. This may degrade performance of the unit.
• Do not use the device if you think it is damaged or if anything appears unusual.
• Do not use this device next to strong electromagnetic elds such as mobile phones
or radio installations. Keep a distance from such devices when using this unit.
• Keep battery away from children.
• Do not open the thermometer.
• Do not drop the thermometer, as this may damage the unit.
• We recommend verifying the accuracy by an authorized laboratory every two years.
SPECIFICATIONS
SIZE: 5”L x 3/4”W x 3/8”H (12.7cm L x 1.905cm W x .9525cm H)
WEIGHT: 0.49 oz (14 grams)
DISPLAY: LCD, Liquid Crystal Display
BATTERY: 1.55v (LR41) Alkaline
BATTERY LIFE: Approximately 4,500 measurements
MEASUREMENT TIME: Oral 60 Seconds / Rectal 40 Seconds / Axillaries 90 Seconds
MEASUREMENT RANGE: 90.0°F - 109.9°F (32.0°C - 43.9°C)
ACCURACY: 0.2°F (0.1°C) between 96.0°F - 107.0°F (34.0°C - 42.0°C) at a room
temperature of 64.4°F - 82.4°F (18°C - 28°C)
MEASUREMENT MODE: Real measurement with peak-hold method
AUDIBLE ALARM: 1 beep at start-up. Continuous beep at measurement completion
AUTO TURN OFF: In approximately 10 minutes
MEMORY FEATURE: Stores last temperature taken
OPERATION RANGE: 50°F - 104°F (10°C - 40°C), relative humidity of 15%~95%
STORAGE RANGE: -13°F - 140°F (-25°C - 60°C), humidity of 15%~95% (non-condensing)
WARRANTY
Warranty does not cover batteries, or damage resulting from improper handling or use.
Specic legal rights stipulated in your state may guide this warranty.
Batteries and electronic instruments must be disposed of in accordance with
the locally applicable regulations, and not as domestic waste. STANDARDS
Complies with EN 12470-3;ISO 80601-2-56;IEC 60601-1; IEC 60601-1-2 (EMC);
IEC 60601-1-11. This device complies with the requirements of the Medical
Device Directive 93/42/EEC.
Distributed by Prestige Medical®
www.prestigemedical.com
1120 • Made in China
Low battery indicator Not made with natural rubber latex
Temperature limit Type BF applied part
Humidity limit Fahrenheit
Important Warning/Caution Celsius
IP21 Protected against solid foreign objects of 12.5mm diameter and greater. Protected
against the ingress of vertically falling water drops with the device positioned on a turntable.
SYMBOL DEFINITIONS
