Prestige medical DT-30 User manual

NON-CONTACT
THERMOMETER
MODEL DT-3 0
Instructions


1. O/IButton
2. Display
3. StartButton
4. Sensor
5. ModeSwitch
6. BatteryCover



1. Temperaturereading
2. ObjectTemperatureIcon
3. BodyTemperatureModeIcon
4. LowBatteryWarningIcon
5. DeviceReadyforMeasurementIcon
6. MemoryModeIcon
7. TemperatureMeasurementUnit(Celsius/Fahrenheit)




1. O/I Button
2. Display
3. Start Button
4. Sensor
5. Mode Switch
6. Battery Cover
1. Temperature reading
2. Object Temperature Icon
3. BodyTemperature Mode Icon
4. Low BatteryWarning Icon
5. Ready for Measurement Icon
6. Memory Mode Icon
7. Temperature Measurement Unit
(Celsius / Fahrenheit)
UNIT DESCRIPTION
DISPLAY DESCRIPTION

ADVANTAGES OF THIS THERMOMETER
Measurement in a matter of seconds
The innovative infrared technology allows
measurement without touching the object for
safe and sanitary measurements within seconds.
Multiple Uses (wide range measurement)
This thermometer oers a wide measurement
range feature from 0 °C to 100.0 °C (32.0 °F
to 212.0 °F), meaning the unit can be used to
measure body temperature or it can be used to
measure surface temperature of the following:
• Milk surface temperature in a baby’s bottle
• Surface temperature of a baby’s bath
• Ambient temperature
Accurate and reliable
The unique probe assembly construction, incor-
porating an advanced infrared sensor, ensures
that each measurement is accurate and reliable.
Gentle and easy to use
• Easy to use ergonomic design.
• Can be used on a sleeping child.
Auto-display memory
The last reading is automatically displayed for 2
seconds when the unit is switched ON.
Multiple reading recall
Users will be able to recall the last 50 readings
when entering the recall mode, enabling ef-
cient tracking of temperature variations.
Safe and hygienic
• No direct skin contact.
• No risk of broken glass or mercury ingestion.
• Cleaning of the probe can be done with an
alcohol moistened cotton tissue, making this
thermometer completely hygienic for use by the
entire family.
Fever alarm
10 short beeps and a red LCD backlight alert the
patient that they may have a temperature equal
to or higher than 37.5 °C (99.5 °F).

IMPORTANT SAFETY INSTRUCTIONS
This instrument may only be used for the
purposes described in this booklet. The
manufacturer cannot be held liable for damage
caused by incorrect application.
• Never immerse in water or other liquids. For
cleaning please follow the instructions in the
Cleaning and Disinfecting section.
• Do not use the instrument if you think it is
damaged or notice anything unusual.
• Never open the instrument.
• A basic physiological eect called vasocon-
striction can occur in the early stages of fever,
resulting in a cool skin eect. The recorded
temperature using this thermometer can,
therefore, be unusually low.
• If the measurement result is not consistent
with the patient’s nding or unusually low,
repeat the measurement every 15 minutes or
double check the result by another core body
temperature measurement.
• This instrument comprises sensitive
components and must be treated with caution.
Observe the storage and operating conditions
described in the technical Specications
section.
• Ensure that children do not use the instrument
unsupervised; some parts are small enough to
be swallowed.
• Protect this instrument from extreme hot
or cold temperatures, impact and dropping,
contamination and dust, and direct sunlight
• If the instrument is not going to be used
for a prolonged period the battery should be
removed.
WARNING: Use of this instrument is not
intended as a substitute for consultation
with your physician.This instrument is NOT
waterproof so do not immerse in liquids.

HOW THIS THERMOMETER MEASURES
TEMPERATURE
This thermometer measures infrared energy
radiated from the forehead or objects.This
is collected through the lens and converted to
a temperature value. Pointing at the area above
the eyebrow will provide the greatest accuracy.
CONTROL DISPLAYS AND SYMBOLS
• All segments displayed:
Press the O/I button to turn on
the unit; all segments will be
shown for 2 seconds.
• Memory: The last reading
will automatically be shown
on the display for 2 seconds.
• Ready for measurement:
When ready, the C° or F° icon
will ash while the mode
icon (body or object) will be
displayed.
• Measurement complete:The reading will
be shown on the display with the C° or F° icon
and the mode icon steady. The unit is ready for
the next measurement as soon as the C° or F°
icon is ashing again.
• Low battery indication:The
battery icon will ash if the battery
needs to be replaced.
CHANGING TO BODY OR OBJECT MODE
For changing from body to object mode, slide
the mode switch at the side of the thermometer
downwards.
For switching
back to body
mode, slide the
switch up again.





MEASURING IN BODY MODE
1. Press the O/I button. The display is activated to
show all segments for 2 seconds.
2.The last measurement reading will automati-
cally be shown on the display for 2 seconds with
the“M”icon at the lower right corner.
3.When the C° or F° icon is
ashing, a beep sound is heard
and the thermometer is ready
for measurement.
4. Point the thermometer at the area above the
eyebrow of the forehead with a distance of no
more than 5 cm (2 inches). If the forehead is
covered with hair, sweat or dirt, please remove
the obstacle beforehand to improve the reading
accuracy.
5. Press the START button.
6. After 1 second a long beep will verify the
completion of measurement.
7. Read recorded temperature from the display.
MEASURING IN OBJECT MODE
1. Follow steps 1-3 above, then aim the ther-
mometer at the center of the object you want
to measure with a distance of no more than 5
cm (2 inches). Press the START button. After 1
second a long beep will verify the completion of
measurement.
2. Read recorded temperature from the display.
OPERATING NOTES
• For more accurate readings, the patient and
thermometer should remain in a steady room
condition for 30 minutes before measurement.

5 cm

• Don’t take a measurement immediately after
nursing a baby.
• Don’t use in high humidity environments.
• Patients should not drink, eat, or exercise
before/while taking the measurement.
• Don’t move the measurement device from
the measuring area before hearing the
termination beep.
• Use an alcohol swab to carefully clean the
probe and wait for 15 minutes before taking a
measurement on another patient.
• 10 short beeps and a red LCD backlight alert
the patient that they may have a temperature
equal to or higher than 37.5 °C (99.5 °F).
• Always take the temperature in the same
location, since temperature readings may vary
according to location.
• Doctors recommend rectal measurement for
newborns within the rst 6 months, as other
measuring methods may lead to ambiguous
results. In these cases, we recommend to verify
the readings with a rectal measurement.
• In the following situations it is recom-
mended that three temperatures be taken
and the highest one used as the reading:
1. For children under three years of age
with a compromised immune system and
for whom the presence or absence of a
fever is critical.
2. For new users learning how to use the
thermometer. Recommended until they
have familiarized themself with the instru-
ment and can obtain consistent readings).
3. If the measurement is surprisingly low.
Readings from dierent measuring sites
should not be compared as the normal
body temperature varies by measuring
site and time of day, being highest in the
evening and lowest about one hour before
waking up.

CHANGING THE UNIT OF MEASUREMENT
FROM CELSIUS TO FAHRENHEIT
1. Make sure the unit is turned o.
2. Press and hold the START button for more
than 5 seconds until the current unit of
measurement is displayed.
3. Press the START button again to switch
between °C (Celsius) and °F (Fahrenheit).When
your desired unit of measurement is shown on
the display, wait a few seconds until all symbols
are displayed. It is now ready for use.
Note: All saved measurement data will adjust
to the newly selected unit of measurement.
HOW TO RECALL 50 READINGS IN
MEMORY MODE
• Recall mode:
While the power is turned
o, press the START button to
enter Recall mode. The
memory icon «M» will ash.
• Reading 1
(The last reading):
While the power is turned
o, press and release the
START button to recall the
last reading. The display will
indicate a“1”alone with the
memory icon.
• Reading 50
(Readings in succession):
Press and release the START button consecu-
tively to recall the last 50 readings in succession.
Pressing and releasing the START button after
the last 50 readings have been recalled will
resume the above sequence from reading 1.




ERROR MESSAGES
• Measured temperature
too high: Displays“H”when
measured temperature is
higher than 42.2 °C (108.0 °F)
in body mode or 100 °C
(212 °F) in object mode.
• Measured temperature
too low: Displays“L”when
measured temperature is lower
than 34.0 °C (93.2 °F) in body
mode or 0 °C (32 °F) in object
mode.
• Ambient temperature
too high: Displays“H”In
conjunction with the“ “
when ambient temperature is
higher than 40.0 °C (104.0 °F).
• Ambient temperature
too low: Displays“L”In
conjunction with the“ “
when ambient temperature is
lower than 16.0 °C (60.8 °F) in
body mode or is lower than
5.0 °C (41.0 °F) in object
mode.
• Blank display: Check if
the battery has been loaded
correctly. Be sure to check the
polarity (<+> and <->) of
the battery.
• Error function display:
The system has a malfunction
and is not working correctly.
• Flat battery indication:
If a (steady) battery icon is the
only symbol shown on the display,
the battery should be replaced immediately
(see next page for details).







CLEANING AND DISINFECTING
Use an alcohol swab or cotton tissue moistened
with alcohol (70% Isopropyl) to clean the
thermometer casing and the measuring probe.
Ensure that no liquid enters the interior of the
thermometer. Never use abrasive cleaning
agents, thinners or benzene for cleaning and
never immerse the instrument in water or other
cleaning liquids. Take care not to scratch the
surface of the probe lens and the display.
BATTERY REPLACEMENT
This instrument is supplied with one lithium
battery, type CR2032. Replace with a new
CR2032 battery when the ashing battery
symbol appears on the display. Remove the
battery cover by sliding it in the direction
shown.
Remove the battery and replace with a new
one. Batteries and electronic instruments must
be disposed of in accordance with the locally
applicable regulations, not with domestic
waste.
WARRANTY
This product is warranted against defects
in manufacturing during normal use by the
original purchaser for one year.

TECHNICAL SPECIFICATIONS
Type: Non ContactThermometer [DT-30]
Measurement range:
• Body Mode: 34.0-42.2 °C (93.2-108.0 °F)
• Object Mode: 0-100.0 °C (32-212.0 °F)
Resolution: 0.1 °C
Measurement accuracy:
Laboratory: ±0.3 °C, 36.0 ~ 39.0 °C
(±0.4 °F, 96.8 ~ 102.2 °F)
Display: Liquid Crystal Display, 4 digits plus
special icons
Acoustic:
• The unit is turned ON and ready for the
measurement: 1 short beep
• Complete the measurement: 1 long beep
(1 sec.) if the reading is less than 37.5 °C
(99.5 °F), 10 short“Beep”sounds, if the
reading is equal to or greater than 37.5 °C
• System error or malfunction: 3 short
“Beep”sounds
Memory:
• Auto-Display the last measured temperature
• 50 readings recall in the Memory Mode
Backlight:
• The display light will be GREEN for 4
seconds, when the unit is turned ON.
• The display light will be GREEN for 5 sec-
onds, when a measurement is completed
with a reading less than 37.5 °C (99.5 °F).
• The display light will be RED for 5 seconds,
when a measurement is completed with
a reading equal to or higher than 37.5 °C
(99.5 °F).
Operating temperature:
• Body Mode: 15-40.0 °C (59-104.0 °F)
• Object Mode: 5-40.0 °C (41-104.0 °F)
Storage temperature:
-20 °C to +50 °C (-4 °F to 122 °F) 15-95 %
relative maximum humidity

Automatic Switch-o: Approx. 1 minute
after last measurement has been taken.
Battery: CR2032 Battery (X1) 3V - at least
1000 measurements
Dimensions: 112±0.3mm × 30±0.2mm
× 24±0.2 mm
Weight: 50±0.5 g (with battery), 47±0.5
(w/o battery)
Reference to standards:
ASTM E1965-98; IEC 60601-1; IEC 60601-1-2
(EMC); IEC 60601-1-11; ISO 80601-2-56: 2017
Microlife AG
Espenstrasse 139
9443Widnau - Suisse
ONBO Electronics (Shenzhen) Co., Ltd.
No. 497 Ta Laneg Nan Road,Ta Laneg Street,
Longhua New District, Shenzhen, China
03/19
8600 Wilbur Avenue
Northridge, California 91324
www.prestigemedical.com
Distributed by:
Made in China
Follow Instructions for Use.This document
provides important product operation and safety
information regarding this device. Please read
this document thoroughly before using the
device and keep for future reference.
Type BF Applied Part
