Page 1
PATENTED: www.voxxintl.com/company/patents
Model APS-25E
3 Button Remote Security
System Owner's Manual
FCC COMPLIANCE
This device complies with Part 15 of the FCC rules and with RSS-210 of Industry
Canada.
Operation is subject to the following two conditions:
1. This device may not cause harmful interference, and
2. This device must accept any interference received, including any interference
that may cause undesired operation.
Warning!
Changes or modications not expressly approved by the party responsible for
compliance could void the user’s authority to operate the equipment
NOTE:The manufacturer is not responsible for any radio or TV interference
caused by unauthorized modications to this equipment. Such modications
could void the user’s authority to operate the equipment
Table Of Contents:
Introduction Features and Options Page 2
Arming The System Page 3 - 4
Protection While Armed Page 4
Disarming Your System Page 4
Intrusion Signals Page 4
Valet Override, Programming & Safety Control Switch Page 5
Manually Overriding Your System Page 5
Eliminating the Arm/Disarm Chirps Page 5
Remote Panic Operation Page 6
Trunk Release/Optional Device Channels Page 6
Replacement or Additional Transmitters Programming Page 7
Transmitter Battery Replacement Page 7
System Features At A Glance Page 8

128-9321
Page 2/8
Page 2
PRESTIGE
Congratulations! Your purchase of this state-of-the-art security system
expresses a deep concern for the security of your vehicle, its contents,
and passengers. To fully appreciate the many functions and safeguards
incorporated in this system, please spend a few minutes reading this
manual. You may nd unexpected features that could mean the difference
between “protected” and “fully protected”.
FEATURES:
2 Three Button Programmable Code Hopping RF Transmitters
Three Channel Receiver ( capable of accepting 4 transmitters )
Code Learning
Remote Panic in all modes
Protected Valet
7 Function LED - Arm / Disarm / Zones 1, 2, & 3 / Valet / Arming
Intrusion Alert with Memory
 Audible Arm / Disarm / Defective Zone / Tamper Conrmation
Instant Siren Activation
Starter Disable
True Last Door Arming ( hardwire only )
Defective Zone By - Pass
Hardwire or Voltage Sense Selectable
Active or Passive Arming Selectable
User Programmable Permanent Chirp Delete
6 Tone Multi-Tone Siren
Additional Negative Trigger Input
RF Inhibit with Ignition On
Parking Light Flasher
Plug In Dual Stage Shock Sensor
OPTIONS:
Remote Trunk Release
Remote Keyless Entry
Multiple Vehicle Capable
Remote Starter
Remote Power Window Roll Up

128-9321
Page 3/8
Page 3
ARMING THE SYSTEM: (ACTIVE)
1. Turn off the engine, exit the vehicle, and close and lock all doors, hood and
trunk.
2. Press and release the Lock button on the keychain transmitter. The siren
will "chirp" once, the vehicle's parking lights will ash once, the doors will
lock (optional) and the dash mounted LED will begin to slowly ash.
WARNING! Excessive pressure on the transmitter buttons will damage the in-
ternal components on the circuit board. All that is required is a light
push to the button.
NOTE: If the siren "chirped" three times when Locked, then one of the entry points
(hood, trunk, doors) has been left opened. Closing the hood, trunk, or doors
will correct the problem and you do not need to disarm the system to make
the correction. If the siren "chirped" three times, sometime after arming,
the exclusive delayed dome light learn circuit has been programmed and
the system detected a open entry point after the learned delay expired.
Again, closing the hood, trunk, or doors will correct the problem and you
do not need to disarm the system to make the correction.
ARMING THE SYSTEM: (PASSIVE)
1. Turn off the engine, exit the vehicle, close and lock all doors, hood and trunk.
2. The dash mounted LED will begin to ash rapidly, indicating that the system
is automatically (passive) arming. As an added convenience, the automatic
passive arming will not begin until all doors and trunk lid are closed, allowing
passengers to exit the vehicle at their convenience.
3. In 30 seconds, you will hear a single short "chirp" from the siren and the
vehicle's parking lamps will ash one time, indicating the system is ARMED.
At this time, the dash mounted LED will begin to ash slowly, providing a visual
indication that the system is fully ARMED.
OPTION NOTE: If the optional (not included) power door lock interface has been
installed, the alarm control module can be programmed to:
a) Automatically lock the doors during step 3 above, or
b) Lock the doors only when the transmitter is operated
4. If you wish to arm the system immediately, simply press and release the
ARMING button on the keychain transmitter. The siren will "chirp" once, the
vehicle's parking lamps will ash once, the doors will lock (optional), and the
dash mounted LED will begin to slowly ash.

128-9321
Page 4/8
Page 4
PROTECTION WHILE THE SYSTEM IS ARMED:
1. Opening any door, hood or trunk will cause the alarm to immediately sound.
The siren will continue to sound for 30 seconds, then stop and automatically
re-arm the vehicle. If the potential thief left a door opened, the siren will sound
for six 30 second cycles, then re-arm and ignore the opened door.
2. Any strong impact to the vehicle’s glass will cause the alarm to trigger for the
full 30 second alarm cycle, with "Dual Stage". Any mild impact to the vehicle's
glass or body will cause the alarm to sound a short series of warning tones.
3. Whenever the system is armed, the dash mounted LED indicator will slowly
ash. This serves as a visual deterrent to the potential thief. The LED is a very
low current bulb and will not cause the vehicle's battery to drain, even when left
unattended for extended periods.
4. Whenever the system is triggered, the vehicle's parking lights will ash for the
30 second alarm cycle, attracting added visual attention to the vehicle.
5. Whenever the system is armed, the vehicle's starter will be bypassed. If a thief
should choose to ignore the siren, the vehicle can not be started.
DISARMING THE SYSTEM:
1. As you approach the vehicle, press and release the Unlock button on the
keychain transmitter.
2. The siren will "chirp" 2 times and the vehicle's parking lamps will ash two times.
3a. ACTIVE: The dash mounted LED will turn off, and remain off until the system
is re-armed.
3b. PASSIVE: Never attempt to disarm the system from a distance that prevents
you from opening a door within 30 seconds. Since the system is programmed for
passive arming, it will begin to re-arm until a door is opened. Opening the door
will suspend the passive arming cycle.
INTRUSION WARNING SIGNALS:
The system will inform you if an intrusion attempt has occurred while you were
away from the vehicle. If an intrusion attempt has occurred, the siren will "chirp" 4
times when disarming the system.
The vehicle's parking lights will also ash 3 times to indicate an intrusion has oc-
curred. Enter the vehicle and observe the dash mounted LED for further information.
1. If the LED is ashing one time... pause...one time... etc., then an intrusion attempt
was made to a light activated entry point, or the shock sensor was activated.

128-9321
Page 5/8
Page 5
2. If the LED is ashing two times...pause...two times...etc., then an intrusion
attempt was made to the hood, trunk, or an optional sensor that has been
connected to zone 2.
3. If the LED is ashing three times...pause...three times...etc., then an intrusion
attempt was made through one of the vehicle's doors.
These intrusion warning indicators are stored in the system's memory and will only
be erased from memory when the ignition key is turned on.
Push-Button LED Valet / SYSTEM OVERRIDE Switch:
The "Valet" switch allows you to temporarily bypass all alarm functions, eliminating
the need to hand your transmitter to parking attendants or garage mechanics.
When the system is in valet mode, all alarm functions are bypassed, however, the
remote panic feature and remote door locks (optional) will remain operational. To
use the valet mode;
1. Enter the vehicle and turn the ignition key to the "on" position.
2. Press and hold the LED valet push-button switch for 5 seconds until the LED
turns on solid. The LED will remain on as long as the system is in the valet mode.
3. To return to normal operation, with the ignition switch on, press and release the
LED valet push-button switch one time. The LED will turn off indicating the unit
has been returned to the normal mode of operation.
In the event you lose your keychain transmitter, or if the transmitter fails to disarm
the system, the valet switch can be used as a system override switch.
Open the car door (the alarm will sound). Turn the ignition key on, and press and
hold the LED valet switch on. The alarm will stop sounding, and the vehicle can
now be started.
NOTE: Always remember to exit Valet Mode to ensure that the vehicle remains
protected at all times.
ELIMINATING THE ARM / DISARM CHIRPS:
The normal arming and disarming conrmation "chirps" can easily be turned on
and off using the valet push-button switch. To do this...
1. Turn the ignition key on, and then off.

128-9321
Page 6/8
Page 6
2. Within 10 seconds of turning the ignition key off, press and release the LED valet
push-button switch three times.
3a. If, before proceeding with step 2, the chirps were on, then you will hear 2 chirps
to indicate that the chirps have been turned off.
3b. If, before proceeding with step 2, the chirps were off, then you will hear 1 chirp
to indicate that the chirps have been turned on.
NOTE: Whenever the chirps are by-passed, the 3 chirp defect and 4 chirp in-
trusion indicator will always operate. This feature will always warn you if
there is a defective sensor during the arming sequence or if the vehicle
had been tampered with in your absence, even if the normal arming and
disarming chirps have been turn off.
REMOTE PANIC OPERATION:
The Lock and Unlock buttons on your keychain transmitter also functions as a
"panic" switch for instant activation of the alarm in emergency situations. To use
the remote panic switch;
1. Press and hold the arming button on the keychain transmitter for 3 seconds or
more. The alarm will immediately sound.
2. To stop the alarm, press and release the Trunk/Key button on the keychain
transmitter. If the button is not pressed, the alarm will automatically stop after
30 seconds.
TRUNK RELEASE:
This security system has an additional feature that can be wired to a number of dif-
ferent optional accessories. Some of the more common uses for this "channel" are:
 Remote Trunk Release - available for any vehicle with factory installed electronic
push-button trunk release.
 Remote Car Starter - available for most automatic transmission, fuel injected
vehicles.
 Remote Window Roll Up - available for most vehicles equipped with power
windows.
TO ACTIVATE THIS OPTIONAL ACCESSORY
Press and hold the Trunk/Key button on the keychain transmitter for approximately 3
seconds. If the system has been programmed differently by your installation center,
this output may be accessed by pressing buttons 1&2 simultaneously for 3 seconds.
NOTE: This feature will not operate when the vehicle's ignition key is turned "ON".

128-9321
Page 7/8
Page 7
PROGRAMMING NEW OR REPLACEMENT TRANSMITTERS
(BANK 1)
Transmitter Model Name, 143BP Is Also Found On Back Of
Transmitter Case (Battery Use CR2032)
1) Turn the ignition key to the on position.
2) Press and release the valet/programming switch 3 times (Siren Chirps)
3) Press the Lock Button of each transmitter you want programmed until you hear
a chirp from the horn or siren.
4) Press the valet/program button to advance to the unlock channel two, (siren
chirps)
5) Press the Unlock button of each transmitter you want to operate the unlock
function until you hear a chirp from the horn or siren.
6) Press the valet/program button to advance to the trunk release channel three,
(siren chirps).
7) Press the trunk button of each transmitter you want to operate the trunk release
feature. until you hear a chirp from the horn or siren.
8) Turn the ignition switch off.
The above action programs the Lock, Unlock, & optional Trunk Release,
This remote has the ability to operate 2 similar alarms from a single transmitter.
To toggle on and off vehicle one or two,,,
Press the Trunk/Key button + the Lock button for 5 seconds.
The LED ashes 2 times. Release the buttons, to select 2nd vehicle mode.Program
this transmitter into the second vehicle's system. Any time you are in 2nd vehicle
when the transmitter is operated, the LED will ash twice for each function. When
in in the prime vehicle mode, the LED will ash once for each function.
Transmitter Battery Replacement:
1) Locate and remove the "00" point Philips head screw on the back of the
transmitter case.
2) Carefully separate the front case from the rear.
3) Slide the CR2032 battery out from under the battery clip and dispose of
properly.
4) Install the new battery with the (+) side facing up away from the circuit board.
5) Close the case and reassemble in reverse of disassembly.

128-9321
Page 8/8
Page 8
© 2014 Voxx Electronics Corporation 150 Marcus Blvd. Hauppauge NY 11788 128-9321
APS-25E
SYSTEM FUNCTIONS AT A GLANCE
DASH LED INDICATORS
RAPID FLASHING .............................................. PASSIVE ARMING
SLOW FLASHING.............................................. ARMED
OFF .................................................................... DISARMED
ON - SOLID........................................................ VALET MODE
3 FLASH ... PAUSE............................................ INTRUSION ZONE 3
2 FLASH ... PAUSE............................................ INTRUSION ZONE 2
**1 FLASH ... PAUSE ............................................ INTRUSION ZONE 1
SIREN CHIRP INDICATORS
*1 CHIRP..............................................................ARM
*2 CHIRPS ...........................................................DISARM
3 CHIRPS...........................................................ARM / ZONE ACTIVE
4 CHIRPS...........................................................DISARM / INTRUSION
PARKING LAMPS (Optional)
1 FLASH.............................................................ARM
2 FLASH.............................................................DISARM
3 FLASH.............................................................DISARM / INTRUSION
** Where applicable.
*These chirps are optional and may be disengaged.
To purchase replacement transmitters
or to get additional product information go to:
www.prestigecarsecurity.com
Optional Channel 2 Device
Your System Has These Features Activated:
Starter Cut-out
Door Lock Interface
Shock Detector



Motion Detector
Hardwire


