Presto Lifts PPS2200-62NFO-21 Setup guide

Power Stak
PPS2200-62NFO-21
PPS2200-62NFO-27
PPS2200-62NAS
Installation, Operation
and Service Manual
Model Number ___________________
Serial # _________________________
Date Placed in Service _____________
IMPORTANT: READ CAREFULLY
BEFORE INSTALLING OR OPERATING LIFT
Part orders are subject to a $50 minimum charge.
SEPTEMBER 2011

PRESTO OWNER’S MANUAL Page 2 POWER STAK
This manual was current at the time of printing. To obtain the latest, most updated version, please contact the
Customer Service Department or go to our website: www.PrestoLifts.com -- you will find a complete list of cur-
rent Owner’s Manuals to print.
Presto Lifts Limited Power Stacker Warranty Policy
Presto Lifts warrants the Power Stacker against defects on the mast, fork carriage, chains, pumps,
DC motors, controllers, cylinders and wiring harnesses from faulty material and workmanship for a
period of one (1) year from the date of invoice.
All wear items such as batteries, wheels, motor brushes, seals, bearings, hydraulic hoses, all switches,
battery chargers and forks have a limited warranty against defects in faulty material and workmanship
for a ninety (90) day period from the date of invoice and 30 day limited warranty on labor. Please
note that prior authorization from Presto Lifts is required on all warranty work.
There are no implied warranties of any kind, more specifically; there are no warranties of merchant-
ability or fitness for any particular purpose. Presto Lifts’ sole warranty shall be as set forth in this
limited warranty. Presto Lifts will elect to repair or replace a defective component without charge,
if any components should become defective within the limited warranty period. Proof of purchase is
required for warranty. The charge for shipping the defective component is the responsibility of the
buyer and must be accompanied with an RGAnumber. The shipping charge to return the component
to the buyer is the responsibility of Presto Lifts, Inc.
This limited warranty does not cover labor expense for removal or reinstallation of components
after thirty days. This limited warranty shall not cover, among other things: damages resulting
from foreign matter or water, failure to provide reasonable and necessary maintenance, and if
applicable, use of product while charger is plugged into an AC outlet, or failure to follow operat-
ing instructions. The limited warranty is not valid for damage resulting from negligence, accident,
unreasonable use, abuse or misuse, exceeding data plate capacities or altering the product without
Presto Lifts authorization.
Presto Lifts expressly disclaims and excludes any liability for consequential, incidental, indirect
or punitive damages or financial loss to people or property resulting from any breach of warranty or
the operation or failure of this product.
Presto Lifts makes no representation that this product complies with local, state, or federal safety/
product standards codes. Should this product fail to comply in any way with those codes, it shall
not be considered a defect of materials or workmanship. Presto Lifts shall not be held liable for any
damages resulting from noncompliance. It is the dealer’s responsibility to exercise this limited war-
ranty. This limited warranty is provided to the original purchaser (defined as the original end user)
and is nontransferable. This constitutes the complete and final agreement involving Presto Lifts and
limited warranty obligations for products.

PRESTO OWNER’S MANUAL Page 3 POWER STAK
TABLE OF CONTENTS
S E C T I O N 1:
Limited Warranty................................................................................................................................................2
Introduction.........................................................................................................................................................5
Specifications......................................................................................................................................................5
S E C T I O N 2:
Safety ..............................................................................................................................................................6-7
S E C T I O N 3:
Installation...........................................................................................................................................................7
A. Inspection ....................................................................................................................................................7
B. Removing from Pallet ..............................................................................................................................7-8
C. Preparation for Use.......................................................................................................................................8
S E C T I O N 4:
Operation.............................................................................................................................................................9
A. Operating Instructions...................................................................................................................................9
B. Daily Operations Maintenance Checks.......................................................................................................11
Suggested Daily Operator Checklist.................................................................................................................10
S E C T I O N 5:
Battery Maintenance.........................................................................................................................................11
A. Preparing to Charge a Battery ....................................................................................................................11
B Charging the battery....................................................................................................................................11
C. Warnings and Battery Info...........................................................................................................................11
D. Battery maintenance....................................................................................................................................11
E. Charger Operations................................................................................................................................ 11-12
S E C T I O N 6:
Maintenance......................................................................................................................................................12
A. Weekly Operations Maintenance Checks....................................................................................................12
B. Monthly Operations Maintenance Checks .................................................................................................12
S E C T I O N 7:
Troubleshooting ................................................................................................................................................13
ORDERING REPLACEMENT PARTS...........................................................................................................................58
RESTOCKING POLICY..................................................................................................................................................59
LIST OF TABLES:
Table 1: PPS2200-62NFO Assembly (Prior to November 2008)..........................................................16
Table 2: PST-100/16E-AAAssembly (Prior to November 2008)...........................................................21
Table 3: Drive Wheel Description (Prior to November 2008)................................................................29
Table 4: Recommended Spare Parts List PPS2200-62NFO-21/27..............................................56
Table 5: Recommended Spare Parts List PPS2200-62NAS........................................................57

PRESTO OWNER’S MANUAL Page 4 POWER STAK
LIST OF FIGURES:
Figure 1:Operational Buttons..........................................................................................................7
Figure 2: PPS2200-62NFO (Prior to November 2008).........................................................................14
Figure 3: PPS2200-62NFO Exploded View (prior to November 2008) ................................................15
Figure 4: PPS2200-62NFO (November 2008 to Present).......................................................................................17
Figure 5: PPS2200-62NFO Exploded View (November 2008 to Present)........................................................18
Figure 6: PPS2200-62NAS (Prior to November 2008).........................................................................19
Figure 7: PPS2200-62NAS Exploded View (Prior to November 2008) ................................................20
Figure 8: PPS2200-62NAS (November 2008 to Present) .....................................................................22
Figure 9: PPS2200-62NAS Exploded View (November 2008 to Present) ............................................23
Figure 10: Cylinder View (Prior to November 2008).............................................................................24
Figure 11: Cylinder View (November 2008 to Present) .........................................................................25
Figure 12: Caster Wheel Assembly (Prior to November 2008).............................................................26
Figure 13: Caster Wheel Assembly (November 2008 to Present).........................................................27
Figure 14: Drive Wheel Assembly (Prior to November 2008)...............................................................28
Figure 15: Drive Wheel Assembly (November 2008 to Present)...........................................................30
Figure 16: Handle Assembly (Prior to November 2008).......................................................................31
Figure 17: Control Pod (November 2008 to Present)............................................................................32
Figure 18: Steering Assembly (Prior to May 2007).............................................................................33
Figure 19: Steering Assembly (May 2007 to August 2008)...................................................................34
Figure 20: Steering Assembly (August 2008 to Present)......................................................................35
Figure 21: Power Unit Assembly (Prior to November 2008).................................................................36
Figure 22: Power Unit Assembly (November 2008 to Present).............................................................37
Figure 23: PPS2200-62NFO Carriage Assembly (Prior to November 2008)........................................38
Figure 24: PPS2200-62NFO Carriage Assembly (November 2008 to Present)....................................39
Figure 25: PPS2200-62NAS Carriage Assembly (Prior to November 2008)........................................40
Figure 26: PPS2200-62NAS Carriage Assembly (November 2008 to Present)....................................41
Figure 27: Labels & Precautionary Warnings...............................................................................42
Figure 28: Electric Control Panel (Prior to November 2008) ................................................................43
Figure 29: Electric Control Circuit (Prior to November 2008) ...............................................................44
Figure 30: Wiring (Prior to November 2008).........................................................................................45
Figure 31: Wiring Diagram (Prior to November 2008)..........................................................................46
Figure 32: Wiring Diagrams (November 2008 to Present) ....................................................................47
Figure 33: Wiring Diagrams (November 2008 to July 2011) ..................................................................48
Figure 33b: Wiring Diagrams (August 2011 to Present)....................................................................... 49
Figure 34-39: Wiring Diagrams (November 2008 to Present) ..........................................................50-55

PRESTO OWNER’S MANUAL Page 5 POWER STAK
numbers when ordering parts or requesting further
information.
The Presto stackers are designed for lifting, lower-
ing and positioning a wide variety of loads. WHERE
UNIQUE SITUATIONS ARISE, WHICH ARE NOT
COVERED IN THIS MANUAL, CALL PRESTO
LIFTS FOR FURTHER INSTRUCTIONS.
The battery operated stackers are designed for in-
plant/non-hazardous locations only. They can be used
in a 8' or larger aisle. These units are not for personnel
lifting.
S E C T I O N 1
INTRODUCTION
This manual attempts to provide all of the information
necessary for the safe and proper installation, operation
and maintenance of Presto Lifts Inc. battery operated,
Power Stak. It is important that all personnel involved
with the installation, maintenance or operator of the
stacker read this manual. Additional manuals are avail-
able upon request or at www.PrestoLifts.com.
Each Presto stacker is equipped with nameplate, serial
number and model identifications. Please refer to these
62 NAS 62NFO-27 62NFO-21
Lifting speed (empty) 24fpm 24fpm 24fpm
Lifting speed (loaded) 17fpm 17fpm 17fpm
Lowering speed (empty) 13fpm 13fpm 13fpm
Lowering speed (loaded) 31fpm 31fpm 31fpm
Aisle Spacing 8ft 8ft 8ft
Travel speed (w/o load) 3.4 mph 3.4 mph 3.4 mph
Travel speed (with load) 2.8 mph 2.8 mph 2.8 mph
Usage (for all) 4 - 6 hrs. per 8 hr shift
Lifting (height) 62" 62" 62"
Overall (height) 78" 78" 72"
Overall (length) 67.9" 65" 65"
Overall (width) 58" 32" 32"
Capacity 2200 lbs 2200 lbs 2200 lbs
Load center 24" 24" 24"
Adjustable straddle legs (OD) 46-58" N/A N/A
Adjustable straddle legs (ID) 38-50" N/A N/A
Gradient performance (w/o load) 5% 5% 5%
Gradient performance (with load) 0% 0% 0%
Short term gradient performance (w/o load) 7% 7% 7%
Short term gradient performance (witah load) 3% 3% 3%
Specifications:

PRESTO OWNER’S MANUAL Page 6 POWER STAK
S E C T I O N 2
SAFETY
You must be trained and certified to operate this
powered stacker. Federal law states that only prop-
erly trained operators are permitted to operate a
powered industrial stacker and that your employer
must train you and certify that you are qualified.
(OSHA 1910.178 29QFR-7-1-06 Edition)
Presto lifts does not offer operator training. Op-
erator training programs may be offered by your
local Presto Lifts dealer or obtained online. Enter,
"powered industrial truck operator training" into
a search engine.
The battery operated stackers are very powerful lifts
capable of doing large amounts of work.
DO NOT OPERATE THESE LIFTS WITHOUT
CAREFULLY READING THIS MANUAL. In order
to provide for the safe operation of these stackers,
Presto Lifts Inc. has identified certain hazards that
may occur during the maintenance and use of these
lifts. For safety reasons these units are designed to be
serviced or repaired in the fully lowered position. If
performed properly, this will greatly reduce the pos-
sibility of injury.
WARNING!
When servicing the unit:
1. Key should be in "OFF" position.
2. E-stop should be depressed.
3. Disconnect the batteries at the terminals.
• Do not perform any repair work on lifts if
there is a load on the forks or platform.
• Do not perform any repair work if the forks
or platform is in the raised position.
• All personnel must stand clear of the lift
while in motion.
• Do not put hands or feet under the forks or
platform.
• Do not stand underneath the forks or plat-
form.
• Do not stand in front of the stacker while in
motion.
• Do not stand, sit or climb on the lift.
• Do not use the lift on soft, uneven or unstable
surfaces.
• Do not exceed the load center or capacity.
WARNING!
You or others around you can be seriously injured
or even killed if you don't use this stackercorrectly.
Read and obey all warnings and instructions in this
manual and on the stacker. It is your responsibil-
ity before starting work to make sure it is in good
working order.
Always be alert to the area around you and watch where
you are walking. Be careful that you don't get pinned
or crushed between the stacker and a fixed object such
as a wall or post.
• Watch your hands and feet. A foot or hand
caught between the stacker and a fixed object will
be crushed or even cut off.
• If traveling forks first, keep both hands on
the control handle and be careful when changing
direction of travel. Keep your feet clear of the
stacker.
• Keep the stacker under control at all times.
Operate at a speed that allows you to stop safely.
Be even more careful on slippery or uneven sur-
faces. Do not run over objects on the floor.
• Perform all stacker movements smoothly and
at a speed that will give you time to react if an
emergency occurs.
Tipovers and falls are very serious accidents; you can
be crushed or even killed. To prevent injury, know
where you are at all times and follow the rules of safe
stacker operation.
• Be careful when working around docks,
dockboards and trailers. Stay away from the
edge of docks and ramps. Check to make sure the
wheels of truck or trailers are chocked.
• Travel with the load or forks close to the
ground. Watch for overhead obstructions. Per-
form all stacker movements smoothly and at a
speed that will give you time to react in an emer-
gency.
• Keep your hands and feet away from all mov-
ing parts such as masts, chains, forks or wheels.
• Never stand on or under the forks, or allow
anyone else to stand on or under them. Never ride
on the stacker or allow anyone else to ride. There
is no safe place to sit or stand.
• Before you leave your stacker, be sure to
lower the forks to the floor. Shut the stacker off
with the key.

PRESTO OWNER’S MANUAL Page 7 POWER STAK
and that the lift is complete. Presto tests and inspects
every piece of equipment prior to shipment. If damage
is apparent, a freight claim must be filed with the freight
company. Do not use the stacker if there appears to be
any damage. With the stacker in a lowered position,
check the following:
• Check for signs of damage especially to the
back cabinet that houses the battery, electrical/hy-
draulic power pack.
• Check all electrical and hydraulic connec-
tions for tightness.
• Remove back panel.
1. Turn key switch to "OFF" position.
2. Push in E-stop and unscrew the red knob,
3. Lift off back panel. There is enough wire
to the key switch to allow the panel to be set
aside.
• Inspect for any bent or damaged parts.
B. REMOVING FROM PALLET
Each of the Presto stackers is shipped out on a pallet or
skid. Prior to removing the unit from the pallet or skid,
remove all tie down straps and packaging. Visually
inspect the unit as closely as possible.
With an overhead hoist or forklift, carefully pick up the
unit taking into considerationthe center ofgravity of the
unit. If you choose to pick the unit with an overhead
hoist, use a nylon sling and hoist with a minimum of
2,000-lb.capacity. The nylon sling will not do anydam-
age to the steel construction of stacker. Pick the unit
up. On conventional masts use the top crossmember of
the lift. On narrow masts the cover must be removed
to access lifting equipment. Be careful of the stacker
swinging once fully lifted off the pallet or skid. Have
Figure 1: Operational buttons BELLY BUTTON SWITCH
LIFT UP
LIFT DOWN
HORN
SPEED CONTROL
DIRECTION CONTROL
WARNINGS
DO NOT use this stacker until you have been trained
and authorized to do so.
DO NOT operate until you have read all warnings and
instructions.
DO NOT exceed load center or load weight capacities
(check capacity plate).
DO NOT operate until you have checked the condi-
tions of the stacker: lift systems, forks, chains, and
cables.
DONOTuse if any part is damaged, worn or not work-
ing properly.
DO NOT use on ramps or inclines. Only smooth level
surfaces.
DO NOT use for lifting or carrying people.
DO NOT handle unbalanced, unstable or loosely
stacked loads.
DO NOT travel with forks or platform in an elevated
position.
DO NOT handle tall, unsecured or unstable loads that
could fall.
DO NOT allow people to stand or pass under forks or
platform with or without load.
DO NOT operate when parts of anyone’s body may be
close to mast structure or any moving parts.
DO NOT drop loads on platform or forks.
DO NOT alter or modify this stacker in any way.
S E C T I O N 3
INSTALLATION
A. INSPECTION:
Upon receipt of the stacker, inspect the equipment com-
pletely to determine if there is any shipping damage,

PRESTO OWNER’S MANUAL Page 8 POWER STAK
all personnel completely cleared from the area.
Pick the unit up approximately six inches above the
pallet or skid. Once raised, remove the pallet or skid
from below the lift. Do not move the lift around in the
air. Lower the stacker on the ground.
C. PREPARATION FOR USE
This stacker left our factory in new condition. It has
been inspected and weight tested to assure all perfor-
mance standards have been met.
Visually inspect the stacker for damage. Check for at-
tachments and accessories that may have been ordered.
If there is any damage or missing parts, report it to your
carrier and your Presto dealer immediately.
Remove all metal/plastic bands, cardboard and other
material used for shipping purposes.
Check to see if chains are in place, and that the lift
system is in working order. Inspect for oil leaks.
See instructions for removing back panel on pg. 5.
Connect battery cable. Check cables and wires on bat-
tery charger as well as battery.
Set up procedure for Power Stak Strad-
dle legs
NOTE: The Straddle legs must be adjusted to
the procedure below
1. Determine the required straddle leg dimension.
2. Relieve any weight from the legs. This may need to
be done one side at a time.
3. Adjust the legs and ensure both legs are positioned
equally.
Note: The Power Stak is meant to operate on a non
slip floor or surface. If traction is needed, Presto
Liftsoffers anoptional rubberwheeloranon-mark-
ing wheel.
Note: The travel speed is preset at the factory. For
travel speed adjustment, please contact customer
service at Presto Lifts 1-800-343-9322
Straddle Leg Bolt
Tightenting Procedure
1. Pre-tighten all bolts to
the bottom, but not too
tight.
2. Fully tighten bolt 1.
3. Next, tighten bolt 3.
4. Last, tighten bolt 2.
5. Tighten all bolts to 85
foot pounds.

PRESTO OWNER’S MANUAL Page 9 POWER STAK
S E C T I O N 4
OPERATION
A. OPERATING INSTRUCTIONS:
Operational Speeds:
the Presto Power Stak is designed to operate at the
following speeds:
Rise speed empty: 24fpm
Rise speed loaded: 17fpm
Lowering speed empty: 13fpm
Lowering speed loaded: 31fpm
To Raise and Lower:
There are two buttons located on both sides of the
handle. The inside one is for raising the forks. The
outside one is for lowering the forks. When operating,
always make sure the load being lifted is within the
loading capacity of your stacker and the load has been
stacked safely on the pallet. Also, make sure that the
length of the forks corresponds to the length of the pal-
let. In this way, the load rollers will place themselves
in the opening at the end of the pallet, so that when you
raise the forks, you will not break the bottom boards
of the pallet.Always make sure that when entering the
pallet that the forks are in the fully lowered position.
Be careful when lifting pallets that are too short or too
long for the stacker. It might destroy your pallet by
breaking the bottom boards, and if the forks project
through the end of the pallet, the tips of fork may go
into the next pallet that is behind the pallet that you are
lifting, which may bend the tips of forks and overload
the capacity of the stacker.
To Travel:
To travel, rotate the butterfly controls throttle on the
upper part of the handle. When rotating the butterfly
control CWtowards theforks, the stackerruns forwards
in the forks first direction. When rotating the butterfly
CCW towards you, the stacker runs backwards in the
handle first direction. Always make sure the stacker
clears any obstruction when traveling, and that your
path of travel is clear of people. Never carry loads
above the loading capacityof the stacker. It is suggested
that when traveling without a load, the forks be in the
lowered position. The speed of the stacker is increased
by the degree of the rotation in either direction; it func-
tions like a throttle. When you release your hand from
the butterfly control, it automatically will resume to
the neutral position and the speed of the stacker will
slow down.
To Brake:
Your stacker is equipped with a magnetic brake. The
brake is applied when the handle is in its vertical po-
sition between 10 – 15 degrees and lowered position
between 80 – 90 degrees. The brake could be released
when you pull down the handle at any point between
15 – 80 degrees. Always make sure the brake is re-
leased before operating the stacker. When the stacker
is running, you could brake the stacker by raising the
handle to its vertical position or lowering the handle to
its lowest position. Or, to turn the butterfly controls in
the opposite direction, the change in direction of the
motor will slow down, stop, and reverse the direction
of stacker. When parked, always put the handle in the
full vertical position with the brake applied and the
forks in lowered position.
Reversing Safety:
At the end of the handle there is a large, red reversing
bar (belly button switch) that is designed to protect
the operator from injury. When the operator runs the
stacker backwards, and the end of the handle comes
in contact with the operator’s body, the stacker will
automatically reverse direction and travel away from
the operator. When the reversing safety bar comes in
contact with your body during operation, immediately
releaseyour hands from the butterfly control and put the
handle up to its vertical position or down to its lowest
position and the brake is on. The reversing safety bar
will automatically resume to its original position after
being activated.
Horn:
As standard equipment, a horn that is located on the
top of the handle.
AUTHORIZED OPERATORS SHOULD READ
AND UNDERSTAND ALL INSTRUCTIONS,
PRECAUTIONS AND WARNINGS.
IMPROPER USE OF THIS LIFT TRUCK
COULD RESULT IN INJURYAND/OR DAM-
AGE
TO LOADAND EQUIPMENT.
• Inspect the lift for damaged or worn parts.
Do not use if not in safe operating condition.
• Use lift on hard level surfaces only.
• Make sure load is evenly distributed, not
loose or unstable, and is as far back on platform
or forks as possible. Do not pick up loads on tips
or forks or edge of platform.

PRESTO OWNER’S MANUAL Page 10 POWER STAK
SUGGESTED DAILY OPERATOR CHECKLIST
WALK AROUND INSPECTION
1. Check general condition of lift (loose or broken parts, etc.).
2. Check for dented or scratched panels.
3. Look for broken or cracked welds, broken or worn rollers and
chains. Check for loose pins or fasteners.
4. Ensure condition of wheels are not flat spotted or chunked out.
5. Check for hydraulic leaks.
6. Make sure all precautionary labeling is in place and legible.
7. Check for hydraulic leaks
FUNCTIONAL INSPECTION
1. Check for proper operation of UP/DWN/FOR/REV controls.
2. Check operation of brake system.
3. Check for locations of belly button switch and horn.
4. Check for hydraulic leaks.
OPERATOR ID DATE
DO NOT USE LIFT IF NOT OPERATING
PROPERLY OR IF LIFTAPPEARS
UNSAFE IN ANY WAY
REPORT CONCERNS TO SUPERVISOR IMMEDIATELY!

PRESTO OWNER’S MANUAL Page 11 POWER STAK
S E C T I O N 5
BATTERY MAINTENANCE
A. PREPARING TO CHARGE A BATTERY
1. Always turn offE-stop and key switchbefore work-
ing with the batteries.
2. Be sure the area around the stacker and the battery
is well ventilated while battery is being charged.
3. The battery terminals, connections and wiring
connections should be clean and free of corrosion.
When cleaning anyof thesecomponents wear aface
shield or other suitable protective eyewear.
B. BATTERY CHARGING
Charging must be performed with the charger that is
provided with or prewired into the machine. During
charging,the temperature in thebattery must not exceed
120 F. Charging simultaneously with truck operation is
not recommended. Plug the charger into a 115V outlet.
Charge until the battery gauge indicator lights show
fully charged (approximately 6-8 hours).
C. WARNINGS AND BATTERY INFORMA-
TION
Avoid use of open flame near batteries. At temperatures
around freezing point, battery capacity is reduced by
30%. The battery terminals, connections and wiring
should be clean and free of corrosion. When cleaning
any of these components, wear a face shield or other
suitable protective eyewear. Read, understand, and
folow all battery and battery manufacturer's specific
precautions while working with and/or charging bat-
teries.
D. BATTERY MAINTENANCE
To measure the voltage, use a digital voltmeter (DC) on
the battery poles. The truck must not have been in use
for the previous 30 minutes.
DANGER
Never alter the AC cord or plug provided. If it will
notfit outlet, have properoutletinstalled by a quali-
fied electrician. Improperconnection can result in a
risk of an electric shock.
1. Disconnect the charger from the 110 volt wall out-
let once the indicators read fully charged.
Note: The batteries are designed for intermittent
use. Continual usage will wear the battery out and
charging will be required.
E. CHARGER OPERATION
Power Lamp
1. Green: Connection correct. Charger will operate
normally.
2. Red: Bad connection or bad battery.
VOLTAGE
Approx. 12.7 V Fully charged
Approx. 12.2 V 1/2 charged
Approx. 12.0 V 1/4 charged
Approx. 11.6 V Discharged
• For fork models, adjust forks to the maxi-
mumpractical width. Pick up loads on both forks.
• Do not overload. Check load center and load
weight capacities on the nameplate.
• Make sure travel and work area is clear of
obstructions.
• Check overhead clearance before lifting loads
or transporting.
B. DAILY OPERATIONS
MAINTENANCE CHECKS:
1. Battery
A. Check for corroded and loose terminals.
A white powder substance will be present if
there is any existing corrosion.
B. Visually inspect for any cracks or damage
to the casing.
C. Check for loose battery tie-downs.
2. Charger
A. Inspect wire connections.
B. Check power cord for nicks/damage.
C. Check power charger for proper mounting.
3. Hydraulic System
D. Inspect pump and cylinder for oil leaks.
E. Check hydraulic oil level.
F. Check hydraulic fittings and hoses.
G. Check ram for nicks/damage.
4. Frame Assembly
A. Check chain roller assembly connections.
B. Check for any worn or damaged parts.

PRESTO OWNER’S MANUAL Page 12 POWER STAK
Fault
1. Red light blinks 3 times in 5 seconds: The output
between charger is faulty, loose, or bad connection
2. Red light blinks 5 times in 5 seconds: The tempera-
ture is too hot for the charger to operate.
3. Building power is not compatible; too low or too
high. +- 10% is the general rule.
Charge Lamp
1. Red: Charger can charge normally. The battery is
less than 70%
2. Orange: Battery is between 70% and 100%
charged.
3. Green: BAttery is at 100%. Fully charged.
4. No light: The charger can not charge the battery.
Voltage of the battery may be too low to cause the char-
ger to start. It must be at 9 volts to initiate charge.
S E C T I O N 6
MAINTENANCE
Operation of Presto Power Stak is very simple — as is
their construction. They require very little maintenance.
Reasonable care will result in excellent trouble-free
performance. The Power Stak is designed for one-man
operation and ease of performance.
• Grease floor wheels and casters at least once
a month
• Use only Hydraulic Oil AW32 or Dextron III
in the hydraulic system.
• Do not overload your lift.
• Check brakes, steering mechanisms and con-
trols before each use.
A. WEEKLY OPERATIONS
MAINTENANCE CHECKS:
DAMAGE: Check for bent, dented, worn or broken
parts.
LIFT SYSTEM: Check to assure that there is no bind-
ing or excessive play in the forks. Check for quiet and
smooth operation of the lift cylinder. Check all moving
parts and linkage.
LEAKS: Check hydraulic system for leaks and hydru-
alic oil level.
WHEELS AND CASTERS: Check for wear and that
they are turning smoothly.
LIFT CHAINS: Check to see that they are in place and
not loose.
FORKS: Check that they are not bent or cracked.
BRAKES: Ensure brakes work properly.
CABLES; WIRES: Check that there are no loose cables
or wires.
LABELS: Ensure all precautionary labels and guards
are in place.
B. MONTHLY OPERATIONS
MAINTENANCE CHECKS:
1. Battery (maintenance free)
A. Clean terminals.
B. Clean battery compartment area if there are
signs of corrosion.
2. Hydraulic System
A. Clean and inspect hydraulic cylinder.
B. Lubricate chain with a rust inhibitive lubricant
(light machine oil).
C. Check chain tension. It should be even on both
chains. The chain should be tight enough so
that it does not come off of the roller assem-
bly.
3. Frame Assembly
A. Clean and lubricate all roller bearings, cam
followers and all moving parts.
B. Clean and inspect all welds.
C. Check wheels for wear and damage.
D. Inspect nameplate for legibility. Place theserial
and model number shown on the nameplate on
the cover of the manual for future reference.
4. Electrical
A. Check batteries, motors, controllers, limit
switches, electrical conductors and connec-
tions.
CAUTION:
DO NOT USE LIFT IF IT IS NOT
OPERATING PROPERLY,
OR APPEARS UNSAFE IN ANY WAY!

PRESTO OWNER’S MANUAL Page 13 POWER STAK
S E C T I O N 7
TROUBLESHOOTING
Before starting the troubleshooting, you have to:
A. Put the truck on an even and solid surface.
B. Turn off key switch or disconnect the battery
terminals.
1. Unit will not lift (motor does not
run)
• Faulty wiring from fuse to lift switch in handle
• Faulty lift switch
• Faulty wiring from battery positive terminal to
pump contactor to pump motor
• Burned out brushes in pump motor
• Low hydraulic pressure caused by:
¨ Pressure relief valve needs adjustment
¨ Pump check valve stuck open
¨ Faulty solenoid valve
• Faulty wiring from lift switch to solenoid
• Faulty lift contactor
• Defective control circuit fuse
• Chain or roller bound
• Check oil level
2. Forks will not lower
• Look for binding in chains or rollers
3. No electrical power
Dead Batteries:
¨ Keyswitch on "OFF" position
¨ E-stop button depressed
¨ Loose or dirty battery connections
¨ Blown fuse(s)
• Faulty wiring from fuse to travel control switch
• Faulty control switch
• Faulty wiring from travel control switch direction
contactor
• Faulty contactor
4. No Traction
• Idler wheel needs adjustment
IDLER WHEELADJUSTMENT
The following is a procedure for adjusting the idler
wheel on the Presto PowerStak. Under normal condi-
tions this should notbe necessary becausthe idler wheel
has been adjusted at the factory.
Tools Needed:
Phillips head screw driver
Medium crescent wrench
1 block of wood (2 x 4)
1. Place unit on a flat surface.
2. Turn key to the OFF position and push emergency
stop button down.
3. Remove the 2 screws from the main orange cover
that covers the unit.
4. Remove the emergency stop button by unscrew-
ing.
5. Slide the main cover upand place theblock ofwood
under the right hand side to hold open exposing the
idler wheel and adjusting the screw.
6. With the adjustable wrench loosen the jam nut on
the idler wheel adjusting screw.
7. Loosen the adjusting screw until you have no ten-
sion between the adjusting screw and idler wheel.
You will have some play between the idler wheel
and the left front wheel.
8. Now tighten the screw until you just make contact
with the idler wheel. Continue adjusting until the
idler wheel just touches the floor.
9. Tighten jam nut. You may have a slight rocking
back and forth, from the left front to right rear idler
wheel, but this is not uncommon.
10. Now remove the wooden block and lower the cover
back into place inserting the 2 screws and tighten.
Screw the E-stop button back on.
11. Your adjustment is complete
If the wheel is worn, replace wheel.

PRESTO OWNER’S MANUAL Page 14 POWER STAK
ORDERING REPLACEMENT PARTS
CONTACT PRESTO WITH SERIAL NUMBER
TO GET CORRECT PART NUMBER
PPS2200-62NFO
Prior to November 2008
Figure 2:

PRESTO OWNER’S MANUAL Page 15 POWER STAK
Figure 3:
1001
1002
1003
1004
1005
1055
1056
1057
1058
1059
1060
5000
6000
1039
1040
1041
1042
1043
1044
1045
10461047
1048
1049 1050
1051
1052
1053
1054
7000
8000
2400
1011
1012
1013
1014
1015
1016
1017
1018
1019
1031
1032
1033
1034
1035
1036
1037
1038 1023
1022
1021
1020
2300
4000
1030
1029
1028
1027
1026
1025
1024
3200
Model PPS2200-62NFO
Exploded View
Prior to November 2008

PRESTO OWNER’S MANUAL Page 16 POWER STAK
Item Descripon Qty Item Descripon Qty
2300 Cylinder 1 1029 Chain wheel top base 1
2400 Rear Wheel 2 1030 Chain LH1234 1
3000 Drive Wheel Assembly 1 1031 Bolt M6x25 2
3100 Handle Assembly 1 1032 Flat washer 4 4
3200 Steering Assembly 1 1033 Spring washer 4 4
4000 Liing mechanism 1 1034 H Bolt M4X12 4
5000 Electric System 1 1035 Nut M10 2
6000 Power Unit 1 1036 Nut M10 2
7000 Baery charger 1 1037 Flat washer 10 2
8000 body weld 1 1038 Cylinder hoop 1
1001 Drive wheel cover 1 1039 Vercal mast cover 1
1002 Rear box cover 1 1040 Baery 2
1003 Nut M6 2 1041 B-Pin ?8x40 1
1004 Bolt M6x25 2 1042 Pin ?2.5X12 1
1005 Spring Washer 6 2 1043 Chain pole 1
1011 Bolt M20x65 1 1044 Pin ?2.5X25 1
1012 Nut C-Grade M20 1 1045 Flat washer 16 1
1013 Upper fix plate 1 1046 Nut M16 1
1014 Spring sleeve 1 1047 Baery cover 1
1015 Spring 1 1048 Nut M6 2
1016 Front wheel axle 2 1049 Spring washer 6 2
1017 Washer ?20 2 1050 Bolt M6X25 2
1018 Bearing 6204 4 1051 Bolt M6X35 2
1018 Front wheel 2 1052 Spring washer 6 2
1020 Flat washer 12 2 1053 Flat washer 5 2
1021 Spring washer 12 2 1054 Cover lock plate 1
1022 Bolt M125x25 2 1055 Round cover 1
1023 Baery lock plate 2 1056 Bolt M5X10 1
1024 Chain wheel 1 1057 Flat washer 5 2
1025 Chain wheel axle 1 1058 E-Stop 1
1026 Bearing 6006 2 1059 Key switch 1
1027 Washer 2 1060 Baery meter 1
1028 Washer ?30 1
Model PPS2200-62NFO Assembly
Prior to November 2008
Table 1:

PRESTO OWNER’S MANUAL Page 17 POWER STAK
November 2008 to Present
PPS2200-62NFO-21
PPS2200-62NFO-27
Figure 4:

PRESTO OWNER’S MANUAL Page 18 POWER STAK
November 2008 to Present
Exploded View
PPS2200-62NFO-21
PPS2200-62NFO-27
Figure 5:

PRESTO OWNER’S MANUAL Page 19 POWER STAK
PPS2200-62NAS
Prior to November 2008
Figure 6:

PRESTO OWNER’S MANUAL Page 20 POWER STAK
1001
1002
1003
1004
1005
1007
1008
1009
1010
1011
1012
1013
1014
1015
1016
1017
1018
1019
1020
1021
1022
1023
1024
1025
1026
1027
1028
1029
1030
1031
1032
1033
1034
1035
1036
1037
1038
1039
1040
1041
1042
1043
1044
1045
10461047
1048
1049
1055
1056
1057
1058
1059
1060
1051
1052
1053
1054
1050
1006
5000
6000
7000
8000
2400
2300
4000
3200
PPS2200-62NAS
Exploded View
Prior to November 2008
Figure 7:
