DBP Series
Scissor Lifts
Installation, Operation
and Service Manual
Model Number ___________________
Serial # _________________________
Date placed in service _____________
IMPORTANT: READ CAREFULLY
BEFORE INSTALLING OR OPERATING LIFT
Part orders are subject to a $50 minimum charge.
February 2013

PRESTO OWNER’S MANUAL Page 2 DBP SERIES SCISSOR LIFTS
This manual was current at the time of printing. To obtain
the latest, most updated version, please contact Presto Lifts
Customer Service Department or go to our website: www.
PrestoLifts.com -- you will nd a complete list of current
owner’s manuals to print.

PRESTO OWNER’S MANUAL Page 3 DBP SERIES SCISSOR LIFTS
C O N T E N T S
S E C T I O N 1:
Introduction.............................................................................................................4
S E C T I O N 2:
Safety ......................................................................................................................4
S E C T I O N 3:
Installation........................................................................................................... 4-5
A. Uncrating and Inspection
B. Installing
C. Electrical
D. Hydraulics
E. Testing the Lift with No Load
S E C T I O N 4:
Operation............................................................................................................. 5-6
A. Method of Operation
B. Operating Instructions
S E C T I O N 5:
Battery Maintenance ........................................................................................... 6-7
S E C T I O N 6:
Maintenance........................................................................................................ 7-8
A. Routine Maintenance
B. Troubleshooting Maintenance
S E C T I O N 7:
Service.....................................................................................................................8
A. Replacing Cylinder Seals
S E C T I O N 8:
Troubleshooting.........................................................................................................9
L I S T O F F I G U R E S :
DBP Product Illustration (Figure 1) ..............................................................................................10
Electrical Schematic for 12 Volt DC DBP (Figure 2) ...................................................................11
Hydraulic Pump (Figure 3) ...........................................................................................................12
Hydraulic Arrangement DBP Series (Figure 4) .............................................................................13
Electrical Arrangement DBP Series (Figure 5)..............................................................................14
ACP PORTABLE KIT CASTER for DBP Series (Figure 6).........................................................15
RESTOCKING POLICY..................................................................................................16
ORDERING REPLACEMENT PARTS ...........................................................................17
RETURN GOODS AUTHORIZATION POLICY ...........................................................18
WARRANTY....................................................................................................................19

PRESTO OWNER’S MANUAL Page 4 DBP SERIES SCISSOR LIFTS
sibility of injury. Lifts with oversize table tops require
special handling (See Section 5, Maintenance).
WARNING!
⇑ Do not perform any repair work on lifts if there
is a load on the platform or with the table in a
raised position.
⇑ All personnel must stand clear of the lift when
the lift is in motion.
⇑ Do not put hands or feet under the lift table.
⇑ Do not work under the table without securing the
lift with supplied safety chocks.
⇑ Do not stand, sit or climb on the lift.
⇑ Do not use the lift on soft, uneven or unstable
surfaces.
⇑ Do not exceed the load capacity.
⇑ Do not place a load on a moving lift.
⇑ Place loads in the center of the table and secure
loads properly.
S E C T I O N 3
INSTALLATION
A. UNCRATING AND INSPECTION:
Upon receipt of the DBP Series DC Electric Scissor
Lifts, inspect the equipment completely to determine if
there is any shipping damage, and that the lift is com-
plete. Presto Lifts Inc. tests and inspects every piece of
equipment prior to shipment. If damage is apparent, a
freight claim must be led with the freight company. Do
Not use the lift if there appears to be any damage. With
the lift in a collapsed position, check the following:
CAUTION!
Lifts with oversize table tops must not be over ex-
tended since doing so may disassociate the cylinder
base from its socket. (See Section 5, Maintenance).
⇑ Check for signs of damage especially to the elec-
trical and hydraulic components.
⇑ Check all connections for tightness.
⇑ Check for any bent or damaged metal parts.
⇑ Check base frame for atness.
CAUTION!
When moving the lift, do not attempt to pick it up
by the table top. The lift should be picked up by its
base only.
S E C T I O N 1
INTRODUCTION
This manual attempts to provide all of the information
necessary for the safe and proper installation, operation
and maintenance of Presto Lifts Inc.'s DBP Series DC
Electric Scissor Lifts. It is important that all personnel
involved with the installation, maintenance or opera-
tor of the scissor lift read this manual. Where unique
situations arise, that are not covered in this manual call
Presto Lifts for further instructions. Additional manuals
are available upon request or on our web site at www.
prestolifts.com.
The scissor lift has a nameplate that provides the load
capacity ratings, serial number and model identica-
tions. Please refer to these numbers when ordering parts
or requesting further information.
The Presto Lifts DBP Series DC Electric Scissor
Lifts are designed for lifting, lowering and position-
ing a variety of loads. WHERE UNIQUE SITUA-
TIONS ARISE, THAT ARE NOT COVERED IN THIS
MANUAL, CALL PRESTO LIFTS FOR FURTHER
INSTRUCTIONS.
The DBP Series DC Electric Scissor Lifts is designed
for in plant/nonhazardous location use only. These units
are not for personnel lifting.
S E C T I O N 2
SAFETY
The DBP Series DC Electric Scissor Lifts are very
powerful lifts capable of doing large amounts of work.
They contain scissor legs, that are hydraulically actuated
and are capable of causing serious injury or damage if
adequate precautions are not taken.
DO NOT INSTALL OR OPERATE THESE LIFTS
WITHOUT CAREFULLY READING THIS MANU-
AL. In order to provide for the safe operation of these
scissor lifts, Presto Lifts Inc. has identied certain haz-
ards that may occur during the installation, maintenance
and use of these lifts. For safety reasons the standard
DBP Series DC Electric Scissor Lifts are designed
to be serviced or repaired in the lowered position.
If performed properly, this will greatly reduce the pos-

PRESTO OWNER’S MANUAL Page 5 DBP SERIES SCISSOR LIFTS
B: INSTALLING:
Before starting, be sure that the battery is connected.
Read all of the instructions prior to starting the lift.
1. Handle Assembly
a). Portable lifts have the push handles removed for
ease of shipping. Handles should be inserted in the
holders until they bottom out then tighten set screws
on each holder with an Allen wrench.
C. ELECTRICAL:
1. The motors on DBP Series DC Electric Scissor
Lifts are special intermittent duty motors with high pull
up torques. These motors require heavier duty electrical
controls than standard motors.
WARNING!
Do not attempt to modify or change the electrical
circuit. Any alterations will cause damage to the
pump and possible physical injury. Only authorized
personnel should service the electrical system.
2. For the DBP Series DC Electric Scissor Lifts, a
battery charger is furnished with a short AC 120
plug. A circuit of 15 amps or larger will sufce to
operate the battery charger.
D. HYDRAULICS:
1. Use only hydraulic oil for the lift. The lift has been
supplied with Conoco Super Hydraulic 32. When adding
uid, use only the recommended oils.
2. Before using the lift, check the hydraulic oil level and
add oil if necessary. Check ttings for tightness. Remove
the solid plug on the reservoir and replace it with the
vented plug provided. If the plug is not installed, you
may damage the pump.
CAUTION!
DBP Series DC Electric Scissor Lifts are designed for
normal factory environments. Where below freez-
ing conditions may exist, special uid must be used.
Contact Presto Lifts for further information when
freezing conditions exist.
WARNING!
Do not use automotive hydraulic, brake or transmis-
sion uids. They may damage seals and could pose
a serious re hazard.
E. TESTING THE LIFT WITH NO LOAD:
1. Before testing the lift, clear the area of any loose
material. Be sure the lift has no obstruction above it or
on any side.
2. Using the controls provided, briey operate the lift
(5-10 seconds). If the lift begins to rise with a hum-
ming sound and functions properly, continue to the full
upright position.
CAUTION!
If the lift does not rise immediately, or there is any
operational problem, stop it immediately. Before
continuing, check the rotation of the pump and mo-
tor and the voltage at motor terminals; again briey
operate the lift. If the lift does not move smoothly
with a humming sound, stop and review the proce-
dures in the section on troubleshooting (5B).
3. After raising the lift completely, lower the lift. It
should move slowly and smoothly with a humming
sound. If the lift operates properly, raise and lower the
lift and stop at different levels to get a good perspective
on the lift's operations and movements.
S E C T I O N 4
OPERATION
A. METHOD OF OPERATION:
Electric
All DBP Series DC Electric Scissor Lifts are provided
with a special relief valve and are factory preset for the
maximum safe capacity of the lift. Activating and
holding the up switch will energize the motor. The
motor is attached to a positive displacement pump,
that draws hydraulic uid from the reservoir and
transfers it under pressure to the cylinder. This

PRESTO OWNER’S MANUAL Page 6 DBP SERIES SCISSOR LIFTS
forces the piston forward and the scissor legs to
separate and raise the platform, releasing the up
button will stop the lift. A check valve between the
pump and piston holds the table in position. De-
pressing and holding the down switch will energize
a solenoid, that allows the oil from the cylinder to
return to the reservoir through a preset ow con-
trol. This allows the lift to lower smoothly and at
a controlled speed.
CAUTION!
Do not attempt to change the setting on the pres-
sure relief valve. Do not maintain the up or down
button energized if the lift fails to move or after
it has reached its up or down limits. This will
cause damage to the pump and controls.
B. OPERATING INSTRUCTIONS:
In order to operate the lift follow these operating pro-
cedures.
Read and understand all the instructions before operat-
ing. If the lift has modications or accessories, read and
understand their functions.
1). Load the lift correctly.
Portable lifts: Place the load on the center of the table
top. The load center of gravity must be within 6''
of the lift table top center and equally distributed
over 80% of the table.
If the load is unstable or may become unstable, fasten
it into position.
2). Operate the lift.
a). To raise the lift, press and hold the up button.
b). To lower the lift, press and hold the down
button.
c). Release the button to stop the lift.
3). Wait until the lift has come to a complete stop before
unloading the lift.
4). Stand clear of lift when operating it in order to avoid
injury.
WARNING!
a). Do not stand, sit or climb onto the lift.
b). Do not load or unload a moving lift.
c). If the lift fails to move or exhibits strange move-
ments or sound, stop immediately. Do not operate
the lift until it has been checked and repaired.
d). Obey all warning labels.
e). Do not exceed maximum rated load.
f). Maintain load, center of gravity, within 6'' of the
center of the portable lift.
S E C T I O N 5
BATTERY MAINTENANCE
A. PREPARING TO CHARGE A BATTERY
1. Be sure the area around the stacker and the battery
is well ventilated while battery is being charged.
2. The battery terminals, connections and wiring
connections should be clean and free of corrosion.
When cleaning any of these components wear a face
shield or other suitable protective eyewear.
B. LOCATING THE CHARGER
1. Locate charger as far away from battery as the cables
permit.
2. Do not operate charger in a closed area or restrict
ventilation in any way.
C. PRECAUTIONS FOR GROUNDING
AND AC POWER CORD CONNECTION
Charger should be grounded to reduce risk of electric

PRESTO OWNER’S MANUAL Page 7 DBP SERIES SCISSOR LIFTS
shock. Charger is equipped with an electric cord
having an equipment-grounding conductor and
grounding plug. The plug must be plugged into an
outlet that is properly installed and grounded in ac-
cordance with all local codes and ordinances.
DANGER
Never alter the AC cord or plug provided. If it
will not t outlet, have proper outlet installed by a
qualied electrician. Improper connection can result
in a risk of an electric shock.
D. BATTERY CHARGER CONNECTION
PRECAUTIONS
CAUTION
Connect and disconnect the DC output plug (or
clips) only when the AC cord is disconnected from
the electric outlet. Never allow clips to touch each
other.
1. To charge the unit, plug the charger into the 110 volt
wall outlet. The charger is pre-wired to the battery.
2. Disconnect the charger from the 110 volt wall out-
let
once the indicators read fully charged.
S E C T I O N 6
MAINTENANCE
Generally, the DBP Series DC Electric Scissor Lifts
require very little maintenance. Reasonable care will
result in excellent trouble-free performance.
WARNING!
Never go under or service lift with a load on the table
or with the scissor mechanism unblocked. Always
service the lift in a down position.
A. ROUTINE MAINTENANCE:
All routine maintenance should be performed monthly
and can be performed on the standard DBP Series DC
Electric Scissor Lifts in a lowered height position. Be-
fore performing any maintenance, disconnect the bat-
tery. Then raise the top over its center position, secure
in place and perform the routine listed (1 through 7).
WARNING!
Wood blocks should be cut to the proper length
and be of a hard wood variety. Check for defects
or damage to the blocks prior to each usage. These
blocks are to be used only if the maintenance chock
has been damaged or misplaced.
1). Check oil level. Add oil if necessary.
2). Check rollers for signs of wear. Replace if dam-
aged.
3). Check snap ring and shield. Replace if damaged.
4). Check hydraulic lines for damage or leaking. Replace
if damaged.
5). Check for oil spots on the oor. Trace leaks to the
proper tting and tighten.
6). Check wiring for damage. Replace immediately if
any sign of wear is evident.
7). Bearings on these lifts are permanently lubricated
and require no servicing. Look for any signs of
wear.
B. TROUBLESHOOTING MAINTENANCE:
LIFT WILL NOT MOVE
1. No operational noises:
a). Check power switch.
b). Check voltage at motor -- motor may have
failed.
2. Operational noises:
a). Lift may be overloaded or jammed. Check load
weight and obstructions.
b). Oil shortage -- reservoir low or oil line failure.
Repair or replace.
3. Motor overheats:
a). Excessive cycle rate (15 per hour max.).
b). Low voltage -- check voltage at motor.
c). Oil starvation -- check lter in reservoir.
LIFT OPERATING SLOWLY
1. Up cycle:
a). Oil starvation -- check lter in reservoir.
b). Oil viscosity -- oil is too heavy or too thin.
c). Air in cylinder -- cycle lift with no load 2 times
and hold down button for 20 seconds after
bottoming out on each cycle.
2. Down cycle: (single acting cylinders)

PRESTO OWNER’S MANUAL Page 8 DBP SERIES SCISSOR LIFTS
a). Pinched hydraulic lines.
b). Oil viscosity is too heavy.
3. Lift raises, then slowly lowers without power:
a). Leaking hydraulic lines or ttings (check for
telltale oil spots).
b). Check valve in pump -- may not be seating.
Requires new pump.
4. Lift will not lower when energized:
a). Down solenoid faulty. Check voltage -- may be
low or wrong voltage for coil. Check continu-
ity of coil (burned out).
b). Pinched hydraulic lines.
c). Oil viscosity is too heavy.
S E C T I O N 7
SERVICE
A. REPLACING CYLINDER SEALS:
1. Lower the lift to its lowest position. Then lift
the top to its over center position and secure.
2. Disconnect the negative battery terminal.
3. Disconnect the hydraulic hose from the cylin-
der and cap the line to prevent hydraulic uid
loss.
4. Loosen the set screws holding the cylinder
pin.
5. Remove the cylinder pin.
6. Lift the cylinder out of the lift.
CAUTION!
Hold the cylinder securely while removing the
pin to prevent it from falling to the oor.
7. Clamp cylinder securely at the base end.
8. Completely collapse cylinder piston.
9. Push gland into the cylinder 1/8''- 3/16''.
10. Remove retaining ring.
11. Remove piston rod, piston and gland from cylin-
der.
12. Remove rod nut, piston and gland.
13. Remove and replace seals and wipers.
14. Assemble piston and gland to piston rod.
15. Assemble rod nut to piston rod and torque
to 100 ft./lb.
16. Lubricate piston and seals and install cylinder.
17. Insert retainer ring.
18. Install cylinder and hydraulic lines.
19. Fill reservoir.
20. a). For the lifts serviced in lowered position, lower
tabletop completely.
21. Cycle lift 2-3 times adding oil if necessary.
22. Recheck reservoir oil level.

PRESTO OWNER’S MANUAL Page 9 DBP SERIES SCISSOR LIFTS
TROUBLESHOOTING MAINTENANCE -- ELECTRIC
S E C T I O N 8
TROUBLESHOOTING
IF LIFT DOES NOT RISE TO FULL HEIGHT — check for leaks or shortage of oil. Maintain the
proper oil level. To check oil level, follow these instructions:
⇑ On left hand side, on top of oil well, you will nd a hexagon cap screw which is also a dipstick.
⇑ Remove the cap screw and ll oil well with hydraulic oil. Oil should reach notch on dipstick.
IF THE LIFT TENDS TO CREEP DOWNWARD UNDER A LOAD — a speck of dirt may be obstructing the
seating of the valve and allowing leakage. To correct, follow these instructions:
⇑ Raise lift to full lifting height and then lower it to lowest point of lift. It may be necessary to do this ve or
six times. In lowering the lift, lower it in stages, that is, lower the lift six inches to a foot at a time. This will
dislodge the dirt and lift will operate properly.
Problem Probable Cause Service Required
Lift will not move
w/ no motor noise
Loss of power
Motor failure
Check power switch or battery and charger
Check voltage at motor
Lift will not move with
motor noise
Overloaded lift
Motor
Check load
Low voltage at motor -- battery low
Oil starvation
Check oil reservoir
Motor overheats Excessive cycling rate Check cycle rate, 15 cycles per hour maxi-
mum
Low voltage. Check voltage at motor
Up cycle slow Oil starvation
Oil viscosity
Air in cylinder system
Check and ll reservoir
Check oil viscosity and replace if necessary
Purge system by cycling several times to
full extension and retraction
Down cycle slow Blockage in hydraulic line
Oil
Check for pinched lines
Oil viscosity to heavy; replace
Oil contaminated; replace
Lift raises then lowers
slowly
Check valve
Not seating
Leaking tting
Remove and clean
Check ttings and lines for telltale oil spots

PRESTO OWNER’S MANUAL Page 10 DBP SERIES SCISSOR LIFTS
DBP SERIES PRODUCT ILLUSTRATIONS
F I G U R E 1:
DBP SCISSOR LIFTS

PRESTO OWNER’S MANUAL Page 11 DBP SERIES SCISSOR LIFTS
F I G U R E 2:
ELECTRICAL SCHEMATIC 12 VOLT DC POWER -- DBP

PRESTO OWNER’S MANUAL Page 12 DBP SERIES SCISSOR LIFTS
F I G U R E 3: HYDRAULIC SCHEMATIC -- DBP SERIES
BI-DIRECTIONAL PUMPS
These pumps are driven by reversible motors and are primarily used to power double-acting cylinders in
both directions. Locking checks that hold the load in either direction are standard.
Table 1 – Hydraulic Oil Specications
If the lift will be used at normal ambient temperatures, Presto Lifts supplies the unit with Conoco Super
Hydraulic 32 oil. This may be replaced by any other good quality oil with 150 SSU at 100° F and rust and
oxidation inhibitors and anti-wear properties.
If the lift will be used at ambient temperatures below 0°F, use aircraft grade hydraulic oil. Type 15 aircraft
hydraulic oil is recommended.
The following are equivalent to CONOCO SUPER HYDRAULICS 32:
TYPE MANUFACTURER
AW32 .......................................... CITGO
DTE 24 ....................................... EXXON/MOBIL
NUTO H32 ................................. EXXON/MOBIL
AMOCO AW32 ........................... CHEVRON (AMOCO CO.)
CAUTION!
It is very important to keep the hydraulic oil free of dirt, dust, metal chips,
water, and other contamination. Most of the problems with hydraulic systems
are caused by contamination in the oil.

PRESTO OWNER’S MANUAL Page 13 DBP SERIES SCISSOR LIFTS
FIGURE 4: HYDRAULIC ARRANGEMENT for DBP SERIES

PRESTO OWNER’S MANUAL Page 14 DBP SERIES SCISSOR LIFTS
F I G U R E 5: ELECTRICAL ARRANGEMENT for DBP Series

PRESTO OWNER’S MANUAL Page 15 DBP SERIES SCISSOR LIFTS
FIGURE 6: ACP PORTABLE KIT CASTER for DBP Series

PRESTO OWNER’S MANUAL Page 16 DBP SERIES SCISSOR LIFTS
PARTS
Standard parts may be returned with a 20% restocking fee. Modied or custom-
engineered parts are not returnable. Unfortunately, due to potentially concealed
damage, all sales of electrical assemblies are nal.
QUALITY ISSUES
Should you feel there is a quality problem, please contact the seller to ask ques-
tions and gather information on how to rectify the issue. Presto Lift Inc. reserves
the right to determine potential credits, as a result of factory defects, based on its
inspection of the merchandise.
GENERAL
All products shipped from our factory have passed Quality Assurance inspection and
testing. The carrier of choice has signed for, and accepted the product in new working
condition. The customer should inspect to ensure it is not received damaged, has no
concealed damage or is not incomplete. Parts orders are determined to be complete
based upon Presto Lift, Inc. inspection sheets and carrier shipping weights.

PRESTO OWNER’S MANUAL Page 17 DBP SERIES SCISSOR LIFTS
Ordering Replacement Parts
Presto Lifts has carefully chosen the components in your unit to be the best available for the purpose. Replacement
parts should be identical to the original equipment. Presto Lifts will not be responsible for equipment failures
resulting from the use of incorrect replacement parts or from unauthorized modications to the unit.
Presto Lifts can supply all replacement parts for your lift. With your order, please include the model number
and the serial number of the unit. You can nd these numbers on the name plate. This plate is located within
the scissors mechanism.
To order replacement parts, please call the Presto Parts Department. Parts are shipped subject to the following
terms:
• FOB factory
• Returns only with the approval of our parts department.
• Credit cards preferred (except parts covered by warranty).
• Freight collect for truck (except parts covered by warranty).
• Freight – prepaid and invoice for small parcel shipments (except parts covered by warranty).
Parts replaced under warranty are on a “charge-credit” basis. We will invoice you when we ship the replacement
part, then credit you when you return the worn or damaged part, and we verify that it is covered by our warranty.
Labor is not covered under warranty for Parts orders.

PRESTO OWNER’S MANUAL Page 18 DBP SERIES SCISSOR LIFTS
RETURN GOODS AUTHORIZATION POLICY
Presto Lifts provides the Return Goods Authorization (RGA) Policy, for specic models, as a
courtesy to our distributors in the event they do not receive what they ordered. If a customer
wishes to return a Presto Lifts product, please contact the Customer Service Department and
request an RGA number. This request must be made on or before the fteenth calendar day
following the date of Presto Lifts’ invoice for the merchandise. Not all units are returnable.
Quantity orders and special designs cannot be returned under any circumstances. Presto Cus-
tomer Service reserves the right for nal judgment on all product returns.
The RGA number must appear on the outside of any packaging material for a return to be ac-
cepted and processed by Presto Lifts. Customers shipping returns from the Continental US,
Canada, or Mexico have thirty (30) days from date of RGA issue to have the product arrive at
Presto Lifts’ facility. All merchandise must arrive Free on Board at Presto Lifts’ facility or the
shipment will be refused and returned to the sender. All credits are issued less restocking and
refurbishing charges, regardless if the merchandise was damaged in transit.
Return addresses: please refer to your RMA for the address to which your product should be
returned.

PRESTO OWNER’S MANUAL Page 19 DBP SERIES SCISSOR LIFTS
Presto Lifts Limited Warranty Policy
Presto Lifts warrants all of its products against defects in the welded structural frame and, if applicable, scissor
legs from faulty material and workmanship for a period of ve (5) years from the date of invoice.
All batteries and battery chargers have a limited warranty against defects in faulty material and workmanship
for a ninety (90) day period from the date of invoice through Presto Lifts. All other components have a limited
warranty against defects in faulty material and workmanship for a two (2) year period from the date of invoice
and a 30 day limited warranty on labor. Please note that prior authorization from Presto Lifts is required on all
warranty work.
There are no implied warranties of any kind, more specically, there are no warranties of merchantability or tness
for any particular purpose. Presto Lifts' sole warranty shall be as set forth in this limited warranty.
Presto Lifts will elect to repair or replace a defective component without charge, if any components should become
defective within the limited warranty period. Proof of purchase is required for warranty. The charge for shipping
the defective component is the responsibility of the buyer and must be accompanied with an RMA number. The
shipping charge to return the component to the buyer is the responsibility of Presto Lifts, Inc.
This limited warranty does not cover labor expense for removal or reinstallation of components after thirty days.
This limited warranty shall not cover, among other things: damages resulting from foreign matter or water, failure
to provide reasonable and necessary maintenance, and if applicable, use of product while charger is plugged into an
AC outlet, or failure to follow operating instructions. The limited warranty is not valid for damage resulting from
negligence, accident, unreasonable use, abuse or misuse, exceeding data plate capacities or altering the product
without Presto Lifts authorization.
Presto Lifts expressly disclaims and excludes any liability for consequential, incidental, indirect or punitive dam-
ages or nancial loss to people or property resulting from any breach of warranty or the operation or failure of
this product.
Presto Lifts makes no representation that this product complies with local, state, or federal safety/product stan-
dards codes. Should this product fail to comply in any way with those codes, it shall not be considered a defect
of materials or workmanship. Presto Lifts shall not be held liable for any damages resulting from noncompliance.
It is the dealer's responsibility to exercise this limited warranty. This limited warranty is provided to the original
purchaser (dened as the original end user) and is nontransferable. This constitutes the complete and nal agree-
ment involving Presto Lifts and limited warranty obligations for products.

LET PRESTO MEET THOSE NEEDS!
MANY NEEDS REQUIRE MANY OPTIONS...
