Owner’s Manual

www.pridemobility.com Jazzy 610
SAFETY GUIDELINES
Copyright©2006
PrideMobilityProductsCorp.
INFMANU2897/RevC/January2006
Thesymbolsbelow areusedthroughoutthis owner'smanualandon thepowerchair toidentifywarningsand important
information.Itisveryimportant foryoutoreadthem andunderstandthemcompletely.
WARNING! Failure to follow designated procedures can cause either personal injury, component
damage, or malfunction (black symbol on yellow triangle with black border).
MANDATORY! These actions should be performed as specified. Failure to perform mandatory
actions can cause injury to personnel and/or damage to equipment (white symbol on blue dot).
PROHIBITED! These actions should be prohibited. These actions should not be performed at any
time or in any circumstances. Performing a prohibited action can cause injury to personnel and/
or damage to equipment (black symbol with red circle and red slash).

Jazzy 610 www.pridemobility.com 3
I. INTRODUCTION....................................................................................................................................4
II. SAFETY....................................................................................................................................................6
III. YOUR POWER CHAIR.......................................................................................................................15
IV. ASSEMBLY............................................................................................................................................20
V. COMFORT ADJUSTMENTS...........................................................................................................22
VI. BATTERIES AND CHARGING .......................................................................................................28
VII. OPERATION..........................................................................................................................................32
VIII.CARE AND MAINTENANCE ...........................................................................................................39
IX. WARRANTY...........................................................................................................................................45
CONTENTS
Thisowner’smanualiscompiledfromthelatestspecificationsandproductinformationavailableatthetimeofpublication.
Wereservetherighttomakechangesasthey become necessary.Any changes toourproductsmaycause slight variations
betweentheillustrationsandexplanationsin this manualandtheproductyouhave purchased.

4 www.pridemobility.com Jazzy 610
I. INTRODUCTION
SAFETY
WELCOMEto Pride Mobility Products Corporation(Pride). The powerchair you have purchased combines state-of-
the-artcomponentswithsafety,comfort,andstylinginmind.Weareconfidentthatthesedesign features will provide you
withthe conveniencesyou expect during your dailyactivities. Onceyou understand how tosafely operate and care for
yourpowerchair,it should giveyou yearsoftrouble freeoperationand service.
Readandfollowallinstructions, warnings, andnotesinthismanualbeforeattemptingtooperateyourpower chair for the
first time. Inaddition, your safetydepends upon you, as well as yourprovider,caretaker,orhealthcare professional in
usinggoodjudgement.
Ifthereisanyinformation inthismanualwhich you donotunderstand,or if yourequireadditionalassistance forsetupor
operation,please contact your authorized Pride Provider.Failuretofollowtheinstructionsinthismanualand those
locatedonyourpowerchaircanleadtopersonal injuryand/ordamagetothepowerchair,includingvoidingthe
warranty.
PURCHASER’S AGREEMENT
Byaccepting delivery ofthis product, youpromise that youwill not change,alter,or modify thisproduct or removeor
renderinoperableorunsafeanyguards,shields,orothersafetyfeatures of this product; fail, refuse, or neglect to installany
retrofitkits from time to time provided byPride toenhance orpreserve thesafe useof thisproduct.
INFORMATION EXCHANGE
Wewanttohearyourquestions,comments,andsuggestionsaboutthismanual.Wewouldalsoliketohearaboutthesafety
andreliabilityof your newpowerchair,and about theserviceyou receivedfromyour authorizedPrideProvider.
Please notify us of any change of address, so we can keep you apprised of important information about safety, new
products,and new optionsthat canincrease yourability touse andenjoy your powerchair.Please feelfree tocontact us
atthe addressbelow:
PrideMobilityProductsCorporation
Attn:CustomerCareDepartment
182SusquehannaAvenue
Exeter, PA18643-2694
[e-mail]
800-424-8205
NOTE: If you ever lose or misplace your product registration card or your copy of this manual, contact us and
we will be glad to send you a new one immediately.

Jazzy 610 www.pridemobility.com 5
I. INTRODUCTION
PRIDE OWNERS CLUB
Asanowner ofa Prideproduct, you areinvited toregister yourproduct’swarrantyand enrollin thePride Owners Club.
You may do so by filling out and returning your enclosed product registration card or by visiting Pride's web site at
www.pridemobility.com.Asaregisteredmember,eachtimeyouvisitour site, you willhaveaccesstothemostinteractive
andhonesteducationalvenueavailabletodayforpeoplewithmobilityneeds,theirfamilies,andfriends.
Fromourhome page, select“OwnersClub” toentera page dedicatedtocurrent andpotentialPride product owners.You
willgainaccesstointerviews, stories, recreationideas,dailylivingtips, productandfundinginformation,and interactive
messageboards.Thesemessage boardsinviteyouto communicatewithotherPride customersaswellas Priderepresen-
tativeswhoare available toassist you withany questions orconcernsyou mayhave.
MyAuthorizedPrideProvider:
Name:_____________________________________________________________________________________
Address:___________________________________________________________________________________
Phone Number:______________________________________________________________________________
PurchaseDate:_______________________________________________________________________________

6 www.pridemobility.com Jazzy 610
II. SAFETY
Corrosive chemicals contained in battery. Use only AGM or Gel-Cell batteries to
reduce the risk of leakage or explosive conditions.
Read and follow the information in the owner’s manual.
Maximum seating weight.
Locked and in drive mode.
Place unit on level ground and stand behind or to one side when changing from
drive mode to freewheel mode or freewheel mode to drive mode.
Unlocked and in freewheel mode.
Battery Configuration:
TT
TT
T = Terminal Post
Connect Red wire to TT
TT
T with ++
++
+
Connect Black wire to TT
TT
T with ––
––
–
PRODUCT SAFETY SYMBOLS
Thesymbolsbelowareusedonthepower chair toidentifywarnings,mandatoryactions,andprohibited actions. Itisvery
importantforyouto readandunderstand them completely.

Jazzy 610 www.pridemobility.com 7
II. SAFETY
Do not use a cell phone, walkie/talkie, laptop, or other radio transmitter while operating.
Avoid exposure to rain, snow, ice, salt, or standing water whenever possible. Maintain and
store in a clean and dry condition.
Removal of grounding prong can create electrical hazard. If necessary, properly install
an approved 3-pronged adapter to an electrical outlet having 2-pronged plug access. Failure
to heed could result in personal injury and/or property damage.
Prevent personal injury and equipment damage. Do not connect an extension cord to the
AC/DC converter or the battery charger.
EMI-RFI - This product has been tested and passed at an immunity level of 20 V/m.

8 www.pridemobility.com Jazzy 610
II. SAFETY
SAFETY
MANDATORY! Do not operate your new power chair for the first time without completely reading
and understanding this owner’s manual.
Your powerchairis a state-of-the-artlife-enhancementdevicedesignedtoincrease mobility.Prideprovidesan extensive
varietyof products to best fit the individual needs of the power chair user. Please be aware that the final selection and
purchasing decision regarding the type of power chair to be used is the responsibility of the power chair user, who is
capableofmakingsuch adecision,andhis/her healthcareprofessional(i.e., medical doctor,physicaltherapist,etc.).
Thecontentsofthis manualarebasedon theexpectationthat a mobilitydeviceexpert has properlyfittedthe powerchair
totheuserand has assistedtheprescribing healthcare professionaland/ortheauthorized PrideProviderinthe instruction
processfor the use ofthe product.
Therearecertain situations, includingsomemedicalconditions,wherethepowerchairuserwillneedtopracticeoperating
the power chair in the presence of a trained attendant.Atrained attendant can be defined as a family member or care
professionalspeciallytrainedinassistingapowerchairuserinvariousdailylivingactivities.
Asyoubeginusingyour power chair duringdailyactivities,youwillprobablyencountersituationsinwhichyouwillneed
somepractice.Simplytakeyourtimeandyouwillsoonbeinfullandconfidentcontrolasyoumaneuverthroughdoorways,
onand offof elevators, upand downramps, and overmoderate terrain.
Belowaresomeprecautions,tips,and other safetyconsiderationsthatwillhelp the userbecomeaccustomedtooperating
thepowerchairsafely.
Modifications
Pridehasdesigned andengineeredyourpowerchairtoprovidemaximummobilityandutility.Awiderangeofaccessories
isavailable fromyour authorized PrideProvider to further customize yourpower chair to better suityour needs and/or
preferences.However,underno circumstances shouldyou modify,add, remove,or disable anyfeature, part, orfunction
ofyourpower chair.
WARNING! Do not modify your power chair in any way not authorized by Pride. Unauthorized
modifications may result in personal injury and/or damage to your power chair.
Pre-Ride Safety Check
Getto knowthe feelof yourpower chairand its capabilities. Pride recommends that youperform asafety checkbefore
eachuse tomake sureyour powerchair operatessmoothly andsafely.
Performthefollowinginspectionspriortousingyour power chair:
!Checkforpropertireinflation.Maintainbutdonotexceed35psi(2.4bar)ineachtire(ifequippedwithpneumatictires).
!Checkall electrical connections.Make surethey aretight andnot corroded.
!Checkall controllerconnections to thepower base. Make sure theyare secured properly.
!Checkthe brakes. SeeVIII. “Care and Maintenance.”
!Checkbattery charge. SeeVI. “Batteriesand Charging.”
NOTE: If you discover a problem, contact your authorized Pride Provider for assistance.

Jazzy 610 www.pridemobility.com 9
II. SAFETY
Weight Limitations
Yourpowerchair isratedforamaximum weightcapacity.Please refer tothespecificationstable for thislimit.
WARNING! Exceeding the weight capacity voids your warranty and may result in personal injury
and/or damage to your power chair. Pride will not be held responsible for injuries and/or property
damage resulting from failure to observe weight limitations.
WARNING! Do not carry passengers on your power chair. Carrying passengers on your power
chair may result in personal injury and/or property damage.
Tire Inflation
Ifyourpowerchairis equipped withpneumatictires,youshould checkorhavetheair pressure checkedregularly. Proper
inflationpressureswillprolongthe life ofyourtiresandhelp ensurethesmoothoperationof your powerchair.
WARNING! It is important that 35 psi (2.4 bar) tire pressure be maintained in pneumatic tires at all
times. Do not underinflate or overinflate your tires. Low pressure may result in loss of control, and
overinflated tires may burst. Failure to maintain 35 psi (2.4 bar) tire pressure in pneumatic tires at
all times may result in tire and/or wheel failure, causing serious personal injury and/or damage to
your power chair.
WARNING! Inflate your power chair drive tires from a regulated air source with an available pressure
gauge. Inflating your tires from an unregulated air source could overinflate them, resulting in a
burst tire and/or personal injury.
Incline Information
Moreandmorebuildingshaverampswithspecifieddegreesofinclination,designedforeasyandsafe access.Someramps
mayhaveturning switchbacks (180-degreeturns) that requireyouto havegoodcornering skillsonyour powerchair.
!Proceedwith extreme caution as you approach the downgrade of a ramp or other incline.
!Take wideswingswithyourpowerchair’sfrontwheelsaroundanytightcorners. If youdothat,thepowerchair’srear
wheelswillfollow awidearc, notcut the cornershort, andnotbump intoorget hungup on anyrailing corners.
!When driving down a ramp, keep the power chair’s speed adjustment set to the slowest speed setting to ensure a
safelycontrolleddescent. SeeVII.“Operation.”
!Avoid sudden stopsand starts.
Whenclimbinganincline, try tokeepyourpowerchairmoving.Ifyoumuststop,startupagainslowlyandthenaccelerate
cautiously.Whendriving downan incline,set yourpower chairto theslowest settingand drivein theforward direction
only. If your power chair starts to move down the incline faster than you anticipated or desired, allow it to come to a
completestopbyreleasing thejoystick,then push thejoystickforward slightlytoensurea safelycontrolleddescent.
WARNING! When climbing an incline, do not zigzag or drive at an angle up the face of the incline.
Drive your power chair straight up the incline. This greatly reduces the possibility of a tip or a fall.
Always exercise extreme caution when negotiating an incline.
WARNING! You should not travel up or down a potentially hazardous incline (i.e., areas covered
with snow, ice, cut grass, or wet leaves).
WARNING! When on any sort of an incline or decline, never place the power chair in freewheel
mode while seated on it or standing next to it. Doing so may result in personal injury and/or
damage to your power chair.
WARNING! Never travel down an incline backwards. This may result in personal injury.

10 www.pridemobility.com Jazzy 610
II. SAFETY
Figure 1. Maximum Safe Slope (Ascending and Descending)
WARNING! Even though your power chair is capable of climbing slopes greater than those illustrated in
figure 1, do not, under any circumstances, exceed the incline guidelines or any other specifications
presented in this manual. Doing so could cause instability in your power chair, resulting in personal injury
and/or damage to your power chair.
Incompliancewith theAmericanswith DisabilitiesActof 1990,all handicap publicaccess rampsarerequired tohave a
maximumslopeof 5°(8.7%). Therefore, Priderecommends thatthemaximum slopeof an inclineyou attemptto safely
ascend or descend on your power chair does not exceed 5° (8.7%). See figure 1.
WARNING! Any attempt to climb or descend a slope steeper than 5° (8.7%) may put your power
chair in an unstable position and cause it to tip, resulting in personal injury.
Braking Information
Yourpower chair isequipped with twopowerful brake systems:
1. Regenerative— uses electricitytorapidlyslow thevehiclewhenthe joystickreturnstothe center/stopposition.
2. DiscParkBrake—activates mechanically after regenerativebrakingslowsthevehicletonearstop,orwhenpoweris
removedfromthe system forany reason.
Cornering Information
Whileyourpowerchairisequippedwithfourcasterwheels,excessivelyhighcorneringspeedscanstill createthepossibil-
ityoftipping.Factorswhichaffectthepossibilityoftippinginclude,butare not limited to:corneringspeed,steeringangle
(howsharplyyouareturning), uneven roadsurfaces,inclinedroad surfaces, ridingfromanarea of lowtractiontoan area
ofhigh traction (such as passingfrom agrassy areato apaved area– especiallyat highspeed whileturning), and abrupt
directionalchanges. Highcornering speedsare notrecommended. If you feel thatyou maytip overin a corner, reduce
your speed and steering angle (i.e., lessen the sharpness of the turn) to prevent your power chair from tipping.
WARNING! When cornering sharply, reduce your speed. This greatly reduces the possibility of a
tip or fall. To avoid personal injury and/or property damage, always exercise common sense when
cornering.
Public Streets and Roadways
WARNING! You should not operate your power chair on public streets and roadways. Be aware
that it may be difficult for traffic to see you when you are seated on your power chair. Obey all
local pedestrian traffic rules. Wait until your path is clear of traffic, and then proceed with extreme
caution.
Preventing Unintended Movement
WARNING! If you anticipate being seated in a stationary position for an extended period of time,
turn off the power. This will prevent unexpected motion from inadvertent joystick contact. This
will also eliminate the possibility of unintended chair movement from electromagnetic (EM) sources.
Failure to do so may result in personal injury.
5 (8.7%)

Jazzy 610 www.pridemobility.com 11
II. SAFETY
Freewheel Mode
Yourpowerchairisequippedwith two manualfreewheelleverstoallowformanualmaneuverabilitybyatrainedattendant.
Formoreinformationabouthowtoplaceyourpowerchairintoandoutoffreewheelmode,seeIII.“YourPower Chair.”
WARNING! Do not use your power chair in freewheel mode without an attendant present. Personal
injury may result.
WARNING! Do not attempt to personally place your power chair in freewheel mode while seated
on it. Personal injury may result. Ask an attendant for assistance if necessary.
WARNING! Do not place your power chair in freewheel mode while on an incline. The chair could
roll uncontrollably on its own, causing personal injury.
Outdoor Driving Surfaces
Yourpowerchairisdesignedtoprovideoptimumstabilityundernormaldrivingconditions—dry,levelsurfacescomposed
ofconcrete,blacktop,orasphalt. However,Priderecognizesthattherewillbetimeswhenyouwillencounterothersurface
types.For thisreason, yourpower chairis designedto performadmirably onpacked soil, grass, and gravel. Feel free to
useyour powerchair safelyon lawnsand inpark areas.
!Reduceyourpower chair’sspeedwhendriving onuneven terrain and/orsoft surfaces.
!Avoidtallgrassthatcanentanglethe running gear.
!Avoidloosely packed graveland sand.
!Ifyoufeelunsureabout adrivingsurface,avoid that surface.
Stationary Obstacles (Steps, Curbs, etc.)
Proceedwith extreme caution when drivingnear raised surfaces,unprotected ledges and/ordrop-offs (curbs, porches,
stairs,etc.).The correctmethodfor approachingacurb isillustrated in figure2.
WARNING! Do not attempt to have your power chair climb or descend an obstacle that is higher
than 2 inches unless you have the assistance of an attendant.
WARNING! Do not attempt to have your power chair proceed backwards down any step, curb, or
other obstacle. This may cause the power chair to tip and cause personal injury.
Figure 2. Correct Curb Approach Figure 3. Incorrect Curb Approach
Stairs and Escalators
Powerchairs arenot designed totravel upor down stairsor escalators.Alwaysusean elevator.
WARNING! Never use your power chair to negotiate steps or escalators. You may cause injury to
yourself and to others and/or damage your power chair.

12 www.pridemobility.com Jazzy 610
II. SAFETY
Transfers
Transferring onto and off of your power chair requires a
goodsenseofbalance.Alwayshaveanattendantorhealth-
careprofessionalpresent whilelearningto properlytrans-
feryourself.
Toeliminatethepossibilityofinjury,Priderecommendsthat
youor a trained attendant perform the following tasks be-
foreattemptingatransfer:
!Turnoffthepowertothecontroller.SeeVII.“Operation.”
!Ensureyourpowerchairisnotinfreewheel mode.See
III.“YourPowerChair.”
!Turnthefront casterwheels towardthe transferdesti-
nationtoimprovepowerchairstabilityduring transfer.
!Make sure both armrests are flipped up or removed
fromyourpowerchair.
!Flip up the foot platform or move the leg rests aside;
thiswill help to keep yourfeet fromgetting caughton
thefootriggingduringthetransfer.
!Reducethedistancebetweenyourpowerchairand the
objectyouare transferring onto.
WARNING! Before transferring, position yourself as far back as possible in the power chair seat
to prevent the power chair from tipping forward during transfer and causing injury.
WARNING! Avoid using your armrests for weight bearing purposes. Such use may cause the power
chair to tip and cause personal injury.
WARNING! Avoid putting all of your weight on the foot rigging. Such use may cause the power
chair to tip and cause personal injury.
Doors
!Determineif the door opens towardor awayfrom you.
!Driveyourpowerchairgentlyandslowlyforward to pushthedooropen.Ordriveyour power chairgentlyandslowly
backwardsto pull the dooropen.
Elevators
Modernelevators havea dooredge safetymechanism that,when pushed,reopens theelevator door(s).
!Ifyou are inthe doorway ofan elevator whenthe door(s) beginto close, pushon the rubberdoor edge orallow the
rubberdoor edge to contactthe power chair and the door will reopen.
!Usecare that pocketbooks, packages, or power chair accessories do not become caught in elevator doors.
Lift/Elevation Products
Ifyouwillbetravelingwithyourpowerchair,youmay find itnecessarytousealift/elevationproducttoaidintransporta-
tion.Pride recommendsthat you closely review theinstructions, specifications, and safety informationset forth by the
manufacturerofthelift/elevationproductbeforeusingthatproduct.
Figure 4. IdealTransfer Position

Jazzy 610 www.pridemobility.com 13
II. SAFETY
Inclement Weather Precautions
Exposureofyourpower chair toinclementweather conditions shouldbeavoidedwhenever possible.Ifsuddenlycaught
up in rain, snow, severe cold, or heat while operating your power chair proceed to shelter at the earliest opportunity.
Thoroughlydryyourpower chair beforestoring,charging,or operatingyourpower chair.
WARNING! Operating in rain, snow, salt, mist/spray conditions, and on icy/slippery surfaces can
cause personal injury and/or damage to the power chair and electrical system. Maintain and store
your power chair in a dry and clean condition.
Motor Vehicle Transport
Priderecommendsthatyou do notremainseatedin yourpowerchairwhile traveling inamotorvehicle. Thepowerchair
shouldbe stowed inthe trunk of a car or inthe back ofa truck or van with the batteriesremoved and properlysecured.
WARNING! Do not sit on your power chair while it is in a moving vehicle. Personal injury and/or
property damage may result.
WARNING! Always be sure your power chair and its batteries are properly secured when it is being
transported. Failure to do so may result in personal injury and/or damage to your power chair.
Positioning Belts
Yourauthorized PrideProvider,therapist(s),and otherhealthcareprofessionals areresponsiblefor determiningyour re-
quirementfora positioning beltin order tooperate your powerchairsafely.
WARNING! If you require a positioning belt to safely operate your power chair, make sure it is
fastened securely. Serious personal injury may result if you fall from the power chair.
WARNING! The positioning belt is not designed for use as a seat belt in a motor vehicle. Nor is
your power chair suitable for use as a seat in any vehicle. Anyone traveling in a vehicle should be
properly belted into seats approved by the vehicle manufacturer.
Reaching and Bending
Neverreach,lean,orbendwhiledrivingyour power chair.Ifitis absolutely necessarytoreach,lean,orbendwhile seated
onyour power chair, itis important to maintaina stable center ofgravity and keep the power chair from tipping. Pride
recommendsthat the powerchair user determine his/her personal limitations and practice bending and reaching in the
presenceofaqualifiedhealthcareprofessional.
WARNING! Do not bend, lean, or reach for objects if you have to pick them up from the floor by
reaching down between your knees. Movements such as these may change your center of gravity
and the weight distribution of the power chair. This may cause your power chair to tip, possibly
resulting in personal injury.
WARNING! Prevent personal injury! Keep your hands away from the tires when driving. Be aware
that loose fitting clothing can become caught in drive tires.
Batteries
In addition to following the warnings below, be sure to comply with all other battery handling information. For more
informationaboutyourpower chair’s batteries,seeVI. “Batteries andCharging.”
WARNING! Power chair batteries are heavy. See specifications table. If you are unable to lift that
much weight, be sure to get help. Lifting beyond your capacity can result in personal injury.

14 www.pridemobility.com Jazzy 610
II. SAFETY
WARNING! Battery posts, terminals, and related accessories contain lead and lead compounds.
Wash hands after handling.
WARNING! Always protect the batteries from freezing and never charge a frozen battery. Charging
a frozen battery may result in personal injury and/or damage to the battery.
Removable Parts
WARNING! Do not attempt to lift or move a power chair by any of its removable parts. Personal
injury and/or damage to the power chair may result.
Prescription Drugs/Physical Limitations
Usersmustexercisecareandcommonsensewhenoperatingapowerchair.Thisincludesawarenessofsafetyissueswhen
takingprescribedorover-the-counterdrugs orwhentheuser has specificphysicallimitations.
WARNING! Consult your physician if you are taking prescribed or over-the-counter medication or
if you have certain physical limitations. Some medications and limitations may impair your ability
to operate your power chair in a safe manner.
Alcohol
Thepowerchairusermustexercisecareandcommon sense whenoperatinghis/herpowerchair.Thisincludes awareness
ofsafetyissues whileundertheinfluenceofalcohol.
WARNING! Do not operate your power chair while you are under the influence of alcohol, as this
may impair your ability to operate your power chair in a safe manner.
Electromagnetic and Radio Frequency Interference (EMI/RFI)
WARNING! Laboratory tests have shown that electromagnetic and radio frequency waves can
have an adverse affect on the performance of electrically-powered mobility vehicles.
Electromagneticand Radio Frequency Interference can come from sources such as cellular phones, mobile two-way
radios(suchas walkie-talkies),radio stations,TV stations, amateurradio (HAM)transmitters, wirelesscomputerlinks,
microwavesignals, paging transmitters, and medium-rangemobile transceivers usedby emergency vehicles. In some
cases,thesewavescancause unintended movement ordamagetothecontrolsystem.Everyelectrically-poweredmobility
vehiclehasanimmunity(orresistance)toEMI.Thehighertheimmunitylevel,thegreatertheprotectionagainstEMI.This
producthas beentested andhas passedat animmunity levelof 20V/m.
WARNING! Be aware that cell phones, two-way radios, laptops, and other types of radio transmitters
may cause unintended movement of your electrically-powered mobility vehicle due to EMI.
Exercise caution when using any of these items while operating your mobility vehicle and avoid
coming into close proximity of radio and TV stations.
WARNING! The addition of accessories or components to the electrically-powered mobility vehicle
can increase the susceptibility of the vehicle to EMI. Do not modify your power chair in any way
not authorized by Pride.
WARNING! The electrically-powered mobility vehicle itself can disturb the performance of other
electrical devices located nearby, such as alarm systems.
NOTE: For further information on EMI/RFI, go to the Resource Center on www.pridemobility.com. If unin-
tended motion or brake release occurs, turn your power chair off as soon as it is safe to do so. Call Pride at 800-
424-8205 to report the incident.

Jazzy 610 www.pridemobility.com 15
III. YOUR POWER CHAIR
THE JAZZY 610
TheJazzy610has twomainassemblies: the seatassemblyand the powerbaseassembly.See figure 5.Typically, the seat
assemblyincludesthearmrests,seatback, and seatbase.Thepowerbase assembly includestwomotor/brakeassemblies,
twodrive wheels,four casterwheels, twobatteries, andwiring harnesses.See figure 5, 6, and 7.
SEATBACK
REAR
SHROUD
DRIVE WHEEL
CASTER WHEEL
Figure 5.The Jazzy 610
POWERBASE
ASSEMBLY
SEAT ASSEMBLY
JOYSTICK
FOOTRIGGING
(FOOT PLATFORM SHOWN)
SEATBASE
ARMRESTS
CONTROLLER
(VSI SHOWN)
CASTER WHEEL

16 www.pridemobility.com Jazzy 610
III. YOUR POWER CHAIR
JAZZY610SPECIFICATIONS
Suspension: Active-TracExtreme(ATX)
DriveWheels: 10in.,pneumatic(10in.solidoptional)
FrontCasterWheels: 5in.,solid
RearCasterWheels: 6in., solid
MaximumSpeed:¹ Upto4mph
Brakes: “IntelligentBraking”electronicregenerative,discparkbrake
GroundClearance:² 2.125in.
TurningRadius:² 21.25in.
OverallSize:² Length:39in.(withfootplatform)
Width:23.25in.
SeatingOptions: Medium-backSeat(standard)
LimitedReclineHigh-BackSeat(optional)
FullReclineHigh-backSeat(optional)
PowerElevatingSeat(optional)
Drivetrain: Twomotor, mid-wheeldrive
Batteries:³ Two12-volt,U-1batteries
BatteryCharger: 4-amp,onboard(standard)
4-amponboard/5-ampoff-boardcombo(optional)
Electronics: 50-ampPGDrivesVSIController(standard)
75-ampDynamicFLIGHTController (optional)
WeightCapacity: 300lbs.
ComponentWeights: Base:108.5lbs.(withoutseatandbatteries)
Medium-backSeat:37lbs.
Batteries:25.5lbs.each
¹Varieswith userweight,terraintype, battery amphourrating (AH), batterycharge,battery condition, andtirecondition.
²Duetomanufacturingtolerancesand continued productimprovement,thisspecificationcan be subjecttovarianceof
(+ or – ) 3%.
³AGMor Gel-Cell typerecommended.
NOTE: All specifications subject to change without notice.

Jazzy 610 www.pridemobility.com 17
III. YOUR POWER CHAIR
ELECTRICAL COMPONENTS
Theelectrical components are located insidethe power base. The ammeterand the charger power cordreceptacle are
located on the right side of the power base. The main circuit breaker is located on the front of the battery tray. The
controllerconnector(s) arelocated insidethe powerbase. Seefigure 7.
Ammeter:The ammeter displaysthe charger’scurrent output inamps. See VI.“Batteriesand Charging.”
ChargerPowerCordReceptacle:This iswherethechargerpowercordplugsinto theonboardbattery charger.SeeVI.
“BatteriesandCharging.”
MotorConnectors: This iswhere thecontroller connectsto themotors.
BatteryConnector: This iswhere thecontroller connectsto thebatteries.
Figure 6.The Jazzy 610 Power Base
MOTOR/BRAKEASSEMBLY
REARSHROUDFASTENERS
TRAPEZEBARS
FRONT COVER

18 www.pridemobility.com Jazzy 610
III. YOUR POWER CHAIR
ChargerInhibit Connector:The charger inhibitenables the onboard battery charger to disable the controller during
charging.SeeVII.“Operation.”
ControllerConnector: This iswhere thecontroller connectsto thepower base.
MainCircuitBreaker:Themaincircuitbreakeris a safety feature built intoyourpowerchair.Whenthebatteriesandthe
motorsareheavilystrained(e.g.,fromexcessiveloads),themaincircuitbreakertripstopreventdamagetothemotorsand
theelectronics.Ifthecircuittrips,allowyourpowerchair to “rest”forapproximatelyoneminute.Next,pushinthe circuit
breakerbutton,turn on thecontroller,and continue normaloperation.If themaincircuit breakercontinuesto triprepeat-
edly,contactyour authorizedPrideProvider.
Figure 7. Jazzy 610 Electrical Components
BATTERY
CONNECTOR
CHARGERPOWER
CORDRECEPTACLE
CHARGERCIRCUITFUSE
ONBOARD BATTERY
CHARGER
MAINCIRCUITBREAKER
AMMETER
FLIGHTPOWERMODULE
MOTOR
CONNECTORS
CHARGERINHIBITCONNECTOR
BATTERY
CONNECTOR
VSI CONTROLLER
CONTROLLER CONNECTOR
MOTOR
CONNECTORS

Jazzy 610 www.pridemobility.com 19
MANUAL FREEWHEEL LEVERS
TheJazzy 610has amanual freewheellever oneach motor.Manualfreewheel leversenable youto disengagethe drive
motorsfromthegearboxesandmaneuverthechairmanually.
WARNING! Do not use the power chair while the drive motors are disengaged! Do not disengage
the drive motors when the power chair is on an incline, as the unit could roll on its own, causing
injury!
To engage or disengage the drive motors:
1. Locatethe lever ontop of eachmotor.
2. Pushthe two leversinward toengage thedrive motors.See figure8.
3. Pullthe twoleversoutward todisengage thedrive motors. Seefigure 9.
Ifalever is difficulttomoveineitherdirection,slightlyrockthepowerchairbackandforth.Thelevershouldthenmoveto
thedesiredposition.
WARNING! It is important to remember that when your power chair is in freewheel mode, the
braking system is disengaged.
III. YOUR POWER CHAIR
Figure 9. Freewheel Mode (Drive Disengaged)Figure 8. Drive Mode (Drive Engaged)
MANUALFREEWHEELLEVER
MANUALFREEWHEELLEVER

20 www.pridemobility.com Jazzy 610
INITIAL ASSEMBLY
Yourpowerchairmayrequiresomeassemblyeitherbeforeinitialuseoraftertransportation.Itmayalsorequiredisassembly
tomakesomecomfortadjustments.Figure10detailsthosepartsofthepowerchairthataredesignedtobedisassembledand
assembledbyanenduserorbyaqualifiedcaregiverbeforeusingtheproductormakingcomfortadjustments.
IV. ASSEMBLY
ARMRESTANGLE ADJUSTMENT
SEAT INSTALLATION
ARMREST WIDTH ADJUSTMENT
Figure 10. Jazzy 610 AssemblyView
FOOT PLATFORM HEIGHT/DEPTH ADJUSTMENT
SEATHEIGHT/ANGLEADJUSTMENT
CONTROLLER POSITION
FOOT PLATFORM
ANGLEADJUSTMENT
NOTE: Any nylon insert lock nut removed during the disassembly or adjustment of the power chair must be
replaced with a new nut. Nylon insert lock nuts should not be reused as it may cause damage to the nylon
insert, resulting in a less secure fit. Replacement nylon insert lock nuts are available at local hardware stores
or through your authorized Pride Provider.
