PrimeKinetix MyoStim 2 User manual

Read entire manual before operating this product,Use only as directed.
PrimeKinetix
Austin Tx
877-215-1124
User manual
MyoStim-2
TM
TM

Contents
Please read carefully {CAUTIONS ON SAFETY} and use it correctly.
After reading, be sure to save it for later reading.
In order to make sure that the person who borrowed it can use the product safely,
please forward this manual.
In order to use the product safely and correctly, the following symbols are also
used in this manual and in the product:
warning Failure to observe this symbol may result in
serious injury or death.
warning Failure to observe this symbol may result in
personal injury or property damage.
Note
note
symbols Detailed
Prohibit.
Must be implemented.
Security Considerations
01
02
02
03
04
05
05
06
06
07
08
09
09
10
Security Considerations
Warnings
Precautions
Compulsory Compliance
User Suitability
Parts Included
Functional Area Description
Sticker Operation Instructions
Charging Instructions
Massage Host Operation Istructions
Using
Cleaning And Storage
Parameter
Troubleshooting
02
Warnings
Do not use wet hands.
Keep the product dry, prohibited in the bathroom and humid
environments.
Acupuncture is prohibited.
Prohibited when the power is turned on, peeling the gel or touch
the gel, otherwise you will be feel strongly stimulated.
Do not put the goods into fire or get wet.
Please replace the gel pads when the power is off, please dry
the hands before using the product to prevent failure, burns,
electric shock.
Do not store in direct sunlight. Do not store in dusty places.
Do not store at high temperature. Do not store at high humidity.
Please do not put it into the water to get it wet.
Precautions
Turn off the power after use, and then removed from the
human body.
When using, please take off your body glasses, rings, watches
and other metal items.
This goods is only use for home, please do not use for business
purposes.
01

Pad holder
Functional Area Description
Parts Included
04
Control unit USB cable
Gel pad
PVC carry bag
Control Area Conductive Region
1 2
34
1.Peel off the blue plastic film from one side of the enclosed electrode gel
pad.
2.And follow the schematic to install the electrode gel pad onto the back
side of the control unit.
3. Please keep the gel pad flat to the machine.
4. Peel off the transparent plastic film can be used
(note: Please try to avoi d the gel pad sticky crooked, wrinkles and have the bubbles, if there is
bubble inside, please squeeze the bubbles outside the gel)
Charging Instructions
Before use, it is recommended to charge the EMS device with the enclosed
USB cable, which could connect to the computer or the adaptor.
When charging, the light will
flash, and when the battery is
full, the light will be
consistent on.
Sticker Operation Instructions
03

Compulsory Compliance
06
This goods is only use for home, please do not use for business
purposes.
If the units have unusual smell, sound or delay, please
immediately turn off the power, and contact the sales staff.
Do not use on face.
Replace the gel pads when the power is turned off. Please dry
the hands before using the units to prevent malfunction, burns,
electric shock.
Do not disassemble, install or repair.
Prohibited when the power is turned on, peeling the gel or touch
the gel, otherwise you will be feel strongly stimulated.
DO NOT use this device on children or speech impaired.
DO NOT use this device while driving or operating machinery.
DO NOT use this device while sleeping.
Turn off the unit before charging.
Disassemble the unit and dispose of it when it is discarded.
User Suitability
Please do not use the device if you have the
following conditions：
Do not use this device if you have a cardiac pacemaker, implanted
defibrillator, or other implanted metallic or electronic devices.
Do not place this device over your neck.
Do not place this device across your chest.
Do not use this device during pregnancy.
Do not use this device on children.
Do not place this device over the carotid sinus nerves, the front of the
neck, or around the mouth.
Do not open unit. Opening will void warranty.
Do not use this device over, or in proximity to, cancerous lesions.
Do not place device over open wounds, sores, or rashes, or over
swollen, red, infected, or inflamed areas or skin eruptions (e.g.,
phlebitis, thrombosis, varicose veins).
Do not use this device when in bath or shower.
Do not use this device while sleeping.
Do not use this device while driving or operating machinery.
Do not use this device in the presence of electromagnetic fields.
Do not use this device if unit has been damaged.
Do not use on children or pets.
Do not use in an area where water or moisture can get on the unit, such
as a bathroom or other places with high humidity.
05

Massage Host Operation Istructions
08
LED light
Increase the
intensity ON/OFF
Reduce the
intensity
Press the ON / OFF button to start the unit, buzzing will be on with LED
lighting once. Press the ON / OFF button to turn off the unit, buzzing will be
on with LED lighting three times.
Press the "+" or "-" button to adjust the intensity, the output intensity total
have 15 levels, when the unit is turned on, the intensity is on 1 level, the
buzzing will be on with LED lighting once when you adjust the intensity.
And the buzzer will be sounded twice when it's in the strongest intensity or
lowest intensity.
When the unit leave the skin(The unit is turn on), the buzzing will be on with
LED Lighting to remind you, when the unit returns on the skin again, the
intensity will return to 1 level.
Using
Before use, please take the body parts to clean and keep dry, then Peel
off the surface of the transparent isolation film. Place the EMS device
onto the treatment areas (such as the back, shoulders, arms, legs, etc.)
and Press down firmly and ensure a full and firm contact with skin.
First use, please start from the low intensity, and then gradually increase
the intensity
Please charge in time, if the buzzing weakens, the current intensity
decreases, or the indicator light color is dimmed, the use of sudden
shutdown means that the battery is lower.
Turn off the power after use, and then removed from the human body.
After use, the product will be affixed to the Pad holder and stored in the
PVC carry bag, to prevent the gel dirty or dry.
The electrode gel pads are disposable, such as the use of 20 minutes
each time, about 30 times can be used,(which will vary and depend on
the frequency of use. Avoid touching the adhesive area of pads with
fingertips, the grease on which will shorten the pad lifespan.) The gel
pads should be replaced when they lose their adhesiveness. Keeping
pads clean will extend their lifespan.
Tips
07

Cleaning And Storage
When cleaning, please use a dry cloth, or a damp cloth with a small amount
of soapy water.
Do not allow the control unit to get wet
Do not use detergent.
Do not use sharp objects such as nails or
brushes.
Do not wash in water.
Do not rub during cleaning.
Do not stick two pieces of gel together.
Keep away from direct sunlight and keep
it ventilated.
Do not use other chemicals, such as
alcohol, banana water.
After use, dip a little water on the fingers, stroking stickers surface for
cleaning.
Parameter
Power rechargeable Lithium
battery Material The silicone
Outp ut Voltage
(Max V pp) 55V at 500ΩSize
Pulse width 50-100μSWeight
Frequency 1-100Hz
Other Lone combine mode, with 7 different massage programs
Adjustable intensity of 15 levels Countdown timer of 20 min
10
9
155x54x10mm
Troubleshooting
It does not matter
to use every day?
The same place do not use more than once
a day.
Can be used
continuously?
Do not use more than 20 minutes for the
same part.
Which parts can
not be used?
heart, wound, nevus, vein, mouth, genitals,
face, skin inflammation, itching, cut.
Devise does not
turn on?
Check if battery is low and need to be charged.
The device have continu ous
beep when using, and can
not increase the intens ity
gear?
Be sure skin is clean and pads are firmly
attached to skin, and the battery is low and
need to be charged.
Electrode gel pads
are not sticky?
The electrode gel pads will lose
adhesiveness over use. please contact the
seller for replacements.
Stimulation is
weak or
non-existent?
The battery is low and need to be charged.
Troubleshooting Problem solving
09
