FieldPro 530si Series
Operator’s Manual

i www.printek.com | P: 888.211.3400 | F: 269.925.8539 | E: [e-mail]
FCC Part 15 Class B
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device
may not cause harmful interference, and (2) this device must accept any interference received, including interference that
may cause undesired operation.
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the
FCC rules. These limits are designed to provide reasonable protection against harmful interference in a residential
installation. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee
that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct
the interference by one or more of the following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and the receiver.
Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
Consult the dealer or an experienced radio/TV technician for help.
This equipment complies with Canadian and FCC radiation exposure limits set forth for an uncontrolled environment. This
equipment is in direct contact with the body of the user under normal operating conditions. This transmitter must not be co-
located or operating in conjunction with any other antenna or transmitter.
Part 15.21 Caution: Changes or modifications not expressly approved by Printek, LLC could void the user’s authority to
operate the equipment.
Canadian Department of Communications Radio Interference Statement
This device complies with Industry Canada license-exempt RSS standard(s). Operation is subject to the following two
conditions: 1) this device may not cause interference; 2) this device must accept any interference, including
interference that may cause undesired operation of the device. Under Industry Canada regulations, this radio
transmitter may only operate using an antenna of a type and maximum (or lesser) gain approved for the transmitter
by Industry Canada. To reduce potential radio interference to other users, the antenna type and its gain should be
so chosen that the equivalent isotropically radiated power (e.i.r.p.) is not more than that necessary for successful
communication. Maximum power output plus maximum antenna gain of the EUT is: 4.5W/m2 , Limit is 10Wm2.
Le présent appareil est conforme aux CNR d'Industrie Canada applicables aux appareils radio exempts de licence.
L'exploitation est autorisée aux deux conditions suivantes : (1) l'appareil ne doit pas produire de brouillage, et (2)
l'utilisateur de l'appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage est susceptible d'en
compromettre le fonctionnement. Conformément à la réglementation d'Industrie Canada, le présent émetteur radio
peut fonctionner avec une antenne d'un type et d'un gain maximal (ou inférieur) approuvé pour l'émetteur par
Industrie Canada.
Dans le but de réduire les risques de brouillage radioélectrique à l'intention des autres utilisateurs, il faut choisir le
type d'antenne et son gain de sorte que la puissance isotrope rayonnée équivalente (p.i.r.e.) ne dépasse pas
l'intensité nécessaire à l'établissement d'une communication satisfaisante. La puissance de sortie maximale plus
gain d'antenne maximal du EUT est : 4.5W/m2 Limite est 10W/m2

ii www.printek.com | P: 888.211.3400 | F: 269.925.8539 | E: [email protected]
Battery Disposal
Only dispose of used batteries according to your local regulations. If you do not know your local
regulations, the Rechargeable Battery Recycling Corporation (RBRC) is a non-profit organization
created to promote recycling of rechargeable batteries. For more information visit www.rbrc.org.
Acknowledgments:
Printek is a registered trademark of Printek, LLC
Bluetooth is a registered trademark of Bluetooth SIG, Inc.
Zebra, CPCL and ZPLare registered trademarks of Zebra Technologies
Wi-Fi is a registered trademark of the Wi-Fi Alliance
Windows is a registered trademark of Microsoft Corporation
All other trademarks are the property of their respective owners.
© 2015 By Printek LLC, 1517 Townline Road, Benton Harbor, MI 49022. All rights reserved.
Read all set up and operating instructions before proceeding with operation. Do not operate in an enclosure unless properly
ventilated. Do not operate near a heat source.
Lesen Sie vor der Inbetriebnahme die Aufbau- und Bedienungsanleitung Betreiben Sie den Drucker nicht in einem kleinen,
geschlossenen Raum, es sei denn dieser wird ordnungsgemäß belüftet. Nehmen Sie den Drucker nicht in der Nähe einer Wärmequelle in
Betrieb
No user-serviceable parts inside. Refer service or repairs to a qualified service professional. Use of genuine Printek replacement
parts is required to warrant proper, safe operation. Any alteration or modification of this device voids the user warranty and may make the
product unsafe to operate. The print head and motors get hot during use. Wait until they cool before touching them. Make certain the printer
is disconnected from AC power before removing any covers or performing any required cleaning or maintenance. Connecting this printer
to an ungrounded receptacle can result in electrical shock. Never place the printer near inflammable or explosive substances. Do not
operate near liquid or spill liquid into the printer at any time.
Enthält keine Teile, die vom Bediener instandgesetzt werden können. Bitte wenden Sie sich bei Instandsetzung oder Reparatur an
qualifiziertes Kundendienstpersonal. Die Verwendung von echten Printek Ersatzteilen ist notwendig, um ordnungsgemäßen, sicheren
Betrieb zu gewährleisten. Änderungen oder Modifikationen dieses Geräts machen die Garantie ungültig und können den sicheren Betrieb
des Produkts gefährden. Während des Druckens werden Druckerkopf und Motoren heiß. Warten Sie, bis sich die Teile abgekühlt haben,
bevor Sie sie berühren. Vergewissern Sie sich, dass der Drucker nicht mehr an die Stromquelle angeschlossen ist, bevor Sie Abdeckungen
abnehmen oder das Gerät reinigen bzw. warten. Schließen Sie diesen Drucker nicht an eine ungeerdete Steckdose an; dies kann zum
Elektroschock führen. Setzen Sie den Drucker niemals in die Nähe von feuer- oder explosionsgefährlichen Stoffen. Betreiben Sie den
Drucker nicht in der Nähe von Flüssigkeiten und lassen Sie keine Flüssigkeiten in den Drucker gelangen.
Specifications are subject to change without notice.

1 www.printek.com | P: 888.211.3400 | F: 269.925.8539 | E: [email protected]
Table of Contents
Introduction..................................................................................................................................................2
Printer Features...........................................................................................................................................3
Quick Start Instructions..............................................................................................................................4
A. Paper Load ........................................................................................................................................4
B. 9 Pin D-Connector Pin Out ................................................................................................................5
C. Power On...........................................................................................................................................5
D. Control Panel .....................................................................................................................................5
E. Performing a Printer Self-Test ...........................................................................................................6
Configuration...............................................................................................................................................7
A. Connectivity Parameters....................................................................................................................9
WI-FI Config:..............................................................................................................................................12
B. Image Parameters ...........................................................................................................................15
C. Device Config...................................................................................................................................17
D. Fonts................................................................................................................................................19
E. Graphics...........................................................................................................................................20
F. Update Printer Firmware, Upload Files to Printer Memory..............................................................21
G. Reset Printer Configuration to Factory Defaults (Safe Mode).........................................................21
Printing Modes ..........................................................................................................................................22
A. ASCII Based Print Jobs ...................................................................................................................22
B. Graphic Based Print Jobs................................................................................................................22
Integrating the Printer into your Business Applications ......................................................................23
Step by Step –Creating a Link from Host to Printer .............................................................................23
A. Windows Desktop Computers .........................................................................................................23
Print Drivers.............................................................................................................................................23
I. SERIAL .......................................................................................................................................23
II. USB.............................................................................................................................................23
III. Bluetooth –General....................................................................................................................23
IV. Bluetooth –Windows 7 and above .............................................................................................23
V. Wi-Fi............................................................................................................................................24
B. Windows Tablets and Smartphones................................................................................................25
C. Android Tablets & Smart phones.....................................................................................................25
I. Bluetooth.....................................................................................................................................25
II. Wi- Fi...........................................................................................................................................25
D. Apple™Tablets & Smartphones .....................................................................................................25
Bluetooth.....................................................................................................................................25I. Wi-Fi............................................................................................................................................25II.
Media ..........................................................................................................................................................26
A. Standard Media................................................................................................................................26
B. Black Mark Media Position...............................................................................................................26
Maintenance and Troubleshooting..........................................................................................................27
A. Cleaning...........................................................................................................................................27
B. Troubleshooting ...............................................................................................................................27
General Error Conditions ............................................................................................................28I. Fault Description and Resolution................................................................................................28II.
C. Obtaining Service.............................................................................................................................29
APPENDIX..................................................................................................................................................30
A. Appendix A –FieldPro 530si Printer Specifications ........................................................................30
Glossary of Terms.....................................................................................................................................31
Index...........................................................................................................................................................33

2 www.printek.com | P: 888.211.3400 | F: 269.925.8539 | E: [email protected]
Introduction
Thank you for purchasing the Printek FieldPro 530si Series mobile thermal printer. The FP530si series
prints on special thermal media supplied in roll form up to 3.125 inches wide. All models are equipped
with a USB port which supports printer configuration. All models support an optional internal Bluetooth or
Wi-Fi interface. Complete specifications may be found in Appendix A –FieldPro 530si Printer
Specifications.
The remainder of this manual focuses on preparing the printer for initial use and performing tasks that will
be encountered during daily use.
Maintenance and Troubleshooting describes how to maintain the printer for optimal performance and has
information on how to diagnose any problems that may occur.
Printek recommends using genuine Printek supplied media and accessories. For detailed lists and
contact information, please see Appendix B –Supplies and Accessories & Appendix C –Media.

3 www.printek.com | P: 888.211.3400 | F: 269.925.8539 | E: [email protected]
Printer Features
Paper Door
Paper door release button
USB connector under I/O cover
Control Panel
Serial I/O and Power Connector
Your FieldPro 530si features:
Easy-to-read control face and simple drop-in paper loading
Quickly prints a wide variety of tickets, receipts, and labels.
IP54 rated for water and dust resistance... plus rated for repeated 6-foot drops to concrete
Print speeds up to 5 ips
Extensive fonts, character sets, bar codes and graphic capabilities
Printer configuration is quick and easy with a web based interface
Compatible with Windows, Windows Mobile and Android
Emulations that allow the printer to be a drop-in replacement for nearly any mobile printer
For detailed specifications reference Appendix A –FieldPro 530si Printer Specifications.

4 www.printek.com | P: 888.211.3400 | F: 269.925.8539 | E: [email protected]
Quick Start Instructions
A. Paper Load

5 www.printek.com | P: 888.211.3400 | F: 269.925.8539 | E: [email protected]
Serial Cable
Pin Color Description
2 White Receive data (from Host)
3 Red Transmit data (from Printer)
5 Black Ground
Power Cable
Pin Color Description
5 Black Ground
8 Red Power
B. 9 Pin D-Connector Pin Out
Use table to connect Power and RS232 serial communication:
C. Power On
Printer automatically turns on when power is applied.
D. Control Panel
Control Panel
Power Button
Power Up
Power Down
Toggle IP over USB
on/off
Press & Release
Press & Hold
Press twice
Paper Feed Button
Advance paper
Print Setup Report
Press once
Press twice
Power & Status
(Green/Red)
Alert
(Red)
Indication
On
On
Booting up
On
Off
Ready
On
Flashing
Paper Error/Lid Open
Flashing
Off
Job is arriving
Flashing
Off
Job is printing
Flashing
Flashing
IP over USB active
Solid, Flashes Off Every 2
Seconds
Off
Wireless Personal Area Network
active

6 www.printek.com | P: 888.211.3400 | F: 269.925.8539 | E: [email protected]
E. Performing a Printer Self-Test
With power on, press the paper feed button twice quickly.

7 www.printek.com | P: 888.211.3400 | F: 269.925.8539 | E: [email protected]om
Configuration
Configuration of the FP530si printer is done through a built-in web page. This allows you to configure
the printer from any device that has a browser and is compatible with your FP530si communication
capabilities.
1. Turn the printer ON.
2. Connect a USB cable between the printer and a PC.
3. To access the FP530si web page, push the Power button twice rapidly. This will put the printer
into Configuration mode.
4. When the printer is in Configuration mode the POWER and FAULT LEDs will flash together.
a. Open browser on your PC and type 169.254.200.1 into the address bar of the browser and hit
Enter - A login box should appear:
b. Use the dropdown box to select a language other than English.
c. Type “0000” and hit Enter- you should now be at the home page for FP530si Configuration.

8 www.printek.com | P: 888.211.3400 | F: 269.925.8539 | E: [email protected]om
5. The main configuration screen of the FP530si:
This is an overview of the printer configuration. An AC plug will appear in the battery icon when the
printer is plugged into an external power source.
To return the printer to normal operating mode, double-click the Power button. The POWER LED will
be returned to a solid light.
At the top of the Main Page are selections to access the sub-menus.
Wherever the book icon appears in the printer configuration pages, click it to access the user
manual pages for help.

9 www.printek.com | P: 888.211.3400 | F: 269.925.8539 | E: [email protected]om
A. Connectivity Parameters
This page allows you to setup the connection to your printer. Depending on the optional interface
installed, you will see either Bluetooth Config or WI-FI Config. In the detailed descriptions, an asterisk
(*) indicates the factory default value.
RS-232 Config:
Note: these values must match the host system serial port interface.
Baud Rate:
Possible values: 9600, 19200, 38400, 57600*, 115200
Sets communication speed between the printer and host.

10 www.printek.com | P: 888.211.3400 | F: 269.925.8539 | E: [email protected]om
Handshake:
Possible values: Disabled*, Xon/Xoff
Sets the handshaking protocol.
Parity:
Possible values: Disable*, Even, Odd
Sets the Parity bit.
End of Job Timout:
Possible values: 0.5 through 9.5 seconds at .5 intervals
Sets the time the printer will wait to receive data betore considering the print job complete.
Bluetooth Config:
Paired Mode:
Possible values: UnPaired, Paired*
This feature allows Bluetooth pairing to occur between the printer and the connecting device whenever
Pairing is required by either device. Pairing requires that the PIN on the printer and the connecting
device exactly match each other.
Discoverability:
Possible Values: Off, On*

11 www.printek.com | P: 888.211.3400 | F: 269.925.8539 | E: [email protected]om
This feature is used to set whether the printer may be discovered by other Bluetooth devices. It should
only be set to “Off” after the printer has been discovered and paired with a host computer.
PIN:
Possible Values: 0000*, Up to 16 Numeric Characters.
Note that this feature is only available if Pairing Mode is set to “Paired”. The PIN value must exactly
match the PIN value set in the Bluetooth manager on the host computer.
Connection:
Possible Values: Printer*, Personal Area Network
This feature selects the role of the printer’s interface in the Bluetooth network.
In Printer mode, the printer behaves as a regular Bluetooth device.
In Personal Area Network mode, the printer behaves similar to a WiFi access point.
The Power LED will flash off every two seconds while in this mode.
After pairing with the printer, the host Bluetooth icon will appear different, indicating that an access point
is present.
Some hosts require an extra connect step after pairing. After connecting, the printer will issue
an IP address to the host and the host can communicate to the printer as if it were a WiFi printer. The
printer’s address to the host is always 169.254.200.1.
In the host device’s browser (if equipped) this address may be entered in the address bar to access the
printer web page.
Personal Area Network mode can also be activated outside of the printer web page.
To enter Personal Area Network mode, press and hold the Power and Paper Feed buttons until the
Power and Alert LEDs light. Release both buttons, and the printer will restart in Personal Area Network
mode. To exit Personal Area Network mode, press and hold the Power and Paper Feed buttons until
the Power and Alert LEDs light. Release both buttons, and the printer will restart in normal Bluetooth
mode.

12 www.printek.com | P: 888.211.3400 | F: 269.925.8539 | E: [email protected]om
WI-FI Config:
Wireless Configuration
This will display the current Wi-Fi configuration:
IP Address –user defined. If Static Address Method is selected, type in the address the printer will use on the
network.
SubNetMask –user defined. If Static Address Method is selected, type in the subnet mark of the network.
GateWay –user defined. If Static Address Method is selected, type in the gateway address of the network.
WiFi Port –user defined. Type in the IP port to be used by the printer. (default value = 8023)
Address Method –user selectable
Static –printer will always connect to the network using the IP address defined.
DHCP –printer will acquire an IP address from your network DHCP server
Personal Area Network –The printer will broadcast itself as a network connection. The Power LED will
flash off every two seconds while in this mode. The SSID will be the serial number of the printer.
When connecting to the printer, the passphrase is the printer’s serial number.
Personal Area Network mode can also be activated outside of the printer web page.
To enter Personal Area Network mode, press and hold the Power and Paper Feed buttons until the
Power and Alert LEDs light. Release both buttons, and the printer will restart in Personal Area Network
mode. To exit Personal Area Network mode, press and hold the Power and Paper Feed buttons until
the Power and Alert LEDs light. Release both buttons, and the printer will restart in normal WiFi mode.

13 www.printek.com | P: 888.211.3400 | F: 269.925.8539 | E: [email protected]om
Available Networks –access points detected by the printer will be displayed. Select Add/Connect to use one
of these access points.
Previously Connected Networks –access points detected by the printer or added through Add/Edit
Network will be displayed. Select Connect to use one of these access points, or Remove to delete it from
printer.
Currently Configured Networks –access points added through Add/Edit. They may not have been
connected yet. Select Remove to delete access point from printer.
Set Date –Some Enterprise network connections require this setting. Simply enter the current year.
Add/Edit Network
Enter the SSID of a network connection. If authentication is used select the authentication type. Click Next.
The following form will change depending on the authentication type:
WPA-PSK
Enter the password for the network connection.

14 www.printek.com | P: 888.211.3400 | F: 269.925.8539 | E: [email protected]om
WPA-EAP or IEEE8021X
These are Enterprise network settings. Consult your server manual for recommended settings.
Upload Digital Certificate
If your enterprise network uses digital certificates as another form of authentication, you can upload the
certificates here.

15 www.printek.com | P: 888.211.3400 | F: 269.925.8539 | E: [email protected]om
B. Image Parameters
This page allows you to make selections about the image to be printed.
Current Emulation:
Possible Values: PRINTEK*, ZPL, CPCL, ESCPOS, IPL, AUTOIMAGE, PDF, POSTSCRIPT, IMAGE
The FP530si printer is capable of using several different emulation modes. This feature sets the family of printer
commands that may be used by a host application program to control the various capabilities of the printer. The
printer will only respond to commands valid for the currently selected emulation. For more information, please
refer to the Integrator’s Guide.
Besides the popular printer languages to choose from, the following selections allow the FP530si to print many
other file formats directly, without the need for a driver.
AUTOIMAGE –selected when mixed PDF and POSTSCRIPT images are sent to the printer. The printer will
determine which type of file has been sent. This can increase printer response time.
PDF –When in this mode the printer will directly print Portable Document Files (PDF).
POSTSCRIPT –When in this mode the printer will directly print Postscript formatted files (.ps). You can also
use a generic Postscript driver to print when in this mode.
IMAGE –selected if just image files are being sent to the printer. When in this mode the printer will directly print
the following file types: .png, .jpg, .bmp, .pbm, .svg, .tiff
Default Font:
The FP530si has the ability to use True Type Fonts. All True Type Fonts loaded into printer memory are listed
here. When using emulations that do not specify the font for each line of text, select the font you would like to
use as the default font. All print jobs will use the default font unless a command is sent to the printer to use
another font.

16 www.printek.com | P: 888.211.3400 | F: 269.925.8539 | E: [email protected]om
Chars Per Inch and Default Text Line Spacing:
NOTE: These settings only function in Printek Emulation
This determines how large the characters are and how many characters will print in a one inch space. The
higher the number, the greater the number of lines per vertical inch of print.
Line Wrapping:
Possible Values: OFF*, ON
Determines how a line of text is handled.
OFF –data that is longer than the line length will be truncated
ON –data that is longer than the line length will be printed on the next line.
Input File Size:
Possible values: 3 inch*, 4 inch
If your print job was originally written to print to 4” printer, select 4 inch and the printer will automatically scale
the print job to print on the 3” printer.

17 www.printek.com | P: 888.211.3400 | F: 269.925.8539 | E: [email protected]om
C. Device Config
This page allows you to set certain hardware parameters on the printer.
Login Password
This allows the printer webpage password to be changed.
Units
Select between inches or millimeters. If you change units, do so before entering other settings.
Max Paper Speed
Possible values: 1.0 to 5.5 ips, Default = 5.0
When using labels or heavy paper stock, you may need to decrease the paper speed to prevent paper jams.
Mark Seeking
Possible values: Off*, Front, Rear, Gap. (Note: Rear and Gap are available only on 530si models).
Set the value when using regular or label media with black alignment marks or label media with gaps between
the labels
