Pro Control Pro24.r User manual

Federal Communications Commission Notice
Battery Disposal
Contacting Pro Control
Limited Warranty
In the interest of recycling, please do not dispose of these batteries in the household
waste at the end of their useful life. Instead, dispose of them at an appropriate
collection site. Rechargeable Lithium batteries can explode, catch re, and/or
cause burns if disassembled, punctured, cut, crushed, short circuited, incinerated,
recharged, or exposed to water, re, or high temperatures. DO NOT place loose batteries in
a pocket, purse, or other receptacle containing metal objects, mix with used or other battery
types, or store with hazardous or combustible materials. If batteries catch re, DO NOT
attempt to put out the re with water—use a class “D” re extinguisher or other smothering
agent. Keep batteries away from children. DO NOT tamper with wires or connectors that
are attached to the battery. Failure to follow these directions could result in damage to your
remote control that may not be covered by Pro Control’s warranty. Store lithium batteries in a
cool, dry, ventilated area. Follow applicable laws and regulations for transport, shipping, and
disposal. For more details on recycling lithium batteries please contact a government recycling
agency, your waste disposal service, the reseller where the batteries were purchased, or visit
a reputable online recycling source such as:
www.batteryrecycling.com.
Li-Ion
Safety Suggestions
Pro Control warrants its products for a period of one (1) year (90 days only for included
battery packs); or for a period of time compliant with local laws when applicable from the
date of purchase from Pro Control or an authorized Pro Control distributor.
This warranty may be enforced by the original purchaser and subsequent owners during
the warranty period, so long as the original dated sales receipt or other proof of warranty
coverage is presented when warranty service is required.
Except as specied below, this warranty covers all defects in material and workmanship in
this product. The following are not covered by the warranty:
Damage resulting from:
1. Accident, misuse, abuse, or neglect.
2. Failure to follow instructions contained in this Guide.
3. Repair or attempted repair by anyone other than Pro Control.
4. Failure to perform recommended periodic maintenance.
5. Causes other than product defects, including lack of skill, competence or experience
of user.
6. Shipment of this product (claims must be made to the carrier).
7. Being altered or which the serial number has been defaced, modied or removed.
Pro Control is a division of Remote Technologies Inc. For information on how to become a
trained and authorized Pro Control Dealer, access to the Pro Control Studio programming
software, product information and more, please visit our web site at:
www.procontrol.com
For general information, you can contact Pro Control at:
Pro Control
5775 12th Ave. E Suite 180
Shakopee, MN 55379
Tel. [phone]
Fax [phone]
Sales
952-224-5010
Email: [email protected]
Customer Service
952-224-5020
Email: [email protected]
Technical Support
952-224-5024
Email: [email protected]
The Declaration of Conformity for this product can be found on the Pro Control website at:
www.procontrol.com
This equipment has been tested and found to comply with the limits for a Class B digital
device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential installation. Any changes or
modications not expressly approved by the party responsible for compliance could void the
user’s authority to operate the device.
This equipment generates, uses, and can radiate radio frequency energy and, if not installed
and used in accordance with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference will not occur in a particular
installation.
If this equipment does cause harmful interference to radio or television reception, which can
be determined by turning the equipment off and on, the user is encouraged to try to correct
the interference by one or more of the following measures:
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and the receiver.
Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected.
Consult the dealer or an experienced radio/TV technician for help.
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two
conditions:
1. This device may not cause harmful interference.
2. This device must accept any interference received including interference that may cause
undesired operation.
FCC ID: MMURTI1700
IC (Canada): 3166A-RTI1700
N27917 Programmable “Soft Buttons” Allow
Custom Touchscreen Labeling
LCD Touchscreen
(240w X 320h)
Programmable “Hard Buttons” for Tactile
Control of Commonly Used Functions
IR Emitters and
IR Learning Photodiode
Charging LED
Micro USB Port
Pro24.r (v2)
Quick Reference Guide
Read and Follow Instructions. Read all safety and operating instructions before operating
the unit.
Retain Instructions. Keep the safety and operating instructions for future reference.
Heed Warnings. Adhere to all warnings on the unit and in the operating instructions.
Heat. Keep the unit away from heat sources such as radiators, heat registers, stoves, etc.,
including ampliers that produce heat.
Do Not Open Battery Compartment. This device contains Lithium-Ion or Lithium-Polymer
batteries. Batteries should only be replaced by an authorized service center or trained
installer.
Power Sources. Connect the unit only to a power supply of the type described in the
operating instructions, or as marked on the unit.
Power Cord Protection. Route power supply cords so that they are not likely to be walked
on or pinched by items placed on or against them, paying particular attention to the cord
plugs at power receptacles and at the point at which they exit from the unit.
Water and Moisture. Do not use the unit near water—for example, near a sink, in a wet
basement, near a swimming pool, near an open window, etc.
Object and Liquid Entry. Do not allow objects to fall or liquids to be spilled into the
enclosure through openings.
Cleaning. Clean only with a dry cloth.
Servicing. Do not attempt any service beyond that described in the operating instructions.
Refer all other service needs to qualied service personnel.
Damage Requiring Service. The unit should be serviced by qualied service personnel
when:
Objects have fallen or liquid has been spilled into the unit.
The power supply cord or the plug has been damaged.
The unit does not appear to operate normally or exhibits a marked change in
performance.
The unit has been dropped or the enclosure has been damaged. 71-500002-15 V1.1
Get more control®
®
Service & Support
If you are encountering any problems or have a question about your Pro Control product,
please contact Pro Control Technical Support for assistance (see the Contacting Pro Control
section of this guide for details).
Pro Control provides technical support by telephone or e-mail. For the highest quality
service, please have the following information ready, or provide it in your e-mail.
• Your Name
• Company Name
• Telephone Number
• E-mail Address
• Product model and serial number (if applicable)
If you are having a problem with hardware, please note the equipment in your system, a
description of the problem, and any troubleshooting you have already tried.
If you are having a problem with software, please note what version you have installed,
the operating system on your PC, a description of the problem, and any troubleshooting
you have already tried. If you are calling about a software or programming question or
problem, please be at you computer when you place your call. This will considerably speed
up the troubleshooting process.
Please do not return products to Pro Control without return authorization.
Pro24.r (v2) Quick Reference Guide
PRO C ONTROL
Tomake logo scale correctly
select the logo and go to:
Object>Transform>Scale>Option
s.Then check“Scale strokes and
effects” and click OK.
Tomake the logo permanently
scaleable on anycomputer select
the logo and go to:
Object>Expand.Check all avail-
able boxesand click OK.
PRO C ONTROL
To make logo scale correctly
select the logo and go to:
Object>Transform>Scale>Option
s.Then check“Scale strokes and
effects” and click OK.
To make the logo permanently
scaleable on any computer select
the logo and go to:
Object>Expand. Check all avail-
able boxes and click OK.
Copyright © 2013 • Pro Control Incorporated • All rights reserved.

Installing and Recharging the Battery
The Pro24.r (v2) uses a Lithium-Ion rechargeable battery that does not exhibit any type of “Memory Effect” from being charged too often. The
remote features convenient USB recharging capability, giving you even more control over how and where you choose to recharge the remote’s
battery.
NOTE: Optional Pro24.dock Charging Dock is available for purchase separately.
The Pro24.r comes equipped with:
• One (1) USB programming cable (USB-A to micro USB-B), 6Ft (2m)
• One (1) Charging cable (5VDC universal AC adapter and cable with integrated micro USB connector), 6Ft (2m)
• Four (4) Interchangeable AC adapter plugs for international applications
Follow these steps to install the battery.
1. Remove the access door from the rear of the remote
by sliding it down and off.
2. Orient the battery so that the charging contacts point
toward the top of the remote, and insert the battery
into the battery compartment.
3. Ensure that the battery’s charge contacts are touching
the charging pins inside the battery compartment.
4. Press the battery down into the compartment until it
snaps and locks in place.
5. Turn the unit on by sliding the power switch to the
“ON” position.
6. The battery can be removed by pressing the battery
lock down and lifting the battery out of the battery
compartment.
Follow these steps to charge the battery.
The Pro24.r (v2) can be charged using the included charging cable.
NOTE: Please refer to the instructions included with the optional Pro24.dock Charging
Dock.
IMPORTANT NOTES:
• Third-party AC adapter/charging cables may not t properly and could result
in damage to the unit. Only use the supplied cable.
• Verify the orientation of the USB connector is correct before attempting to
insert it into the remote or damage to the USB port may occur.
1. Insert the micro USB end of the AC Adapter charging cable into the USB port located
on the bottom-side of the remote control unit.
2. Plug the AC Adapter into a wall outlet.
3. The charging LED on the bottom of the unit will ash red while the battery is
charging, and it will remain illuminated when the charging cycle is complete.
To Wall Outlet
Power Switch
Lithium-Ion
Battery Pack
Battery Lock
Battery Compartment Door
The Pro24.r (v2) is capable of capturing infrared codes from original equipment manufacturer remote controls. This IR learning capability is
designed to work together with the Pro Control Studio library manager software.
To capture infrared codes, follow the steps listed below:
1. Connect the Pro24.r to your PC using the provided USB cable.
2. Start the Pro Control Studio software and select Libraries under Controlled Devices.
3. Select IR Library Manager.
4. Add new remote to library - From the upper toolbar, select “Remote.” Click “New” and enter the Manufacturer, Type and Model of the
device being captured.
5. Add function names - From the tabs below the main window, click the “Edit” button, type in the name of the function to be learned (e.g.
Power) in the textbox, and click the “Add” button.
5. From the tabs below the main window, click the “Capture” tab.
6. Place the remote control 3 to 5 inches (7cm to 12cm) away from the Pro24.r IR Window.
7. Select the “Align” button, press, and hold any button on the remote control until “Signal” illuminates on the PC’s screen. Click the “Learn”
button.
8. Press and hold the button on the remote control matching the selected function until the PC has accepted it.
9. Continue with previous step until all the functions have been learned.
IR Learning
Accessing Control Panel
From the Control Panel, you can make adjustments to the operation of the Pro24.r (v2).
Control Panel options:
• Set the backlight level
• Set the backlight timeout
• Turn the tilt switch on/off
• Turn the beep function on/off
• Adjust beeper tone
To access the Pro24.r (v2) Control Panel:
1. Press any of the 4 color buttons for 1 to 2 seconds while sliding the power switch from “OFF” to the “ON” position.
Note: The Control Panel can also be accessed by setting up a “Page Link” on any programmable button.
®Get more control®
Charging Contacts
(For use with
optional Pro24.dock
Charging Dock)
Micro USB Connector
RTI Pro-24r October 5, 2010 Artwork
Artwork to be silkscreened white
Artwork to be silkscreened Red, Pantone 485
“PRO” Logo Artwork
1 3
4 6
7 9
5
8
0
M
E
N
U
G
U
I
D
E
I
N
F
O
E
X
I
T
MUTEPREV
VOL
CH
2
ENTER
-/.
OK
ON OFF
Original Manufacturer Remote Control Pro24.r (v2)
PC with Pro Control Studio
Library Manager Software
IR Signal
3” to 5”
(7cm to 12cm)
USB Programming Cable
Pro24.r (v2) Quick Reference Guide
PRO C ONTROL
Tomake logo scale correctly
select the logo and go to:
Object>Transform>Scale>Option
s.Then check“Scale strokes and
effects” and click OK.
Tomake the logo permanently
scaleable on anycomputer select
the logo and go to:
Object>Expand.Check all avail-
able boxesand click OK.
PRO C ONTROL
To make logo scale correctly
select the logo and go to:
Object>Transform>Scale>Option
s.Then check“Scale strokes and
effects” and click OK.
To make the logo permanently
scaleable on any computer select
the logo and go to:
Object>Expand. Check all avail-
able boxes and click OK.
